Contec SPT-100A-22TP01 User manual

Reference Manual
CONTENTS
STAND-PC 21.5-inch model, 4GB memory integrated type
SPT-100A-22TP01
STAND-PC 21.5-inch model, 8GB memory integrated type
SPT-100A-22TP02
Introduction .................................................................. 5
Safety Precautions....................................................11
Product Nomenclature and Function................18
Hardware Setup.........................................................31
BIOS Setup ..................................................................42
Appendix......................................................................71
Customer Support and Inquiry ...........................93

- 2 -
Table of Contents
Introduction ............................................................................5
1. Related Manuals ...................................................................................................................................... 6
2. About the Product................................................................................................................................... 7
3. Features .....................................................................................................................................................8
4. Supported OS........................................................................................................................................... 9
5. Product Configuration List...................................................................................................................10
Safety Precautions .............................................................. 11
1. Safety Information.................................................................................................................................12
2. Handling Precautions............................................................................................................................13
1. FCC PART 15 Class A Notice ..........................................................................................................15
2. EN55032 Class A Notice.................................................................................................................15
3. Battery handling and the storage in EU signatory .........................................................................16
4. Security Warning....................................................................................................................................17
1. Information security risks...............................................................................................................17
2. Security measures – e.g. .................................................................................................................17
Product Nomenclature and Function ............................. 18
1. Nomenclature of Product Components............................................................................................19
2. Description of Product Components.................................................................................................22
1. LED: POWER, ACCESS, STATUS......................................................................................................22
2. DC power connector: DC-IN (Display section) ..........................................................................22
3. USB: USB for the touch screen (Display section).......................................................................23
4. DVI Interface: DVI-D (Display section).........................................................................................24
5. Analog RGB connector: VGA (Display section)..........................................................................25
6. DC power input connector: DC-IN...............................................................................................25
7. Power switch: POWER-SW .............................................................................................................25
8. Mic input interface: MIC.................................................................................................................26
9. Line output interface: LINE OUT...................................................................................................26
10. DVI interface: DVI-I..........................................................................................................................26
11. USB3.0 port: USB3.0 ........................................................................................................................27
12. USB2.0 port: USB2.0 ........................................................................................................................27
13. Giga bit-Ethernet: LAN A, B...........................................................................................................28
14. CFast card connector: CFast 1, 2...................................................................................................29
15. Serial Port Interface: SERIAL A, B..................................................................................................30
Hardware Setup................................................................... 31
1. Before Using the Product for the First Time ....................................................................................32
2. Hardware Setup .....................................................................................................................................33
1. How to remove the display............................................................................................................33
2. How to set the display....................................................................................................................34
3. Install the display vertically............................................................................................................35

- 3 -
Table of Contents
4. Display setting menu ......................................................................................................................37
5. Calibration setting ...........................................................................................................................39
6. Installation Requirements ..............................................................................................................41
BIOS Setup............................................................................ 42
1. Introduction............................................................................................................................................43
1. Starting Setup...................................................................................................................................43
2. Using Setup.......................................................................................................................................44
3. Getting Help......................................................................................................................................44
4. In Case of Problems.........................................................................................................................44
5. A Final Note About Setup..............................................................................................................44
2. Main Menu..............................................................................................................................................45
1. Setup Items .......................................................................................................................................45
3. Main..........................................................................................................................................................46
4. Advanced.................................................................................................................................................47
1. ACPI Settings ....................................................................................................................................48
2. Super IO Configuration...................................................................................................................49
3. H/W Monitor.....................................................................................................................................51
4. CPU Configuration...........................................................................................................................52
5. PPM Configuration ..........................................................................................................................53
6. SATA Configuration .........................................................................................................................54
7. CSM Configuration..........................................................................................................................55
5. Chipset.....................................................................................................................................................56
1. North Bridge.....................................................................................................................................57
2. Intel IGD Configuration ..................................................................................................................58
3. LCD Control.......................................................................................................................................59
4. South Bridge .....................................................................................................................................60
5. Azalia HD Audio Configuration.....................................................................................................61
6. USB Configuration ...........................................................................................................................62
7. LAN Configuration...........................................................................................................................63
6. Security ....................................................................................................................................................64
1. Secure Boot menu...........................................................................................................................66
7. Boot Configuration................................................................................................................................67
8. Save & Exit..............................................................................................................................................69
Appendix............................................................................... 71
1. System Reference...................................................................................................................................72
1. Specifications....................................................................................................................................72
2. Physical Dimensions..............................................................................................................................75
1. Display horizontal installation.......................................................................................................75
2. Display vertical installation............................................................................................................75
3. POST Codes ............................................................................................................................................77
4. SERIAL I/O Address and Register Function ......................................................................................80
5. Watch-Dog-Timer..................................................................................................................................85
6. Battery Disposal.....................................................................................................................................90
1. Battery Specification .......................................................................................................................90

