Contec IPC-PT/L600S(PCW)P User manual

Celeron CPU loading PANECON-PC
IPC-PT/x600x(PCW)-HMU
User’s Manual

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P i
Copyright
Copyright 2001 CONTEC CO., LTD. ALL RIGHTS RESERVED
No part of this document may be copied or reproduced in any form
by any means without prior written consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep
current the information contained in this document.
The information in this document is subject to change without
notice.
All relevant issues have been considered in the preparation of this
document. Should you notice an omission or any questionable
item in this document, please feel free to notify
CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no
responsibility for any errors that may appear in this document nor
for results obtained by the user as a result of using this product.
Trademarks
MS, Microsoft, MS-DOS and Windows are trademarks of Microsoft
Corporation. Other brand and product names are trademarks of
their respective holder.

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
ii
Table of Contents
Copyright............................................................................i
Trademarks ........................................................................i
1. Introduction .............................................................1
Features.........................................................................1
Compatible Operating Systems ...................................2
Limited One-Year Warranty.........................................2
How to Obtain Service..................................................2
Liability.........................................................................2
Handling Precautions...................................................3
About the Manual.........................................................6
2. Overview..................................................................7
Specifications.....................................................................7
Display Optical Specifications..........................................9
System Configuration.....................................................10
External Dimensions......................................................11
3. Hardware Setup ..................................................... 15
Before Using the PANECON-PC for the First Time.....15
Hardware Setup..............................................................16
Removing the Top Cover and HDD Bracket..............16
Locations and Settings of Internal Connectors and
Jumpers.......................................................................18
Installing the Hard Disk ............................................20
Installing the Main Memory (DIMM)........................21
Fastening the Power Cable ........................................23
Installation Procedure................................................24
Installation Requirements .........................................25
4. BIOS Setup ............................................................ 27
BIOS Setup......................................................................27
Starting the Setup Screen..........................................27
Keystrokes...................................................................28
Main Menu..................................................................29

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P iii
IDE Adapter Window..................................................30
Embedded Window .....................................................31
Advanced Window.......................................................33
PCI Configuration Window ........................................35
Cache Memory Window..............................................36
I/O Device Configuration Window .............................37
Security Window.........................................................40
Power Window.............................................................41
Boot Window ...............................................................42
Exit Window................................................................43
5. Each Component Function....................................... 45
Component Locations.................................................45
Keyboard Interface .....................................................48
Mouse Interface ..........................................................48
Floppy Disk Interface.................................................49
Serial Port Interface...................................................51
CRT Interface..............................................................59
PCMCIA Slots (C Model)............................................60
Printer Port Interface.................................................61
RAS Functions............................................................63
Watchdog Timer..........................................................64
General-purpose I/O and Remote Reset....................71
S1.................................................................................75
Reset Switch................................................................75
USB Ports....................................................................76
Ethernet ......................................................................77
IDE Interface ..............................................................79
Expansion Slots (P Model)..........................................81
6. Touch Panel............................................................ 85
Touch panel serial interface.......................................85
7. Appendix................................................................ 87
Memory Map ...................................................................87
I/O Port Addresses ..........................................................88
Interrupt Level List........................................................89

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
iv
8. List of Options........................................................ 91
List of Figures
Figure 2.1. Definition of viewable range .................................... 9
Figure 2.2. System Configuration............................................. 10
Figure 2.3. External Dimensions of theIPC-PT/L600S(PCW)C.11
Figure 2.4. External Dimensions of theIPC-PT/L600S(PCW)P 12
Figure 2.5. External Dimensions of theIPC-PT/H600X(PCW)C13
Figure 2.6. External Dimensions of theIPC-PT/H600X(PCW)P14
Figure 3.1. Removing the Top Cover........................................ 16
Figure 3.2. Removing the HDD Bracket................................... 17
Figure 3.3. Locations and Settings of Jumpers, Connectors, and
Switches inside the Top Cover
(IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P,
IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P) 18
Figure 3.4. Installing the Hard Disk.......................................... 21
Figure 3.5. Installing the DIMM............................................... 22
Figure 3.6. Uninstalling the DIMM.......................................... 22
Figure 3.7. Removing the Screw............................................... 23
Figure 3.8. Installing the Metal Brace and the Clamp............... 23
Figure 3.9. AC Cord in Clamped State...................................... 23
Figure 3.10. Panel Opening Dimensions..................................... 24
Figure 3.11. Assembling Method ............................................... 24
Figure 3.12. Distances between the PANECON-PC and
Its Vicinity.............................................................. 25
Figure 4.1. Initial Screen.......................................................... 27

