Convaid Trekker User manual

Trekker™ Troubleshoot Guide
1

Trouble Shooting Guide
Problem Probable cause
Part
Location
Solution
Reference Guide
Tilt Adjustment Lever not
working
Cable out of position
Tilt Adjustment
Lever Cable out
of position
Cable on the Tilt
Adjustment Lever
may be pulled loose
or dislodged during
transport and/ or
initial assembly.
Tilt Adjustment Lever
Cable
Bottom of Seating System
Plug the cable end into the
Adjustment Barrel.
Make
sure cable end is fully
seated inside Adjustment
Barrel.
Slide 3
Propeller not aligned correctly
Upper Propeller
not aligned at
90°
Upper Propeller
Align Upper Propeller at
90° to create gap which is
required for propeller to
fully retract.
Slide 4 - 5
Loose cable
Loose Tilt
Adjustment
Lever cable
Tilt Adjustment Lever
Cable
Tilt Adjustment Lever
Handle
Cable end must be fully
seated insed
Adjustment
Barrel
Slide 6 - 7
2

Check TiltAdjustment Lever
1. Plug the cable end into the adjustment barrel.
2. Make sure the chrome cable end is fully seated
inside adjustment barrel.
Cable on the tilt adjustment lever be pulled loose or
dislodged during transport and/or initial assembly.
Please check the following cable position.
Tilt cable end out
of position
Correct

Cable on the seating system can be pulled loose or
dislodged during transport and/or initial assembly.
Please check the following cable positions.
Upper Propeller at 90°
alignment
Tilt cable out of
position
Check TiltAdjustment Lever
Correct
1. Plug the cable end into the adjustment barrel.
2. Make sure the chrome cable end is fully seated
inside adjustment barrel.
Upper Propeller
not aligned at 90°
4

INCORECT CORRECT
Trekker Upper Propeller
(Under Seat)
IMPORTANT NOTE: GAP is REQUIRED in order for propeller to fully
retract.
If it doesn’t, please follow the barrel adjustment steps that follow:
Gap
No Gap
Gap is required for propeller
to fully retract.
5

Barrel Adjustment Steps
Step 1:
Loosen locking Nut
Step 2:
Adjust Barrel Adjuster
Until Desired Cable Slack
6

Barrel Adjustment Steps
Step 3:
After Desired Cable Slack Achieved
Tighten Locking Nut
7

Trekker™ Technical Information
8

Trekker Seat Back View
Tilt Cable tie downs
Tilt adjustment lever
Height adjustable
knobs
Height Adjustable
Solid Back System
Recline adjustment
strap
Tilt Cable
Adjustment barrel
Components
9

Trekker Seat Bottom View
Chrome Cable End
Seating Tilt
Cable
Depth Adjustable
Knobs
Pommel Attachment Knob
Safety Lock Lever
Depth Adjustable
Knobs
Cable Clamp
Adjustment barrel
Upper Propeller
Components Spring
Inner Cable
10

Trekker Front View
Anterior
Tilt Limit
Stop Lever
11
