Convaid Cruiser 12 Manual

Cruiser 12
Convaid Replacement Parts & Accessories Manual

Cruiser 12
www.convaid.comii
TABLE OF CONTENT
FRAME
REPLACEMENT PARTS
FOOTPLATES
WHEELS
UPHOLSTERY
One Piece Height Adjustable Push Handle ·················································································· 2
One Piece Height Adjustable Push Handle with Attendant Handbrake ············································· 4
991688
996014
991619
991696
991621
991697
991694
991698
991695
991699
996015
996016
996017
996018
992658
992659
994757
994758
996010
996011
996012
996013
994749
994750
996009
995690
994746
994747
994748
996005
996006
996007
996008
996611
996612
996613
996614
Standard Footplate - Left ········································································································ 6
Standard Footplate - Right······································································································· 8
Angle Adjustable Footplate - Left ····························································································· 10
Angle Adjustable Footplate - Right ·························································································· 12
Standard Footplate Assy Kit - Left···························································································· 14
Standard Footplate Assy Kit - Right·························································································· 16
Angle Adjustable Swing Away Footplate Assy Kit - Left································································ 18
Angle Adjustable Swing Away Footplate Assy Kit - Right ····························································· 20
Part#
Part#
Part#
Part#
7.5" x 2" Front Solid Wheel Assy - Each···················································································· 22
7.5" x 2" Front Pneumatic Wheel Assy - Each ············································································ 24
Caster Fork Assy for 7.5" x 2" Front Rolko Tire - Each································································ 26
Caster Fork Assy with Caster Lock for 7.5" x 2" Front Rolko Tire - Pair ········································· 28
11.5" x 2.5" Rear Solid Wheel Assy - Each ················································································ 30
12.5" x 2" Rear Solid Knobby Wheel Assy - Each ······································································· 32
12.5" x 2" Rear Pneumatic Knobby Wheel Assy - Each ······························································· 34
Brake Assy for Rolko Wheel - Left ···························································································· 36
Brake Assy for Rolko Wheel - Right ························································································· 38
Brake Assy for Rolko Attendant Brake - Left ·············································································· 40
Brake Assy for Rolko Attendant Brake - Right ············································································ 42
Scout - Brake Assy w/Pneumatic Knobby Wheel - Left ································································ 44
Scout - Brake Assy w/Pneumatic Knobby Wheel - Right ······························································ 46
Scout - Brake Assy w/Solid Knobby Wheel - Left ········································································ 48
Scout - Brake Assy w/Solid Knobby Wheel - Right ······································································ 50
Cordura Seat Bottom Upholstery ····························································································· 54
Cordura Back Upholstery ······································································································· 54
Heavy Duty Cordura Seat Bottom Upholstery ············································································ 56
Heavy Duty Cordura Back Upholstery ······················································································· 56
Textilene Seat Bottom Upholstery ··························································································· 58
Textilene Back Upholstery ······································································································ 58
Heavy Duty Textilene Seat Bottom Upholstery ·········································································· 60
Heavy Duty Textilene Back Upholstery ····················································································· 60
Cordura Upholstery with +3" Seat Depth Extension···································································· 62
Heavy Duty Cordura Upholstery with +3" Seat Depth Extension··················································· 64
Textilene Upholstery with +3" Seat Depth Extension ·································································· 66
Heavy Duty Textilene Upholstery with +3" Seat Depth Extension ················································· 68
Upholstery Colors ···························································································································· 52

