Convaid Rodeo User manual

ENGLISH
User’s Guide
Rodeo
Lightweight Tilt-In-Space Chair
SAVE THIS BOOK FOR FUTURE REFERENCE
READ INSTRUCTIONS BEFORE USING

CONVAID USER’S GUIDE
i
Noti ce:
The i nformati on contai ned i n thi s document i s subject to change wi thout noti ce.
No part of thi s document may be photocopi ed, reproduced, transmi tted,
transcribed, stored in a retrieval system or translated to another language
or computer language, in any form or by any means, electronic, mechanical,
magneti c, opti cal, chem i cal, manual or otherwi se wi thout the pri or wri tten
consent of Convaid.
Use only Convai d accessori es and parts on Convai d products. Convai d parts
are not interchangeable with other manufacturers’ products. Replace any
worn parts immediately.
Customer Service Support
Toll Free: 1-888-Convaid (266-8243)
Phone: [phone]
Fax: [phone]
Emai l: custservi ce@convai d.com
Internati onal Ema i l: i nternati onal@convai d.com
Website: www.convaid.com
Technical assistance or repair information hours are:
Monday-Friday, 7 a.m. to 5 p.m. PST
Before Calling:
Please fill in the following. Customer Service will be
able to help you more quickly if the information
indicated below is readily available.
Serial number of chair:
Model of chair:
Date purchased:
© Copyright 2011 by Convaid. All rights reserved.

Unpacki ng . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Unfolding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Foldi ng . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Seat back hei ght . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Seat width. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Seat depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Three-point posi ti oni ng belt . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Depth adjustable crotch strap . . . . . . . . . . . . . . . . . . . . . . . . . . 7
H-harness with padded covers . . . . . . . . . . . . . . . . . . . . . . . . . 8
Two-pi ece seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Footplate adjustment:
Height adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Angle adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Depth adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Foot positi oners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Addi ti onal supports:
Lateral supports . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Medi al thi gh support (abductor) . . . . . . . . . . . . . . . . 12
Lateral thi gh support (adductor) . . . . . . . . . . . . . . . . 12
Calf panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Full torso swing-away support vest . . . . . . . . . . . . . .13
Padded headwing and Occi headwing. . . . . . . . . . . . . . . . . . . 14
Headrest extensi on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Height adjustable fli p-up armrests . . . . . . . . . . . . . . . . . . . . . 16
Solid & mesh si de panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Seat Cushions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Upper extremi ty support surface (tray) . . . . . . . . . . . . . . . . . 19
Medi cal necesssity storage tray . . . . . . . . . . . . . . . . . . . . . . . 19
Heavy-duty medical necesssity storage tray . . . . . . . . . . . . . 20
Headrest cover (canopy) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Attendant hand brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Utility bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Oxygen tank bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Bus transport models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Fabric removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Speci fi cati ons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Locking and unlocking brake . . . . . . . . . . . . . . . . . . . . . . . . . 25
Rear ti re removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Rear ti re i nstallati on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Anti-shimmy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Ti lt adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Recli ne adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Operati ng and safety instructi ons . . . . . . . . . . . . . . . . . . . . . 29
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back cover
ii
Table of Contents
Setting Up
Fitting Guide
Wheels
Tilt & Recline
Accessories
Transit Models
Miscellaneous
Important
Information

SETTING UP
1
Setting Up
Unpacking
Unfolding
Fig. 1
Fig. 2 Fig. 3
Check to see that the followi ng i tems are i ncluded wi th
the chai r:
• One-pi ece footplate.
• Accessori es as or der ed
• H ex w ren ch (5 /32)
1. Lay chair down
with seat facing
upward. Fig. 1
2. Unbuckle closure
strap. Fig. 2
3. Push i n gray detent
buttons on footplate,
and swi ng footplate
out and upward
until parallel with
the ground. Fig. 3
Rodeo
Si ze Model No.
10" RD10
12" RD12
14" RD14
16" RD16
SIZE / MODEL
CHART

2
SETTING UP
Fig. 5
Fig. 6
4. Apply wheel locks. Fig. 4
5. Push in gray detent buttons on handle, and lift upward until handle is
at a 90-degree angle with chair. Fig. 5
6. Grasp handle, place foot on the frame’s lower support tube, and pull
upward on chair until the red safety lock clicks into place. Fig. 6
7. Adjust handle and footplate i nto desi red posi ti on.
Fig. 4