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P v
Figure 4.2. Main Window (Factory Settings)............................ 29
Figure 4.3. IDE Adapter Window (Factory Settings)................ 30
Figure 4.4. Embedded Window (Factory Settings) ................... 31
Figure 4.5. Advanced Window (Factory Settings) .................... 33
Figure 4.6. PCI Configuration Window.................................... 35
Figure 4.7. Cache Memory Window (Factory Settings)............ 36
Figure 4.8. I/O Device Configuration Window
(Factory Settings)................................................... 37
Figure 4.9. Security Window (Factory Settings)....................... 40
Figure 4.10. Power Window (Factory Settings).......................... 41
Figure 4.11. Boot Window (Factory Settings) ............................ 42
Figure 4.12. Exit Window .......................................................... 43
Figure 4.13. S1 Factory Setting................................................. 44
Figure 5.1. Component Locations............................................. 46
Figure 5.2. Terminal Resistor Settings....................................... 53
Figure 5.3. Slot Numbers and Locations................................... 60
Figure 5.4. Attaching the Metal Brace to Keep the Card
in Place................................................................... 60
Figure 5.5. How to Use the Watchdog Timer............................ 65
Figure 5.6. Index Register Port................................................. 66
Figure 5.7. Register A: Counter Clock Frequency Setting ........ 67
Figure 5.8. Register B: Counter Clock Output Control............. 67
Figure 5.9. Alarm Out Output Control Port (4001h)................. 68
Figure 5.10. WDT Control Port (4002h)..................................... 68
Figure 5.11. WDT Counter Port (4003h).................................... 69
Figure 5.12. Event Output Control Port (4004h)......................... 69

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
vi
Figure 5.13. RAS Status Port (4005h) ........................................ 70
Figure 5.14. How to Use General-purpose I/O and Remote Reset71
Figure 5.15. General-purpose Input Port (4000h) ....................... 72
Figure 5.16. Event Input Control Port (4001h) ........................... 72
Figure 5.17. Index Address Setting Port (4006h)........................ 73
Figure 5.18. RS-485 Transmission and Reception Control Port
(4007h)................................................................... 73
Figure 5.19. Half-Duplex Connection Method............................ 74
Figure 5.20. Full-Duplex Connection Method............................ 74
Figure 5.21. Input Circuit........................................................... 74
Figure 5.22. Output Circuit......................................................... 75
Figure 5.23. Factory Settings...................................................... 75
Figure 5.24. Expansion Board Dimensions................................. 81
Figure 5.25. Removing the Top Cover........................................ 82
Figure 5.26. Removing the PCB Brace 2.................................... 82
Figure 5.27. Installation of an Expansion Board......................... 83
Figure 5.28. Attaching the PCB Brace........................................ 83
Figure 5.29. Adjusting to Use the ISA Card .............................. 83
Figure 5.30. Replacing the Top Cover ........................................ 84
Figure 7.1. Memory Map.......................................................... 87

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P vii
List of Tables
Table 2.1. Functional Specifications < 1 / 2 >.......................... 7
Table 2.1. Functional Specifications < 2 / 2 >.......................... 8
Table 2.2. Installation Environment Requirements...................... 8
Table 2.3. IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P ........ 9
Table 2.4. IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P ...... 9
Table 3.1. Jumper List ............................................................... 19
Table 3.2. Internal Connector List ............................................. 19
Table 4.1. Key Function List ..................................................... 28
Table 5.1. Component Functions ............................................... 47
Table 5.2. Keyboard Connector................................................. 48
Table 5.3. Mouse Connector...................................................... 48
Table 5.4. FD Connector ........................................................... 49
Table 5.5. SERIAL 1 and 2 I/O Addresses and Interrupts.......... 51
Table 5.6. Serial Port Connector................................................ 51
Table 5.7. Serial Port D I/O Addresses and Interrupts................ 52
Table 5.8. Output Connector When the RS-422/RS-485 Is in Use
(RAS Connector).................................................... 52
Table 5.9. I/O Addresses............................................................ 54
Table 5.10. Function of Each Register < 1 / 4 >..................... 55
Table 5.10. Function of Each Register < 2 / 4 >..................... 56
Table 5.10. Function of Each Register < 3 / 4 >..................... 57
Table 5.10. Function of Each Register < 4 / 4 >..................... 58
Table 5.11. Baud Rate Settings.................................................. 58
Table 5.12. CRT Connector....................................................... 59
Table 5.13. Drivers for Each OS................................................ 59

IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
viii
Table 5.14. Power Supply to the Card........................................ 61
Table 5.15. Printer Ports and I/O Addresses............................... 61
Table 5.16. Printer Port Connector ............................................ 62
Table 5.17. RAS Connector....................................................... 63
Table 5.18. Index Register Settings ........................................... 66
Table 5.19. Counter Clock Frequency Settings.......................... 67
Table 5.20. WD_S1 and WD_S0: Alarm-out Output Status
Settings................................................................... 68
Table 5.21. WM2-WM0: Interrupt Output Modes ..................... 69
Table 5.22. RESET: Reset Output Modes.................................. 69
Table 5.23. PIM2-PIM0............................................................. 72
Table 5.24. RESET: Reset Input Modes..................................... 72
Table 5.25. USB Connector....................................................... 76
Table 5.26. Ethernet Connector................................................. 77
Table 5.27. Primary IDE Connector (CN15).............................. 79
Table 5.28. Secondary IDE Connector (CN2)............................ 80
Table 5.29. Expansion Slots....................................................... 81
Table 6.1. Touch panel specifications ........................................ 85
Table 6.2. SERIAL C I/O Addresses and IRQ........................... 86
Table 7.1. I/O Port Addresses.................................................... 88
Table 7.2. Hardware Interrupt Levels (Factory Settings)............ 89

Introduction
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P 1
1. Introduction
CONTEC has been actively engaged in the development of
software that is indispensable to the optimization of systems and for
factory automation. Recent years have seen an increasing number
of users who embrace FA and LA utilizing personal computers. In
response to this trend, CONTEC has developed and marketed FA
computers (the IPC series) and a variety of interface boards.
The PANECON-PC is a compact FA computer loaded with every
function needed. The following three models are available:
Model with PCMCIA Card and Panel Link Interface
-IPC-PT/L600S(PCW)C
-IPC-PT/H600X(PCW)C
Model with Expansion Slot
-IPC-PT/L600S(PCW)P
-IPC-PT/H600X(PCW)P
Features
-Equipped with the latest Low Power Mobile Celeron 400MHz
CPU
-Fan-less operation achieved by natural air-cooling
-Ten-year long-life power supply at an ambient temperature of
40°C
-Long, reliable supply (The CPU and chip set are embedded
versions.)
-Adoption of BIOS (Phoenix Technologies, Ltd.) customized by
CONTEC to support the BIOS level
-Equipped with 100BASE-TX LAN standard
-Equipped with a secondary-IDE connector to allow an optional
external CD-ROM to be connected
-Equipped with a Panel Link interface in addition to CRT interface
(C model)
-The backlight can be replaced by the user
-IP65/NEMA4 compliant front panel.

Introduction
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
2
Compatible Operating Systems
-Windows 2000 Professional
-Windows NT 4.0 Workstation
-Windows 98 Second Edition
Limited One-Year Warranty
CONTEC Interface boards are warranted by CONTEC CO., LTD.
to be free from defects in material and workmanship for up to one
year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned
freight prepaid with a copy of the original invoice and a Return
Merchandise Authorization to the distributor or the CONTEC group
office, from which it was purchased.
This warranty is not applicable for scratches or normal wear, but
only for the electronic circuitry and original boards. The warranty
is not applicable if the device has been tampered with or damaged
through abuse, mistreatment, neglect, or unreasonable use, or if the
original invoice is not included, in which case repairs will be
considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a
copy of the original invoice. Please obtain a Return Merchandise
Authorization Number (RMA) from the CONTEC group office
where you purchased before returning any product.
*No product will be accepted by CONTEC group without the
RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product.
In no event will the warrantor be liable for any incidental or
consequential damages due to such defect or consequences that arise
from inexperienced usage, misuse, or malfunction of this device.