- 4 -
Table of Contents
2. Dispose of the Battery ....................................................................................................................90
7. Life of CFast.............................................................................................................................................92
Customer Support and Inquiry ........................................ 93
1. Services....................................................................................................................................................94

- 5 -
Introduction
This section provides necessary information of the product
such as the outline, bundled items and manuals before
actual use.

—
Introduction
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 6 -
1.Related Manuals
The manuals related to the product are listed below.
Read them as necessary along with this document.
Must Read the Followings.
Name
Purpose
Contents
How to get
Product Guide
Must read this after opening the
package.
This lists the product configuration
and describes the precautions.
Included in the package
(Printed matter)
Reference Manual
Read this when operating the
product.
This describes the hardware aspects
such as functions and settings.
Download from
the
CONTEC
website (PDF)
Download Manuals
Download the manuals accordingly from the following URL.
Download
https://www.contec.com/download/

—
Introduction
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 7 -
2.About the Product
This product is an “All-in-One” PC with an integrated high-performance touch screen.
21.5-inch size of the display monitor is pre-installed, and more than 10 ports of rich, extendable
interfaces such as DVI-I, 1000BASE-T, USB 3.0, serial and Audio are provided.
Embedded-type chipset and CPU have been adopted. The use of readily available parts ensures the
ease of the use of the product.

—
Introduction
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 8 -
3.Features
Shipped to your door already assembled as an “All-in-
One” PC.
The product is shipped from the factory with the display monitor, stand, PC unit pre-assembled. Just connect the cable to the PC and
turn on the power to get started.
Rich, extendable interfaces with more than 10 ports.
With rich and extendable interfaces that include 1000BASE-T×2, USB3.0×1, USB2.0×5, serial (RS-232C) ×2, and general I/O port ×1,
this is the best PC for use in industrial applications where peripheral device extension capability is a must.
High-performance touch screen display.
The high-performance industrial touch screen display is of a type also used for medical equipment. It features touch operations similar
to that of tablets or smartphones with 10-point multi-touch capabilities. It also provides superior visibility thanks to a viewing angle of
178°(Horizontal) / 178°(Vertical).
The front side of the display meets the IP54 standard,
and the fan-less PC design ensures dust-free
specification.
The front side of the display is designed to be dust and drip free to meet the IP 54 standard. The PC unit contains no fan, which ensures
free from dust or foreign substance.
A low center gravity structure achieved by mounting
the PC in the pedestal.
Mounting the PC unit in the pedestal of the display stand achieves a low center gravity structure and makes the product stable.
The pedestal part can also be set with screws.
Long-term product availability contributes to low-cost
operation.
In addition to the industrial display monitor, taking up CPU configurations can contribute to longer-term product availability.
This frees the users from operation checks or device structure changes each time PC models changes, and it also reduces the running
costs of development or verification.
Pre-installation of OS to support the latest integrated
type
Windows 10 IoT Enterprise LTSB 2016 64-bit edition is installed to support Japanese, English, Chinese, and Korean.
Unlike Windows10 commonly used, long-term availability with the same specifications are guaranteed. Moreover, Write Filter, one of
the additional functions, enables the system to operate with Read-only.

