Domestic
Electric convector heater with weekly program control
Электрический конвектор с недельным программатором
Електричний конвектор з тижневим програматором

www.cooperandhunter.com
2
1. Important information
2. Safety measures
3. Technical characteristics
4. Description of the unit
5. Scope of delivery
6. Operation of the unit
7. Cleaning and maintenance of the unit
2
4
1. IMPORTANT INFORMATION
CONTENTS
Dear customer!
Thank you for your good choice and purchase of a
Cooper&Hunter electric heater. It will serve you for a long
time!
T o improve product quality, its design, scope of delivery or manufacturing
process can be revised without advance notice.
The text and digital notations in this manual may have misprints.
Should you have any questions on the functioning and operation of the device,
please refer to the seller or a specialized service center to receive clarification.
Use the device only for purposes, stated in this manual.
Read and follow all the Instructions In this manual even If you feel you are
familiar with the product, and find a place to keep It handy for future
reference.
For your convenience record the complete model number (located on the
product identification plate) and the date you received the product,
together with your purchase receipt and attach to the warranty and
service information. Retain in the event that warranty service is required.
NOTE:
The rating of this product (as marked on the
product identification plate) is based on specific
loading tests. Normal use or the use of other
recommended attachments may draw
significantly less power.
IMPORTANT!
When using any electrically powered
product, basic safety precautions should
always be followed.
8
3
4
5
5

www.cooperandhunter.com
3
5. Water tank 10. Power cord
11. Air outlet
IMPORTANT!
This product is NOT suitable to be used on long pile
carpetsor Flokati rugs.
2. SAFETY MEASURES
Read all instructions carefully prior t o using the device for the first time. T o
avoid electric shock or injury when using this device, always observe key safety
precautions including the following ones:
•Read all instructions before using this appliance and keep them forfuture
reference.
•Use only the voltage specified on the rating plate of the heater.
•Do not cover or restrict airflow to the inlet or exhaust grilles in anymanner
as the appliance may overheat and become a fire risk.
•Do not cover grilles, block entry or exhaust of airflow by placing
appliance against any surface. Keep all object at least 1 meter from the
front, side and rear of the appliance.
•Do not place the appliance close to a radiant heat source.
•Do not operate in areas where gasoline, paint or other flammable liquids
are used or stored.
•This appliance heats up when in use. To avoid burns, do not let bareskin
touch hot surface. Switch off and let cooling before moving.
•Do not use the appliance to dry clothes.
•Do not insert or allow foreign object or metal utensils to enter any
ventilation or exhaust opening, as this may cause an electric shock, fire or
damage to the appliance.
•Do not immerse in liquid or allow running into the interior of the
appliance, as this could create an electrical shock hazard.
•Do not reach for an appliance that has fallen into water. Switch of at
supply and unplug immediately.
•Do not operate any appliance with a damaged cord, plug or after the
appliance malfunctions or has been dropped or damaged in any manner.
Return to a qualified electrical person for examination, electrical or
mechanical adjustment, service or repair.
•Do not operate appliance with wet hands.
•The most common cause of overheating is deposits of dust or fluff in the
appliance. Ensure these deposits are removed regularly by unpluggingthe
appliance and vacuum cleaning air vents and grilles.
•Do not use this appliance in a window as rain may cause electric shock.
•Do not use a abrasive cleaning products on this appliance. Clean with a
damp cloth (not wet) rinsed in hot soapy water only. Always remove plug
from the mains supply before cleaning.
•Do not connect the appliance to the mains voltage until completely
assembled and adjusted.
•This appliance is not intended for use in outdoor locations.
•Do not use this appliance in the immediate surrounds of a bath, a
shower or a swimming pool or other liquids.
•Always operate upright.
•Switch off and let cooling before moving.
•Do not operate with cord set coiled up as a build up of heat is likely,
which could be sufficient to become a hazard.
•The use of an extension cord with this appliance is not recommended.
•Do not remove plug from power socket until the appliance has been
switched off.
•Do not remove plug from power socket by pulling the supply
cord-always grip plug.
•Always unplug appliance when not in use.
•Do not allow cord to come in contact with heated surface during
operation.
•Do not run cord under carpeting, throw rugs or runners etc. Arrange
cord away from traffic areas so that it will not be tripped over.
•Do not twist, kink or wrap the cord around the appliance, as this may
cause the insulation to weaken and split. Always ensure that all cord has
been removed from any cord storage area.
•Do not use outdoors or whilst standing on a damp floor.
•Do not store appliance while it is still hot.
•This appliance is not intended for use by young children or infirm
persons without supervision.
•Young children should be supervised to ensure they do not play with the
appliance.
•The appliance must not be located immediately below a socket-outlet.
•Do not use this appliance with another programmer, timer or any other
device that switches the heater on automatically, since a fire risk exists if
the appliance is covered or positioned incorrectly.

