ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Page 1 of 11
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Page 2 of 11
Need help!
Call us on
1300 527 665
www.jasonl.com.au
E
Table top x4
Table top Return x4
Legs Quadro Square x2
Legs Quadro Square Return x4
Connector frame x1
Beam: Main desk x4
Beam: Return x4
Plastic bracket x24
Joiner plates x8
A
B
C
D
E
F
G
H
I
Allen key x2O
M8x20MM CSK x12
M8x20MM Socket head x16
M6x20MM Socket head x24
M6x30MM Socket head x32
Join plates Screws x32
J
K
L
M
N
COMPONENTS
SCREWS
G
F
H
I
J K L M N
A
B
C
D

ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Page 3 of 11
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation
First we will set up the
workstation frame
without the returns

ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Using Allen Key provided, attach 4 plastic brackets (H) per leg
(C) (as per picture above) using M6x20MM (L) Socket head
screw. Do the same with Connector frame (E).
Using Allen Key provided, attach M8x20MM Socket head (K)-
screw socket half way into leg for both legs (C) and into
Connector frame (E).Page 4 of 11
Need help!
Call us on
1300 527 665
www.jasonl.com.au
K
L
STEP 01 STEP 02
C
E
H

ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
STEP 03
Adjust extendable beam (F) to desired
length using markers and secure beam
at that length using screws provided
Page 5 of 11
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Attach beam (F) to legs (C) and Connector frame (E)
using nut insert in legs. See point attached
Frame looks like this. Using Allen Key, attach beam (F) with Socket (J)
STEP 05
Page 6 of 11
Need help!
Call us on
1300 527 665
www.jasonl.com.au
J
J
J
J
J
J
J
J
STEP 04
TOP VIEW
C
F
E

ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Page 7 of 11
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation
We can now add the
return frames to the
main workstation

J
D
G
STEP 06
Now attach the return beams (G) to return legs (D) using nut insert in legs. See point attached.
Then, connect the hook of the return beam to the beam of the main structure.
Page 8 of 11
ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au

N
I
B
STEP 07
Page 9 of 11
Attach Connector Plates (I) to Return Top (B) by tightening Screws (N)
ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au

STEP 8
Page 10 of 11
Place table tops (A) on top of frame - with cutout at the back of the desk.
Using nut inserts in the desk, use M6x30mm socket (M) and attach desktop to the frame.
Using nut inserts in the desktop, use M6x30mm socket (M) and attach return desktops (B) to the frame.
Once desktop are attached and secure to the frame, use woods screws (N) and secure joiner plates (I) to the underside of desktop A.
nut insert nut insert
TABLE TOP
BOTTOM VIEW
M
I
N
B
A
nut insertnut insert
ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
A

ASSEMBLY INSTRUCTIONS
Quadro Square leg 4 person
corner workstation
H configuration
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
Page 11 of 11
STEP 9
Bring partition towards one another as on the picture. Using an Allen key remove top caps from the four screens uprights where they meet
(circles painted in gray).
Slide 2 way connectors rod - down between the 2 centre screens and slide the 3 way 90 degree connector rod -down between the end screens.
Under the desktops, use l-shaped panel brackets to secure the screens to the table tops (A)(B). Place two brackets in each screen.
Floor based screen divider assembly instruction:
If you
purchased with
screens divider
