ContiPressureCheck™
The tire pressure monitoring system
GB
User Manual

2
1 General.................................................................................................................................6
1.1 Information on this User Manual ................................................................................ 6
1.2 Liability disclaimer ............................................................................................................ 6
1.3 Copyright ............................................................................................................................... 6
1.4 Abbreviations....................................................................................................................... 7
1.5 Explanation of symbols................................................................................................... 7
1.6 Warnings ................................................................................................................................ 8
1.7 Manufacturer's address................................................................................................... 9
1.8 After-sales service ............................................................................................................. 9
2 Technical data Display..................................................................................................9
3 Safety.................................................................................................................................10
3.1 Intended use.......................................................................................................................10
3.2 General safety instructions .........................................................................................11
3.3 Particular hazards............................................................................................................12
4 Tool overview ................................................................................................................13
4.1 Operating keys ..................................................................................................................13
5 Mounting the Display.................................................................................................14
5.1 Display Holder with suction caps for attaching to the windshield ...........15
5.2 Display Holder for screwing to the dashboard...................................................15
6 Commissioning .............................................................................................................17
6.1 Start screen.........................................................................................................................17
6.2 Automatic Language Query........................................................................................17
6.2.1 Setting the language for Automatic Language Query .....................18
6.2.2 Activate/deactivate Automatic Language Query ...............................18
Table of Contents
ContiPressureCheckTM

3
7 Operation.........................................................................................................................19
7.1 Safety instructions...........................................................................................................19
7.2 Setup menu.........................................................................................................................20
7.2.1 Open the settings menu .................................................................................20
7.2.2 Navigating the settings menu......................................................................20
7.2.3 Day/night mode ..................................................................................................21
7.2.4 Switching the buzzer ON/OFF......................................................................22
7.2.5 Display brightness ............................................................................................23
7.2.6 Selecting the language....................................................................................24
7.2.7 Selecting units.....................................................................................................25
7.3 Switching between the vehicle view and
the settings menu ............................................................................................................26
7.4 Vehicle view: Standard screen to monitor pressure/temperature............27
7.5 Operating without automatic trailer detection..................................................28
7.5.1 General....................................................................................................................28
7.5.2 Start screen for pressure/temperature monitoring...........................29
7.5.3 Switching between pressure and temperature display ...................30
7.5.4 Warning message overview..........................................................................30
7.5.5 Low-level warning messages .......................................................................32
7.5.5.1 Tire Sensor defect...........................................................................32
7.5.5.2 No signal..............................................................................................33
7.5.5.3 Temperature......................................................................................34
7.5.5.4 Low pressure.....................................................................................34
7.5.6 High-level warning messages ......................................................................35
7.5.6.1 Check Sensor ....................................................................................35
7.5.6.2 Very low pressure ...........................................................................36
7.5.6.3 Fast pressure loss............................................................................37
7.5.7 Multiple warnings ..............................................................................................38
Table of Contents

4
7.6 Operating with Automatic Trailer Learning (ATL*)...........................................40
7.6.1 General....................................................................................................................40
7.6.2 Start screen for automatic trailer learning.............................................42
7.6.2.1 No trailers found with Tire Sensors ........................................43
7.6.2.2 Special cases with automatic trailer learning....................44
7.6.3 Warning messages in the case of automatic trailer detection .....48
7.6.4 Multiple warnings for trailer tires
in the case of automatic trailer detection ..............................................49
7.6.5 Multiple warnings for truck and trailer tires
in the case of automatic trailer detection ..............................................51
7.6.6 Automatic Trailer Learning with Surrounding Observer (SO*).....52
7.7 Automatic Single Wheel Exchange (SWE) ............................................................54
8 Error messages .............................................................................................................55
9 Pressure Check Indicator .........................................................................................56
9.1 Pressure Check Indicator operating modes........................................................56
9.2 Readjusting the Pressure Check Indicator...........................................................59
10 Cleaning the Display...................................................................................................60
Table of Contents

