Cooper Lighting Shaper 1250-3R User manual

970
SHAPER™
COOPER LIGHTING
HP PENDANT
MATERIAL
Painted and plated cold
rolled steel or natural
aluminum pan with a
matte white acrylic bowl.
Acrylic Trim Rings (ATR)
or optional Glass Trim
Rings.
BALLAST
Integral CFL electronic
HPF, multi-volt 120/277V
(347V Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage. Metal Halide
ballast is electronic HPF,
multi-volt (120V/277V) for
the specified lamp
wattage. 347V MH
ballast - Contact factory.
LAMP/SOCKET
26" - Three (3) or six (6) 27W (2G11) high lumen CFL
lamps, three (3) 32W (GX24q-3) or 42W (GX24q-4)
4-pin triple CFL lamps, or three (3) 39W or 70W T6
CDM metal halide lamps, or three (3) T4 (DC Bay)
clear linear halogen lamps. One (1) 22W (2GX13) T5
circular lamp (bowl illumination).
36" - Three (3) or six (6) 27W, 39W, 40W, 50W or 55W
(2G11) high lumen CFL lamps, three (3) 32W
(GX24q-3), 42W (GX24q-4) 4-pin triple or 57W (GX24q-
5) or 70W (GX24q-6) 4-pin triple HO CFL lamps or
three (3) 35W or 70W T4 39W, 70W or 150W T6 CDM
metal halide lamps or three (3) 150W T4 (DC Bay)
clear linear halogen lamps. One (1) 40W (2GX13) T5
circular lamp (bowl lumination).
44" - Four (4) or eight (8) 27W, 39W, 40W, 50W or 55W
(2G11) high lumen CFL lamps, four (4)
57W (GX24q-5) or 70W (GX24q-6) 4-pin triple HO CFL
lamps or four (4) 70W or 150W T6 CDM metal halide
lamps, or four (4) 150W T4 (DC Bay) clear linear
halogen lamps. One (1) 40W (2GX13) T5 circular lamp
(bowl illumination).
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
Refer to specification
sheet for additional
mounting requirements.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
The 1250 Direct/Indirect High
Performance Luminous Pendant can
be specified without trim or with
Acrylic Trim Rings (ATR), Solid Metal
Trim Rings (STR) or Three Floating
Rods (3R) and is available in three
diameters with multiple mounting
options.
1250-ATR, STR
& 3R SERIES
28"
5-3/4"
32"
6-3/4"
42"
8-3/4"
1250 26" STANDARD 1250 36" STANDARD 1250 44" STANDARD
Notes:
1. Available in 26".
2. Available in 36".
3. Available in 44".
4. Available in 26" Only.
5. Available with Custom Decorative Metal Finish only.
6. Not available in 27W.
Series
Series 1250
Size
26”
36”
44”
Lamp
CFL/3/271, 2
CFL/3/321, 2
CFL/3/392
CFL/3/402
CFL/3/421, 2
CFL/3/502
CFL/3/552
CFL/3/572
CFL/3/702
CFL/4/273
CFL/4/393
CFL/4/403
CFL/4/503
CFL/4/553
CFL/4/573
CFL/4/703
CFL/6/271, 2
CFL/6/392
CFL/6/402
CFL/6/502
CFL/6/552
CFL/8/273
CFL/8/393
CFL/8/403
CFL/8/503
CFL/8/553
HAL/3/1501, 2
HAL/4/1503
MH/3/35
MH/3/391, 2
MH/3/701, 2
MH/3/1502
MH/4/703
MH/4/1503
Voltage
120V
277V
347V
Options
1SAC
3S
QP
SJCAC
SJWAC
TP1, 2
GTR1, 2
DL
DM6
FF
REM
SCA
SSW
FB
Suspension
Height
28'' (OA) - 26'' dia.
32'' (OA) - 36'' dia.
42'' (OA) - 44'' dia.
Or Specify
Stem and
Canopy Finish5
Standard - MW
Premium - CC, NA,
OBRS, PB4, PC4,
PCP4, PN4, SAL, SB,
SC, SCP, SN
Finish
Standard - MW
Premium - CC, NA, OBRS,
PB4, PC4, PCP4, PN4, SAL, SB,
SC, SCL, SCP, SN, SNL
Custom Decorative Metals
CLR, CBT, SPE, SGE, BRS,
CPR, BPL, SGN, CMP, CLE,
IDO, RBE, PWR
Pattern5
COL = Coral
SHL = Seashell
SMT = Smooth
Lamp
(Bowl)
T5/1/221,2
T5/1/403
Sample Number: 1250-26-CFL/3/27 + T5/1/22-120V-SC-FF-28
MATERIAL
Painted and plated cold
rolled steel or natural
aluminum pan. Supplied
with a single stem
assembly.
BALLAST
Integral CFL electronic
HPF, multi-volt 120/277V
(347V Canada),
thermally protected with
end-of-life circuitry
to accommodate the
specified lamp wattage.
LAMP/SOCKET
26" - Three (3) or six (6)
27W (2G11) high lumen
CFL lamps.
36" - Three (3) or six (6)
27W, 39W, 40W, 50W or
55W (2G11) high lumen
CFL lamps.
44" - Four (4) or (8) 27W,
39W, 40W, 50W or 55W
(2G11) high lumen CFL
lamps. CFL socket
injection molded plastic.
Lamps furnished by
others.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
Refer to specification
sheet for additional
mounting requirements.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
The 1270 Indirect High Performance
Pendant features a shallow solid
bowl with a floating trim and is
available in three diameters with
multiple mounting options.
1270 SERIES
28"
5-3/8"
32"
6-7/8"
42"
8"
1270 26" STANDARD 1270 36" STANDARD 1270 44" STANDARD
Notes:
1. Available in 26".
2. Available in 36".
3. Available in 44".
4. Available in 26" Only.
5. Available with Custom Decorative Metal Finish only.
6. Not available in 27W.
Sample Number: 1270-36-CFL/3/39-120V-SAL-DM-32
Series
Series 1270
Size
26”
36”
44”
Lamp
CFL/3/271, 2
CFL/3/392
CFL/3/402
CFL/3/502
CFL/3/552
CFL/4/273
CFL/4/393
CFL/4/403
CFL/4/503
CFL/4/553
CFL/6/271, 2
CFL/6/392
CFL/6/402
CFL/6/502
CFL/6/552
CFL/8/273
CFL/8/393
CFL/8/403
CFL/8/503
CFL/8/553
Voltage
120V
277V
347V
Options
1SAC
3S
QP3
SJCAC
SJWAC
TP1, 2
DL
DM6
FF
REM
SCA
SSW
Suspension
Height
28'' (OA) - 26'' dia.
32'' (OA) - 36'' dia.
42'' (OA) - 44'' dia.
Or Specify
Stem and
Canopy Finish5
Standard - MW
Premium - CC, NA,
OBRS, PB4, PC4, PCP4,
PN4, SAL, SB, SC,
SCP, SN
Finish
Standard - MW
Premium - CC, NA, OBRS,
PB4, PC4, PCP4, PN4, SAL, SB,
SC, SCL, SCP, SN, SNL
Custom Decorative Metals
CLR, CBT, SPE, SGE, BRS,
CPR, BPL, SGN, CMP, CLE,
IDO, RBE, PWR
Pattern5
COL = Coral
SHL = Seashell
SMT = Smooth
RIP = Ripples
KLP = Kelp
WVS = Waves
WTR = Waterfall
