9853, 9752, 9751 Version 5 Update Guide
This document applies to control panels using software version 5.x.x.
© Cooper Security Ltd. 2007
Every effort has been made to ensure that the contents of this book are correct. However, neither the authors nor Cooper Security
Limited accept any liability for loss or damage caused or alleged to be caused directly or indirectly by this book. The contents of this book
are subject to change without notice.
Printed and published in the UK.
Part No. 1792362

Page 3
1. INTRODUCTION
About this Manual
This Update Guide describes the new features and changes introduced to the
9853, 9752 and 9751 with version 5.0x software.
The changes described in this guide are apply to the following manuals:
Updated manuals are available on the Cooper Security web site at
www.coopersecurity.co.uk
2. Changes To Hardware
The control unit can now operate on 60Hz 230VAC mains supplies. Use
command 991 to check if the control unit is connected to a 50 or 60 Hz
supply.
3. Changes To Installer Programming
Leading ‘0’ Now Allowed in Access Codes
All access codes, both user and installer, four-digit and six-digit, can have “0”
as the first digit.
Entering and Leaving Installer Mode
When you enter Installer Mode you do not need to press “0” before entering
the Engineer Code. (Unless, that is, you have set the Engineer Code to have
“0” as the first digit.)
The control unit now carries out an extra check when you leave programming.
You will see a new message on the keypad display as follows:
1. Press 99yat the keypad
The display shows: 99:Checking Bus
followed after a few seconds by 99:Exit Eng?
2. Press y.
The display shows: 99:Checking Sys
followed by the time and date.
The system is now in user mode.

Page 4
Command 81 to 84 - Option 38
This option is now active for the following faults:
AC Fail, Anti-Mask, Aux DC, Battery Load Test Fail, Battery Missing,
Comms Fail, Jamming, Keypad Ident Fail, Line Fail (internal
communicator only), Low Battery, RF Low Battery, Supervision Fail,
Telecommand Low Battery, uCom Fail, Zone AC Fail, Zone Battery
Fault, Zone Fault, Zone Low Battery and Zone Pwr O/P.
(Plug-By/Plug-On fail no longer trigger an All Fault output.)
Command 106: - Option 0
When using option 0, the control unit does not monitor the telephone line
connected to the internal communicator. The control will still report faults on a
plug-by communicator (provided the Line Fault output from the communicator
are connected to the control unit).
Command 131:
Various new reports have been added to command 131. The table below
shows the reports now available in full, with new or changed entries
underlined.
BASIC
Event SIA Code CID Code
ALARM CONFIRM BV 139
BURG BA 130
BURG RESTORE BR 130‡
DURESS HA 121
DURESS RESTORE HH 121‡
EXIT TIMEOUT EA -
EXPANDER TAMPER TA 137
EXPANDER TAMPER RESTORE TR 137‡
FIRE FA 110
FIRE RESTORE FR 110‡
FORBI INTERFACE TAMPER TA 137
FORBI INTERFACE TAMPER RESTORE TR 137‡
FORBI LOOP TAMPER TA 137
FORBI LOOP TAMPER RESTORE TR 137‡
FORBI TAMPER TA 137
FORBI TAMPER RESTORE TR 137‡
GLOBAL TAMPER TA 137
GLOBAL TAMPER RESTORE TR 137‡
KEYBOX OPEN BA 150
KEYBOX CLOSED BR 150‡

Page 5
KEYPAD MEDICAL MA 100
KEYPAD FIRE FA 110
KEYPAD PA HA 120
LID TAMPER TA 137
LID TAMPER RESTORE TR 137‡
MAN TRIGGER TEST REPORT RX 601
PANIC (see note 2) PA 120
PANIC RESTORE PR 120‡
PERIODIC TEST REPORT RP 602
SENSOR SELF TEST FAILURE - 389
SENSOR TAMPER TA 137
SENSOR TAMPER RESTORE TR 137‡
SMOKE DETECTOR FA 111
SMOKE DETECTOR RESTORE FR 111‡
BELL TAMPER TA 137
BELL TAMPER RESTORE TR 137‡
SUPERVISION FAIL BZ 381
SYSTEM TAMPER TA 137
SYSTEM TAMPER RESTORE TR 137‡
TA (Technical alarm) UA 150
TA RESTORE UR 150‡
TAMPER KEYPAD TA 137
TAMPER KEYPAD RESTORE TR -
TELCO1 FAULT LT 351
TELCO1 FAULT RESTORE LR -
ZONE OMIT BB 573
ZONE TAMPER TA 137
ZONE TAMPER (DAY) TA -
ZONE TAMPER RESTORE TR 137‡
SUMMARY
Event SIA Code CID Code
AC LOST AT 301
AC RESTORE AR 301‡
ALARM ABORT BC 406
ANTI MASK ZONE OPEN (see note 3) BT 380
ANTI MASK ZONE TAMPER (see note 3) BT 380
ANTI MASK ZONE RESTORED (see note 3) BJ 380
AUX TROUBLE (see note 4) YP -
AUX RESTORE (see note 4) YQ -
BATT MISSING (see note 5) YM 311
BATT RESTORED (see note 5) YR 311‡
FAULT ZONE TA 300
FAULT ZONE RESTORE TA 300‡
LOW BATT (see note 6) YT 311

