Novis BetterLiving User manual

Transit Wheelchair
Detachable, swing away footrests
Padded seat and backrest
Solid 7”
(180 mm)
front wheels
Nylon heel loops
Lift up,
padded armrests
Pneumatic 12”
(305 mm) rear wheels
Profiled grip attendant handles
Park brakes
Prior to use please read all instructions.
We recommend you keep this User Guide in a safe place for future reference.
user guide
Prior to use please read all instructions.
We recommend you keep this User Guide in a safe place for future reference.
user guide

2
Product Overview
A compact, transit wheelchair with folding
lightweight aluminium frame for easy
transport and manoeuvrability. Available in
two different seat widths, this chair features
padded seat and backrest, sturdy brakes,
padded lift up armrests
for easy lateral transfer and profiled attendant
grip handles.
The detachable, height adjustable footrests
are equipped with heel loops, offering
greater security and user comfort during
transport. Both footrests fold away to increase
accessibility and ease of transfer.
With pneumatic 12” (305 mm) rear wheels
and solid 7” (180 mm) rubber front wheels for
smooth transit, the chair is simple to fold for
easy travel and storage.
Transit Wheelchair
Box Contents and Inspection
Carefully remove all components from the box
and check items against the list below. Any
damaged or missing components should be
reported to your authorised dealer or Novis
Healthcare.
Prior to use, remove all packaging and plastic
wrapping and check the wheelchair for any
damage that may have occurred in transit,
paying particular attention to:
›Any cracks or damage to the wheels,
tyres or chassis.
›Damage to the seat and backrest.
›Any missing or loose screws, wheelnuts
or fasteners.
Intended Use
›This wheelchair is designed for indoor and
outdoor use, and is intended for propulsion by
an attendant.
›The maximum occupant weight is 110 kilograms,
as stated on the manufacturer’s label.
›The wheelchair should only be used and
maintained in accordance with the instructions
in this User Guide.
User Guide (this document)
Wheelchair
Backrest cover
Seat cushion
Left hand footrest
Right hand footrest
Tool kit

3
Unfold the wheelchair
To unfold the wheelchair, place on a stable
surface and stand behind the wheelchair.
Use both hands to press down on the outer
edges of the seat frame to unfold. It may help
to gently tilt the wheelchair back to lift the
front wheels off the floor. Once open, press
firmly to make sure cross brace is locked.
Set Up
Secure the backrest
Place the backrest over the back straps of the
wheelchair with the padded foam cushion facing
forwards. Push firmly to ensure the hook and loop
fastener is securely attached both back and front.
Pull the bottom flap under the back of the seat and
push firmly to secure the hook and loop fastener
attachment. This closes any gap between the seat
and the backrest.
Secure the seat cushion
Place the seat cushion onto the wheelchair, with
the zip towards the back of the seat and the
angled edge facing forwards.
Make sure the attachment strips are aligned and
push firmly to ensure the hook and loop fastener
is securely attached.
Attach the footrests
With the footrest at a 90° angle to the chassis
(ie swung outwards), attach the footrest by aligning
the two holes at the top of each footrest with the
corresponding hinge pins on the chassis frame, and
push down firmly to insert.
Now swivel the footrest inward to lock into
position, and fold down the footplates.

4
Adjusting the handle height
To move the attendant handles up or down, turn the
lock lever (located on the back of the seat directly
beneath each handle) anti-clockwise until loose.
Adjust the handles to the required height (level with
the attendant’s wrist height when standing), then
tighten by turning the lock lever clockwise.
Ensure the handles are at the same height.
If the lever is protruding from the side of the
wheelchair it can be repositioned. Holding your
thumb against the red centre point of the handle,
pull the handle outwards and rotate.
Adjustments
Adjusting the brakes
When fully released, the maximum
distance between the brake latch
and the tyre should be no more than
25 mm.
To adjust the brakes, use the Allen
Key (provided in the toolkit) to loosen
both bolts in the brake assembly
(refer to picture). Slide the assembly
up or down to set the correct
distance.
Securely tighten both bolts again
and check the adjustment has not
affected proper brake function
(when the brakes are engaged the
rear wheels should
not move).
25mm

5
Adjustments
Adjusting the footrest height
Correct leg position is achieved when the
occupant’s feet can be placed flat on the
footplates when his/her thighs are resting
horizontally on the seat.
To adjust the height of the footrests, use the
Allen Key (provided in the toolkit) to loosen
the bolt on the leg support (do not remove).
Adjust each footrest by sliding up or down
until the desired position and height are
reached, ensuring both footplates are at the
same height.
Tighten the bolt firmly to lock into place.