888-Convaid (266-8243) iii
Cruiser 12
HEAD SUPPORT
TRUNK POSITIONING
996610
996025
996026
996636
996035
996036
995938
Part#
Part#
Headrest Extension - Curved Cordura······················································································· 70
Headrest Extension - Rectangular Textilene··············································································· 70
Occi Headwings ···················································································································· 72
Padded Headwing ·················································································································· 72
PELVIC POSITIONING
995683
994716
996019
996020
996021
996029
996030
996638
996639
Part#
H-Harness with Padded Cover ································································································ 74
Full Torso Support Vest for Cordura Upholstery ········································································· 76
Full Torso Support Vest for Textilene Upholstery ········································································ 76
Reducer Seat Insert ·············································································································· 76
Soft Adjustable Lateral Support - Single Flap············································································· 78
Soft Adjustable Lateral Support - Double Flap············································································ 78
Upper Extremity Support Surface Tray (Hardware Included) ························································ 80
FOOT & LEG POSITIONING
996615
996616
996617
996618
996619
Part#
3 Point Belt with Depth Adjustable Crotch Strap········································································· 82
Adjustable Crotch Strap for 3 Point Belt ··················································································· 82
Support Seat Cushion Assy ····································································································· 84
Align Seat Cushion Assy ········································································································· 86
Position Seat Cushion Assy ····································································································· 88
Lateral Thigh Support - Adductor ····························································································· 90
Medial Thigh Support - Abductor······························································································ 90
Q'Straint Transit Lap Belt ········································································································ 92
Sure-Lok Transit Lap Belt········································································································ 92
ACCESSORIES
996022
996023
996024
996623
996625
996620
996621
995937
996622
994764
995688
Part#
Calf Panel ····························································································································· 94
Foot Positioner - Small ·········································································································· 94
Foot Positioner - Medium ······································································································· 94
Foot Positioner - Large ·········································································································· 94
Footplate Securement Strap···································································································· 94
Headrest Cover (Canopy) ······································································································· 96
Extended Headrest Cover - No Windows (Canopy) ····································································· 96
Extended Headrest Cover - With Windows (Canopy) ·································································· 96
Mosquito Net ························································································································ 98
Rain Cover ··························································································································· 98
Saddle Bag - Pair·················································································································· 100
Wheelchair Travel Bag··········································································································· 102
Under Seat Storage Basket ··································································································· 102
Utility Bag ··························································································································· 102
Frame Armrest Cover - Pair···································································································· 104
Rear Anti-Tip Tube - Pair········································································································ 106
996027
996028
995932
996033

Convaid, the company that invented the compact folding adaptive assisted wheelchair,
has helped special needs children and their families live fuller, more productive lives
since 1976. Convaid produces high-performance, easy-to-use and attractive mobility
products for all stages of a young person’s life, from infancy to young adulthood. Each
product is custom-built to individual specications to provide the optimum comfort,
safety, and convenience.
Convaid meets the assisted mobility needs of thousands of special needs families every
year by manufacturing pediatric push wheelchairs in a variety of sizes and models,
and backs its products with one of the best warranties in the industry and a highly
responsive customer service department. The patented compact folding mechanism
allows custom wheelchairs to be easily carried up stairs, placed in the trunk of most
compact cars, or used while traveling. Convaid’s chairs provide the optimal combination
of corrective positioning, comfort, durability and safety for the user in a product that is
both attractive and easy-to-use for the caregiver.
www.convaid.com

888-Convaid (266-8243) 1
Warranty

www.convaid.com2
Cruiser 12
Close-up
991388
QTYDESCRIPTION
PART NUMBERITEM
1CX10 Single Pc Handle Assy5067641
2
Locknut #10-24 Jam Flexlock
1001182
2Screw #10-24 x 1-1/4" Phil Pan1003333
1
3
2
3
Cruiser Back Tube
Cruiser Back Tube
Cruiser 10 One Piece Push Handle
Assembled
Exploded
One Piece Height Adjustable Push Handle
FRAME
Item Description Qty
1 CX12 Single Pc Handle Assembly 1
2 Locknut #10-24 Jam Flexlock 2
3 Screw #10-24 x 1-1/4" Phil Pan 2
Assembled
Cruiser Back Tube
Cruiser Back Tube
991688
Kit Includes
#
FRAME
991388
QTYDESCRIPTION
PART NUMBERITEM
1CX10 Single Pc Handle Assy5067641
2
Locknut #10-24 Jam Flexlock
1001182
2Screw #10-24 x 1-1/4" Phil Pan1003333
1
3
2
3
Cruiser Back Tube
Cruiser Back Tube
Cruiser 10 One Piece Push Handle
Assembled
Exploded
3
3
1
2

888-Convaid (266-8243) 3
Cruiser 12
INSTRUCTIONS
One Piece Height Adjustable Push Handle
1. Using a phillips screwdriver and a 3/8” wrench, remove the screw attaching the
handle tube assembly from the Cruiser Back Tubes.
2. Slide existing handle assembly off.
3. Slide new handle assembly onto the back tube. Item 1
4. Align the holes on the plastic pivot joint of the handle tube assembly with the holes
of the back tubes.
5. Insert new screw Item 3 into pivot joint.
6. Attach the nut Item 2 and tighten using a phillips screwdriver and a 3/8” wrench.