5
11 Maintenance...................................................................................................................61
12 Disposal ............................................................................................................................61
12.1 General instruction..........................................................................................................61
12.2 Tire Sensor ..........................................................................................................................62
12.3 Electrical/electronic components ............................................................................62
12.4 CPC collection point........................................................................................................62
13 Declaration of Conformity.......................................................................................63
14 Certiications..................................................................................................................64
14.1 Radio permit.......................................................................................................................64
14.2 General Operating Permit ............................................................................................64
14.3 ADR.........................................................................................................................................64
15 Index ..................................................................................................................................65
Table of Contents

6
General
1 General
1.1 Information on this User Manual
The information listed here serves to become familiar with the Display
and the ContiPressureCheckTM system and make full use of its functions.
The User Manual must always be in the immediate vicinity of the Display.
It must be read and observed by everyone who is involved with
●installation,
●startup and
●operation
of the Display and of the ContiPressureCheckTM system.
1.2 Liability disclaimer
The manufacturer assumes no liability for damage and operational faults
resulting from:
■failure to observe this User Manual,
■use for other than the intended purpose,
■faulty installation,
■technical changes and modiications,
■misuse,
■failure to maintain in accordance with manufacturer instructions.
1.3 Copyright
This User Manual is copyrighted.
This User Manual may not be duplicated either wholly or in part without
the express permission of Continental Reifen Deutschland GmbH.

7
General
1.4 Abbreviations
The following abbreviations are used in this User Manual:
Abbreviation Meaning
ATL* Auto Trailer Learning
CPC ContiPressureCheckTM
SO* Surrounding Observer
SWE Single Wheel Exchange
HHT Hand-Held Tool
* Optional functions that are not activated for all CPC systems.
1.5 Explanation of symbols
Warnings in this User Manual are also indicated by warning symbols.
The following warning symbols are used in this User Manual:
Symbol Meaning
General warning
General instructions and useful suggestions on
handling
Note on observing environmental regulations for
disposal
Electric/electronic components with this symbol
may not be disposed of in the normal household
waste.

8
General
1.6 Warnings
In the current User Manual, the following warnings are used:
WARNING
A warning of this hazard level indicates a hazardous
situation.
If the hazardous situation is not avoided, it can result in
serious injuries.
►Follow the instructions in this warning to avoid serious
injuries to persons.
ATTENTION
A warning of this hazard level indicates potential dam-
age to equipment.
If the situation is not avoided, it can result in equipment
damage.
►Follow the instructions in this warning to avoid the
equipment damage.
NOTE
►A note draws attention to additional information of
importance for further work or which simpliies the
work step described.

9
Technical data Display
1.7 Manufacturer's address
Continental Reifen Deutschland GmbH
Büttnerstraße 25
30165 Hannover
Germany
www.contipressurecheck.com
1.8 After-sales service
In the case of technical questions on the Display, Pressure Check Indica-
tor or the entire ContiPressureCheckTM system, please contact your CPC
supplier or the authorized garage that installed the CPC system.
2 Technical data Display
Dimensions (L x W x H) 117 x 107 x 40
4.60 x 4.21 x 1.57
mm
inches
Weight 240
8.47
grams
oz
Supply voltage 12/24 Volts
Minimum mating cycles:
- diagnosis plug
- connecting plug
100
10
cycles
cycles
Minimum mating cycles between
Display and Display Holder 5 cycles
Operating temperature -40 to 85
-40 to 185
°C
°F
Readability of the LCD (screen)
without restrictions
-20 to 80
-4 to 167
°C
°F

10
Safety
3 Safety
3.1 Intended use
The Display is only intended for displaying the data detected by the CPC
system (air pressure and temperature of the tires) as well as warning
messages.
The Pressure Check Indicator installed in the trailer is intended to be
used for displaying the status of the CPC system at the trailer using light
signals.
Use for any other purpose is not considered as intended use.
WARNING
Hazard from use for other than the intended purpose!
Any use other than and/or going beyond the intended
use of the CPC system can lead to damage and serious
injuries.
►Use the system only for its intended purpose.
No claims of any kind will be accepted for damage resulting from use for
other than the intended purpose.
In such cases, the risk must be borne solely by the user.

