NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
731
COOPER LIGHTING
SCALA
801-IW
DIRECT-INDIRECT
WALL
Construction
Housing is die formed cold rolled steel forming an
1-1/2” x 9” architectural profile. Standard 4’-0” and
8’-0” fixture lengths combine for individual or
continuous runs. 3' and 6' sections available by
special order.
End Caps
End caps are precision die-cast aluminum
mechanically attached without exposed fasteners.
Reflectors
Optical reflectors are die-formed high reflectance
white painted steel.
Electrical
Fixtures use UL listed Class P, T5 program rapid
start electronic ballasts. Power factor of 97% with
less than 10% THD. Fixtures and electrical
components certified to UL and CUL standards.
Diffusing Media
Standard ribbed semi-transparent/translucent
diffusing lens are available. Custom diffusers can
be specified (consult factory).
Mounting
Fixture mounts directly to existing structure over a
2” x 4” standard electrical box mounted
horizontally in the wall. Refer to installation section
for details.
Optional perforated top diffuser attenuates up light
and redirects energy toward task below with soft
ambient glow.
1-1/2" [38mm]
11"
[279mm]
9" [229mm]
9-1/2"
[238mm]
• Companion Pendant
• Customizable diffuser
material including
architectural glass
• Can be row mounted with
included joiners
• Use with or without diffusion
material
• Slim 1-1/2” Height x 7-1/8”
Extension
• Die-cast aluminum end caps
• Modular construction allows
easy creation of rows with
included joiners
• Precision formed steel
fixture body available in
Polished and Satin Chrome
finishes
• Companion Scala pendant
available
ORDERING INFORMATION:
Sample number: 801IW-2T5-48-1EB-SI-S28A
Series
801=Scala
Light Output
I=Indirect
Mounting
W=Wall
Number of Lamps (not included)
2=2 Lamps
Lamp Type
T5 T5HO
Run Length
Overall Nominal Run Length__ft. (Any combination of 8’, 6’, 4’ and 3’
sections)
Voltage 1
1=120V 2=277V U=Universal
Ballast
EB=Electronic Ballast (Standard) DB=Dimming Ballast
[Only slim line ballast (small case)]
Switching
SI=Single Switching DU=Dual Switching
Emergency
EM=Emergency Pack (Consult Factory)
Diffuser Type
S28A=Ribbed Clear Plastic S28C=Ribbed Blue Plastic
S28B=Ribbed Texture Plastic S28D=Ribbed Green Plastic
PT=Perforated Top Diffuser
Options
CB=Chrome housing with black gloss ends
SB=Satin housing with black gloss ends
AS=20 Watt AR70 Halogen Spot Kit (2) per 4’ section (see note)
AF=20 Watt AR70 Halogen Flood Kit (2) per 4’ section (see note)
(accent lamp kits are factory installed options)
1 Due to various constraints, some options may not be combined with others.
48"[1219mm]*
96"[2438mm]*
*Dimensions do not include end caps.
36"
72"
STANDARD LUMINAIRE LENGTHS* SPECIAL ORDER
= Slim Line Ballast only.
S
S
Position of accent lamp kits as above or specify custom location.
30” 9”
NEO-RAY™
