Contec 955 Series User manual

IPC Series
PANEL-PC 955 Series
Fanless, Atom N270, CF, 12.1 inch
XGA model
User’s Manual
CONTEC CO.,LTD.

PT-955LXC-DC5311 User’s manual i
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your
retailer.
If you use IPC-SLIB-01 (driver & utility software set), download it from the CONTEC’s Web site.
Product Configuration List
PT-955LXC-DC5311
[Panel Mount]
OS-installed model
[WES2009]
Japanese
Name Pcs.
Panel-PC 1
Waterproof packing 1
The attachment fittings 8
CF card removal prevention fitting 1 *1
Power supply connector complete set
Power connector 1
Contact 4
Cable clamp 1
DVI-analog RGB conversion adapter 1
Product guide (this sheet) 1
IPC Precaution List 1
Warranty Certificate 1
Serial number label 1
Royalty consent contract 1
Setup Procedure Document 1
Notes on using Windows Embedded Standard 1
Recovery Media *2 1
*1 It is attached to the main body.
*2 Please confirm latest information on the CONTEC homepage though the user's manual is stored in Recovery
Media.

ii PT-955LXC-DC5311 User’s manual
Product Configuration Image
Product guide IPC
Precaution
List Setup Procedure
Document
Royalty
consent
contract
Panel-PC
(PT-955LXC-DC5311)
The attach
ment fittings
(for PT955LXC)
Cable clamp Power supply
connector complete
set
DVI-analog RGB
conversion adapter
CF card
removal
prevention
fitting
Product guide IPC Precaution List Royalty
consent
contract
Setup
Procedure
Document
Notes on using
Windows Embedded
Standard
Recovery Media
Waterproof packing
(for PT955LXC)
Power connector
Contact
Notes on using
Windows
Embedded
Standard
Warranty Certificate
XXXX XXXXXX XXX
XXXX XXXXXX XXX
Serial number label
Warra nt y
Certificate
* See the Product Configuration List to check if all the components are included for the specified number of units.
About the handling of the battery and the storage battery in E U
signatory
Note: This symbol mark is for EU countries only.
This symbol mark is according to the directive 2006/66/EC Article 20 Information
for end-users and Annex II.
This symbol means that batteries and accumulators, at their end-of-life, should be disposed of separately from your
household waste.
If a chemical symbol is printed beneath the symbol shown above, this chemical symbol means that the battery or
accumulator contains a heavy metal at a certain concentration.
This will be indicated as follows:
Hg: mercury (0.0005%), Cd: cadmium (0.002%), Pb: lead (0.004%)
These ingredients may cause serious hazardous for human and the global environment.
Please refer to the user's manual for the annulment of detaching a detailed battery specification and the battery and the
batteries.

PT-955LXC-DC5311 User’s manual iii
Copyright
Copyright 2013 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document.
The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel, Intel Atom, Intel Core and Celeron are registered trademarks of Intel Corporation. MS, Microsoft
and Windows are trademarks of Microsoft Corporation. Other brand and product names are trademarks
of their respective holder.

iv PT-955LXC-DC5311 User’s manual
Table of Contents
Check Your Package ................................................................................................................................i
Copyright ............................................................................................................................................... iii
Trademarks ............................................................................................................................................iii
Table of Contents................................................................................................................................... iv
1. INTRODUCTION 1
About the Product....................................................................................................................................1
Features.............................................................................................................................................1
Supported OS....................................................................................................................................2
Customer Support....................................................................................................................................3
Web Site............................................................................................................................................3
Limited One-Year Warranty ...................................................................................................................3
How to Obtain Service ............................................................................................................................3
Liability....................................................................................................................................................3
Safety Precautions ...................................................................................................................................4
Safety Information............................................................................................................................4
Caution on the PT-955 Series ..........................................................................................................4
2. SYSTEM REFERENCE 7
Specification ............................................................................................................................................7
Power Management Features ................................................................................................................11
Power Requirements..............................................................................................................................11
Power Consumption .......................................................................................................................11
Physical Dimensions .............................................................................................................................12
3. HARDWARE SETUP 13
Before Using the Product for the First Time........................................................................................13
Hardware Setup .....................................................................................................................................14
Attaching the CF Attachment Fittings...........................................................................................14
Attaching the FG ............................................................................................................................14
Fastening the Cable ........................................................................................................................15
Hardware Setup ..............................................................................................................................15
Installation Requirements...............................................................................................................18
4. EACH COMPONENT FUNCTION 21
Component Name..................................................................................................................................21
Side view.........................................................................................................................................21
System Configuration............................................................................................................................22