Page 6
LOW BATT RESTORE (see note 6) YR 311‡
PARTITION RESET OR 305
RESET OR 305
INTERMEDIATE
Event SIA Code CID Code
ARM CL 401
DISARM OP 401
KEYSWITCH DISARM OS 409
KEYSWITCH ARM CS 409
ZONE FAULT IA 389
ZONE FAULT RESTORE IR 389
FULL
Event SIA Code CID Code
COMMS FAIL - 350
DOWNLOAD SUCCESS RS 412
EXCESS KEYS JA 461
EXPANDER MISSING TA 137
EXPANDER MISSING RESTORE TR 137‡
FORBI MISSING TA 137
FORBI MISSING RESTORE TR 137‡
JAMMING XQ 380
PASSWORD DEFAULTS LOADED RH -
PROG MODE START LB 627
PROG MODE END LS 628
TD (Time and day) RESET JT 625
TX BATTERY TROUBLE XT 384
USER CODE CHANGED JV -
USER CODE DELETED JX -
Notes:
1. If Command 143, option 1 is selected, all messages with a CID Code are sent. If
option 0 is selected, the restores marked with ‡ are not sent.
2. This message also sent for PAs started from a telecommand.
3. The control unit logs an Anti-Mask event to the zone number one below that assigned
the Anti-Mask type.
4. This message also sent for Power zones.
5. This message also sent for Battery Fault zones.
6. This message also sent for Low Battery zones.
Command 141: Alert Tone On/Off
This is a new command in version 5.0x. Use this command to disable the
Alert fault tones. When enabled (default) the system gives an alert tone and
displays alerts on the keypad.

Page 7
Option
0 Disabled. The display shows alert messages for faults, but does not
sound alert tones.
1 Enabled (default). The display shows alert messages, and the system
gives alert tones.
Command 151 to 158: Plug-by Communicator Outputs
1. Note that All Fault is active for the following faults: AC Fail, Anti-Mask, Aux
DC, Battery Load Test Fail, Battery Missing, Comms Fail, Jamming,
Keypad Ident Fail, Line Fail (internal communicator only), Low Battery, RF
Low Battery, Supervision Fail, Telecommand Low Battery, uCom Fail,
Zone AC Fail, Zone Battery Fault, Zone Fault, Zone Low Battery and Zone
Pwr O/P. (Plug-By/Plug-On fail no longer trigger an All Fault output.)
2. In the event of a mains fail (or if the installer leaves engineering with mains
absent) the control unit waits one minute and then logs an AC Alert, but
does not start any communication. If the mains fail persists, then after a
time of 15-19 min (chosen at random) the control unit logs an AC Fail and
also starts a communication.
If you select a Scandinavian default in Command 0, the control unit waits at
least 60 minutes before reporting.
Printing the Event Log (9853 only)
The following log messages are new in version 5.0x.:
Keypad Display Printed (9853 only)* Meaning
AC Alert Keypad displayed mains fail message
AC Fail AC Lost Mains power supply failed
Z== Lock Out The system locked out the zone when
attempting to rearm at the end of the bell
run time.
Z== Lock Out Rst The system restored a locked out zone
zone.
4. Changes For the End User
Access Codes
With version 5 access codes can have “0” as the first digit.
The end user no longer has to press Xto cancel a mistake in entering an
access code, they simply key in the correct code again.
If a user keys in an incorrect code four times, the control unit locks all keypads
for 90 seconds.

Page 8
Downloader Calling Control Unit
The end user can now control access to the control unit for incoming calls
from Downloader. To do this the user:
1. Keys in an access code (or presents a tag).
2. Presses 0.
The display shows: Call CS ?
3. Presses B and then y.
The display shows: Remote PC _
In Progress
The Installer's PC can then attempt to call the
control unit over the telephone line. While
Downloader is connected, the keypad display
shows the time and date.
Note: If you connect a PC with Downloader directly to
the control unit by a cable then the user must
authorise the connection by pressing A in step 3
above.