CONVAID USER’S GUIDE
3
Folding
Caution: Keep fingers free
of folding mechanism.
1. Before foldi ng, front wheels of
chair should be in a forward
faci ng posi ti on. Fig. 7
2. Tilt chair in upright position.
Fig. 8a. For chairs with arm-
rests, fli p armrests up. Fig. 8b
3.Rotate footplate until it is
parallel wi th the ground.
Fig. 9
Fig. 7
Fig. 8a
Fig. 9
Fig. 8b
!

4
SETTING UP
4. Usi ng left hand, move red safety lock to the ri ght, and at the same ti me, li ft
up on foldi ng lock bar - hold i n posi ti on unti l fold begi ns. Fig. 10 & 11
5. Push chair downward into the folded postion. Fig. 12 & 13
6. Push i n gray detent buttons on the handle, and rotate handle back on to chai r.
Fig. 14
7. Fli p footpla te up.
8. Push i n gray detent buttons on legrest, and rotate legrest under cha i r.
Fig. 15 & 16
9. Secure closure strap to keep chair folded. Fig. 17
10.With a straight back, bend knees and lift chair
as shown i n photo. Fig. 18
Fig. 10 Fig. 11 Fig. 12
Fig. 14
Fig. 16
Fig. 17
Fig. 18
Fig. 15
Fig. 13

CONVAID USER’S GUIDE
5
Fitting Guide
Correct seati ng and posi ti oni ng encourages good posture, whi ch i n
turn ai ds ci rculati on, breathi ng and di gesti on. Please take the ti me
to properly adjust the cha i r to fi t the user. If the user i s not correctly
posi ti oned, check the accessori es secti on of thi s manual to see i f one
or more of our accessories would help to facilitate posture or consult
a physical therapist. Improper seating can cause problems. Please
consult a physical therapist or doctor for additional guidance.
When properly fi tted, Convai d chai rs wi ll provi de years of comfort-
able use. As the user grows, refer back to thi s Fi tti ng Gui de to
adjust the dimensions of the chair.
Seat Back Height
Seat back height varies according to chair size. Headrest
exten si on s a r e a va i la ble w hen extra hei ght i s n eeded to
support the head.
To determi ne the seat back hei ght, measure from the seat
to the upper part of the head. Fig. 19
Fig. 19
Sea t back hei ght
Proper seat wi dth enables the user to si t comfortably and
prevents problems from developi ng. Whi le user i s seated
on a flat surface, measure from hip to hip. Fig. 20
The user should have enough room to prevent hi ps and
thi ghs from rubbi ng agai nst the frame. However, the
chai r should not be too wi de or the user wi ll sli de around
and posture could be affected.
Seat Width
Fig.20

6
FITTING GUIDE
Seat Depth
Seat Depth Adjustment:
1. Remove bolts located on the front of
seat frame. Fig. 23
2. Adjust seat to desi red posi ti on and
reinsert bolts.
Measure from the most posteri or porti on of the buttocks
to the ba ck of the knee. Su btr a ct from tha t m ea su r emen t
1-2” to allow adequate clearance between the seat and
the ba ck of the knee. Fig. 22
Seat depth
Fig. 22
Fig.23
Fig. 21
Seat wi dth i s
measured from
the outsi de edge of
the seat frame.
Fig. 21
Note: Adjust one si de of the seat at
a time.

7
CONVAID USER’S GUIDE
Depth Adjustable Crotch Strap
The depth adjustable crotch
strap prevents the user from
sliding out of the chair. It
connects to the posi ti oni ng
belt vi a the qui ck-release
buckle, and can be adjusted
by threadi ng the strap
through desi red slot on the
seat upholstery.
Fig. 25
Fig. 25
Three-Point Positioning Belt
Fig. 24
The 3-poi nt belt keeps the user secure i n the wheelcha i r.
To Buckle:
Sli p the metal clasp on the
belt strap i nto the crotch
strap buckle. Fig. 24
To Release:
Press the red button on
the buckle and pull out
the clasp.