Introduction
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P 3
Handling Precautions
Take the following precautions when handling this product.
-Do not use or store the product in a location exposed to extremely
high or low temperature or susceptible to rapid temperature
changes.
Example: - Exposure to direct sun
- In the vicinity of a heat source
-Do not use the product in extremely humid or dusty locations.
It is extremely dangerous to use the product with its interior
penetrated by water or any other fluid or conductive dust. If the
product must be used in such an environment, install it on a dust-
proof control panel, for example.
-Avoid using or storing the device in locations subject to shock or
vibration.
-Do not use the product in the vicinity of devices that generate
strong magnetic force or noise. Such devices will cause this
device to malfunction.
-Do not use or store the product in the presence of chemicals.
-The lower center of the left face (seen from the connector's front
surface) may become hot. To avoid being burned, do not touch
that section while the product is in operation or immediately after
turning off the power. Avoid installation in a location where
people may come into contact with that section.
-To clean the PANECON-PC, wipe it gently with a soft cloth
dampened with either water or mild detergent. Do not use
chemicals or a volatile solvent, such as benzene or thinner, to
prevent pealing or discoloration of the paint.
-When you need to continually operate the device using the hard
disk, be sure to run the HDD in standby mode. Running in other
than standby mode significantly shortens the product's life. (For
more information, see form titled "Precautions" that comes with
the optional product [2.5inch HDD.])
-Before installing or uninstalling an expansion board (the P model)
or connecting or disconnecting a connector, be sure to unplug the
power cable from the wall outlet.
-CONTEC reserves the right to refuse to service a product
modified by the user.

Introduction
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
4
-In the event of failure or abnormality (foul smells or excessive
heat generation), unplug the power cord immediately and contact
the sales representative you purchased the product from or the
CONTEC Information Center.
-Use an AC cable that is compatible with both the rated supply
voltage and the receptacle. (The cable provided with the
product is for 125VAC.)
-Do not use any sharp-pointed object such as a mechanical pencil
to touch the touch panel. Doing so may scratch the touch panel,
resulting in malfunctions.
-Do not subject the touch panel to shock as doing so may break it.
-When the surface or frame of the touch panel has become dirty,
wipe it with neutral detergent. Do not wipe the touch panel with
thinner, alcohol, ammonia, or a strong chlorinated solvent. Use
a protective sheet (available as an option) if the touch panel is
used where it can easily collect dust and dirt.
-Burn-in on TFT Display
"Burn-in" may occur if the same display is retained for a long
time. Avoid this by periodically switching the display so that
the same display is not maintained for a long time.
* Burn-In: Phenomenon characterized by a TFT display as a
result of long-time display of the same screen where a
shadow-like trace persists because electric charge
remains in the LCD element even after the patterns are
changed.
-It is a characteristic of analog touch panels that their resistance
may vary with changes to the ambient environment (temperature
and humidity) and with their own aging, resulting in the deviation
of the detection point. If this is the case, calibrate the touch
panel again to re-set calibration data.
-Life expectancy of components
(1) Power supply:
Assuming continuous use at 40°C, the expected life of the
power supply is about 10 years (when installed vertically).
Note that it is shortened depending on the operating
temperature (high temperature).
(2) Battery:
A lithium-ion primary battery is used to back up the internal
clock/calendar and CMOS RAM. The deenergized backup
time at 25°C is 10 years or more.

Introduction
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P 5
(3) LCD backlight:
Display brightness decreases over time with use.
The operating lifetime of the backlight is as follows (the
time until the brightness is lowered to 50% of the initial
value):
-IPC-PT/L600S(PCW) : 50,000 hours
-IPC-PT/H600X(PCW) : 25,000 hours
(4) Touch panel:
The operating lifetime of the touch panel is at least 1 million
touches (as tested by mechanical touching under 300 g of
force at a rate of two presses per second).
*CONTEC accepts your request for replacing each consumable in
the PANECON-PC as a request for repair (at an additional cost).
FCC PART 15 Class A Notice
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass Adigitaldevice,
pursuanttopart15 oftheFCC Rules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferencewhentheequipmentisoperatedincommercialenvironment.
Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergy and,ifnotinstalledand
usedinaccordancewiththeinstructionmanual,maycauseharmfulinterferencetoradio
communications.Operationofthisequipmentinaresidentialareaislikelytocauseharmful
interferenceathisownexpense.
NOTE
Changeormodificationsnotexpresslyapprovedthemanufacturercanvoidtheuser'sauthorityto
operatethisequipment.
WARNINGTOUSER
Note! To connect with peripherals, use a grounded, shielded cable.

