TPMS SE TOOL
User Guide
1
User Guide
AUTODIAGNOS™ TPMS SE TOOL
1. SPECIFICATIONS
Battery Type
:
Rechargeable Lithium-Ion
Battery Life
:
Approximately 300 activations per full charge.
Dimensions (Max. L,W,D)
:
7.9" x 4.7" x 1.6" (20.0 cm x 12.0 cm x 4.0 cm).
Case Material
:
High Impact ABS.
Response Frequency
:
Main frequencies: 315 MHz and 433.92 MHz (supporting
most specific frequencies).
Low Battery Indication
:
LCD bar graph display.
Weight
:
1.37 lbs.
Temperature
:
Operating: -4°F to 131°F (-20°C to +55°C).
Storage: -40°F to 140°F (-40°C to +60°C).
Operating Altitude
:
Up to 6560 ft (2000 m).
Product content:
• TPMS SE Tool
• USB cable
• Charger with Universal Adapters
• OBD Quick Connect Cable
• Quickstart Guide

TPMS SE TOOL
User Guide
2
2. IMPORTANT SAFETY INSTRUCTIONS
Do not discard. Retain for future reference.
This device complies with:
• Part 15 of the FCC Rules (FCC ID: 2ABSJ-VT46)
• CE / CEM standards
• ROHS standards
Operation is subject to the following two conditions:
1. This device will not cause harmful interference, and
2. This device will accept any interference received, including interference thatmay cause undesired or
improper operation.
WARNING
: This product emits electromagnetic and electronically generated
waves that may interfere with the safe operation of
pacemakers
.
Individuals that have pacemakers should never use this product.
WARNING:
Do not use on live electrical circuits.
Please read instructions before use.
Wear safety goggles. (User and bystanders).
Risk of entanglement.
Read the Warranty, Safety and recycling information at the end of this user guide.

TPMS SE TOOL
User Guide
3
3. CAUTIONS
PLEASE READ THESE INSTRUCTIONS BEFORE USE
Your Tire Pressure Monitoring (TPM) tool has been designed to be durable, safe, and reliable
when properly used.
All
TPMS TOOLS
are intended for use only by qualified and trained automotive technicians
or in a light industrial repair shop environment. Please read all instructions below before use.
Always follow these safety instructions. If you have any questions pertaining to the safe or
reliable use of this tool, please call your localdealer.
1.
Read All Instructions
All warnings on the tool and in this manual should be adhered to. All operating
instructions should be followed.
2.
Retain Instructions
The safety and operating instructions should be retained for future reference.
3.
Heed Warnings
Users and bystanders must wear safety goggles and must-read instructions before use.
Do not use on live electrical circuits, risk of entanglement.
4.
Cleaning
Clean with a soft dry cloth, or if necessary, a soft damp cloth. Do not use any harsh
chemical solvents such as acetone, thinner, brake cleaner, alcohol, etc. as this may
damage the plastic surface.
5.
Water & Moisture
Do not use this tool where contact or immersion in water is a possibility. Never spill
liquid of any kind onto the tool.
6.
Storage
Do not use or store the tool in an area where it is exposed to direct sunlight or excessive
moisture.
7.
Usage
To reduce the risk of fire, do not operate the tool in the vicinity of open containers or
flammable liquids. Do not use if the potential for explosive gas or vapors exists. Keep the
tool away from heat generating sources. Do not operate the tool with the battery cover
removed.

TPMS SE TOOL
User Guide
4
4. TOOL OVERVIEW
4.1.
LIGHTS
4.2.
CONNECTORS
BOTTOM OBDII Quick
Connect Port
SIDE
USB connector for
battery charge and
software update.
Trigger
light
Result light
"
Fail
"
Result light
"
Pass
"
Battery status
Keypad
Display screen
Antenna

TPMS SE TOOL
User Guide
5
5.
FUNCTION KEYS
Power ON/OFF switch
Test or trigger sensor.
Next, continue or confirm.
Cancel, previous step.
Navigate to select "
up
”.
Navigate to select “
down
”.
Navigate to select “
left
”.
Navigate to select “
right
”.

TPMS SE TOOL
User Guide
6
6.
POWER ON
Press to turnon device,
The tool will display the boot logo.
The
MAIN MENU
will then be displayed

TPMS SE TOOL
User Guide
7
7.
OPERATING INSTRUCTIONS
7.1.
TPMS TOOLOVERVIEW
Note
: With most vehicles, when the vehicle is in “learn
mode” the vehicle will also confirm that the TPM sensor
has communicated with the ECM with a series of horn
chirps.
Recommended Vehicle Service Procedure
Read Sensor Test
Before servicing the tires/wheels using the
TPMS TOOL
,
trigger each of the vehicle's tire pressure sensors to make sure
they are working properly.
This will eliminate accountability associated with replacing
previously damaged or defective sensors. Triggering sensors will
not change the vehicle settings because the vehicle has yet to be
put into learn/retraining mode.
Triggering sensors allows damaged or defective sensors to be be identified. Some vehicles do not
report a damaged or defective sensor condition on the instrument cluster for up to 20 minutes.
Note
: If the sensors do not trigger, please refer to the Troubleshooting section of this Guide.
For vehicles that require relearning, please see Section 2.0 below
Learning TPMS Systems
With the vehicle in learn mode, begin by triggering the driver's front
left (LF) wheel sensor.
Note:
Many vehicles will provide an audible beep confirming that
the sensor ID has been learned by the vehicle on board computer.
The communication between the sensor and the on-board TPM module will
also confirmed on LCD display of the
TOOL
by showing the sensor ID
Trigger all wheel sensors in a clockwise rotation, until all the vehicle sensors
have been retrained. (RF then RR, ending with LR)
After triggering the driver's rear wheel sensor, some vehicles horns will
chirp twice, indicating that the TPM system has been relearned.
1 Start FL
4 End RL
Fig. 5
FR 2
RR 3
For vehicles that do not require relearning we recommend you trigger each wheel sensor, one final time, to
make sure they are working correctly prior to releasing the vehicle to the customer.

