PC-HDD5000
1
2.5 inch Hard Disk Drive
PC-HDD5000
User’s Guide
Thank you for purchasing the CONTEC PC-HDD5000. Please use this product in
accordance with the procedures described in this document.
General Caution
･Do not apply pressing force on the top of cover (See Figure 1. on page 2).
･Do not cover the breathing hole on the top cover (See Figure 2. on page 2).
･Do not touch the interface connector pins and the surface of printed circuit board .
･Hard disk are precision instruments. Be extremely careful in handling during and
after assembly.
･The drive can be easily damaged by shocks or ESD (Electrical Static Discharge), so
any damages applied to the drive after taking out from shipping package and opening
ESD protective bag are user’s responsibilities.
･Be sure to turn off the power of the unit when plugging in or unplugging connectors.
･Use the mounting screws (M3x5 with sw, w : for screwing the base) provided with
the product. Longer screws may damage the interior of the product.
･CONTEC bears absolutely no responsibility for use if modified hard disk.
取り扱いの注意
･トップカバーを上から押さえる力を加えないでください。（2頁Figure 1. 参照）
･トップカバーの穴をふさがないでください。（2頁Figure 2. 参照）
･インターフェイスコネクタのピンや底面の基板表面に手をふれないでください。
･ハードディスクは精密機器です。移動時や組み立て時の取り扱いは慎重にお願いしま
す。
･ドライブは衝撃や静電気放電(ESD)によって簡単に壊れてしまいます。
多くの障害はお客様が開梱後または静電気防止バッグから取り出した後に引き起こされ
ます。
･コネクタの抜き差しをする場合は、必ずユニットの電源を切ってください。
･取り付け用のネジは添付のM3x5(sw, w付き)を使用してください。
これ以上長いネジでは商品を壊してしまう恐れがあります。
･本商品を改造したものにつきましては弊社は一切の責任を負いかねます。

PC-HDD5000 2
Caution of usage
DO NOT PRESS!
Figure 1. Handling caution of PC-HDD5000
･DO NOT PRESS WHEN YOU TAKE OUT THE DRIVE.
･DO NOT PRESS WHEN YOU CARRY THE DRIVE.
･ATTACH THE DRIVE FREE FROM PRESSING FORCE.
DO NOT COVER THIS HOLE
Figure 2. Breathing hole caution of PC-HDD5000
COVERING THIS HOLE WILL RESULT LOSS OF DATA.
Absolutely No Impact!
Excessive impact (greater than 800G;1ms or 120G;11ms), if this hard disk is subjected
to, might cause a fatal error that is not recoverable. When transporting, avoid leaving
the disk in the equipment. Instead, use the box the product came in. An impact of
100G is equivalent to the impact when dropped from a height of about 1cm.
衝撃厳禁 !
本ハードディスクに過度の衝撃［800G(1ms)以上または120G(11ms)以上］が加わると回復
不能のエラーが発生する恐れがあります。輸送時は、できるだけ機器に組み込まず、本商
品の梱包箱を利用してください。
100Gは約1cmの高さから落としたときの衝撃に相当します。

PC-HDD5000
3
Operating requirements for 24-hour
uninterrupted operation
For 24-hours continuous operation, it is recommended to stop the spindle motor using
the standby mode to ensure a long life. (Longer standby time is preferable.)
For the standby of the spindle motor, if it necessary to configure the Standby Mode on
your host computer.
24 時間連続稼働時の動作条件
24時間連続で稼働を行う場合は、寿命低下防止のためスタンバイモードの使用によりスピ
ンドルモータ停止を行うことを推奨します。（スタンバイ時間はできるだけ長い方が有利
です。）
スピンドルモータの停止を行うためには、ホストコンピュータでStandby Modeの設定が必
要です。
Unaccommodated host PCs
You can not use this drive when if you use these host PCs.
IPC-PT/M30(PC)、IPC-PE/M30(PC)、IPC-PS/M30(PC)、IPC-PL/M30(PC)、
IPC-BX/M20(PC)、IPC-BX/M10(PC)、PC-386(PC)、PC-386(PC)S、PC-486M(PC)、
IPC-PT/M140(PC)、IPC-PS/M140(PC)、IPC-PT/M100(PC)、IPC-PS/M100(PC)
非適応機種について
下記の機種では製品の仕様上ご利用になれません。
IPC-PT/M30(PC)、IPC-PE/M30(PC)、IPC-PS/M30(PC)、IPC-PL/M30(PC)、
IPC-BX/M20(PC)、IPC-BX/M10(PC)、PC-386(PC)、PC-386(PC)S、PC-486M(PC)、
IPC-PT/M140(PC)、IPC-PS/M140(PC)、IPC-PT/M100(PC)、IPC-PS/M100(PC)、
IPC-BC/M200(98)、IPC-BC/M200(98)A、PC-IDE/FD(98)

PC-HDD5000 4
Product Configuration
･Hard Disk Drive……1
･Screw (M3x5, with sw, w) ……4
･Insulation Film……1
･Jumper……1
Note!
Check the contents to make sure that you have everything listed above.
If you don’t have all the items, Please contact CONTEC.
External Dimensions
69.85 ±0.25
100.2±0.25
14.0±0.25
61.72±0.25
10.00
3.00 ±0.25
9.5±0.25
76.6±0.25
10.00
3.99
8-M3
(Depth3.5±0.5)
(mm)
Figure 3. External Dimension