Introduction
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
6
About the Manual
This manual consists of the following chapters :
Chapter 1 Introduction
Chapter 2 Overview
Chapter 3 Hardware Setup
Chapter 4 BIOS Setup
Chapter 5 Each Component Function
Chapter 6 Touch Panel
Chapter 7 Appendix
Chapter 8 List of Options

Overview
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P 7
2. Overview
Specifications
Table 2.1.Functional Specifications < 1 / 2 >
Display LCD type
Number of
colors
Touch panel Resolution
Detection method
Backlight ON/OFF
CPU
Chip Set
Memory L2 Cache
Main memory 256 MB maximum in 3.3-V, 144-pin SO DIMM socket x 2
(Use 1 socket for 64 or 128 MB; 2 sockets for 256 MB.)
BIOS ROM
Video Controller
Video RAM
Video BIOS
CRT I/F
FDD I/F
IDE HDD I/F Primary
Secondary
Serial I/F *1
Parallel I/F *1
LAN I/F
Controller
PC Card Slot *1 None PCMCIA type I/II x 2 or
III x 1 *2 None PCMCIA type I/II x 2 or III x 1 *2
USB I/F
Keyboard I/F
Mouse I/F
General-purpose I/O
for remote reset.)
RAS function
Expansion board slots *1
PCI/ISA shared slot x
2,
Acceptable board
length: 240 mm max.
None
PCI/ISA shared slot x
2,
Acceptable board
length: 240 mm max.
None
RTC/CMOS
*1 No all of these functions can be used at the same time because the number of interrupt resources is limited.
*2 Cannot be started from ATA card.
WDT: 244.14 µsec to 255 sec (RESET or external output enabled upon time-out)
Remote reset: External input signal
Lithium ion battery backup. Battery life: 10 years min.
PC/AT keyboard compatible (6-pin MIN DIN connector)
PS/2 mouse compatible (6-pin MIN DIN connector)
Photocoupler insulated inputs and outputs: 3 channels each
(One output channel also serves for WDT external output; one input channel also serves
Bidirectional Centronics compliant DB-25 connector
Ethernet 100BASE-TX/100BASE-T RJ-45 connector
82559 (Intel)
2ch
Dedicated 40-pin half-pitch connector (for optional CD-ROM drive)
RS-232C (general-purpose): 2 channels (serial ports 1 and 2), DB-9 connector
RS-232C (touch panel): 1 channel (serial port 3)
RS-422/485 (general-purpose): 1 channel (serial port 4) (inside RAS connector)
128KB E0000H to FFFFFH (Phoenix)
2MB (Built-in the controller)
B69000(C&T)
48KB (C0000H to CBFFFH)
HDB-15 connector
Dedicated 26-pin half-pitch connector (2-mode x option FDD: PC-FDD25BH)
Internal 2.5-inch IDE HDD or silicon disk drive
128KB
4096 x 4096
(emulated in 1024 x 768 mode)
4096 x 4096
(emulated in 800 x 600 mode)
Low Power Mobile Celeron 400MHz, FSB100MHz (Intel)
Analog resistive
Enabled (software control)
440BX (Intel)
IPC-PT/H600X(PCW)C
12.1-inch TFT color LCD,
SVGA (800 x 600 dots)
260,000
Model IPC-PT/L600S(PCW)P IPC-PT/L600S(PCW)C IPC-PT/H600X(PCW)P
15-inch TFT color LCD,
XGA (1024 x 768 dots)