www.cooperandhunter.com
4www.cooperandhunter.com 4
•All covers of this appliance is intended to prevent direct access to the
IMPORTANT!
Inorder to avoid overloading, do not cover the
heater
•To reduce the risk of electric shock, do not immerse or expose the
product or flexible cord to rain, moisture or any liquid other than those
necessary for correct operation of the product.
•The fireguard does not give full protection for young children and for
infirm persons.
•If the supply cord is damaged, it must be replaced by a qualified
electrical persons in order to avoid a hazard.
•Do not use this appliance outdoors or on wet surfaces Avoid spilling
liquid on the appliance.
IMPORTANT!
In order to avoid a hazard due to inadvertent
resetting of the thermal cutout, this appliance must
not be supplied through an external switching
device, such a timer, or connected to a circuit that
is regularly on and off by the utility
•Use this appliance only as described in this manual. Any other use is
not recommended by the manufacturer and may cause fire, electric
shock or injury.
•This appliance is intended for household use only and not for
commercial or industrial use.
3. TECHNICAL CHARACTERISTICS
Table 1
Air outlet Control unit
Switch
Castor wheel stand
4. DESCRIPTION OF THE UNIT
Fig. 1 Overview of the appliance
o
Model
Number
CH
-
1000
E
CH
-
1500
E
CH
-
2000
E
Rated Power
500
W
/ 1000
W
750
W
/ 1500
W
1000
W
/
2000
W
Rated Voltage
220
V
-
240
V
~
50
Hz
Dimensions
(
mm
)
460
*
107
*
400 595
*
107
*
400
830
*
107
*
400
O

www.cooperandhunter.com 5
Heating element
KSD thermostat KSD thermostat
Temperature sensor
Switch
Tip over switch
5. SCOPE OF DELIVERY
1. Convector – 1 pc.
2. Operation manual – 1 pc.
3. Warranty card - 3 pc.
4. Packing – 1 pc.
5. Castor wheel stand – 2 pc.
6. Wall mount bracket – 2 pc.
7. Rubber emphasis in a wall – 1 pc.
8. Screw – 3 pc.
21
35 7 8 94 1 2 10 11
MON
TUE
WED
THU
FRI SAT SUN
LO HI M A
20 19 18 17 16 15 14 13 12
1. Power indicator
2. Heater element power
3. Heating indicator
4. Half Heating indicator
5. Full heating indicator
7. Manual mode indicator
8. Auto mode indicator
9. Timer indicator
10. Upwards adjustment (+) button
11. Downwards adjustment (-) button
12. Program confirm
13. Program set
14. Degrees Celsius symbol
15. Temperature indicator
16. Minute indicator
17. Hour indicator
18. Daily indicator
19. Auto & Mechanical mode
change button
20. Power button
21. Power switch
Operation guide
1. STARTING
1.1 Take out the heater from the carton carefully. Please save the
carton for off-season storage.
1.2 Make sure the power switch (21) is in the OFF position before
plugging it in.
1.3 Ensure the heater is fully assembled according to the Mounting
Guide.
1.4 It’s better not to use the same electric outlet with other high
wattage electrical appliances in order to avoid overloading your circuit.
6. OPERATION OF THE UNIT
Fig. 3 Control panel
Circuit diagram
Fig. 2 Electric circuit
so
o
6
z
TJ
O
00
Q
O
O
©
-
1
D
B
0
B
a
CD
TO
B
CO
B
<
s
D
*
f
>
1
fl
o
<
*
AN
D D
n
^
iW
°
f
D
QD
DD
D
D
DD DD
_
D
_
n
-
