Convair Magicool User manual

™
Magicool
Owners Manual
English • Español • Português • Italiano • Français • Deutsch
Nederlands • • • Suomi • Norsk • SvenskaJezyk Polski ÅëëçíéêÜ

Contents
English 02
Please read these instructions prior to using the
unit and save them for future reference.
Per favore leggete queste istruzioni prima di usare
l'apparecchio e preservarlo da danneggiamenti.
Português 14
Italiano 20
Français 26
Nederlands 38
44
50
Suomi 56
Norsk 62
Svenska 68
Español 08
Deutsch 32
Sírvase leer estas instrucciones antes de usar la
unidad y guárdelas como referencia para el futuro.
Por favor leia estas instrucções antes de usar o
aparelho e guarde-as Como referência para o futuro.
Veuillez lire ces consignes avant d'utiliser l'appareil
et les conserver pour toute référence ultérieure.
Bevor Sie Ihr neues Kühlgerät nutzen, lesen Sie bitte
sorgfältig diese Gebrauchsanweisung. Bewahren Sie
sie zum späteren Nachschlagen gut auf.
Vennligst les denne bruksanvisningen før
kjøleapparatet tas i bruk. Oppbevares til fremtidig bruk.
Gelieve deze aanwijzing te lezen voordat u het
apparaat gebruikt en bewaar hem voor later.
Ole hyvä ja lue nämä ohjeet ennen laitteen
käyttöä ja säilytä ne myöhempää käyttöä varten.
Var så god och läs dessa instruktioner innan du använder
apparaten och spara dem för framtida hänvisning.
Jezyk Polski
Prosimy o przeczytanie instrukcji przed przyst pieniem do
korzystania z klimatyzatora i o zachowanie ich do przysz ego u ytku.
à
ù ý
ÅëëçíéêÜ

01
01
Waste electrical products must not be disposed of with household waste.
This product should be taken to your local recycling centre for safe
treatment.
Los desechos eléctricos y electronicos no se deben disponer a la basura.
Este producto se debe llevar a su centro de reciclaje local para el
tratamiento seguro.
Produtos eléctricos para deitar fora não devem ser despejados junto com
o lixo doméstico. Este produto deve ser levado para o centro de
reciclagem local para que seja tratado de forma segura.
I refiuti elettrici non devono essere smaltiti insieme ai rifiuti domestici.
Questo prodotto dovrebbe portato al centro di riciclaggio locale per uno
smaltimento sicuro.
Déchets d’équipements électriques et électroniques ne diovent pas tre
débarrassés avec les déchets domestiques. Ce produit devrait tre pris
votre déchetterie communale pour un traitement systématique.
ïññßììáôá. ÁõôÜ ôá ðñïúüôá ðñÝðåé íá ôá ðáßñíåôå óôï êïíôéíüôåñï
ôïðéêü êÝíôñï áíáêýêëùóçò ãéá áóöáëÞ ìåôá÷åßñéóç.
ê
ê à
Elektro- und Elektronikaltgeräten sollen nicht als unsortierten
Siedlungsabfall beseitigt werden. Dieses Produkt muss zur Entsorgung
an Ihren Wertstoffhof abgeliefert werden.
Elektro- und Elektronikaltgeräten sollen nicht als unsortierten
Siedlungsabfall beseitigt werden. Dieses Produkt muss zur Entsorgung
an Ihren Wertstoffhof abgeliefert werden.
Afgedankte elektrische producten mogen niet bij het gewone huisvuil
worden gezet. Breng dit product naar uw plaatselijke milieustraat zodat
het op de juiste wijze wordt behandeld.
Nie wolno wyrzuca odpadów pochodz cych z produktów elektrycznych
wraz z odpadami pochodz cymi z gospodarstwa domowego. Produkty te
powinny by zabrane do lokalnego punktu utylizacji w celu ich
inaktywowania.
Kasserade elektriska apparater får inte slängas tillsammans med vanligt
hushållsavfall. Dessa produkter måste lämnas till den lokala
återvinningen.
ã à
à
ã
ÇëåêôñéêÜ ðñïúüíôá ðïõ åßíáé ãéá ðÝôáìá äåí ðñÝðåé íá ñß÷íïíôáé ìáæß ìå ôá
ïéêéáêÜ áð
Käytöstä poistettuja sähkölaitteita ei saa hävittää kotitalousjätteen
mukana.Tämä tuote pitää toimittaa paikalliselle jäteasemalle turvallista
jatkokäsittelyä varten.
Elektriske produkter som skal kasseres må ikke deponeres i
husholdningsavfallet. Dette produktet bør tas til lokal gjenvinningsbedrift
for forsvarlig deponering.
End of Life Disposal
01

Flip-out foot
Rear panel clips
Rear panel
Water filling area
Rating label
Drain plug
Handle
Controls
Front grille
Water tank
Water level
window
Wheel
G
H
I
J
K
L
A
B
C
D
E
F
Back View Component List
Front View
02
English
Congratulations on purchasing your
Convair cooler, manufactured and
backed by Convair, a world leader in
natural climate control solutions.
Please read these instructions prior
to using the appliance and save them
for future reference.
Ensuring the appliance has
adequate ventilation is important in
maintaining cooling performance.
This Convair appliance is a powerful
evaporative cooler, that will give you
plenty of cool, fresh air in summer.
Place the appliance in front of an open
door or window so that it is drawing in
fresh air. Open a door or window
opposite to create cross-ventilation.

