Contec IPC SERIES User manual

IPC Series
Panel PC System
CA-RU150R30XG-3965U-01-W10
User’s Manual
CONTEC CO., LTD.

ii CA-RU150R30XG-3965U-01-W10 User’s Manual
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is completed. If you discover damaged or missing
items, contact your retailer or the general CONTEC information.
◆Product Configuration List
CA-RU150 Series
Name
Pcs.
Panel-PC
1
Power Cord
1
Adapter
1
Product Guide
1
Product Configuration Image
Panel-PC...1 Power Cord...1 Adapter...1 Product Guide...1
* See the Product Configuration List to check if all the components are included for the specified
number of units.

CA-RU150R30XG-3965U-01-W10 User’s Manual iii
◆Must Read the Following Manuals.
Name
Purpose
Contents
How to get
Product Guide
Must read this after
opening the package.
This lists the product
configuration and describes
the precautions.
Included in the package (Printed
matter)
User’s Manual
(This document)
Read this when operating
the product.
This describes the
hardware aspects such as
functions and settings.
Download from the
CONTEC website
(PDF)
IPC Precaution List
Read this before
operating the product.
This describes the
precautions when using the
product.
Download from the
CONTEC website
(PDF)
MICROSOFT
SOFTWARE
LICENSE TERMS *1
Must read this after
opening the package.
This describes the rights
and conditions of user
when using Windows
software.
Download from the
CONTEC website
(PDF)
Manual for OS
Pre-installed Model *1
Must read this after
opening the package.
This describes the basic
information of OS, and the
procedures of setup and
recovery.
Download from the
CONTEC website
(PDF)
*1 Reference for pre-installed models only.
◆Download MICROSOFT SOFTWARE LICENSE TERMS
Download it from the following URL.
Download https://www.contec.com/support/useterms/
◆Download Manuals
Download the manuals accordingly from the following URL.
Download https://www.contec.com/download/

iv CA-RU150R30XG-3965U-01-W10 User’s Manual
Option Available
The more details information about options should look at Web.
Copyright
Copyright 2020 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document.
The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel, Intel Atom, Intel Core and Celeron are registered trademarks of Intel Corporation. MS, Microsoft
and Windows are trademarks of Microsoft Corporation. Other brand and product names are trademarks
of their respective holder.
Certification
Contec is certified to ISO 9001:2015 standard.
FCC PART15 Class A Notice
EN55032 Class A Notice
Warning:
Operation of this equipment in a residential environment could cause radio interference.
This equipment has been tested and found to comply with the limits for a ClassA digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
NOTE
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.

CA-RU150R30XG-3965U-01-W10 User’s Manual v
Attention
1. This manual contains important information for the proper setup and maintenance of the
product(s). Before setup and usage of the product(s), please read this manual thoroughly.
2. The specifications shall apply only to the product(s) in this manual.
3. The specifications may be modified without any notice in advance. Please inquire with your
supplier for latest specifications, driver, or manual.

vi CA-RU150R30XG-3965U-01-W10 User’s Manual
Table of Contents
Check Your Package............................................................................................................................ii
◆Product Configuration List........................................................................................................ii
◆Must Read the Following Manuals. .........................................................................................iii
◆Download MICROSOFT SOFTWARE LICENSE TERMS....................................................iii
◆Download Manuals..................................................................................................................iii
Option Available................................................................................................................................. iv
Copyright............................................................................................................................................iv
Trademarks......................................................................................................................................... iv
Certification........................................................................................................................................ iv
Table of Contents................................................................................................................................ vi
1. INTRODUCTION 8
About the Product................................................................................................................................ 8
◆Appearance ............................................................................................................................... 8
◆Supported OS............................................................................................................................ 9
Customer support............................................................................................................................... 10
◆Web Site ................................................................................................................................. 10
How to Obtain Service....................................................................................................................... 10
Liability ............................................................................................................................................. 10
Safety precaution ............................................................................................................................... 11
◆Safety information .................................................................................................................. 11
◆Caution on the CA-RU150 Series ........................................................................................... 11
2. SYSTEM REFERENCE 13
Specification ...................................................................................................................................... 13
Physical dimensions........................................................................................................................... 15
3. BIOS SETUP 16
Introduction ....................................................................................................................................... 16
Starting Setup .................................................................................................................................... 16
Using Setup ....................................................................................................................................... 17
◆Getting Help ........................................................................................................................... 17
◆In Case of Problems................................................................................................................ 17
◆A Final Note About Setup....................................................................................................... 17
Main Menu ........................................................................................................................................ 18
Main .................................................................................................................................................. 19
Advanced........................................................................................................................................... 20
◆CPU Configuration ................................................................................................................. 22