6
Transferring in and out the wheelchair
When transferring in or out of the wheelchair,
place the wheelchair as close as possible to
the transfer destination. Ensure that the front
wheels are in the forward position and both
footplates are folded up. Always secure the
wheelchair by engaging both left and right
brake levers.
The Transit Wheelchair also features folding
and removable footrests and lift up armrests to
increase access options for easy transfer.
Lift up the armrests
For increased access during lateral or sliding
transfers, the armrests can be lifted up.
To release the armrests, press the lever
located at the front of the armrest to
release the lock. Swing the armrest
upwards until vertical (the armrest will
sit safely out of the way in an upright
position).
To return the armrest, hold the lever while
lowering the armrest and locking into place. Ensure the lock
is engaged before use.
Fold out the footrests
Ensure the footplates are folded up.
On the back of the leg support, pull the lever to the rear and
swing the footrests outwards.
From this position, footrests can also be removed
(simply lift up on the footrest assembly to remove).
Operation
Positioning the occupant
One the occupant is seated, swing the footrests inwards until they lock into
place. Fold the footplates down and ensure the occupant’s feet are placed
flat on each footplate. This wheelchair features heel loops for occupant
safety and comfort. Always ensure the heel loops are securely attached to the
footrests and that the occupant’s feet are firmly located against the straps.
The occupant should be seated as far back as possible in the seat at all times.

7
Propelling the wheelchair
The chair should be propelled forward and
backward by an attendant using the profiled
grip handles.
Make sure the attendant has sufficient strength
to guide the wheelchair down slopes over
rough terrain, or to negotiate over curbs or
obstacles.
Activating the brakes
The brakes should always be applied whenever
the wheelchair is stationary, or when getting
in and out of the wheelchair. Apply brakes to
both wheels to ensure the wheelchair can not
move or swing sideways.
To apply the brakes, make sure the wheelchair
has come to a complete stop. Push the brake
lever all the way forwards until the brakes
come to rest firmly against each wheel. Always
check both brakes are properly applied before
helping the occupant get in or out of the
wheelchair.
To release the brakes simply pull the brake
lever back.
Using the tilt-assist pedal
The tilt-assist pedal helps the attendant to tilt
the wheelchair backwards when negotiating
obstacles. The pedal is located beside the right
rear wheel.
To tilt the wheelchair, attendant places one
foot on the tilt assist pedal, and presses down
while pulling back on the attendant handles.
Ensure balance is maintained while the front
wheels are lifted.
Operation

8
Folding the wheelchair
To fold the wheelchair, firstly fold up the
footrests. If needed, the footrests can be
removed for easy storage. To remove the
footrests, pull the lever on the back of the leg
support to the rear and swing the footrests
outwards. Simply lift up on the footrest
assembly to remove.
Detach the padded seat cushion by pulling
firmly. Detach the backrest by removing the
hook and loop fastener attachment from
underneath the seat and remove.
Pull up on the centre of the seat by gripping
the front and rear edges with both hands – the
sides of wheelchair then fold inwards.
To protect the seat during transportation or
storage, push the folded seat back down so it
is positioned between the wheels for added
protection.
Transportation & Storage

9
General Safety Precautions
Do not use the wheelchair as a seat in a
handicap vehicle.
Safety & Maintenance
›A risk assessment should always be carried
out to ensure the product is suitable for a
new occupant.
›Before use, both the occupant and the
attendant should read these instructions and
familiarise themselves with the wheelchair.
Ensure all components are properly and
securely installed.
›Do not use the wheelchair without the
designated backrest or seat cushion attached.
›The attendant should make sure they have
sufficient strength to safely operate and
control the wheelchair with the occupant
seated in the wheelchair – especially when
negotiating a step, curb or slope.
›To ensure safe clearance when negotiating
ramps or inclines, the clearance between the
ground and the footrests should never be less
than 50 – 60 mm.
›Before sitting down in the wheelchair
ensure the brakes are firmly applied. It is
recommended the footrests are folded out of
the way to assist the occupant when getting
into the wheelchair.
›When travelling in the wheelchair the
occupant must not lean forward; it is
recommended the occupant’s feet are located
in the heel loops for extra safety and comfort.
›Do not tip the wheelchair back beyond its point
of balance or the wheelchair may overbalance.
›Never suddenly apply the brakes while the
wheelchair is moving. First stop the wheelchair
and then apply the brakes firmly.
›Do not touch the tyre when propelling the
wheelchair. Be aware of the risk of friction
injury or entrapment between the tyres and
the side armrest.
›Never stand on the footrests or the seat.
›Do not exceed the maximum recommend
working load.
›Do not attach any weights to the wheelchair.
›Do not use the wheelchair to transport more
than one person at a time.
›Keep the wheelchair out of the direct sunlight
or keep the wheelchair covered; cushions or
parts exposed to sunlight will heat up and may
cause injury to the skin.