—
Introduction
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 9 -
4.Supported OS
Windows 10 IoT Enterprise LTSB 2016 64-bit (Japanese / English / Chinese / Korean)

—
Introduction
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 10 -
5.Product Configuration List
The product consists of the items listed below.
Check, with the following list, that your package is complete.
If you discover damaged or missing items, contact your retailer.
Product…1
AC Adapter for PC...1
AC Power Cable for PC...1
DVI Cable for Display ...1 *1
DVI-Analog RGB
Conversion Adapter...1
Stand Wiring Cover...1
AC Adapter for Display...1
AC Power Cable for
Display...1
USB Cable for Touch
Screen...1*1
Cable Tie...2
Serial Number Label...1
USB removal prevention
fitting (angle)…6
Washer assembled screw
(M3 x 6)...6
Washer assembled screw
(M3 x 8, black)...4
Washer assembled and
cross
recessed hexagonal
bolt (M4 x 10, black)...4
Setup Procedure
Document…1
IPC Precaution List...1
Warranty Certificate...1
End User License
Agreement (EULA)...1
Setup Procedure
Document…1
CFast User’s Guide...1
Recovery Media...1
*1 Preset upon shipping.

- 11 -
Safety Precautions
Understand the following definitions and precautions to
use the product safely.
Never fail to read them before using the product.

—
Safety Precautions
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 12 -
1. Safety Information
This document provides safety information using the following symbols to prevent accidents
resulting in injury or death and the destruction of equipment and resources.
Understand the meanings of these labels to operate the equipment safely.
DANGER
DANGER indicates an imminently hazardous situation which, i
f not
avoided, will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or in property
damage.

—
Safety Precautions
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 13 -
2.Handling Precautions
WARNING
Always check that the power supply is turned off before connecting or disconnecting power
cable.
Do not modify the product.
This product is not intended for use in aerospace, space, nuclear power, medical equipment,
or other applications that require a very high level of reliability. Do not use the product in
such applications.
If using this product in applications where safety is critical such as in railways, automotive, or
disaster prevention or security systems, please contact your retailer.
Do not attempt to replace the battery as inappropriate battery replacement poses a risk of
explosion. For battery replacement, contact your retailer as it must be performed as a process
of rep air.
When disposing of a used battery, follow the disposal procedures stipulated under the
relevant laws and municipal ordinances. For details on replacing the battery, refer to the
appendix.
CAUTION
Do not use or store this product in a location exposed to high or low temperature that
exceeds range of specification or susceptible to rapid temperature changes.
e.g. - Exposure to direct sun - In the vicinity of a heat source
Do not use this product in extremely humid or dusty locations. It is extremely dangerous to
use this product with its interior penetrated by water or any other fluid or conductive dust. If
this product must be used in such an environment, install it on a dust-proof control panel, for
example.
Avoid using or storing the product in locations subject to shock or vibration that exceeds
range of specification.
Do not use this product in the vicinity of devices that generate strong magnetic force or
noise. Such products will cause this product to malfunction.
Do not use or store this product in the presence of chemicals.
To clean this product, wipe it gently with a soft cloth dampened with either water or mild
detergent. Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent
pealing or discoloration of the paint.
This product’s case may become hot. To avoid being burned, do not touch that section while
this product is in operation or immediately after turning off the power. Avoid installation in a
location where people may come into contact with that section.
CONTEC does not provide any guarantee for the integrity of data on storage.

—
Safety Precautions
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 14 -
Always disconnect the power cable from the receptacle before mounting or removing the
expansion board, before connecting or disconnecting any connector.
To prevent corruption of files, always shutdown the OS before turning off this product.
CONTEC reserves the right to refuse to service a product modified by the user.
In the event of failure or abnormality (foul smells or excessive heat generation), unplug the
power cord immediately and contact your retailer.
To connect with peripherals, use a grounded, shielded cable.
Do not use any sharp-pointed object such as a mechanical pencil to touch the touch panel.
Doing so may scratch the touch panel, resulting in malfunctions.
When the surface or frame of the touch screen has become dirty, wipe it with neutral
detergent. Do not wipe the touch screen with thinner, alcohol, ammonia, or a strong
chlorinated solvent.
Use your fingers to perform operations on the touch screen. Operations with the stylus pen
on the screen might not perform well due to the pen you are using with.
LCD may have a few bright spots that are always on or a few black spots that are always off.
Color irregularity may also occur depending on the viewing angle. This however is due to the
structural characteristics of the LCD; therefore, it is not a product fault.
Be certain to use the bundled AC adapters and power cables. Also, do not use these AC
adapters or power cables with any other devices.
Burn-in on TFT Display
“Burn-in” may occur if the same display is retained for a long time. Avoid this by periodically
switching the display so that the same display is not maintained for a long time.
* Burn-In: Phenomenon characterized by a TFT display as a result of long-time display of the
same screen where a shadow-like trace persists because electric charge remains in the LCD
element even after the patterns are changed.
The backlight lifetime of the touch screen display.
The rated life of the backlight is 30,000 hours or longer.
*Ambient temperature25°C±5°C, I F =110mA, Drops to 50% of the initial luminance.

