Continental Refrigerator ContiCormect Live User manual

ContiConnect™Live
The truck and trailer telematic solution for live tire monitoring
GB /USA Installation Manual

2
ContiConnectTM Live
Table of Contents
1 General..............................................................................................................................4
1.1 Version note....................................................................................................................... 4
1.2 Information on this Installation Manual................................................................ 4
1.3 Liability disclaimer.......................................................................................................... 5
1.4 Explanation of symbols ................................................................................................ 5
1.5 Warnings.............................................................................................................................. 7
1.6 Copyright............................................................................................................................. 8
1.7 Warranty terms................................................................................................................. 8
1.8 Manufacturer's address ................................................................................................ 8
1.9 After-sales service........................................................................................................... 8
2 Safety .................................................................................................................................9
2.1 General ................................................................................................................................. 9
2.2 Prohibited modiications.............................................................................................. 9
2.3 Intended use ...................................................................................................................... 9
2.4 Qualiications for installation...................................................................................10
2.5 Personal protective equipment ..............................................................................11
3 Technical data.............................................................................................................12
3.1 Tire sensor ........................................................................................................................12
3.2 In-Cabin Unit (Main control unit)............................................................................14
3.3 Enabler Unit (Receiver unit)......................................................................................16
3.4 Trailer Unit (Unit at the trailer) ................................................................................18
4 Installation....................................................................................................................21
4.1 Scope of supply ..............................................................................................................21
4.2 Disposal of the packaging materials ....................................................................21
4.3 General notes on damage prevention .................................................................21
4.4 Recommended installation sequence .................................................................22
4.5 Installation of the tire sensors.................................................................................23
4.6 Typical conigurations.................................................................................................23
4.7 Initialization using Hand-Held Tool .......................................................................25
4.8 Installation of the In-Cabin Unit..............................................................................26
4.9 Installation of the Enabler Unit ...............................................................................31
4.10 Installation of the Trailer Unit ..................................................................................37

3
Table of Contents
4.11 Checks after installation.............................................................................................42
5 Activation of the system coniguration ..........................................................43
6 Information on the system....................................................................................44
6.1 General ...............................................................................................................................44
6.2 Operation ..........................................................................................................................44
7 Troubleshooting.........................................................................................................45
8 Dismantling and Disposal......................................................................................46
8.1 Dismantling ......................................................................................................................46
8.2 Disposal..............................................................................................................................48
9 Declaration of Conformity ....................................................................................50
10 Certiications ...............................................................................................................51
10.1 Radio permit ....................................................................................................................51
10.2 General Operating Permit..........................................................................................51

4
General
1 General
1.1 Version note
In case of doubt, the English original version of the “Installa-
tion manual” applies.
1.2 Information on this Installation Manual
This Installation Manual is intended for qualiied technicians
with technical know-how in vehicle electrics and tire itting.
Knowledge of its contents enables the system to be installed
on commercial vehicles.
This Installation Manual is a crucial aid to the successful
and safe installation of the system. It contains important
instructions on installing and operating the system correctly
and safely. Observation of its contents helps avoid dangers,
increase the reliability and service life of the system and
maintain the system warranty.
The current version of the installation manual is available
for everyone online (https://www.continental-tires.com/
transport/tire-monitoring/conticonnect/downloads). It must
be read and observed by everyone who is involved with
●Installation,
●Activation,
●Operation
●and/or Diagnosis
of the system.
Observe the instructions contained – in particular the safety
instructions.

5
General
1.3 Liability disclaimer
The manufacturer assumes no liability for damage and
operational faults resulting from:
■Failure to observe this Installation Manual
■Used for other than the intended purpose
■Installation by unqualiied or insuiciently qualiied
personnel
■Faulty installation
■Use of other than original spare parts and accessories
■Technical changes and modiications
1.4 Explanation of symbols
Warnings are additionally identiied in this Installation
Manual by warning symbols. The following warning symbols
are used in this Installation Manual:
Symbol Meaning
General warning
Electric shock hazard
Special instructions on safe working
General instructions and useful sug-
gestions on handling
Note on observing environmental
regulations for disposal
Electric/electronic components with
this symbol may not be disposed of in
the normal household waste.

