NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
775
COOPER LIGHTING
SURFACE
OMNI
66-DS
DIRECT
9" [229mm]
3-1/2"
[89mm]
ORDERING INFORMATION:
Sample number: 66DS-2T8-40-2EB-SI-1EM-S58
Series
66=Omni
Light Output
D=Direct
Mounting
S=Surface
Number of Lamps (per cross section) (not included)
1=1 Lamp 2=2 Lamps
Lamp Type
T8 T5 T5HO
Run Length
Overall Nominal Run Length__ft. (Any combination of 8’, 6’, 4’ and 3’
sections)
Voltage 1
1=120V 2=277V 3=347V U=Universal
Ballast
EB=Electronic Ballast (Standard) DB=Dimming Ballast
Switching
SI=Single Switching DU=Dual Switching
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR GMF
Shielding
S58=KSH-12 Clear Acrylic Prismatic Lens
S79=Semi-specular Aluminum Parabolic Baffle
1 Due to various constraints, some options may not be combined with others.
Construction
Extruded aluminum housing. Nominal 4’ or 8’
illuminated sections.
Louver
Semi-specular aluminum parabolic baffle.
Electrical
120, 277, 347 or Universal Voltage electronic ballast.
Luminaires and electrical components certified to
UL and CUL standards.
Finish
Durable, low gloss, white, powder coated acrylic
finish.
Mounting
Surface.
MOUNTING INFORMATION
• Direct light distribution.
• T5 and T8 lamping.
• Extruded aluminum housing,
nominal 4’ and 8’ illuminated
sections.
• Parabolic louver designed for
continuous unbroken
appearance.
• Pearlescent low glare louver
finish.
• .125” thick aluminum end
caps.
• Selection of 2 light diffuser
options
SHIELDING OPTIONS
S58 Acrylic Lens S79 Parabolic Baffle
86-1/4" [2191mm]
8FT 6FT 4FT 3FT
5-1/4" [133mm]
1-1/8" [29mm]
1/8" [29mm]
END PLATE
96-1/2" [2451mm]
96-3/4" [2458mm]
7/8" [22mm] HOLE (INDIVIDUAL FIXTURES ONLY)
CONSULT FACTORY FOR CONTINUOUS RUN APPLICATIONS
62-1/4" [1581mm]5-1/4" [133mm]
1/8" [29mm]
END PLATE
72-1/2" [1842mm]
72-3/4" [1848mm]
38" [965mm]5-1/4" [133mm]
1/8" [29mm]
END PLATE
48-1/4" [1226mm]
48-1/2" [1232mm]
26" [660mm]5-1/4" [133mm]
1/8" [29mm]
END PLATE
5-1/4" [133mm]
1/8" [29mm]
END PLATE
36-1/4" [926mm]
36-1/2" [927mm]
NEO-RAY™