8
Two-piece Seat
The lower seat panel has a
double Velcro® attachment
for adjusti ng the seat. To
adjust the tautness of the
seat, pull apart the double
Velcro flap at the rear under-
si de of the seat. Place the
Velcro i n the desi red posi -
ti on a nd rea tta ch the double
flap. Fig. 28
Fig. 28
FITTING GUIDE
Fig. 26 Fig. 27
H-harness shoulder straps
help the user retain upright
trunk posi ti on. To adjust
the hei ght, i nsert the bolt at
the en d of the str a p thr ough
the grommet hole i n the seat
back, and secure wi th the
threaded knob. Grommet
choi ce should be level wi th
or hi gher tha n the top of the
shoulders - thi s wi ll keep
the user secure, wi thout the
strap rubbing against the
fa ce or n eck. Fig. 26 & 27
H-Harness with Padded Covers

CONVAID USER’S GUIDE
9
Footplate Adjustment
To determi ne the correct
seat-to-footplate hei ght,
measured from the back
of the knee to the bottom
of the heel.
All Convaid footplates are
hei ght adjustable. Fig. 29
Fig. 30
Fig. 31
Height Adjustment:
The soles of the feet or heels
should rest comfortably on top
of the footplates. To achi eve
thi s, remove detent pi ns on
the front of the leg tubes, sli de
the footplate to the desi red
hei ght and rei nsert the pi ns.
When the footpla te i s a dj u sted
i n i ts hi ghtest posi ti on, the
excess materi al of the calf flap
may be wrapped under the
footplate and attached with
Velcro. Fig. 30
Angle Adjustment:
To adjust the footplate angle,
loosen the four bolts on the
ou ter edge of the legr est w her e
the footplate tubes are located.
Adjust the footplate to desi red
angle, and ti ghten the bolts.
Fig. 31
Foot
support
hei ght
Fig. 29

FITTING GUIDE
Depth Adjustment:
To adjust the depth of the footplate,
loosen the two bolts on ea ch si de of
the footpla te. Sli de the footpla te
i nto desi red posi ti on, and ti ghten
the bolts. Fig. 32
Fig. 32
Fig. 35
Fig. 34
Adjustable foot posi ti oners hold
feet i n posi ti on on the footplate.
The foot posi ti oners may be
criss-crossed over the top of the
foot to secure the enti re foot, or
ca n be converted i nto a si mple
ankle strap by wrappi ng the
right strap around the ankle and
fasteni ng the buckle. Fig. 33
To attach the posi ti oners, thread
the strap through footplate, and
bolt to undersi de of footplate.
Fig. 34 & 35
Fig. 33
Foot Positioners
10

CONVAID USER’S GUIDE
11
Folding Lateral Supports:
The lateral supports help mai ntai n mi dli ne posi ti oni ng of the trunk.
To adjust the lateral supports:
1. Release the velcro upholstery straps on the back si de of the chai r.
2. Loosen the knobs on the lateral mounti ng bracket.
3. Reposi ti on laterals to the desi red locati on.
4. Ti ghten the knobs and replace the upholstery. Fig. 36
Lateral Supports Fig.36
Fig.37
Convai d offers a wi de vari ety of supports to help properly posi ti on the user.
Note: Convaid’s chairs provide a semi-contour fit around the body. The user must
be fitted correctly into the chair to achieve optimal posture and comfort.
Additional Supports
Lateral Supports
To fold laterals, squeeze the latch located at
the bottom of Lateral Support Bar, and fold
inwards. Fig. 37 & 38

FITTING GUIDE
12
Medial Thigh Support (Abductor)
Fig.40
Separates thi ghs to i mprove hi p ali gn-
ment and stabilize sitting posture.
Degree of a bdu cti on ca n be va r i ed a n d
can favor one side.
1. Wrap the abductor flaps over
the user’s thi ghs from i nsi de to
outsi de.
2. Buckle the straps around
the seat tube or armrest, and
adjust. Fig. 39
Pulls thi ghs together to i mprove hi p
alignment and stabilize sitting pos-
ture. Degree of adduction can be var-
ied.
1. Fold the a ddu ctor fla ps over the
user’s thighs.
2. Wrap straps under and around the
seat tube and attach wi th the buckle
under seat. Fig. 40
Lateral Thigh Support (Adductor)
Fig.39
Fig. 38