6
General
1.4.1 Abbreviations
The following abbreviations are used in this Installation
Manual:
Abbreviation Meaning
ATO Assemble-to-order
BT Bluetooth
CAN
(Controller Area Network)
Data bus system for communication
between vehicle systems
DTCO Digital Tachograph
FMS Fleet Management System
GND Ground
Battery voltage (negative pole / chassis)
GPS Global Positioning System
GSM Global System for Mobile Communications
HHT Hand-Held Tool
IGN Ignition
TPMS Tire Pressure Monitoring System
Truck/
UV
Heavy Goods Vehicles/
Utility vehicle
OBD On Board Diagnosis
RF Radio Frequency
RSSI Transmission power of the tire sensors
(Received Signal Strength Indicator)
Sensor ID Sensor identiication number
SIM Subscriber Identity Module
+ VDC Battery voltage (positive pole)

7
General
1.5 Warnings
The following warnings are used in this Installation Manual:
WARNING
Severe injuries!
A warning of this hazard level indicates a
possible situation that could lead to death or
irreversible injuries.
►Follow the instructions in this warning.
CAUTION
Minor injuries!
A warning of this hazard level indicates a
possible situation that could lead to reversi-
ble injuries.
►Follow the instructions in this warning.
ATTENTION
Damage to property.
A warning of this hazard level indicates a
situation that could lead to damage to the
equipment.
►Follow the instructions in this warning.
SAFETY INSTRUCTIONS
Instructions on safe working
These instructions include important infor-
mation and instructions on safe working
during the following actions.
►Follow the instructions in this warning to
avoid accidents and injury.
NOTE
A note contains additional information that is
important for further processing or for simpli-
fying the procedure step explained.

8
General
1.6 Copyright
This Installation Manual and all documents supplied with
this system are protected by copyright.
These documents may not be duplicated either wholly or in
part without the express permission of Continental Reifen
Deutschland GmbH.
1.7 Warranty terms
The respective relevant "Continental AG terms and condi-
tions" apply with the exception of possible dierent contrac-
tual agreements.
The latest version can be obtained via your ContiCon-
nect™ Live supplier.
1.8 Manufacturer's address
Continental Reifen Deutschland GmbH
Vahrenwalder Strasse 9
30165 Hannover
Germany
www.conticonnect.com
1.9 After-sales service
In the case of technical questions on the system, please
contact your ContiConnect™ Live supplier or the authorized
garage that installed the system.

9
Safety
2 Safety
2.1 General
In addition to the safety instructions speciied in these
installation instructions, the “General Safety Notes” (arti-
cle no.: 17342240000) belonging to the product must be
observed.
Hazards that could occur during a particular action are
described before the instructions for each step.
Failure to observe the “General Safety Notes” and procedur-
al instructions speciied in these installation instructions can
lead to considerable hazards.
2.2 Prohibited modiications
All modiications and changes to the system are prohibited.
The manufacturer assumes no liability for any resulting
damage.
In the event that conversions or modiications to the system
should become necessary, contact the manufacturer.
2.3 Intended use
This ContiConnect™ Live solution is only intended to,
■determine the condition of each tire (e.g. tire pressure or
tire inner temperature),
■determine the vehicle position and current state,
■transmit the collected data to an external evaluation unit
via GSM.