www.convaid.com4
Cruiser 12
Close-up
3
2
31
One Piece Height Adjustable Push Handle
with Attendant Handbrake
Assembled
Cruiser Back Tube
Cruiser Back Tube
FRAME
Item Description Qty
1 CX-12 Attendant Brake Handle Assembly 1
2 Locknut #10-24 Jam Flexlock 2
3 Screw #10-24 x 1-1/4" Phil Pan 2
996014
#
Kit Includes
3
3
1
2

888-Convaid (266-8243) 5
Cruiser 12
INSTRUCTIONS
One Piece Height Adjustable Push Handle with Attendant
Handbrake
1. Remove Cable from Lever by pulling the cable away from the lever & routing
the inner cable off the level
2. Using a phillips screwdriver and a 3/8” wrench, remove the screw attaching the
handle tube assembly from the Cruiser Back Tubes.
3. Slide existing handle assembly off.
4. Slide new handle assembly onto the back tube. Item 1
5. Align the holes on the plastic pivot joint of the handle tube assembly with the
holes of the back tubes.
6. Insert new screw Item 3 into pivot joint.
7. Attach the nut Item 2 and tighten using a phillips screwdriver and a 3/8”
wrench. Attached cable onto the lever on the new handle.

www.convaid.com6
Cruiser 12
Close-up
992658
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, LH
5049871
1
Cruiser 10-12 Small Footplate Assembly LH
Assembled
Exploded
Standard Footplate - Left
Assembled
FOOTPLATE
Item Description Qty
1 CX-10 Footrest Assembly, LH 1
992658
#
992658
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, LH
5049871
1
Cruiser 10-12 Small Footplate Assembly LH
Assembled
Exploded
Kit Includes

888-Convaid (266-8243) 7
Cruiser 12
INSTRUCTIONS
Standard Footplate - Left
1. Remove the exsiting footplate assembly by pressing the detent button then
pulling the footplate off.
2. Insert the new footplate assembly into the footplate adjustment tube then press
the detent button to allow the footplate assembly to slide in and lock in place.

www.convaid.com8
Cruiser 12
Close-up
992659
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, RH
5049881
1
Cruiser 10-12 Small Footplate Assembly RH
Assembled
Exploded
Assembled
FOOTPLATE
992659
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, RH
5049881
1
Cruiser 10-12 Small Footplate Assembly RH
Assembled
Exploded
Standard Footplate - Right
Item Description Qty
1 CX-10 Footrest Assembly, RH 1
992659
#
Kit Includes

888-Convaid (266-8243) 9
Cruiser 12
INSTRUCTIONS
Standard Footplate - Right
1. Remove the exsiting footplate assembly by pressing the detent button then pulling
the footplate off.
2. Insert the new footplate assembly into the footplate adjustment tube then press
the detent button to allow the footplate assembly to slide in and lock in place.

www.convaid.com10
Cruiser 12
Close-up
994757
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Pivot Footplate Assy LH
5048851
Cruiser 10-12 Small Angle Adjustable Footplate Assembly LH
Exploded
Assembled
Assembled
FOOTPLATE
994757
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Pivot Footplate Assy LH
5048851
Cruiser 10-12 Small Angle Adjustable Footplate Assembly LH
Exploded
Assembled
992659
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, RH
5049881
1
Cruiser 10-12 Small Footplate Assembly RH
Assembled
Exploded
Angle Adjustable Footplate - Left
Item Description Qty
1 CX-10 Pivot Footplate Assembly, LH 1
994757
#
Kit Includes

888-Convaid (266-8243) 11
Cruiser 12
INSTRUCTIONS
Angle Adjustable Footplate - Left
1. Remove the exsiting footplate assembly by pressing the detent button then pulling
the footplate off.
2. Insert the new footplate assembly into the footplate adjustment tube then press the
detent button to allow the footplate assembly to slide in and lock in place.

www.convaid.com12
Cruiser 12
Close-up
994758
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Pivot Footplate Assy RH
5044861
Cruiser 10-12 Small Angle Adjustable Footplate Assembly LH
Assembled
Exploded
1
Assembled
FOOTPLATE
994758
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Pivot Footplate Assy RH
5044861
Cruiser 10-12 Small Angle Adjustable Footplate Assembly LH
Assembled
Exploded
1
Angle Adjustable Footplate - Right
Item Description Qty
1 CX-10 Pivot Footplate Assembly, RH 1
994758
#
Kit Includes