CA-RU150R30XG-3965U-01-W10 User’s Manual vii
◆Super IO Configuration .......................................................................................................... 24
◆H/W Monitor .......................................................................................................................... 27
◆Smart Fan Configuration......................................................................................................... 28
◆PCI/PCIE Device Configuration............................................................................................. 29
◆GPIO Group Configuration..................................................................................................... 31
Boot ................................................................................................................................................... 32
Security.............................................................................................................................................. 34
◆PCH-FW Configuration.......................................................................................................... 36
◆AMT Configuration................................................................................................................ 39
◆Trusted Computing ................................................................................................................. 41
◆Serial Port Console Redirection.............................................................................................. 42
Chipset............................................................................................................................................... 43
Power................................................................................................................................................. 45
Save & Exit ....................................................................................................................................... 47
4．EACH COMPONENT FUNCTION 48
Power Control Button........................................................................................................................ 48
I/O Definition .................................................................................................................................... 49
◆I/O Connector ......................................................................................................................... 49
◆Power Connector..................................................................................................................... 50
◆LAN RJ45 Connector ............................................................................................................. 50
◆USB 3.2 Gen1 Connector ....................................................................................................... 51
◆USB 2.0 Connector................................................................................................................. 52
◆DisplayPort ............................................................................................................................. 52
◆HDMI Port.............................................................................................................................. 53
◆Serial Port ............................................................................................................................... 54
6．LVDS BACKLIGHT BRIGHTNESS CONTROL 55
◆Set the Level of LVDS Backlight ........................................................................................... 55
◆Read the Level of LVDS Backlight ........................................................................................ 55
7．WATCHDOG TIMER – WDT 56
◆Set WDT Time Unit................................................................................................................ 56
◆Disable WDT.......................................................................................................................... 57
8. LIST OF OPTIONS 58

8CA-RU150R30XG-3965U-01-W10 User’s Manual
1. Introduction
About the Product
This product is an Intel®Kaby Lake-U Processor fanless 304 stainless steel front bezel plus metal back
covered touch panel pc with IP65.
◆Appearance
Front View (CA-RU150)
Back View (CA-RU150)
Side View (CA-RU150)
Up/ Down View (CA-RU150)

CA-RU150R30XG-3965U-01-W10 User’s Manual 9
Wall Mount Type
VESA
Clamp
◆Supported OS
-Windows®10 IoT Enterprise LTSB 2016 64bit.

10 CA-RU150R30XG-3965U-01-W10 User’s Manual
Customer support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
◆Web Site
https://www.contec.com/
■Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
■Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please obtain a
Return Merchandise Authorization number (RMA) from the CONTEC group office where you purchased
before returning any product.
* No product will be accepted by CONTEC group without the RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be
liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.

CA-RU150R30XG-3965U-01-W10 User’s Manual 11
Safety precaution
Understand the following definitions and precautions to use the product safely.
◆Safety information
This document provides safety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels to
operate the equipment safely.
Signal word used to indicate an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Signal word used to indicate a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Signal word used to indicate a potentially hazardous situation which, if not
avoided, could result in minor or moderate injury.
◆Caution on the CA-RU150 Series
Handling Precautions
WARNING
-Always check that the power supply is turned off before connecting or disconnecting power cables.
-Do not modify the product.
-Always turn off the power before inserting or removing circuit boards or cables.
-This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other
applications that require a very high level of reliability. Do not use the product in such applications.
-If using this product in applications where safety is critical such as in railways, automotive, or disaster
prevention or security systems, please contact your retailer.
-Do not attempt to replace the battery as inappropriate battery replacement poses a risk of explosion.
-For battery replacement, contact your retailer as it must be performed as a process of repair.
-When disposing of a used battery, follow the disposal procedures stipulated under the relevant laws and
municipal ordinances. For details on replacing the battery, refer to the appendix.
-This product is connected to a socket-outlet with earthing connection by means of a power cord.
-This product is not suitable for use in locations where children are likely to be present.
DANGER
WARNING
CAUTION