PT-955LXC-DC5311 User’s manual v
Component Function.............................................................................................................................23
LED: POWER, ACCESS, STATUS.............................................................................................23
DC Power Input Connector: DC-IN..............................................................................................23
Power switch: POWER SW...........................................................................................................24
Line out Interface: LINE OUT......................................................................................................24
Mic in Interface: MIC....................................................................................................................24
Giga bit-Ethernet: LAN A - B.......................................................................................................25
USB Ports: USB.............................................................................................................................26
Serial Port Interface: SERIAL A - B.............................................................................................27
DVI Interface: DVI........................................................................................................................28
CF Card Connector (Primary IDE Connection): CF1 - 2.............................................................30
5. BIOS SETUP 31
Introduction ........................................................................................................................................... 31
Starting Setup ........................................................................................................................................31
Using Setup....................................................................................................................................32
Getting Help...................................................................................................................................32
In Case of Problems.......................................................................................................................32
A Final Note About Setup .............................................................................................................32
Main Menu ............................................................................................................................................33
Setup Items.....................................................................................................................................33
Standard CMOS Setup..........................................................................................................................35
Main Menu Selections ..........................................................................................................................36
IDE Adapters..................................................................................................................................37
Advanced BIOS Features Setup ...........................................................................................................38
CPU Feature ..........................................................................................................................................39
Hard Disk Boot Priority........................................................................................................................40
Virus Warning................................................................................................................................41
Advanced Chipset Features Setup........................................................................................................48
PCI Express Root Port Function...........................................................................................................51
VGA setting...........................................................................................................................................52
Integrated Peripherals ...........................................................................................................................53
OnChip IDE Device..............................................................................................................................54
On Chip Serial ATA setting .................................................................................................................58
Onboard Device.....................................................................................................................................59
Super IO Device....................................................................................................................................63
Power Management Setup ....................................................................................................................65
PnP/PCI Configuration Setup...............................................................................................................71
IRQ Resources.......................................................................................................................................73
PCI Express relative items....................................................................................................................76

vi PT-955LXC-DC5311 User’s manual
PC Health Status....................................................................................................................................77
Frequency/Voltage Control...................................................................................................................79
Defaults Menu .......................................................................................................................................80
Supervisor/User Password Setting........................................................................................................81
Exit Selecting.........................................................................................................................................82
POST Messages.....................................................................................................................................82
POST Beep.............................................................................................................................................82
Error Messages ......................................................................................................................................83
6. APPENDIX 85
Memory Map .........................................................................................................................................85
I/O Port Addresses.................................................................................................................................86
Interrupt Level List................................................................................................................................87
POST Codes...........................................................................................................................................88
SERIAL I/O Address and Register Function .......................................................................................93
Watch-Dog-Timer .................................................................................................................................99
Life of CF............................................................................................................................................ 103
Battery................................................................................................................................................. 104
7. LIST OF OPTIONS 107

