1. Introduction
The i-on16 is a wireless intruder alarm system intended mainly
for use in domestic and small commercial properties.
The heart of the i-on16 system is the control unit and its keypad.
The control unit contains the main wireless receiver, the power
supply and stand-by battery. The stand-by battery can keep the
alarm system going for up to 12 hours if the mains supply fails.
Connected to the control unit by cable is a keypad. The keypad
has a two line display to show you status information, and various
keys for operating the system. The keypad also contains a
speaker to give warning tones when the system is setting or
unsetting.
Users identify themselves to the system by keying in access
codes. If they do not wish to use access codes then the keypad
also contains a proximity tag reader, allowing users to identify
themselves by means of small electronic tags that they carry with
them.
To protect an area the control unit can operate a range of
detectors, each containing a small radio transmitter that
communicates back to the control unit. Figure 1 shows some
examples. In addition to fixed detectors the control unit can also
monitor small portable transmitters that users can employ to
start alarms remotely, for example in the case of a panic alarm.
When the control unit detects an alarm, it can start an external
sounder/strobe unit by sending the appropriate radio signal. In
addition the control unit can also communicate over the public
switched telephone network (PSTN) using a plug on module. The
module also provides speech recording and playback facilities so
that the system can send recorded speech messages to pre-
programmed telephone numbers.
The control unit also provides sets of connectors for four outputs.
If necessary the installer can use these connectors to link the
control unit to siren/strobe units or other equipment.

Introduction
Page 2
1. Two button panic alarm.
2. Two button panic alarm with tilt
switch.
3. Two button panic alarm
4. Four button remote control.
5. Wireless arming station.
6. Door Contact/Universal Transmitter.
7. Smoke Detector.
8. Passive Infra Red.
9. External siren/strobe.
A
B
A
B
C
D
1
4 ghi
7 pqrs
*0#
2 abc
5 jkl
3 def
6 mno
8 tuv 9 wxyz
Figure 1. i-on16 Peripherals
A complete i-on16 system comprises a control unit and up to:
16 fixed wireless alarm detectors
One external siren/strobe unit
16 portable four button remote controls
16 portable panic alarm buttons
16 users.

Introduction
Page 3
This rest of this guide shows the simple procedures required to
operate and administer the system. For information on installing
the i-on16 please read i-on16 Installation and Programming
Guide. Each of the radio peripherals also have their own guides.
Controls and Displays
Figure 2 shows the controls and displays available on the keypad.
A
B
C
D
1
4 ghi
7 pqrs
*0#
2 abc
5 jkl
3 def
6 mno
8 tuv 9 wxyz
2
3
4
5
7
6
1
1. LCD display . 5. Panic Alarm (PA) keys.
2. Programming keys. 6. Alpha/numeric keys.
3. Navigation key 7. Set/Unset status LEDs.
4. Setting and unsetting keys.
Figure 2. Controls and Displays
Displays
The LCD display shows messages and prompts to help guide you
through setting, unsetting, resetting and programming the
system.
When the system is idle (either while
set or unset) the display shows the
“standby screen”, comprising the time
and date:
I-ON16
11:15 20/3/08
(The top line of the display may show the installer’s name
instead of “i-on16”.)

Introduction
Page 4
To draw your attention to special events the rim of the navigation
key glows red.
The four LEDs on the right of the programming keys show you
that the system is set or unset. The left hand LED glows when the
system is full set, the second from left glows when the system is
part set. Note that the installer can disable these LEDs in order to
hide the state of the system. (The two right hand LEDs are never
used.)
Controls:
A Full sets the system. (All detectors in use.)
B Part sets the system. (Some of the detectors in use.)
Unsets the system.
uIn menus: scroll up. In text editing: move cursor left
nIn menus: scroll down. In text editing: move cursor right.
> If the bottom line of the display shows a “>” at the right,
pressing this key selects the submenu named on that line.
If the bottom line of the display shows “On” “Off” “yes”
“no” “I” (for include) “O” (for omit) then pressing this key
changes the value to its opposite.
<Deletes characters when editing names.
Y Press this key to confirm a decision.
X a) Moves the display to a higher level of the menu.
b) Press this key to abandon your decision when the
display shows “Are you sure Y/N?”
Press this key to gain access to the programming menus.
1 to 0,
*, # Used when keying in user codes and telephone numbers. Can also be used to key in text for names.
# When keying in text press # to change between capitals
or small letters.
Press these keys to start a Personal At alarm. (Press both
at the same time.)