11
Safety
3.2 General safety instructions
Observe the following general safety instructions to ensure safe handling
of the CPC system:
■The operator must ensure that tires in which Tire Sensors are
installed, are only operated in vehicles, in which monitoring is
ensured by the CPC system.
■If continuous technical monitoring is not ensured, the operator
must make sure that the condition of the Tire Sensor is checked
regularly, at the latest after 20 000 km (12 425 miles).
■In the case of continued use of the tires on other vehicles where
monitoring is not ensured, the Tire Sensors must irst be removed
from the tires.
■The operator of the vehicle must ensure that the CPC system is
properly installed and put into operation. This includes setting the
nominal pressures recommended in the tire guide, correct assign-
ment of the Tire Sensors to the wheel position, etc.
Observe the following general safety instructions to ensure safe handling
of the Display:
■Check the Display for visible damage before using. Do not put a
damaged Display into operation.
■Never open the housing of the Display.
■The Display is designed for a temperature range from -40 °C to
85 °C (-40 to 185 °F) however, temporary Display errors may occur
at temperatures lower than -20 °C (-4 °F) or above 80 °C (167 °F).
■Protect the Display against moisture and penetration by liquids.

12
Safety
3.3 Particular hazards
Special characteristic in the case of vehicles for hazardous substances
(ADR):
■If the CPC system is installed in a vehicle for hazardous materials
(ADR) and if the CPC system remains switched on, although the
vehicle’s ignition is switched o, it is possible that sparks, other
ignition sources or similar could lead to a reaction with the hazard-
ous material in the event of a fault. This can result in accidents and
serious injuries.
– For this reason, when parking vehicles for hazardous substances,
it is absolutely necessary to disconnect the CPC system from the
power supply (normally via the battery main switch)

13
Tool overview
4 Tool overview
4.1 Operating keys
12 3 4
Button Symbol Task
1SET Switch between vehicle view and settings
2Navigation between menu items and warning
messages
3OK Conirmation of the selected menu item
4Switch between pressure or temperature display
in the vehicle view

14
Mounting the Display
5 Mounting the Display
WARNING
Risk of injury!
The risk of injury cannot be ruled out, if the installation
instructions are not followed.
►Do not mount the Display in front of the driver and the
front passenger(s).
►Do not mount the Display in the impact zone of the
body or the head and not in the airbag area (driver &
front passenger).
NOTE
The vehicle driver must have a suicient ield of view
under all operating and weather conditions.
►Mount the Display so that the driver’s ield of view is
not restricted.

15
Mounting the Display
5.1 Display Holder with suction caps for attaching to the
windshield
To attach the Display to the windshield use the Display Holder with the
suction caps.
Connect the Display with the Display Holder supplied. Make sure
that the Display is completely engaged and locked into the Holder.
Choose a suitable location on the windshield. Make sure that you
install in a location which would avoid glare due to sunlight.
Loose the screws to adjust the Display, and tighten them when the
desired position is set.
NOTE
►The Display must always be clearly visible to the
driver.
National regulations!
►If national regulations stipulate that devices may not
be attached to the windshield, mount the Display
with the holder according to chapter „5.2 Display
Holder for screwing to the dashboard“
5.2 Display Holder for screwing to the dashboard
To mount the Display to the dashboard, glue and screw the Display Hold-
er to the dashboard.
Connect the display with the Display Holder supplied.
Choose a suitable location on the dashboard. Make sure that you
install in a location which would avoid glare due to sunlight.
ATTENTION
Damage!
In the case of improper screwing of the Display Holder, it
is possible to damage components or cables in the dash-
board of the vehicle:
►Before screwing the Display Holder tight, make sure
that components or cables cannot be damaged when
ixing the Display Holder.