12 CA-RU150R30XG-3965U-01-W10 User’s Manual
CAUTION
-Do not use or store this product in a location exposed to high or low temperature that exceeds range of
specification or susceptible to rapid temperaturechanges.
Example: - Exposure to direct sun
- In the vicinity of a heat source
-Do not use this product in extremely humid or dusty locations. It is extremely dangerous to use this product
with its interior penetrated by water or any other fluid or conductive dust. If this product must be used in
such an environment, install it on a dust-proof control panel, for example.
-Avoid using or storing this product in locations subject to shock or vibration that exceeds range of
specification.
-Do not use this product in the vicinity of devices that generate strong magnetic force or noise. Such
products will cause this product to malfunction.
-Do not use or store this product in the presence ofchemicals.
-To clean this product, wipe it gently with a soft cloth dampened with either water or mild detergent.
Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing or discoloration
of the paint.
-This product’s case may become hot. To avoid being burned, do not touch that section while this product is
in operation or immediately after turning off the power. Avoid installation in a location where people may
come into contact with thatsection.
-Always remove the power cable from the power outlet before mounting or removing an expansion board
and before connecting or disconnecting aconnector.
-To prevent corruption of files, always shutdown the OS before turning off this product.
-CONTEC reserves the right to refuse to service a product modified by the user.
-In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord
immediately and contact your retailer.
-To connect with peripherals, use a grounded, shielded cable.
-Component Life:
(1) Battery---The internal calendar clock and CMOS RAM are backed by a Lithium primary battery. The
backup time at a temperature of 25°C with the power disconnected is 7 years or more.
(2) HDD --- HDD models use the HDD to store the operating system.
*Replacement of expendables is handled as a repair (there will be acharge).
*The service life for consumable parts are reference values and are not guaranteed values.
*This product's specifications allow the device to be rebooted from the BIOS screen during startup. This
has no effect on operation after the OS boots
-Use the included or optional AC adapter. Also, do not use the included AC adapter or AC cable for
anything other than this product. We cannot take any responsibility.

CA-RU150R30XG-3965U-01-W10 User’s Manual 13
2. System Reference
Specification
Table 2.1. Functional specification
Model CA-RU150 Series
LCD
Display Type 15.0”
Panel Ratio 4:3
Max. Resolution 1024 x 768
Max. Colors 16.7M
Luminance 300 cd/m2
Viewing Angle (H/V) 176°/176°
LED Backlight (Hrs) 70,000
Contrast 2500:1
Response Time 21ms
Active Area (HxV) mm 340.1 x 228.1 mm
Bezel & Housing #304 Stain-less front bezel, metal back cover
Touch Screen
Type 5W Resistive
Touch Screen Single touch
System
CPU Intel®Core i5-7300U
Chipset Integrated
System BIOS AMI UEFI BIOS
System memory 1x260 pin DDR4 SO-DIMM 4GB
Graphics Intel®HD Graphics
Display interface HDMI, DP
Storage Slot
1 x 500GB HDD
Ethernet
2x LAN (RJ-45 on rear, 1x Intel
®
I219-LM, 1x Intel
®
I210-AT)
Expansion Slot 2x mPCIe (full size)
- mini-PCIe1 Slot w/NANO SIM-Holder
- mini-PCIe2 Slot w/mSATA
Interface
1 x USB 2.0
4 x USB 3.2 Gen1 (USB3.0)
1 x RS-232/ 422A/ 485 ports
1 x RS-232
1 x DC Jack
Stereo Speaker
2W x 2
Watchdog Timer
Programmable WDT to generate system reset event
Power
Requirement
Power Input 12VDC ± 5%
Power Adapter AC to DC, DC12V / 8A, 96W
Power Consumption
77W

14 CA-RU150R30XG-3965U-01-W10 User’s Manual
Mechanical
Mounting VESA 75x75 mm
Net Weight (kg)
5.0
Dimension (mm) 380 x 280 x 58.1 mm
Certificate RoHS & CE & FCC Class A & UKCA
Table 2.2. Installation Environment Requirements
Model
CA-RU150 Series
Ambient
Specificatio
ns
Operating temperature 0°C - 50°C with Air Flow: 0.5 m/s
Storage temperature
-20 - +50°C (-4°F - +122°F)
Humidity
10% - 95% @40°C non-condensing
Front Panel Protection
IP65 (in front) dust and water resistant

CA-RU150R30XG-3965U-01-W10 User’s Manual 15
Physical dimensions
CA-RU150 Series
[mm]
Figure 2.1. CA-RU150 Series Dimension