Handle Assembly
To attach the handle, push it into the slot at
the back of the appliance until it clicks into
place. The handle has been designed to be
a permanent addition to the appliance. Do
not attempt to remove it once assembled.
The handle will make moving the appliance
easier.
01
03
Safety
When using electrical appliances please
follow these precautions to reduce the
risk of fire, electrical shock and injury to
persons.
Warning
Caution!
Caution!
Caution!
Do not move the appliance when it is
full of water
Caution!
! This appliance is not intended for
use by young children or infirm persons
without supervision.
Do not use this appliance in a closed room
when only occupied by children.
Before connecting your Convair
cooler to an electrical outlet, check that the
required voltage shown on the rating label is
the same as your power supply.
To avoid accidents and fire hazards, keep
the cord out of heavy traffic areas, never put
near heat registers, radiators or stoves. Do
not use this appliance if the plug or cord is
damaged.
Do not plug in the cord with wet
hands as electric shock may result.
This appliance is designed with a safety
feature so that if the rear panel is removed
the appliance will not operate. Do not
attempt to defeat this safety feature.
Use this appliance for the intended use only.
Do not use this appliance outdoors.
Your Convair cooler
holds water so be sure to move it carefully.
- it is advisable to move it into
position before filling it.
Always switch your Convair
cooler off and unplug it before filling it with
water, cleaning it or servicing the appliance.
At the end of each season, or at least
monthly if heavily used, it is advisable to
carry out some simple maintenance on your
Convair cooler. Refer to the Maintenance
section.
English
The flip-out foot can be used to increase the
angle of the air flow.
Hold the cooler firmly at the top and lean it
slightly backwards. Locate the foot at the
bottom of the tank and pivot it forward until it
locks into place. Return the cooler to its
upright position, so it is resting, at the front,
on the flip-out foot. You should now notice
the cooler angled back slightly increasing
the height of the air flow.
Flip-out foot
02

English
5. Ensure that there is adequate cross-
ventilation in the room by leaving a door or
window open opposite the cooler.
6. Plug the Convair cooler into the
electrical outlet and turn the power on.
7. Turn the comfort control knob ( ) to
the ‘on’position.
8. Turn the fan ( ) to the desired speed.
! Maximum moisturizing capacity will
not be reached until the moisturizing pad is
completely saturated. This may take several
minutes.
Note
05
ILL1258-C
06
ILL1259-C
9. If the desired comfort level is not
achieved after this time, increase the fan
speed. Lower fan speeds provide
quieter operation.
07
ILL1260-C
08
ILL1261-C
07 08
05
06
Operation
1. Place the cooler in front of an open
window or door so that it is drawing in fresh
air.
2. Pour clean water into the opening at the
back of the appliance. The maximum
water capacity of the Convair cooler is 13
litres. The minimum amount of water
required to operate the pump is 1.9 litres. No
damage occurs to the appliance when it is
operated without water.
3. Fill the appliance with water until the
water reaches the maximum fill level
indicated inside the tank.
4. Refill the appliance with clean water
whenever the water level in the
window is low.
Caution! Do not overfill the appliance as
water will spill on the floor.
04
03
04
03
04

2. To gain access to the inside of the
appliance remove the rear panel by
disengaging the clips at the top. Pivot the
rear panel backwards and lift it off. Take care
when removing the rear panel as water may
drip from the cooling pad secured to the
inside of the panel.
10. If the room becomes too cool or too
humid, turn the comfort knob ( ) off and /or
turn the fan knob ( ) to a lower setting.
11.Turn your Convair cooler off by turning
the fan knob ( ) ‘off’.
Ensure that the Convair cooler is switched
off and the plug is removed from the
electrical outlet before any maintenance is
performed.
To clean the exterior of the appliance use a
damp cloth and mild household detergent.
Maintenance
Note: The tank must be drained of water
before the appliance is stored.
At the end of each season, or more often if
heavily used, it is advisable to carry out
some simple maintenance on your Convair
cooler. This will help maintain its high
performance.
1. Drain the water from the appliance. Move
it to a drain and remove the drain plug
located on the bottom of the tank. When the
appliance is empty replace the plug in the
tank.
English
3. Wash the cooling pad with a gentle spray
of water while it is still in the rear panel. Do
not use a high pressure hose to clean the
pad. Replace the pad if salt has built-up on
the pad as it will reduce the Convair cooler’s
performance.
09
ILL1262-C
10
ILL1263-C
11
13
12
11
10
09
12
05

