Cooper Lighting PM121ob User manual

®
RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311
Toll Free: 800-356-3030 • 818-349-3030 • Fax: [phone]
©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice www.cooperlighting.comwww.rsalighting.com
PM74
#
,
#
,
"537!9/242!#+
352&!#%
,OCKING
!DJUSTABILITY
"USWAYONLY
,OCKING
!DJUSTABILITY
v
v
v
v
 v h
"USWAY
 v v
 #CT.TL4RACK
 v v
OR#CT4RACK
Catalog #
Type
Project
A machined aluminum track fixture for line voltage
PAR16 lamps up to 75 watts. For use with RSA Profile
Series 60 Amp Busway, 20 Amp 1 or 2 Circuit Track
or 20 Amp 2 Circuit / 2 Neutral Track.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed.
Available in White, Black, Natural Aluminum or
custom finishes.
PAR16 120V
Open Back Machined Fixture
PM621ob | PM421ob | PM221ob | PM121ob
Ordering Example: PM621ob-75-AL
Open Back Machined Fixture Lamp Wattage Finish
❑ PM621ob - PAR16 for 60 Amp Busway
❑ PM121ob - PAR16 for 20 Amp 1 Circuit Track
❑ PM221ob - PAR16 for 20 Amp 2 Circuit Track
❑ PM421ob - PAR16 for 20 Amp 2 Circuit / 2 Neutral Track
❑ 75 75 Watt Max. PAR16 ❑ WH White
❑ BK Black
❑ AL Natural Aluminum
❑ PT Custom Finish
PM621ob
60 Amp Busway
PM421ob
20 Amp Track
2 Cct. 2 Ntl.
PM121ob
PM221ob
20 Amp Track
1 or 2 Cct.

PM75
®
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
PAR16 Halogen E26 Medium Base
60 PAR16 /CAP /NSP10 OSI 6 139 1.2 1.2 5 150 1.3 1.2 2.9 2 313 1.6 0.9 3.5 3 278 1.2 0.9 3.0
Beam Spread = 10° x 10° 8 78 1.6 1.6 7 77 1.8 1.6 4.0 3 139 2.3 1.2 5.2 5 100 1.9 1.4 5.0
CBCP = 5,000 10 50 1.9 1.9 9 46 2.3 2.0 5.2 4 78 3.0 1.6 6.9 7 51 2.6 1.9 7.0
Rated Life = 2,000 Hrs. 12 35 2.3 2.3 11 31 2.7 2.4 6.4 5 50 3.7 1.9 8.7 9 31 3.3 2.4 9.0
60 PAR16 /CAP /NFL30 OSI 5 200 1.0 1.0 4 234 1.1 1.0 2.3 3 139 2.3 1.2 5.2 3 278 1.2 0.9 3.0
Beam Spread = 30° x 30° 6 139 1.2 1.2 5 150 1.3 1.2 2.9 4 78 3.0 1.6 6.9 4 156 1.6 1.2 4.0
CBCP = 1,300 7 102 1.4 1.4 6 104 1.6 1.4 3.5 5 50 3.7 1.9 8.7 5 100 1.9 1.4 5.0
Rated Life = 2,000 Hrs. 8 78 1.6 1.6 7 77 1.8 1.6 4.0 6 35 4.5 2.3 10.4 6 69 2.3 1.7 6.0
75 PAR16 /CAP /NSP10 OSI 5 300 1.0 1.0 5 225 1.3 1.2 2.9 3 208 2.3 1.2 5.2 4 234 1.6 1.2 4.0
Beam Spread = 10° x 10° 7 153 1.4 1.4 6 156 1.6 1.4 3.5 4 117 3.0 1.6 6.9 5 150 1.9 1.4 5.0
CBCP = 7,500 9 93 1.7 1.7 7 115 1.8 1.6 4.0 5 75 3.7 1.9 8.7 6 104 2.3 1.7 6.0
Rated Life = 2,000 Hrs. 11 62 2.1 2.1 8 88 2.0 1.8 4.6 6 52 4.5 2.3 10.4 7 77 2.6 1.9 7.0
75 PAR16 /CAP /NFL30 OSI 3 211 1.8 1.8 3 158 2.4 2.0 1.7 2 119 5.6 2.3 3.5 2 238 2.5 1.7 2.0
Beam Spread = 30° x 30° 4 119 2.3 2.3 4 89 3.1 2.6 2.3 3 53 8.4 3.4 5.2 3 106 3.6 2.4 3.0
CBCP = 1,900 5 76 2.8 2.8 5 57 3.8 3.3 2.9 4 30 11.1 4.5 6.9 4 59 4.8 3.2 4.0
Rated Life = 2,000 Hrs. 6 53 3.4 3.4 6 40 4.6 3.9 3.5 5 19 13.8 5.5 8.7 5 38 5.9 4.0 5.0
Optivex UV
Filter
Red Color
Filter
Blue Color
Filter
Amber Color
Filter
Cosmetic Peach
2800K Filter
Milk White
Lens
Diffusion Spread
Lens
Linear Spread
Lens
LN25 LN26 LN27 LN29 CP16 LN24 LN21 LN23
Prismatic Spread
Lens
20% Reduction
Screen
30% Reduction
Screen
40% Reduction
Screen
Hex Cell
Louver
Cross
Baffle
Snoot
LN22 RS2016 RS3016 RS4016 LN20 CB16 SN16
