convenience concepts NORTHFIELD HALL CONSOLE Series User manual

ASSEMBLY INSTRUCTIONS
We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,
step by step instructions will guide you through the project from start to finish .
Feel confident that this will be a fun and rewarding project . The final product will be a quality
piece of furniture that will go together smoothly and give years of enjoyment .
Please do not return to the store
Broken or missing parts?
Need help with assembly?
If you have any questions just call 1-800-468-6447 or email us at
[email protected]
STOP
NORTHFIELD HALL CONSOLE
111091WW 111091CH 111091W
111091WGY 111091BL 111091A

Panel List
Hardware List
Page 2 of 3
AB C D
Assembling the unit with camlocks and wood dowels.
Gently screw cam
bolt into the
threaded anchor.
Screw the camlock
firmly into locked
posion.
Lightly glue one end of
the wood dowel and tap
halfway into hole.
Lightly glue wood dowel and
connect to second panel by
inserng dowels into holes.
Arrow must face hole
Cam bolt ( 14pcs ) Camlock ( 14pcs )
Wood dowel ( 4pcs )
Glue ( 1pc )
Front support panel (1pc)
Le side panel (1pc) Right side panel (1pc)
Back support panel (1pc)
Top panel (1pc)
1
2
3
5
4

1.Place top panel upside down on carpet or another so surface .
2.Screw cam bolts (A) into top panel .
3.Insert wood dowels (C) into top panel
using glue (D) instrucons from page 2 .
A
A
A
A
A
A
A
C
C
D
D
Page 3 of 3
Step 1
Step 2
Step 3
B
B
B
B
B
B
B
C
1
1
1
2
2
2
3
3
3
5
5
5
5
5
5
4
4
4
1.Screw cam bolts (A) into le side panel and right side panel .
2.Insert camlocks (B) into front support panel
and back support panel .
3.Connect side panels to support panels as shown ,
by gently ghtening camlocks.
1. Connect the top panel to unit by gently ghtening camlocks .
2. Turn table over and enjoy .
X 8
X 6
B
X 8
A
X 6
X 4
X 1
