LOGAN DOUBLE LATERAL FILE


Date:9‐Mar‐16www.potterybarn.com  Page2of8
Rev:  


Important Safety Instructions:
Please read all instructions carefully before assembling.
For your safety, assembly by two or more adults is strongly recommended.
Keep instructions for future use.
Use only vendor supplied hardware to assemble. Using unauthorized hardware could jeopardize the structural
integrity of the item.
Pre-assembly:
Remove all parts and hardware from the box and lay out on a clear carpeted or scratch-free work surface, as
this will avoid damaging parts during assembly. The shipping box provides an ideal work surface.
Do not dispose of any packaging or contents of the shipping carton until assembly is completed to avoid
accidentally discarding small parts or hardware.
Use the parts and hardware lists below to identify and separate each of the pieces included.
The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.
The use of power tools to aid in assembly is not recommended. Power tools can damage hardware and split
wood.
Parts Included:
(A) Cabinet 1x










Tools Required (not included):
Philips Head Screwdriver
Hardware Included:
(B)
Connecting screws

M4x25mmL
(C)
Sleeve Nut

M4x19mmL
(D)
Drill Bit
5mm
(E)
Allen Key

4mm
Anti-Tip Kit
2x2x1x1x
A


Date:9‐Mar‐16www.potterybarn.com  Page3of8
Rev:  


Assembly Instruction Steps:
1. Optional: The File bar can be move to the front position as shown below.
2. Remove the upper drawer by pressing the plastic locks on the side drawer slides upwards and downwards as
shown while pulling drawer out.















3. If need to pull out the bottom drawer, push back the front wing ofAnti-Tilt guards as shown.And then pull out the
bottom drawer as step 1.















Date:9‐Mar‐16www.potterybarn.com  Page4of8
Rev:  


4. Adjusting the levelers:
Due to an uneven floor, the furniture may not sit level due causing it to wobble. If the furniture wobbles,
determine which corner does not touch the ground correctly. With two people follow these steps:
1) Adjust the levelers using the Allen key (E) on the interior holes of the bases until adequate contact will be
made with the floor.
2) Gently set down the piece and check stability and door alignment.
3) Repeat steps until furniture sits firmly and the doors are properly aligned.



















5. Fully extend the bottom slides, align the slides on the drawer boxes with the slides on base and install the
drawers back.




















E


Date:9‐Mar‐16www.potterybarn.com  Page5of8
Rev:  


6. Fully close the bottom drawer and then install the upper drawer back to the base.
























To secure units together, follow the steps 7:
7. If it is placed next to another base, use Drill Bit (D) to drill through the pre-drilled holes on the side panel, and
then move these two bases together, secure with Connecting Screws (B) and Sleeve Nut (C) by a Philips Head
Screwdriver.
C
B
D
! WARNING
These drawers are equipped with Anti-Tilt
guards which prevent both drawers being
pulled out at the same time. Only one
drawer can be open at a time to prevent
the cabinet from tipping over.
DO NOT REMOVE THIS LABEL


Date:9‐Mar‐16www.potterybarn.com  Page6of8
Rev:  


To place hutch on this, follow the steps 8:
8. Using the pilot holes on the top of base as a guide, bore holes using a drill with the 5mm drill bit (c). Carefully lift
the hutch onto the base and align the holes under the hutch with the pre-drilled holes on the top of the base,
secure using the connecting screws and sleeves enclosed in the hardware packet of hutch. Tighten with the
Phillips head screwdriver.
D


Date:9‐Mar‐16www.potterybarn.com  Page7of8
Rev:  


9. Assembly is complete.
NOTE: USE THE ANTI-TIP KIT PROVIDED TO SAFELY SECURE YOUR PRODUCT(S). FOLLOW THE
INSTRUCTIONS PROVIDED TO PREVENT SERIOUS INJURY FROM TIPPING FURNITURE.
Possible configurations:
Care Instructions:
Dust often using a clean, soft, dry and lint-free cloth.
Blot spills immediately and wipe with a clean, damp, cloth.
We do not recommend the use of chemical cleansers, abrasives or furniture polish on our lacquered finish.
Hardware may loosen over time. Periodically check to make sure all connections are tight.
Re-tighten if necessary.
Thankyouforyourpurchase
Stores|catalog