CONVAID USER’S GUIDE
13
The Calf Panel provi des support for the lower legs. To
attach, wrap Calf Panel around legrests and velcro.
Fig. 41
Calf Panel
Fig. 41
Adjustable support vest posi ti ons user comfortably
and securely, maintains midline-seating position,
and prevents forward slumpi ng.
The vests attaches to the chai r wi th straps that wrap
around the seat back and connect with Velcro, and
shou lder stra ps tha t a r e i n ser ted thr ough hori zonta l
sli ts i n the seat back. Adjust the si de straps on the
vest for proper fi t. Fig. 42
Full Torso Swing-Away Support Vest
Fig. 42

14
FITTING GUIDE
Fig. 43 Fig. 44
Padded Headwing
Padded headwi ngs provi de fi rm support for mi dli ne posi ti oni ng. Fig. 43 The
headwi ngs can be attached at any hei ght by wrappi ng the straps around the
frame and securing at the back of the chair. Fig. 44
Occi Headwing
Fig. 45 Fig. 46
The Occi Headwi ng comfortably posi ti ons the head i n ali gnment. To attach,
thread the stra ps through the sli ts i n the upholstery and attach at the back of
the chai r. For a dded securement, thread laces through the grommet holes i n the
upholstery, and ti e. Fig. 45-50

CONVAID USER’S GUIDE
15
Fig. 47 Fig. 48
Fig. 49 Fig. 50
Headrest Extension
Extends back hei ght to provi de head support of taller i ndi vi duals. The
Headrest Extensi on fi ts easi ly i nto sockets on seat back. To adjust hei ght, move
rubber grommets on the mounti ng posts to desi red posi ti on.
Fig. 51 & 52
Fig. 51 Fig. 52

Fig. 53 Fig. 54
The hei ght adjustable fli p-up armrests provi de added support and
posi ti oni ng. Armrests “fli p-up” out of the wa y for easy access i nto
the chai r, and adjust i n hei ght for added comfort.
To attach or a djust the hei ght of the armrests, rem ove the two
screws from ea ch bracket, adjust bracket to the desi red hei ght, and
reinsert the screws. Fig. 53 & 54
Height Adjustable Flip-Up Armrests
Fig. 54bFig. 54a Fig. 54c
The si de panels are desi gned to keep the occupants arms i nsi de the chai r
and to provi de added securi ty. The si de panels are attached to the chai r
wi th 1 screw at the top and 2 Velcro straps at the bottom.
The si de panels wi ll adjust to accommodate varyi ng degrees of recli ne. To
adjust: loosen the Velcro strap on the front/outsi de of the panel, recli ne the
chai r to desi red posi ti on and re-ti ghten the Velcro strap. Fig. 54a
Si de panels are avai lable i n soli d or mesh fabri c. The mesh fabri c allows for
increased ventilation. Fig. 54b & Fig. 54c
16
FITTING GUIDE
Solid & Mesh Side Panels

Seat Cushions
Fig. 55
Fig. 56
CONVAID USER’S GUIDE
17
Fig. 57
• Medi al thi gh support helps posi ti on the legs out
of adduction and into better alignment, which
can provide for improved weight-bearing
balance and stability.
• When used wi th a lap belt, the 1” anti -thrust
shelf in front of the ischials helps eliminate
sliding or thrusting forward of the pelvis. This
provides improved stability and reduces
sacral si tti ng.
• Promotes stability and posture control and
provi des comfort for the user.
• Wa ter fa ll f r on t eli m i n a tes pr essu r e
poi nts at the back of the knees.
• Cost effecti ve cushi on choi ce.
• Contoured edges provi de lateral, pelvi c and
thi gh posi ti oni ng to reduce lateral movement of
the pelvi s a n d i m pr ove low er extr em i ty
stability.
• Increased surface contact for better
wei ght di stri buti on.
Support: General Use Cushion
Flat foam with wooden insert Fig. 55
Position: Medial Thigh Support and Anti-Thrust Cushion
Contoured foam with wooden insert Fig. 56
Align: Lateral Pelvis and Lateral Thigh Support Cushion
Contoured foam with wooden insert Fig. 57
