Cooper Lighting Shaper 645 Series User manual

645 SERIES
Interior Wall Luminaire
Starter Collection
Classic Vanity
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
Catalog # Type
Date
Project
Comments
Prepared by
645 classic vanity features a rectangular shape providing
direct/indirect illumination.
SPECIFICATION FEATURES
Material
Solid aluminum construction
with a white acrylic diffuser.
Finish
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Laquered Satin
Aluminum (SAL), Matte White
(MW) or Custom Colors (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
18": One (1) 27W (2G11) high
lumen CFL lamp or two (2) 60W
A-19 lamps.
24":Two (2) 14WT5 linear
fluorescent lamps or three (3)
60W A-19 lamps. Fluorescent
socket injection molded plastic.
INC socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
Installation
Supplied with a universal
circular strap for a standard 3" or
4" J-box or plaster ring.
Options
Fluorescent Dimming Ballast -
Contact the factory for ballast
options (DM), Remote
Emergency Battery - Supplied by
others (REM), MRI Applications
(INC only) - Contact the Factory.
Damp Location (DL): All Painted
finishes only. Energy Star Rating
- Consult factory.
Labels
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
ADS042674
2008-09-15 16:19:13
Sample Number: 645-18-CFL/1/27-277V-SAL
Voltage
120V
277V 3
347V 3
Finish
Standard
NA Natural Aluminum=
Premium
CC Custom Color=
MW Matte White=
SAL Lacquered
Satin Aluminum
=
Options
DL Damp Location=
DM CFL Dimming Ballast 4
=
REM Remote Emergency Battery 5
=
Series
645 Classic
Vanity
=
Size
18"
24"
Lamp
CFL/1/27
INC/2/60 1
INC/3/60 2
T5/2/14 2
1Available in 18".
Notes:
2Available in 24".
3Available with CFL only.
4Consult the factory for available options.
5Supplied by others.
ORDERING INFORMATION
MAGNETIC
RESONANCE
IMAGING (MRI)
ENERGY
STAR
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
645 SERIES INTERIOR WALL LUMINAIRE
18"
24"
24"
4-5/8"
18"
4-5/8" 4-5/8"
5-1/4"
2-1/4"
18" STANDARD
24" STANDARD
DIMENSIONS
ADS042674
2008-09-15 16:19:13