Date:9‐Mar‐16www.potterybarn.com  Page8of8
Rev:  


Importedby/Importépar/Importadopor
WILLAMS-SONOMA INC.
3250 Van Ness, SF CA 94109, US
CANADIAN DISTRIBUTION ADDRESS/ ADRESSE DE DISTRIBUTION CANADIENNE / DIRECCIÓN DE DISTRIBUCIÓN EN CANADÁ:
3401 Dufferin St. Space 215, Toronto, Ontario, M6A2T9, CA
FURNITURETIPPINGRESTRAINT
WARNING:Thisproductisonlyadeterrent.Itisnotasubstituteforproperadultsupervision.Manufacturer
assumesnoliabilityforimproperinstallationorexcessiveloadsplacedonscrews,bracketsorstraps.

Youngchildrenmaybeinjuredbytippingfurnitureandtheuseofatippingrestraintishighlyrecommended.

Whenproperlyinstalled,thisrestraintwillprovideprotectionagainsttippingoffurniture.Thistippingrestraint
MUSTbesecuredtoawall‐studorwallstructureofsimilarstrength.

Hardwareincluded:
(2)Brackets(1)NylonStrap
(2)LongStudMountingScrews(2)ShortFurniture‐SideMountingScrews

Note:Forsafemountingitisessentialtousetheproperhardwareforyourwalltype.Theincludedhardwareisfor
drywallorstudmountingonly.Forotherwalltypes(e.g.,plaster,concreteandbrick)pleaseconsultyourlocal
hardwarestoreforfasteneradvice.

Toinstall:

1) LOCATINGTHESTUDS:Useastudfindertolocatetheverticalwoodenstudswithinyourwalllocated
behindthefinalpositionofthefurnitureitem.Markthestudlocationswithalightpencil‐mark.

2) MOUNTINGTHEFURNITURE‐SIDEBRACKET:Movethefurnitureitemclosetothewalltoitsfinalposition.
Usepiecesoftapeorapenciltotranscribethestudlocationsofthewallontothefurnitureitem.Movethe
furnitureitemagainsoyoucanaccessitsbackandusethemarkstolocateasuitablemountingpointforthe
furniture‐sidebracket.Makesurethatthebracketissecuredtoafirmportionofthefurnitureframeandashigh
aspossible.Remember:Thefurniture‐sidebracketmustbepositionednearawallstud.Usingapencil,andthe
bracketasaguide,mark“screwmarks”onthefurnitureitemthroughthebracketholes.

Usea3/32”drillbittodrillpilotholesintothefurnitureitematthe“screwmarks”.UsetheTWOShortscrews
tosecurethefurniture‐sidebracket.Thisbracketcanbepositionedeitherverticallyorhorizontalasnecessary
(SeeFigure1).

3) MOUNTINGTHEWALL‐SIDEBRACKET:Positionthewall‐sidebracketalongtheselectedstudmarksothatit
willbeadjacentthefurniture‐sidebracketwhenthefurnitureitemismovedtoitsfinalposition.Thewall‐side
bracketshouldbeaboutONEinchlowerthanthefurniture‐sidebracket(SeeFigure3).UsetheTWOLong
screwstosecurethewall‐sidebrackettothewall.Remembertopositionthewall‐sidebracketverticallysothat
bothscrewswillengagetheselectedwallstud(SeeFigure2).

4) ATTACHINGTHESTRAP:Whenbothbracketsaresecurelyattached,movethefurnituretoitsfinaldesired
positionandthreadthestrapthroughtheopeningsofeachbracketandalsothroughtheratcheting“buckle”.
Tightenthestrapuntilseveral“clicks”areheard.Thefurnitureitemisnowsecurelytetheredtothewall.

Note:Ifyoumustmovethefurnitureitem,youcanreleasethestrapbydepressingtheleverarmlocatedatits
buckleandsimultaneouslywithdrawingthestrapfromthebuckle.Makesuretoreconnectthestraponcethe
furnitureitemisreturnedtoitspreviousposition.

Figure 1 Figure 2 Figure 3