888-Convaid (266-8243) 13
Cruiser 12
INSTRUCTIONS
Angle Adjustable Footplate - Right
1. Remove the exsiting footplate assembly by pressing the detent button then
pulling the footplate off.
2. Insert the new footplate assembly into the footplate adjustment tube then
press the detent button to allow the footplate assembly to slide in and lock
in place.

www.convaid.com14
Cruiser 12
Close-up
996010
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, LH
5049871
1
Footplate Adjustment Tube LH
5009692
1Footrest Extens. Housing Assy5006903
1Tube Connector 7/8" Heavy Duty100017
4
2Screw 1/4"-20 x 1-1/2" Flat Skt100262
5
1Detent Pin With Webbing Assembly5038796
1Thread Locker-Medium-Vibra-tite100690
7
6
4
57
2
1
Cruiser 10-12 Small Footplate Assembly Kit LH
Assembled
Exploded
996010
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, LH
5049871
1
Footplate Adjustment Tube LH
5009692
1Footrest Extens. Housing Assy5006903
1Tube Connector 7/8" Heavy Duty100017
4
2Screw 1/4"-20 x 1-1/2" Flat Skt100262
5
1Detent Pin With Webbing Assembly5038796
1Thread Locker-Medium-Vibra-tite100690
7
6
4
57
2
1
Cruiser 10-12 Small Footplate Assembly Kit LH
Assembled
Exploded
Assembled
FOOTPLATE
Standard Footplate Assy Kit - Left
Item Description Qty
1 CX-10 Footrest Assembly, LH 1
2 Footplate Adjustment Tube, LH 1
3 Footrest Extension Housing Assembly 1
4 Tube Connector 7/8" Heavy Duty 1
5 Screw 1/4"-20 x 1-1/2" Flat Skt 2
6 Detent Pin With Webbing Assembly 1
7 Thread Locker-Medium-Vibra-tite 1
996010
#
Kit Includes
3

888-Convaid (266-8243) 15
Cruiser 12
INSTRUCTIONS
Standard Footplate Assy Kit - Left
1. Pull out metal pin and remove the existing footplate extension tube. Item 2
2. Using a 5/32" allen wrench, remove both bolts from the housing bracket on the
frame and remove existing footplate assembly components.
3. If needed, install tube connector Item 4 into the front leg by hammering or
pressing it into the front leg tube.
4. Slide the loop portion of the detent pin with webbing assembly over the front
x-brace tube.
5. Align footrest extension housing Item 3 with the front leg.
6. Apply some thread locker Item 7 on the thread portion of the screws Item 5 .
7. Using a 5/32" allen wrench, attach the footrest extension housing onto the front
leg using the screws provided Item 5 .
8. Reattach the footplate adjustment tube and secure it with the
detent pin Item 6 .

www.convaid.com16
Cruiser 12
Close-up
996011
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, RH
5049881
1
Footplate Adjustment Tube RH
5009702
1Footrest Extens. Housing Assy5006903
1Tube Connector 7/8" Heavy Duty100017
4
2Screw 1/4"-20 x 1-1/2" Flat Skt100262
5
1Detent Pin With Webbing Assembly5038796
1Thread Locker-Medium-Vibra-tite100690
7
6
57
4
1
2
Cruiser 10-12 Small Footplate Assembly Kit RH
Assembled
Exploded
996011
QTYDESCRIPTIONPART NUMBERITEM
1
CX-10 Footrest Assembly, RH
5049881
1
Footplate Adjustment Tube RH
5009702
1Footrest Extens. Housing Assy5006903
1Tube Connector 7/8" Heavy Duty100017
4
2Screw 1/4"-20 x 1-1/2" Flat Skt100262
5
1Detent Pin With Webbing Assembly5038796
1Thread Locker-Medium-Vibra-tite100690
7
6
57
4
1
2
Cruiser 10-12 Small Footplate Assembly Kit RH
Assembled
Exploded
Assembled
FOOTPLATE
3
Standard Footplate Assy Kit - Right
Item Description Qty
1 CX-10 Footrest Assembly, RH 1
2 Footplate Adjustment Tube, RH 1
3 Footrest Extension Housing Assembly 1
4 Tube Connector 7/8" Heavy Duty 1
5 Screw 1/4"-20 x 1-1/2" Flat Skt 2
6 Detent Pin With Webbing Assembly 1
7 Thread Locker-Medium-Vibra-tite 1
996011
#
Kit Includes