PC-HDD5000
5
Master/Slave Settings
43 41
44 42
AC
1
3
DB
24
MasterSetting
(Open:DefaultSetting)SlaveSetting
A-BShort
C A
B
D
C A
B
D
Figure 4. Master/Slave Settings External Dimension
Note!
Specifications differ slightly depending on the drive manufacturer. Sometimes two
drives from two different manufacturers will not operate together.
PC-HDD5000 (mfd. by IBM, DJSA-205)
Installation
HDD InsulationFilm
InstallationPart
S
c
r
e
w
(
w
i
t
h
s
w
,
w
)
Figure 5. Installation

PC-HDD5000 6
Hard Ware Specifications
Format Capacity 5Gbyte
Bus Specification IDE-AT
Transfer Speed (Max.) 66.6MB/sec (Ultra DMA Mode4)
16.6MB/sec (PIO Mode-4)
Data Reliability Frequency of unrecoverable errors per bit :
Less than 1 times per 1013 reads
Nominal Supply/Tolerance DC+5V/±5%
Consumed Current During Startup 940mA (Typ.)
During read/write 420mA (Typ.)
During idle 170mA (Typ.)
Operating Conditions Temperature 5°C~55°C (Ambient)
5°C~60°C (Surface)
Humidity 8%~90% (With no condensation)
Maximum Wet Bulb Temperature 29.4°C
Maximum Temperature Gradient 20°C/Hour
Altitude -300m to 3000m
Anti-Vibration (during operation) Less than 1G (5~500Hz)
Anti-Shock (during operation) Less than 175G (2ms half-sine Pulse)
Weight 99g (Max.)
Item Specification
Connector Pin Assignment
Pin Signal Function I/O Pin Signal Function I/O
1RESET- Bus Reset I2GND Signal Ground
3DB7 Data Bus Bit 7 I/O 4DB8 Data Bus Bit 8 I/O
5DB6 Data Bus Bit 6 I/O 6DB9 Data Bus Bit 9 I/O
7DB5 Data Bus Bit 5 I/O 8DB10 Data Bus Bit 10 I/O
9DB4 Data Bus Bit 4 I/O 10 DB11 Data Bus Bit 11 I/O
11 DB3 Data Bus Bit 3 I/O 12 DB12 Data Bus Bit 12 I/O
13 DB2 Data Bus Bit 2 I/O 14 DB13 Data Bus Bit 13 I/O
15 DB1 Data Bus Bit 1 I/O 16 DB14 Data Bus Bit 14 I/O
17 DB0 Data Bus Bit 0 I/O 18 DB15 Data Bus Bit 15 I/O
19 GND Signal Ground I/O 20 KEY Key Pin
21 Open 22 GND Signal Ground
23 IOW- Host I/O Write I24 GND Signal Ground
25 IOR- Host I/O Read I26 GND Signal Ground
27 IORDY I/O ch RDY O28 Reserved
29 Reserved 30 GND Signal Ground
31 INTRQ Interrupt Request O32 IOCS16- Drive 16 Bit I/O O
33 ADD1 Host Address 1 I34 PDIAG- Passed Diagnostic I/O
35 ADD0 Host Address 0 I36 ADD2 Host Address 2 I
37 CSO- Chip Select 0 I38 CS1- Chip Select 1 I
39 DASP- Active (LED) O40 GND +5V Return
41 +5V +5VDC 42 +5V +5VDC
43 GND +5V Return 44 Reserved

PC-HDD5000
7
Drive Characteristics (Logical Drive Format)
Description Logical Logical Logical Logical Total Customer Total Customer
Head Sector Cylinder Sector Usable Data Usable Data
Number /Track Number Size Sector Bytes
PC-HDD5000 15 63 10,336 512 9,767,520 5,000,970,240
Copyright
Copyright 2000 CONTEC Co., LTD. ALL RIGHTS RESERVE
No part of this document may be copied or reproduced in any form by any means
without prior written consent of CONTEC Co., LTD.
CONTEC Co., LTD. makes no commitment to update or keep current the information
contained in this document. The information in this document is subject to change
without notice.
All relevant issues have been considered in the preparation of this document. Should
you notice an omission or any questionable item in this document, please feel free to
notify CONTEC Co., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any
errors that may appear in this document nor for results obtained by the user as a result of
using this product.
Limited One-Year Warranty
CONTEC Interface boards are warranted by CONTEC to be free from defects in
material and workmanship for up to one year from the date of purchase by the original
purchaser.
Replacement or repair will be free of charge only when this device is returned to
CONTEC freight prepaid with the original invoice.
This warranty is not applicable for scratches or normal wear, but only for the electronic
circuitry and original boards. The warranty is not applicable if the device has been
tampered with or damaged through abuse, mistreatment, neglect, or unreasonable use,
or if the original invoice is not included, in which case repairs will be considered
beyond the warranty policy. If replacement with a new device is needed, regular
factory prices will be charged, the product will be returned to you COD, and no other
written warranty will apply.
The obligation of the warrantor is solely to repair or replace the product. In no event
will the warrantor be liable for any incidental or consequential damages due to such
defect or consequences that arise from inexperienced usage, misuse, or malfunction of
this device.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original
invoice. Please obtain a Return Merchandise Authorization Number (RMA) from our
Sales Administration Department before returning any product. No product will be
accepted without an RMA number.
