Safety 02

EN Before you start

These instructions are for

your safety. Please read the

following instructions and the

sections of “Installation, Care

and maintenance” carefully

before proceeding with the

installation and use of this

appliance. Keep the instruction

manuals for future reference.

WARNING: All installation

work must be carried out by

a suitably qualiﬁed person,

strictly following local

building regulations and these

instructions.

• To avoid the risks that are

always present when you use

an electrical appliance it is

important that this electric

hob is installed correctly

and that you read the safety

instructions carefully to avoid

misuse and hazards. After

unpacking the electric hob

please check that it is not

damaged. If in doubt, do not

use the appliance but contact

Customer Services on

0800 324 7818 (UK) and

1-800 932 230 (Eire).

• Check the package and make

sure you have all of the parts

listed and decide upon the

appropriate location for your

product.

• As this product contains

glass please take care with

ﬁtting or handing to prevent

personal injury or damage to

the product.

• The speciﬁcation plate shown

on this appliance displays all

the necessary identiﬁcation

information for ordering

replacement parts.

• If you sell the appliance, give

it away, or leave it behind

when you move house, please

ensure that you pass on this

manual so that the new owner

can become familiar with

the appliance and its safety

warnings.

Safety

WARNING: Before connecting

the hob, check that the

supplied voltage and

frequency match with that

indicated on the appliance

rating plate.

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 2211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 2 07-01-2021 10:42:4907-01-2021 10:42:49

Safety 03

• Failure to install the appliance

in accordance with these

instructions may result in a

safety hazard.

• If in doubt, ask for advice

in store or from a qualiﬁed

installer.

WARNING: Consult local

regulations regarding

extraction outlets and ensure

these are complied with.

WARNING: This appliance

can be used by children

aged from 8 years and

above and persons with

reduced physical, sensory

or mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and understand the

hazards involved. Children

shall not play with the

appliance. Cleaning and user

maintenance shall not be

made by children without

supervision. Keep the

appliance and its supply cord

out of the reach of children

less than 8years old.

• Do not use inappropriate child

safety shields or hob guards.

These can cause accidents.

• Do not use covers. These

can cause accidents or

overheating and damage to

the electric hob.

• We recommend that great

care be taken during use and

cleaning. Read the cleaning

and maintenance sections of

this appliance carefully.

• Risk of electric shock! Do

not use any high pressure

cleaners or steam cleaners,

which can result in an electric

shock.

• Danger of burns! The

hotplates and surrounding

area become very hot. Never

touch the hot surfaces. When

a cooking zone has been in

use, the surface remains hot

for some time afterwards. Be

careful not to touch the hot

surface and not to place any

objects on it.

• After use, switch off the hob

element its control and do not

rely on the pan detector.

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 3211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 3 07-01-2021 10:42:4907-01-2021 10:42:49

Safety 04

• Metallic objects such as

knives, forks, spoons and lids

should not be placed on the

hob surface since they can

get hot.

• Never use water to put out

burning oil or fat. Switch

off the hotplate. Extinguish

ﬂames carefully using a ﬁre

blanket.

• Risk of ﬁre! The hotplates

become very hot. Never place

combustible items on the hob.

• Never store objects on the

hob.

• Risk of ﬁre! Do not use

ﬂammable sprays in close

vicinity to the appliance.

• Risk of ﬁre! Do not store

detergents or ﬂammable

materials beneath the hob.

• This appliance is intended

for domestic use only. The

appliance must only be used

for the preparation of food

and drink.

• The appliance must be

supervised during operation.

Only use this appliance

indoors.

• The manufacturer declines

all liability for personal or

material damage as a result

of misuse or incorrect

installation of this appliance.

Please dispose of the packing

material carefully.

• Risk of injury! Saucepans may

suddenly move due to liquid

between the pan base and

the hotplate. Always keep

the hotplate and saucepan

basesdry.

WARNING: There is a risk

of electric shock and ﬁre if

cleaning is not carried out

in accordance with these

instructions.

WARNING: Use only the same

size of ﬁttings and mounting

screws as recommended

in this instruction manual.

Failure to follow these

instructions may result in

electrical hazards.

WARNING: Switch off the

appliance at the mains supply

before carrying out any

maintenance work.

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 4211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 4 07-01-2021 10:42:4907-01-2021 10:42:49

Safety 05

WARNING: Accessible parts

may become hot when used

with cooking appliances.

Young children should be kept

away. Care should be taken to

avoid touching the appliance.

WARNING: Means for full

disconnection must be

incorporated in the ﬁxed

wiring in accordance with the

local wiring installation rules

for your country. An all-pole

disconnection switch having a

contact separation of at least

3 mm in all poles should be

connected during installation.

WARNING: Only clean the

hob when it has cooled down

sufﬁciently. When the power

to the cooktop is switched off,

there will be no residual heat

indication but the cooking

zone may still be hot. Take

extreme care!

WARNING: Unattended

cooking on a hob with fat or

oil can be dangerous and may

result in ﬁre. NEVER try to

extinguish a ﬁre with water,

but switch off the appliance

and then cover ﬂame e.g. with

a lid or a ﬁre blanket.

CAUTION: The cooking

process has to be supervised.

A short term cooking

process has to be supervised

continuously.

WARNING: Danger of ﬁre: do

not store items on the cooking

surfaces.

WARNING: Use only hob

guards designed by the

manufacturer of the cooking

appliance or indicated by the

manufacturer of the appliance

in the instructions for use

as suitable or hob guards

incorporated in the appliance.

The use of inappropriate

guards can cause accidents.

WARNING: If the surface

is cracked, switch off the

appliance to avoid the

possibility of electric shock.