Page 5
2. Everyday Operation
Everyday operation involves setting and unsetting the alarm
system and occasionally dealing with alarms. If you need to know
how to set up new users, or change the way the system operates
then please read the “Administration” section.
Access to the System
To operate the system a user must identify themselves, either by
entering an access code on the keypad or by presenting a
proximity tag to the front of the keypad.
Access code and tag act as unique identifiers for each user, and
may be used interchangeably at any time.
When delivered from the factory the control unit recognises just
one user, and this user has Administrator privileges (see page
15). This user’s default access code is “1234”, and they do not
have any tag or other device registered to their account.
Cooper Security Limited recommend that you change the
default access code as soon as possible (see page 16).
The installer has a separate access code which they cannot use to
set or unset the alarm system. Neither can they use that code to
change details of other users registered to the system. Similarly,
the Administrator code has no access to any installer
programming menus.
Entering and Leaving the Protected Area
In many alarm systems the keypad is inside the protected area.
To make sure that you can get to the keypad when the system is
set without starting an alarm the installer programs the control
unit to pause for a few moment if it detects activity on specific
entry/exit routes. The installer chooses the length of the pause to
enable you to get to the keypad if you are entering, or leave the
protected area if you are setting the system. During the pause
the keypad will give a warning tone. When you hear the warning
tone do not stray off the entry/exit route chosen by the installer
or you will start an alarm.

Everyday Operation
Page 6
Setting
Note: Whenever you set the system you should first make sure
that all doors and windows are secure.
Full Set
When the system is full set, all the detectors intended to detect
intruders are primed, ready to raise an alarm. (If you want to
protect just part of your premises use “part set”, see page 8 .)
Make sure the system is idle.
1. EITHER: Key in your access
code.
OR Present a proximity tag to the
keypad.
The display shows:
A : Full Set
B : Part Set
(The names for A and B may differ from that shown, depending
on how the installer has set the system up. If your system does
not have a part set facility then it will start setting immediately,
go to step 3.)
2. Press A.
The display shows the number
of seconds you have to left in
which to leave the premises.
The keypad gives the exit
warning tone:
A continuous tone means the
system can set normally.
An interrupted tone means
that your exit door is open.
See Note b) on next page.
3. Leave by the exit door and
make sure it is closed
properly.
Setting:Full Set
10 to set

Everyday Operation
Page 7
At the end of the exit time the
exit warning tone stops and
you should hear a double
“beep” confirmation tone to let
you know that the system is
set.
The display shows the
message "System Set" for a
few seconds, followed by the
standby screen. The LED
marked “A” glows to show that
the system is full set.
System Set
Notes:
a) If you decide you want to stop setting then press .
b) Your system may be programmed to set silently. If so,
there will be no exit warning tone as the system sets.
c) If your system is full set you cannot go directly to part
set. You must unset the system first.
d) If your system is part set, then you cannot go directly to
full set. You must unset the system first.

Everyday Operation
Page 8
Quick Set
Quick Setting does not require the use of an access code or tag.
(The Installer must enable this facility for you.)
Make sure the system is idle.
1. Press A.
The keypad gives the exit
warning tone.
Setting:Full Set
10 to set
2. Leave by the exit door and
make sure it is closed
properly.
At the end of the exit time the
display shows the message
"System Set" for a few
seconds.
While the system is set the
display shows the standby
screen.
System set
Note: If you decide you want to stop setting then press .
Part Set
When programming your system, the installer can mark some of
the zones “Part Set”. If, when setting the system, you press B
instead of A then the control unit sets the zones selected by the
installer, and none of the others. This feature is designed so that
you can protect, for example, the perimeter of your house while
you remain inside it, or the downstairs rooms while you are
asleep upstairs.

Everyday Operation
Page 9
If the System Will Not Set
Normally, the system will set only when all the detectors are
“quiet”, that is: not reporting any activity. (This does not apply to
those detectors on your exit door or exit/entry route. The system
expects these detectors to be active as you leave the protected
area.)
If you try to set when one or more detectors are still active then
the display shows the words “SETTING FAULTS” and which zones
are active.
You can make the system “omit” those active zones, either while
you are setting the system (see below) or beforehand (see page
16 for instructions on how to omit zones before setting the
system).
1. Follow the instructions on page
6 to set the whole system.
If any detectors are not yet
ready to be set then the
display shows, for example:
SETTING FAULTS
Z02 A Back Door
2. EITHER Press Yto carry on
setting.
The system sets with the
active zones omitted.
OR Stop the setting process by
pressing X.