—
Safety Precautions
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 15 -
1. FCC PART 15 Class A Notice
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
2. EN55032 Class A Notice
Warning:
Operation of this equipment in a residential environment could cause radio interference.

—
Safety Precautions
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 16 -
3. Battery handling and the storage in
EU signatory
This symbol mark is for EU countries only.
This symbol mark is according to the directive 2006/66/EC Article 20 Information for end-users and
Annex II.
This symbol mark means that batteries and/or accumulators, at their end-of-life, should be disposed
separately from the household waste.
If a chemical symbol is printed beneath the symbol mark shown above, it indicates that the battery
or accumulator contains a heavy metal at a certain concentration.
The concentration standard is indicated below:
Hg: mercury (0.0005%), Cd: cadmium (0.002%), Pb: lead (0.004%)
These ingredients may cause hazardous conditions for human and the global
Refer to the Appendix for the specification as well as how to remove and dispose of the battery.

—
Safety Precautions
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 17 -
4.Security Warning
When connecting to the network, be aware of security-related problems. See the examples of
Security measures below and set up the product properly along with the network devices.
1. Information security risks
Unauthorized access from the outside through a network could cause the system halt, data
damage, or exposure to malware. *1
Invaded and used as a stepping stone, a device might attack the others through networks. (a
victim becomes an assailant)
Information might leak without realizing due to the connection to the network.
Secondary damages such as harmful rumors, liability in damages, social credibility fall, and
opportunity loss are expected led by the troubles described above.
*1: Malware (Malicious Software) is software that brings harm to a computer system and performs
unintended operations.
2. Security measures – e.g.
Do not keep using the default password. (Refer to the product manual for the password
setting).
Set a strong password.
Combined with upper and lowercase letters, and numbers so that it cannot be easily
analogized by others.
Change the password periodically.
Disable unnecessary network services and functions.
Restrict access to the network with network devices. *2
Restrict ports to be released on the network with network devices. *2
Create a closed network connection using such as dedicated network or VPN*3
*2: Inquire for setting procedure to manufacturers.
*3: VPN (Virtual Private Network) a secured network that wards off unauthorized access by
protecting the communication path with authentication and encryption.
Unfortunately, there are no perfect ways to avert unauthorized access or close a security hole
that are endlessly found day and night.
Please understand that risks are always involved with the Internet connection, and we strongly
recommend a user should constantly update information security measures.

- 18 -
Product Nomenclature
and Function
This section describes product component names and their
functions, pin assignment of each connector.

—
Product Nomenclature and Function
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 19 -
1.Nomenclature of Product Components
Component names of the product are shown in the figure below.
Product front view
Display section rear view
Display section bottom view
Touch screen display
Display section
PC section
Menu screen button
↑ button
↓ button
Sslect button
Display power button

—
Product Nomenclature and Function
—
SPT-100A22TP01, SPT-100A22TP02 Reference Manual (Hardware)
- 20 -
PC section connector view
PC section side view
Name
Function
Display section back
POWER LED
Power ON display LED
DC-IN
DC power input connector
USB
USB for the touch screen TYPE-B connector x 1
DVI-D
Display port (24-pin Female)
VGA
Display port (15-pin HD-SUB Female)
PC section connector
POWER LED
PC power ON display LED
STATUS LED
Status LED
ACCESS LED
CFast disk access display LED
DC-IN
DC power input connector
POWER-SW
Power switch
MIC IN
Mic input (3.5φ PHONE JACK)
LINE OUT
Line out (3.5φ PHONE JACK)
DVI-I
Display (29-pin Female)
USB2.0
USB3.0
POWER-LED
DC-IN
MIC IN
POWER SW
LINE OUT
CFast1 CFast2
DVI-I
LAN A LAN B
SERIAL A
STATUS LED
ACCESS LED
USB2.0 SERIAL B
POWER-SW