Overview
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
8
Table 2.1.Functional Specifications < 2 / 2 >
Power Input supply voltage
supply Current consumption 95VA(Max.) 50VA(Max.) 95VA(Max.) 50VA(Max.)
Expansion board
supplies power
+5V:2A(1A × 2 slots),
-5V:Not supplied,
+12V:0.3A,
-12V: 80mA
None
+5V:2A(1A × 2 slots),
-5V:Not supplied,
+12V:0.3A,
-12V:80mA
None
Panel cut dimensions (mm)
370(W)×307(H)×139(D)
(Board depth) 370(W)×307(H)×79(H) (Board depth) 428(W)×336(H)×139(D) (Board depth) 428(W)×336(H)×79(D) (Board depth)
Weight About7.5kg About6.6kg About8.5kg About7.6kg
Waterproofing, dustproofing IP65, fornt
Dustproof & Waterproof Front in compliance with IP65
Outside dimensions (mm)
100 to 120 VAC or 200 to 240 VAC (50/60 Hz): Input automatically selected
344±0.5(W)×281±0.5(H)
(12 stud holes are required around.) 398±0.5(W)×306±0.5(H) (12 stud holes are required around.)
Model IPC-PT/L600S(PCW)P IPC-PT/L600S(PCW)C IPC-PT/H600X(PCW)P IPC-PT/H600X(PCW)C
Table 2.2. Installation Environment Requirements
Power supply specifications
Allowable instantaneous
power outage
One minute each for 3.0 kVAC (input-output), 2.0 kVAC (input-FG),
and 0.5 kVAC (output-FG)
Insulation resistance 50MΩ(DC500V)
Ambient specifications
0 to 50ºC(SDD in use)
Operating temperature 0 to 45ºC(HDD in use)
5 to 45ºC(FDD in use)
Storage temperature -10 to 60ºC
Humidity *1 10 to 90%RH(No condensation)
Floating dust particles Not to be excessive
Corrosive gases None
Line noise AC line/2kV, Signal line/1kV (IEC1000-4-4Level 3, EN61000-4-4Level 3)
Contact discharge/4kV (IEC1000-4-2Level 2, EN61000-4-2Level 2)
Atmospheric discharge/8kV (IEC1000-4-2Level 3, EN61000-4-2Level 3)
10 to 50Hz/semi-amplitude 0.15mm 50 to 500Hz/2.0G
23 min. each in x, y, and z directions
(JIS C0040-compliant, IEC68-2-6-compliant)
30 min. each in x, y, and z directions
(JIS C0040-compliant, IEC68-2-6-compliant)
Impact resistance *2 10G, half-sine shock for 11 ms in x, y, and z directions
(JIS C0041-compliant, IEC68-2-27-compliant)
Grounding Class D grounding (previous class 3 grounding)
*1 When a floppy disk is not in use.
*2 When the HDD and FDD are not in use.
Requirement description
Static electricity
resistance
Line-noise
resistance
Parameter
Less than 20ms
Vibration
resistance *2
Sweep resistance
Fixed-vibration
resistant
Dielectric strength

Overview
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P 9
Display Optical Specifications
Table 2.3.IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P
Parameter Min. Typical
φ = 180° 20deg 35deg
φ = 0° 50deg 65deg
φ= +90° 40deg 60deg
φ= -90° 40deg 60deg
Contrast 100 ---
Brightness (at center) 200cd/m2250cd/m2
Condition
View angle (Vertical)
CR≥10
Display. Monochrome
Display. White
View angle (Horizontal)
Display.
Monochrome
Table 2.4. IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
Parameter Min. Typical
φ = 180° 20deg 35deg
φ = 0° 50deg 65deg
φ= +90° 40deg 60deg
φ= -90° 40deg 60deg
Contrast 100 ---
Brightness (at center) 200cd/m2250cd/m2
Display. Monochrome
Display. White
View angle (Horizontal)
Display.
Monochrome
Condition
View angle (Vertical)
CR≥10
Contrastratio(CR)=Brightness atscreencenterwithwhitedisplayed
Brightness atscreencenterwithblackdisplayed
Left
(φ=-90°)
Z
Y
X
Up
(φ=180°)
Right
(φ=90°)
Down
(φ=0°)
(θ=0°)
Measurementdirection
θ
Module
φ
Figure 2.1. Definition of viewable range

Overview
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P
10
System Configuration
LAN
RS-232C
USB
IPC-PSD-20
Built-in
2.5inch
hard(silicon)
diskdrive
Mainmemory
144pinSO-DIMM
Mouse
Keyboard
OptionCD-ROM
PCMCIAcardslot
(Cmodel)
PCMCIAtypesI,II x2,
orIII x1
Printer
CRTdisplay
DedicatedFDDrive
PC-FDD25BH
RS-485
General-purposeI/O(3)
RAS
Terminal
block
PC-HELPER
series
FA-PAC(PC)
series
*Notall devicesshowninthefigure
canbeusedsimultaneouslydueto
alimitonthenumberofinterrupt
resources.
Expansionslot
(Pmodel)Whenthree ormoreslotsareneededor
whenafull-sizeboardisused
Expansion
busadapter
PCIandISA
half-sizeboards
Figure 2.2. System Configuration

Overview
IPC-PT/L600S(PCW)C, IPC-PT/L600S(PCW)P, IPC-PT/H600X(PCW)C, IPC-PT/H600X(PCW)P 11
External Dimensions
IPC-PT/L600S(PCW)C
119 119119 342
989898 279
24 2.4
13
370
307
12-M4STUD
40
37.3
89.75 99.75
[mm]
80
8.5
8.5
79
251
4
-
R4
Figure 2.3. External Dimensions of the
IPC-PT/L600S(PCW)C