TPMS SE TOOL
User Guide
8
REDI UNLOCK
Select REDI Unlock.
Select Part Number
While holding the
sensor above the tool’s
antenna, press the
trigger button to unlock
Once unlocked, the REDI
Sensor is now ready for use
= Continue
= Unlock

TPMS SE TOOL
User Guide
9
TPMS
IMPORTANT:
Vehicle specific information in this manual is used as an example and may not represent specific instructions a
specific make and model may require. When performing various functions with the tool, it is important to refer
to the on-screen prompts and/or repair manual information.
1.
TPMS
= Continue
= Previous
1.1.
SELECT CAR MANUFACTURER
= Continue
= Previous
1.2.
SELECT CAR MODEL
= Continue
= Previous

TPMS SE TOOL
User Guide
10
1.3.
SELECT YEAR
1.4.
SERVICE
Select Service
= Continue
= Previous
= continue
= Previous

TPMS SE TOOL
User Guide
11
To change selected tire
RIGHT FRONT
RIGHT REAR
LEFT REAR
Trigger all wheels.
= Continue = Previous
Possible Reasons that the tool does not detect a sensor:
1. Tool Antenna is not positioned correctly on the tire
2. Sensor battery has expired
3. Wrong sensor part number was installed
4. Technician has removed sensor from the tire
5. Aftermarket sensor was not programmed with tool
6. Indirect system works off ABS wheel sensor speed
2.
SERVICE TPMS
Servicing TPM System to ensure the dash light is not illuminated maybe required when
adding air, rotating tires, or replacing a sensor.
Servicing may require the use of the TPMS trigger tool and a device to access the OBDII
Port. Two methods are shown
1. TPMS tool w/optional OBDII Module
2. TPMS tool with an existing diagnostic scan tool.

TPMS SE TOOL
User Guide
12
This section details how to relearn sensors to the ECU.
Select "
SERVICE
"
Select "
Relearn
"
Select either Manual or OBDII.
= continue
= Previous
= continue
= Previous
= continue
= Previous

TPMS SE TOOL
User Guide
13
2.1
SERVICE TPMS
MANUAL OR STATIONARY RELEARN SYSTEMS
Use Tool and follow instructions on the screen.

TPMS SE TOOL
User Guide
14
2.2
SERVICE TPMS (OBDII)
OBDII RELEARN
1. Start left front wheel and trigger sensor
2. Next right front wheel and trigger thesensor
3. Next right rear wheel and trigger the sensor
4. Next left rear wheel and trigger thesensor
5. OBDII
11ACE57
31.4 PSI
315 MHz
11AC923
31.1 PSI
315 MHz
11AD0FA
30.4 PSI
315 MHz
F198d
37.6 PSI
315 MHz
6. Examples of 5th Wheel (spare tire) option depending on the make/model/year; Toyota RAV 4,
Tundra,
Land Rover, and many Jeeps. Visually inspect the spare, test sensor with TPMS tool, or reference
the VIN number with new car dealer. Relearn will fail if spare ID number is not registered; a DTC
code may be set.

TPMS SE TOOL
User Guide
15
3. PROGRAM SENSOR
This section is to recover a sensor ID in order to enter it in the spare blank sensor. If the "old"
sensor can be read, use the "
COPY
" function to recover the ID. If it cannot be read, use the
"
CREATE
" function to create a randomized ID.
This section details how to relearn the sensor to the ECU with the OBD-II port or to have the
part # lookup for all the sensors available for the vehicle.
= continue
= previous
Select "
PROGRAM
" menu.
The tool will display compatible part number(s) for the selected vehicle.
= continue
= previous

TPMS SE TOOL
User Guide
16
3.1 "COPY ORIGINAL SENSOR"
Wait a few seconds.
ID of the old sensor is
displayed.
= continue
= Previous
To trigger the
original sensor
= continue
= Previous

TPMS SE TOOL
User Guide
17
Hold the new
programmable sensor
near the device antenna.
Wait a few seconds.
The data is successfully
uploaded to the sensor.
To upload data
to the blank
sensor.
= continue

TPMS SE TOOL
User Guide
18
3.2.
"CREATE ID”
Hold the new
programmable sensor
near the device antenna.
Wait a few seconds.
The data is successfully
uploaded to the sensor.
= continue
= Previous
To upload data
to the blank
sensor.
= continue

TPMS SE TOOL
User Guide
19
4. PLACARD ADJUSTMENT
For adjusting internal placard values when changing tire types or load sizes.
Select Placard
Please read
disclaimer
regarding
proper
placard
procedures
Connect the
OBD Cable to
the tool and
vehicle, and
allow the tool
to capture the
internal values
Note
: Turn the
ignition
ON
,
Keep the
engine
OFF
.
= Continue
= Previous
= Continue
= Previous

TPMS SE TOOL
User Guide
20
The tool will display the current stored values.
Select the axle you wish to
change, then press OK
Change the PSI
value using the arrow keys. Select OK
Once updated, use
the trigger button to
write thenew values to
the ECU
= Continue
= Previous