16
Mounting the Display
Remove the Display from the Holder.
Pull of the protective foil of the contact surfaces on the holder and
glue the holder to the desired location.
Also screw the holder onto the dashboard with the 2 screws sup-
plied.
Connect the Display with the Display Holder. Make sure that the
Display is completely engaged and locked into the Holder.
Adjust the Display by turning it in the desired direction.
The Display must always be clearly visible to the driver.
NOTE
It is recommended to ix the Display by gluing and
screwing!
►The adhesive foil compensates unevenness between
the Holder and installation location and ensures a
tighter it.
►The screws secure the Holder against vibration during
operation and therefore against unintentional loosen-
ing.
NOTE
Dismantling the Display Holder!
►After dismantling the Display Holder, two holes remain
in the dashboard. In addition, residual adhesive could
remain on the dashboard.

17
Commissioning
6 Commissioning
6.1 Start screen
CONTINENTAL
The start screen is displayed for
3 seconds after ignition.
6.2 Automatic Language Query
NOTE
►By default, the automatic language query is activated
for initial startup
■If the Automatic Language Query is activated, the display switch-
es from the start screen to the settings - Language view, see
chapter „6.2.1 Setting the language for Automatic Language
Query“.
If no button is pressed within 15 seconds, the display switches
automatically to the vehicle view.
■If the Automatic Language Query is deactivated, the display im-
mediately switches from the start screen to the vehicle view.

18
Commissioning
6.2.1 Setting the language for Automatic Language Query
If the Automatic Language Query is activated, the Settings - Language
view appears for 15 seconds.
Autostart ON
Česky
Deutsch
English
Español
Français
Italiano
Press the -button to
select a language (the
selected language is
highlighted).
Press the OK-button to
conirm the language
selection.
The display switches then
to the vehicle view.
6.2.2 Activate/deactivate Automatic Language Query
Press the SET-button, the Setup view is displayed.
Press the -button to select the "Language" menu item.
Press the OK-button to conirm.
Press the -button to select the "Autostart" menu item.
Select "Autostart ON“ or "Autostart OFF" with the OK-button.

19
Operation
7 Operation
7.1 Safety instructions
WARNING
Danger of accident!
Operating the Display while driving can lead to accidents.
►Do not operate the Display while driving.
►View the screen, only if the traic situation allows.
An incorrectly or carelessly mounted Display can impair
driving safety!
►Before each journey, check the seating of the Display
and stability of the holder.
■The ContiPressureCheckTM system supports monitoring of tire
pressure. The responsibility for the correct pressure lies with the
driver.
■Correct the tire pressure only when the tire temperature corre-
sponds to the ambient temperature. Otherwise there is a risk that
the wrong pressure is set.
■The ContiPressureCheckTM system is a comfort system. It cannot
be completely ruled out in the event of adverse conditions that the
CPC system does not display any warnings or conversely, that the
CPC system displays an incorrect warning.
NOTE
►Use of snow chains can impair the transmission power
of the Tire Sensors in the corresponding tires. This can
lead to a delay in transmitting the tire pressures and
the resulting warning messages for those tires.

20
Operation
7.2 Setup menu
The following functions can be set in the settings menu:
→
English
(100%)
bar / °C
Day/night mode
Buzzer ON/OFF
Display brightness
Language selection and
Automatic Language Query
on/o
Selection of units
7.2.1 Open the settings menu
Press the SET-button to open the settings menu.
7.2.2 Navigating the settings menu
Button Task
Select between the menu items, selection is highlighted
OK Change settings or open submenus
SET Return to vehicle view
If no button is pressed within 30 seconds, the display switches auto-
matically to the vehicle view