• The appliance is not intended

to be operated by means of

an external timer or separate

remote-control system.

• If the supply cord is damaged,

it must be replaced by the

manufacturer, its service

agent or similarly qualiﬁed

persons in order to avoid a

safety hazard.

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 5211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 5 07-01-2021 10:42:4907-01-2021 10:42:49

Safety 06

IMPORTANT: Heavy-duty scourers, some nylon scourers and

harsh/abrasive cleaning agents may scratch the glass. Always

read the label to check if your cleaner or scourer is suitable.

IMPORTANT: Never leave cleaning residue on the cooktop; the

glass may become stained.

IMPORTANT: The appliance is for domestic use as a cooking

device; do not use as a source of heat.

Installation

All installation must be carried out by a competent person or

qualiﬁed electrician. Before connecting the mains supply ensure

that the mains voltage corresponds to the voltage on the rating

plate.

Direct connection

• The appliance must be connected directly to the mains using

an omnipolar circuit breaker with a minimum opening of 3mm

between the contacts.

• The installer must ensure that the correct electrical connection

has been made and that it complies with the wiring diagram.

• The cable must not be bent or compressed.

• Regularly check the power cord for damage.

WARNING: This is a Class I appliance and MUST be earthed.

• The appliance is supplied with a 4 core mains cable coloured as

follows:

Brown = L2

Black = L1

Blue = N or Neutral

Green and Yellow = E or Earth

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 6211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 6 07-01-2021 10:42:4907-01-2021 10:42:49

Safety 07

WARNING: Securely crimp the two Live cables together

(L1 and L2) before connecting them to the Live terminal of

themains supply.

WARNING: Before obtaining access to the terminals, all supply

circuits must be disconnected.

32 A~

220-240 V~ 50Hz

This appliance should be connected directly to the consumer

unit with a 32Amp Residual Current Device (RCD) protecting

itscircuit.

To avoid the risks that are always present when you use an

electrical appliance it is important that this appliance is installed

correctly and that you read the safety instructions carefully to

avoid misuse and hazards. Please keep this instruction booklet

for future reference and pass it on to any future owners. After

unpacking the appliance please check that it is not damaged. If in

doubt, do not use the appliance but contact Customer Services.

The manufacturer declines all liability for damage caused to

persons and objects due to incorrect or improper installation of

the appliance. Any permanent electrical installation must comply

with the latest wiring regulations applicable to your country and

for your own safety a qualiﬁed electrician or contractor should

undertake the electrical installation.

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 7211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 7 07-01-2021 10:42:4907-01-2021 10:42:49

Safety 08

Technical data

Supply voltage 220-240V~ 50Hz

Max. power consumption 5500 - 6600W

Dimensions (W x D x H) 590 x 520 x 55mm

Symbol Value Unit

Model identiﬁcation CLCER65

Type of hob Electric hob

Number of cooking zones and/or areas 4 zones

Heating technology (induction cooking

zones and cooking areas, radiant cooking

zones, solid plates)

Induction cooking areas

For circular cooking zones or area:

diameter of useful surface area per

electric heated cooking zone, rounded to

the nearest 5mm.

Ø Front left zone: 20

Rear left zone: 16.5

Rear right zone: 20

Front right zone: 16.5

For non-circular cooking zones or areas:

length and width of useful surface area

per electric heated cooking zone or area,

rounded to the nearest 5mm

L, W - cm

Energy consumption per cooking zone or

area calculated per kg EC

electric

cooking

Front left zone: 180.7

Rear left zone: 192.9

Rear right zone: 180.7

Front right zone: 209.1

Wh/ kg

Energy consumption for the hob EC

electric hob

190.9 Wh/ kg

The measurement and calculation method of the above table was done in accordance with commission

regulation(EN) No 66/2014.

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 8211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 8 07-01-2021 10:42:4907-01-2021 10:42:49

Safety 09

Troubleshooting

Problem Possible cause Solution

The hob cannot be

turned on. No power. Make sure the ceramic hob is connected

to the power supply and that it is

switched on.

Check whether there is a power outage

in your home or area. If you’ve checked

everything and the problem persists, call

the Customer service helpline.

The touch controls

are unresponsive. The controls are locked. Unlock the controls. See the section

‘Locking the Controls’ in the instructions.

The touch controls

are difﬁcult to

operate.

There may be a slight ﬁlm of

water over the controls or

you may be using the tip of

your ﬁnger when touching the

controls.

Make sure the touch control area is dry

and use the ball of your ﬁnger when

touching the controls.

The glass is being

scratched. Rough-edged cookware.

Unsuitable, abrasive scourer

or cleaning products are being

used.

Use the correct cookware and follow the

guidance in ‘Care and Maintenance.

Pans make

crackling or

clicking noises.

This may be caused by the

construction of your cookware

(layers of different metals

vibrating differently).

This is normal for cookware and does

not indicate a fault.

Recycling & disposal

Waste electrical products (WEEE) should not be disposed of with household waste.

Please recycle where facilities exist. Check with your local governmental authority, domestic

waste disposal services or the retailer where the product was bought for recycling advice. The

wheelie bin symbol on the product or its packaging indicates that this product cannot be treated

as normal household waste. This product must be handed over to an electric and electronic equipment

collection point for recycling.

On ensuring that this product is disposed of correctly, you will help to avoid possible negative

consequences for the environment and public health, which could occur if this product is not handled

correctly.

211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 9211859_s1_s8-5059340158013-C&L-A5-SM-Safety-V01-Multi.indd 9 07-01-2021 10:42:4907-01-2021 10:42:49