1. Introduction
PT-955LXC-DC5311 User’s manual 1
1. Introduction
About the Product
This product is a fanless PANEL-PC for embedded use based on Intel (R) Atom processor N270 and a
945GSE (GMA950 incorporated) chipset. Adoption of the long life power saving LED and Intel (R)
Atom processor offers low power consumption while ensuring sufficient performance.
The “resource-saving PC” contributes downsizing and power-saving of equipment to reduce your
running cost and to promote energy efficiency.
It has extended interfaces such as 1000BASE-T, USB2.0, and serial. It adopts CF card for the storage and
is fanless, which demonstrate the totally spindleless design that simplifies the maintenance.
Embedded-type CPU and chip set have been adopted. The use of readily available parts ensures the ease
of the use of the product. In addition, the use of CONTEC-customized BIOS allows support to be
provided at the BIOS level.
According to your application, two types (the panel mount type and the open frame type) are available.
This product is available in the following 1 model:
- WES-installed model and panel mount type equipped with Intel Atom Processor N270 1.60GHz
PT-955LXC-DC5311 (12.1 inch, LCD (XGA), Memory 1GB,
Windows Embedded Standard 2009 (Japanese version), CF 2GB)
Features
- Contributing to reduction of running cost and promotion of energy efficiency
Power consumption is about 30% less compared to the conventional standard model
(IPC-PT700HX-AC426). Due to adoption of the low power consumption LED backlight and Intel (R)
Atom processor N270, low power consumption, approximately 41W*1 even at a high load condition, is
achieved at the same time sufficient performance is ensured, contributing to the lesser running cost.
*1 Median value of power consumption of a standard model PT-955LXC-DC5311 with input power of
24VDC under unloaded and fully-loaded conditions.
- High definition supported DVI external display output
This product has the up to 1920 x 1080 pixels DVI external display output as standard feature. A
stand-alone two-displays application which, for example, displays the screen on a big LCD TV separately
from the main LCD, can be built. Also, with the accompanying analog RGB (15 pin HD-SUB)
conversion adapter, connecting to an analog RGB display is supported.
- Remote power management function to reduce operation tasks
This product supports timed/automated system start-up (Resume By Alarm). For example, it enables
unattended operation, such as starting to show information of an establishment in unison at opening time.
Also, it supports system start-up externally via network (Wake On LAN) and modem (Power On by Ring).
It encourages significant labor saving in operation.
- Major types of peripherals are supported with rich interfaces including the two CF card slots
It has a variety of extended interface such as 1000BASE-T x 2, USB2.0 x 4, serial (RS-232C) x 2.
It has 2 CF card slots that can use for OS and data. They are very useful because you can use one slot for
system start-up and the other for maintenance, system log, or taking away the collected data.

1. Introduction
2PT-955LXC-DC5311 User’s manual
- Falling-off prevention tools and cable clamps provided to avoid trouble caused by disconnected cable
This product stays trouble-free, being equipped with USB removal prevention fitting and cable clamp for
connectors with no locking mechanism, such as USB cable, and with hardware to properly mount and
avoid falling out of CF card.
- Safety design required for embedded applications
Retention of CMOS data by EEPROM allows the system to start up even when the battery has run out.
For Windows Embedded Standard installed model, it is possible to use the EWF*2 function of OS. It is
designed for safety required for embedding purpose, for example, prohibiting unwanted writing to the CF
card with EWF function will relieve the concern about the writing limits to the CF card and prevent an
unintentional system alteration.
*2 EWF (Enhanced Write Filter) is a function specific to Windows Embedded Standard that protects the disk from being actually written
by redirecting the writing to RAM.
- A wide range of power supplies (10.8 - 31.2VDC) supported
As the product supports a wide range of power (10.8 - 31.2VDC), it can be used in a variety of power
environments. The separately available AC adapter adds support for 100VAC power. *3
*3 When using the AC adapter, limits are placed on the expansion board power supply capacity and the external device power supply
capacity.
- Touch panel enables keyboard-less operation.
These products have analog touch panel enabling mouse emulation using driver software.
Supported OS
-Windows Embedded Standard 2009 (PT-955LXC-DC5311)

1. Introduction
PT-955LXC-DC5311 User’s manual 3
Customer Support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
Web Site
Japanese http://www.contec.co.jp/
English http://www.contec.com/
Chinese http://www.contec.com.cn/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One-Year Warranty
CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in material and
workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office, from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
original products. The warranty is not applicable if the device has been tampered with or damaged
through abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in
which case repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization number (RMA) from the CONTEC group office where you
purchased before returning any product.
* No product will be accepted by CONTEC group without the RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be
liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.