10
Regular Maintenance
Professional inspection of the wheelchair is
recommended at least once a year.
Any service or repairs, especially to the brakes,
must be performed by a trained professional.
Any unauthorised repairs or service may void
your warranty.
›Regularly check the wheelchair for damage and wear,
paying special attention to the workings of the brakes and
the condition of the wheels and tyres. If the wheelchair
is damaged in any way, stop using the wheelchair
immediately and contact your authorised dealer or the
manufacturer.
›Check the efficiency of the braking system to ensure
the rear wheels cannot rotate when the park brakes are
engaged. With brakes released, there should be no drag
on the rear wheels and the wheelchair should be wheeled
easily. If you notice an unfamiliar braking sensation or any
abnormalities, stop using the wheelchair immediately and
contact your authorised dealer or the manufacturer.
›Check all screws and wheelnuts are firmly secured.
Use the toolkit provided to tighten any loose fixtures.
›Ensure tyres are inflated to the specified pressure (optimal
pressure 280kPa or 40 PSI) and have sufficient tread depth
(> 1 mm). Defective tyres must be replaced before use.
›In the event of a puncture or constant loss of pressure
to one or other of the rear wheels,
stop using the wheelchair
immediately and contact
your authorised
dealer or the
manufacturer.
Care & Cleaning
Cleaning
Do not use high pressure
cleaners or harsh, caustic
chemicals for cleaning.
Frame
Wipe the wheelchair frame with a
damp cloth.
For more stubborn dirt, use a mild
detergent solution up to 40 °C.
Dry thoroughly before use to avoid
corrosion.
Clean the wheels using a damp
brush with plastic bristles (do
not use a wire brush or you may
damage the rubber).
Upholstery
Regularly clean the upholstery
materials using a mild detergent
solution up to 40 °C, or washed
with alcohol-based disinfectants
if necessary.
Dry thoroughly before use.

11
Warranty
This warranty is provided by
Novis Healthcare (ABN 45 102 735 491)
of Unit 12, 12 Mars Road Lane Cove
2066 New South Wales Australia.
Australian Consumer Law
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or may be entitled to
a refund for a major failure and compensation for
any other reasonable foreseeable loss or damage.
You are also entitled to have the goods repaired or
replaced if the goods fail to be acceptable quality
and the failure does not amount to a major failure.
Where a failure does not amount to a major failure
Novis Healthcare is entitled to choose between
providing you with a repair, replacement or refund.
To obtain compensation, you would need to provide
documentary evidence of the loss or damage
suffered and documentary evidence that such loss or
damage was a reasonable foreseeable consequence
of a failure by Novis Healthcare to comply with
a consumer guarantee under the Australian
Consumer Law.
At our option:
›goods repaired may be replaced by refurbished
goods of the same type rather than being repaired
›refurbished parts may be used to repair goods
In addition to all rights and remedies which you may
be entitled to under the Competition and Consumer
Act 2010 (Commonwealth) and any other relevant
legislation, Novis Healthcare warrants each of
its products to be free of defects in materials and
workmanship for a period of 12 months (unless
otherwise stated), commencing from the date the
product is received by the purchaser.
Product Warranty
In addition to all rights and remedies which you may
be entitled to under the Competition and Consumer
Act 2010 (Cth) and any other relevant legislation,
Novis Healthcare warrants each of its products will,
with normal use and service to be free from faulty
parts, manufacture or workmanship for a period of
12 months (unless otherwise stated), commencing
from the date of purchase.
Subject to the provisions of the Australian Consumer
Law, Novis Healthcare excludes, to the fullest extent
permitted by law, all liability in respect of loss of
profit or other economic loss, direct or indirect or
consequential, special, general or other damages
or other expenses or costs which may include
negligence.
Warranty Claims
To claim under this warranty, please contact Novis
Healthcare and have your receipt or proof of
purchase available. Novis Healthcare may need to
assess the defect before determining any claim, and
additional information may be requested to process
your claim.
Any expenses incurred relating to the return of the
defective product to Novis Healthcare will be borne
by us. We will then, at our discretion, either repair or
replace the product, or refund your money and take
back the product. Warranty repairs do not extend
the length of the warranty period.
Limited Liabilities
Our liability under this manufacturer’s warranty is
subject to us being satisfied that a defect was caused
by faulty parts, manufacture or workmanship, and
was not caused or substantially contributed to by
other factors or circumstances beyond our control,
including (but not limited to) defective installation,
maintenance or repair, product modification
or alteration, any neglect, misuse, or excessive
use, normal wear and tear or failure to follow
manufacturer’s instructions.
The benefits conferred by this manufacturer’s
warranty are in addition to all rights and remedies
conveyed by the Competition and Consumer Act
2010 (Cth), and any other statutory rights to which
you may already been entitled, and this warrant
does not exclude, restrict or modify such rights or
remedies that are implied by law.
Mail To
Novis Service Centre:
Unit 12, 12 Mars Road Lane Cove NSW 2066
For more information please contact us on
1300 738 885, email [email protected]
or visit www.novis.com.au

Code BL1393 BL1317
Seat width 405 mm 457 mm
Chassis Aluminium
Safe working load 110 kg
Complies to ARTG 176832
Product weight 16 kg
Seat height 470 mm
Seat depth 410 mm
Seat back height 410 mm
Front wheels 180 mm (solid)
Rear wheels 305 mm (pneumatic)
Manufacturer Novis Healthcare
Specifications
bringing you the world in health
Novis Healthcare ABN 45102 735 491
12/12 Mars Road Lane Cove 2066
New South Wales Australia
T1300 738 885 www.novis.com.au