6. Replace the rear panel by placing the
bottom of the rear panel in the tank and
pivoting it forward until the clips engage.
A n y a d d i t i o n a l m a i n t e n a n c e o r
servicing should only be performed by
qualified personnel. Failing to do so may
void your warranty.
4. Clean the tank and the perforated water
strainer located in the tank by using a damp
cloth and mild household detergent. Do not
use abrasive cleaners or solvents. Remove
any foreign matter. This will ensure that the
strainer does not clog up during operation.
5. If the pump drive belt needs
replacing, remove it from the pulleys.
Ensure that the belt is replaced in the same
orientation as shown in the diagram so that
the pump rotates in the right direction.
06
English
12
13
13
14
1415
15
16
14
15
16

Espanol
07
Condition
1. Appliance will not
operate .
2. Appliance stops
operating after
running for some
time.
3. No cooling.
4. Appliance causes an
unpleasant odor.
5. Appliance makes
scraping or rattling
noise.
6. Water overflows from
the tank.
7. Damaged power
supply cord.
8. Too much moisture
or room is too cool.
Possible Cause
1.1 Power outlet or supply is faulty.
1.2 Wrong voltage.
2.1 Motor has overheated (safety
cutout).
3.1 Comfort control knob is off.
3.2 Tank is empty or nearly empty.
3.3 Pad and/or pump is blocked or
dirty.
3.4 Pump is not working properly.
3.5 Pump drive belt faulty or broken
4.1 Tank or pad is dirty.
4.2 Water quality is poor.
5.1 Dirt has built-up in the pump.
6.1 Too much water in the tank.
1.3 Electrical fault.
Remedy
1.1.1 Check the power supply.
1.1.2 Check the power outlet.
1.2.1 Check that the power supply is the same as
that specified on the appliance’s rating label.
2.1.1 Wait 30-45 minutes for the motor to cool down. It
should restart automatically. If this condition
persists, take the cooler to a service agent.
3.1.1 Turn the comfort control knob to ‘on’.
3.2.1 Fill the tank with water until the water reaches the
maximum water level mark (13 litres).
3.3.1 Clean the parts. See Maintenance section.
3.4.1 The pump is not a separate electric pump. It is
connected to the fan and motor and is driven
mechanically. Turn the cooler off and drain the
tank completely. Refill with clean water. Switch fan
knob to high speed, turn the cool knob to ‘on’
and run the cooler for 10-15 minutes. This will
help to flush out the dirt. The pad should now be
wet. If the pad is not wet then the pump is still
clogged and you should have the cooler checked
by a service agent.
3.5.1 Replace the drive belt. See Maintenance section.
4.1.1 Drain the tank and fill the cooler with clean water.
If the odor persists, clean run the cooler for 10-15
minutes then repeat the process. If the odor still
persists, clean the tank and clean or replace the
cooling pad.
4.2.1 Add vanilla essence or perfume to the water.
5.1.1
5.1.2 Replace the drive belt. See Maintenance section.
6.1.1 Drain some water out.
7.1.1 If the power supply cord is damaged it should be
replaced by an authorised service agent.
8.1.1 Reduce the fan speed and/or turn the water off.
See Operation section.
1.3.1 Electrical parts must only be repaired and
replaced by Authorised Service Agents.
Clean the parts. See Maintenance section.
Troubleshooting
English
As the policy of this company is one of continuous improvement, all specifications are subject to change without notice.

Vista posterior Lista de Componentes
Español
Vista frontal
08
Español
Felicidades por su compra de Convair
climatizador, fabricado y garantizado por
Seeley International, líder mundial en
soluciones de control de climatización
natural.
Antes de usar el climatizador, lea estas
instrucciones y guárdelas como
referencia para el futuro .
El Convair climatizador es también un
poderoso climatizador adiabático, que le
brindará aire frío y puro. Coloque el
climatizador con la parte posterior del
mismo junto una puerta o ventana abierta
al exterior de manera que pueda
absorver el aire (15 CMS. SON
SUFIENTES). Abra una puerta o una
ventana en el otro lado de la habitación
para expulsar el aire viciado y conseguir
renovar el aire de la sala constantemente.
Manija
Controles
Parrilla frontal
Tanque de agua
Indicador del nivel de
agua
Ruedas
A
B
C
D
E
F
Pie rebatible
Clips del panel
trasero
Panel trasero
Boca para el llenado
de agua
Etiqueta de ráting
Tapón del drenaje
G
H
I
J
K
L