10
Safety
This solution may only be used for its intended purpose
within the limits stipulated in the technical data.
Use for any other purpose is not considered as intended use.
Operation of the solution in a faulty condition is prohibited.
No claims of any kind will be accepted for damage resulting
from use for other than the intended purpose.
The risks associated with such improper use shall be borne
solely by the user.
2.3.1 Use of the tire sensors
Even if continuous technical monitoring is ensured, the op-
erator must make sure that the condition of the tire sensor
is checked regularly, at the latest after 20 000 km
(12 425 miles) or after 6 months.
In the case of continued use of the tires on other vehicles
where monitoring is not ensured, the tire sensors must irst
be removed from the tires.
2.4 Qualiications for installation
The following qualiications are speciied in this Installation
Manual:
■Qualiied sta
is deemed capable of independently carrying out the
work assigned to them and of recognizing and avoiding
possible dangers due to their technical training,
know-how and experience (tire mounting and repair,
mechanical and electrical automotive experience) and
their knowledge of the relevant regulations.
The solution may only be installed by persons who have
been trained for this work and who have technical know-
how of vehicle electronics and tire itting.

11
Safety
2.5 Personal protective equipment
Wear the following protective equipment during installation:
Symbol Meaning
Wear protective goggles.
Wear protective gloves.
Wear safety shoes.

12
Technical data
3 Technical data
NOTE
►All components to be installed on the
vehicle are designed for an operating tem-
perature range of -20 °C to 55 °C (-4 °F to
131 °F). When other temperature ranges
are applicable, it is mentioned in the below
tables.
3.1 Tire sensor
3.1.1 Generation 1
Dimensions (L x W x H) 38 x 28 x 22
1.5 x 1.1 x 0.87
mm
inches
Weight 26
0.92
g
oz
Cover color black
Transmission frequency 433.92 MHz
Reception frequency 125 kHz
Typical service life* of the
permanently installed battery
approx.
6
or
600 000
372 820
years
km
miles
Temperature measuring range -40 to 120
-40 to 248
°C
°F
Pressure measuring range
(rel.)
0 to 12
0 to 173
bar
psi
* Constantly high tire inside temperatures (caused for example by high
ambient temperature, low tire pressure, etc.) can lead to a decrease of the
battery service life.
Technical Data - Tire sensor

13
Technical data
3.1.2 Generation 2
Dimensions (L x W x H) 38 x 28 x 22
1.5 x 1.1 x 0.87
mm
inches
Weight 26
0.92
g
oz
Cover color orange
Transmission frequency 433.92 MHz
Reception frequency 125 kHz
Bluetooth
(Active only at standstill) 2,4 GHz
Typical service life* of the
permanently installed battery
approx.
4
or
600 000
372 820
years
km
miles
Measuring ranges
– Temperature -40 to 120
-40 to 248
°C
°F
– Pressure (rel.) 0 to 12
0 to 173
bar
psi
Temperature ranges
– Tire sensor -40 to 120
-40 to 248
°C
°F
– Bluetooth -10 to 120
+14 to 221
°C
°F
* The typical service life applies to a long-distance vehicle operated at mod-
erate outside temperatures and with correct tire pressure.
It is assumed that the user does not connect to the tire sensor via Bluetooth
(pairing).
Deviations from these general conditions can lead to a shortening of the
typical service life.
Exemplary variations, but not exhaustively limited, are:
– high internal tire temperatures (Caused by e.g. high ambient temperatures,
lower tire pressure, overload, etc.)
– regular connections via Bluetooth
– high proportion of standstill phases/low speed
– high proportion of Stop-and-Go phases (urban traic)
Technical Data - Tire sensor

14
Technical data
3.2 In-Cabin Unit (Main control unit)
Dimensions (L x W x H) 111 x 64 x 31
4.4 x 2.5 x 1,22
mm
inches
Weights
– with battery 132
4.66
g
oz
– with battery and bracket 164
5.78
g
oz
Supply voltage 9 to 32 VDC
Supply current (Sleep mode) 7.5 mA
Power consumption
– Operation
(average at 24 V DC) 50 mA
RF frequency 433 MHz
Temperature ranges
– Operation -20 to 60
-4 to 140
°C
°F
– Storage -20 to 85
-4 to 185
°C
°F
– Charging 0 to 45
32 to 113
°C
°F
Backup battery Li-Ion
Technical Data -In-Cabin Unit (Main Control Unit)