16 CA-RU150R30XG-3965U-01-W10 User’s Manual
3. BIOS setup
Introduction
This chapter discusses American Megatrends’ (AMI) Setup program built into the FLASH ROM BIOS.
The Setup program allows users to modify the basic system configuration. This special information is then
stored in FLASH ROM so that it retains the Setup information when the power is turned off.
The rest of this chapter is intended to guide you through the process of configuring your system using Setup.
Starting Setup
The AMI BIOS is immediately activated when you first power on the computer. The BIOS reads the system
information contained in the FLASH ROM and begins the process of checking out the system and configuring
it. When it finishes, the BIOS will seek an operating system on one of the disks and then launch and turn
control over to the operating system.
While the BIOS is in control, the Setup program can be activated in one of two ways:
1By pressing <Del> or <ESC> immediately after switching the systemon, or
2By pressing the <Del> or <ESC> key when the following message appears briefly at the bottom of the
screen during the POST (Power On Self-Test).
Press <DEL> or <ESC> to enter SETUP.
If the message disappears before you respond and you still wish to enter Setup, restart the system to try again
by turning it OFF then ON on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>,
and <Delete> keys.

CA-RU150R30XG-3965U-01-W10 User’s Manual 17
Using Setup
In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown
keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail
about how to navigate in the Setup program using the keyboard.
Table 3.1. Using Setup
Key Function
Up Arrow
Move to the previous item
Down Arrow Move to the next item
Left Arrow Move to the item on the left (menu bar)
Right Arrow Move to the item on the right (menu bar)
Esc
Main Menu: Quit without saving changes
Submenus: Exit Current page to the next higher-level menu
Move Enter Move to the item you desired
+ key Increase the numeric value or make changes
- key Decrease the numeric value or make changes
F1 key General help on Setup navigation keys
F2 key Load the previous settings
F3 key Load the optimal defaults from the BIOS default table
F4 key Save all the changed settings to the FLASH ROM and exit
◆Getting Help
Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections
for the highlighted item. To exit the Help Window press <Esc> or the F1 key again.
◆In Case of Problems
If you cannot boot the computer after using Setup to change and save system settings, the computer will have
to be repaired. It is safest not to change system settings you do not fully understand. Therefore, it is strongly
recommended that you do not change any of the default settings for the chipset. These defaults have been
selected with enough consideration by the AMI and system manufacturers to ensure maximum performance
and reliability. Even changing the chipset settings slightly can result in an unavoidable need for repairs.
◆A Final Note About Setup
The information in this chapter is subject to change without notice.

18 CA-RU150R30XG-3965U-01-W10 User’s Manual
Main Menu
When the setup program (Aptio Startup Utility) is started, the main menu will be displayed. Navigate through
the various tabs by pressing the right and left arrow keys. (Represented by using CA-RU150P30XG-3965U
model)
Figure 3.1. Main Menu
◆Main
Use this menu for basic system configurations, such as time, date, etc.
◆Advanced
Use this menu to set up the items of special enhanced features.
◆Boot Use
this menu to specify the priority of boot devices.
◆Security
Use this menu to set supervisor and user passwords.
◆Chipset
This menu controls the advanced features of the onboard chipsets.
◆Power
Use this menu to specify your settings for power management.
◆Save & Exit
This menu allows you to load the BIOS default values or factory default settings into the BIOS and exit the
BIOS setup utility with or without change

CA-RU150R30XG-3965U-01-W10 User’s Manual 19
Main
Figure 3.2. Main menu
◆System Date
This setting allows you to set the system date. The date format is <Day>, <Month> <Date> <Year>.
◆System Time
This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>.
◆SATA Mode Selection
Table 3.2. SATA Mode Selection
Item
Option
Description
SATA Mode Selection AHCI
RAID

20 CA-RU150R30XG-3965U-01-W10 User’s Manual
Advanced
Figure 3.3. Advanced Manu
◆Full Screen Logo Display
This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or
system manufacturer’s full-screen logo. When it is enabled, the BIOS will display the full-screen logo during
the boot-up sequence, hiding normal POST messages. When it is disabled, the BIOS will display the normal
POST messages, instead of the full-screen logo.
Please note that enabling this BIOS feature often adds 2-3 seconds of delay to the booting sequence. This delay
ensures that the logo is displayed for an enough time. Therefore, it is recommended that you disable this BIOS
feature for a faster boot-up time.
◆Bootup NumLock State
This setting is to set the Num Lock status when the system is powered on. Setting to [On] will turn on the Num
Lock key when the system is powered on. Setting to [Off] will allow users to use the arrow keys on the
numeric keypad.
◆Option ROM Messages
This item is used to determine the display mode when an optional ROM is initialized during POST. When set
to [Force BIOS], the display mode used by AMI BIOS is used. Select [Keep Current] if you want to use the
display mode of optional ROM.