15
Technical data
3.2.1 In-Cabin Unit connectors
1 23
1Power Connector J4
2Main Connector J8
3Status LED’s
3.2.2 Pin assignment Power Connector J4 (2x3 Pin)
Pin Signal name Description Wire color
1+ VDC Main power supply red
2Ignition Ignition sense input green
3Analog In3 Analog input 3
(optional) orange
4CAN 0 (H) CAN Bus 0
High signal orange/white
5CAN 0 (L) CAN bus 0
Low signal yellow/white
6GND Battery negative 0V black
3.2.3 Blinking code of the In-Cabin Unit status LED’s
1 Sec 1 Sec 1 Sec
1 Sec
1 Sec 1 Sec 1 Sec
1 Sec
1
2
3
4
1Searching GPS signal
2GPS position established
3Searching GSM signal
4GSM connection established
13
6 4
Technical Data - In-Cabin Unit (Main Control Unit)

16
Technical data
3.3 Enabler Unit (Receiver unit)
Dimensions (L x W x H) 155.4 x 110 x 39
6.1 x 4.33 x 1.54
mm
inches
Weight 296
10.44
g
oz
Supply voltage 9 to 32 VDC
Supply current (Sleep mode) 5mA
Supply current (Operation) 50 mA
RF frequency 433 MHz
Temperature ranges
– Operation -40 to 70
-40 to 158
°C
°F
– Storage -40 to 85
-40 to 185
°C
°F
3.3.1 Enabler Unit connector
1
2
1Main Connector
2Status-LED’s
4
3
1
2
Technical Data - Enabler Unit (Receiver unit)

17
Technical data
3.3.2 Pin assignment Main connector (2x2 Pin)
Pin Signal name Description Wire color
1+ VDC Main power supply red
2RS232 RX OPTIONAL
(RS232 Data In) light blue
3GND Battery Negative 0V black
4RS232 TX OPTIONAL
(RS232 Data Out) pink
3.3.3 Blinking code of the Enabler Unit status LED’s
******************************
*----------*----------*--1sec---*----------*
*----------*-----------------------*----------*
1
2
3
1Searching for In-Cabin Unit
2Connect unit established
3TPMS sensors indication
Technical Data - Enabler Unit (Receiver Unit)

18
Technical data
3.4 Trailer Unit (Unit at the trailer)
Dimensions (L x W x H) 199 x 104 x 44
7.83 x 4.09 x 1.73
mm
inches
Weight
– with battery 680
23.99
g
oz
Supply voltage 7 to 52 VDC
Supply current (Sleep mode) 5mA
Power consumption
– Operation
(average at 24 V DC) 50 mA
RF frequency 433 MHz
Temperature ranges
– Operation -20 to 60
-4 to 140
°C
°F
– Storage -20 to 85
-4 to 185
°C
°F
– Sleep mode -10 to 60
14 to 140
°C
°F
– Battery charging 0 to 45
32 to 113
°C
°F
Backup battery Li-Ion
Technical Data - Trailer Unit (Unit at the trailer)

19
Technical data
3.4.1 Trailer Unit connector
1
2
1Main Connector
2Status LED’s
106
1 5
3.4.2 Pin assignment Main connector (2x5 Pin)
Pin Signal name Description Wire color
1CAN 0 (H) CAN bus 0 High
signal orange/white
2OUT Open collector
output white/black
3RS232 Tx RS232 Data out pink
4Ignition/In Ignition sense input green
5+ VDC Main power supply red
6CAN 0 (L) CAN bus 0 Low signal yellow/white
7 n.c. Not connected
8RS232 Rx RS232 Data in light blue
9GND Battery negative 0V black
10 GND Battery negative 0V black
Technical Data - Trailer Unit (Unit at the trailer)

20
Technical data
3.4.3 Blinking code of the Trailer Unit status LED’s
1 Sec 1 Sec 1 Sec
1 Sec
1 Sec 1 Sec 1 Sec
1 Sec
1
2
3
4
1Searching GPS signal
2GPS position established
3Searching GSM signal
4GSM connection established
Technical Data - Trailer Unit (Unit at the trailer)