Everyday Operation
Page 10
Setting With a Remote control
Note: You must program the control unit to recognise ("learn") a
remote control, see page 23.
Secure all your windows and doors.
Make sure the system is idle, and that you can hear the warning
tones from the keypad.
1. On the remote control, either press A (full set) or B (part
set), see page 20.
The keypad sounds the exit warning tone.
2. Leave by the exit door and make sure it is closed properly (if
you have not already done so).
At the end of the exit time the warning tone stops you should
hear a double “beep” confirmation tone. The display shows
the message "System Set" for a few seconds. The installer
may also have programmed your external sounder/strobe to
flash briefly.
While the system is set the display shows the standby screen
and the left hand LED glows.
If The System Will Not Set
If one of the detectors is still active when you try to set the
system then you will not hear the exit warning tone.
What happens next depends on how the installer has set up your
system.
a) Try pressing A once more on your remote control. If the
installer has programmed the system to do so then it will carry on
and set, omitting the active detector.
b) If the system will not set on the second press of button A then
you will have to go to the keypad and set the system from there.

Everyday Operation
Page 11
Unsetting
When unsetting the system do not stray from the entry route
designated by the installer. If you do then you will cause an
alarm.
1. Enter by the designated entry
door.
The control unit starts the
entry tone.
2. EITHER Key in your access
code.
OR Present a prox tag to the
keypad.
The system unsets.
The display shows:
Followed by the standby
screen.
System Unset
Unsetting With a Remote control
1. Enter by the designated entry door.
2. Press on your remote control.
The system unsets. At this point the system displays the standby
screen.

Page 12
3. Alarms
Types of Alarm
The i-on16 normally starts an alarm when it receives an alarm
signal from one of its detectors. In addition, you can start a panic
alarm from the keypad. The table below shows the different kinds
of alarms possible.
Type of
Alarm Signal (see note) Started by:
Intruder Loud
warbling tone
from siren.
Normal alarm or entry route zone
activated when system is set.
24 hour zone activated at any time.
Fire Repeated
“Dee Dah”
from siren.
Fire zone activated at any time.
Panic Loud
warbling tone
from siren
PA zone or Panic Alarm transmitter
activated at any time.
Pressed on keypad.
(The installer must enable this
feature on your system.)
Technical Loud
warbling tone
from siren.
Technical alarm zone activated at
any time.
Note: As well as making an audible signal, the installer can
program the i-on16 to send pre-recorded voice messages
over the telephone network. These messages can go to a
person nominated to monitor alarm calls. Note that this
facility requires fitting an extra module to your alarm
system, ask your installer for more details.

Alarms
Page 13
Silencing an Alarm
In an alarm the i-on16 operates the siren. The siren runs for a
limited time set by the installer (a maximum 15 minutes for
intruder and PA alarms).
If you return to the control unit after the siren has stopped and
key in your access code then the red LEDs around the navigation
keys glow to tell you that an alarm has occurred. Press >to see
information about the alarm. (Press uor nto see the name of
the zone.) Press Yto restore the display to normal.
If you return to the system while the siren is running you can
silence the siren as follows:
1. Key in your access code.
The siren stops and the screen
shows the first zone to cause
the alarm, for example:
(Press uor nto see the
name of the zone.)
2. Press y.
The display returns to normal.
Press tick to reset
Burg Z03 Alarm
If you wish to see any other zones that were triggered during the
alarm, look in the log (see page 24).

Page 14
4. Alerts (or Why is it Beeping?)
From time to time the control unit may detect that there is a
problem with the system. It will try to inform you of this by
starting an alert. During an alert the rim of the navigation pad
glows red, and the keypad will give an short “beep” every few
seconds.
To see the cause of the alert:
1. Make sure the system is unset and that the keypad display
shows the standby screen.
2. Press Y.
The display asks you to key in an access code.
3. Key in a user access code.
The bottom line of the display shows a message describing
the most recent active alert.
4. Either:
Press Yto acknowledge that you have read the alert.
If you press uor nthen the system will show you any other
alerts that may be active. If there are no other alerts the rim
of the navigation pad will glow green and the keypad will
return to its’ standby screen. In addition the keypad will stop
beeping.
OR: Press X. The rim of the navigation pad will stay red and
the system will show the text of the alert the next time you
key in an access code.
Note: 1. The system will not alert you to short interruptions of
mains power. If the cause of an alert goes away, then the
system will remove the Alert message.
2. The system records all alerts in the log, with the time
when you acknowledged them.

Page 15
5. Administration
To make changes to the way your system works you must enter
the Menu. Your degree of access to the Menu depends on what
type of user you are: Admin User or Normal User. An Admin User
has access to all the options of the Menu. A Normal User:
Can change their own access code.
Cannot add or delete other users.
Can turn the Chime feature on or off.
Entering the Menu
1. Make sure the display shows the standby screen.
2. Press .
3. Key in an access code.
The display shows the first item in a list of options. (See
page 29 for a complete list of options.)
4. Press uor nto scroll through the options available, followed
by >to select (gain access) to an option.
5. Press Yto confirm an option when you have finished making
changes.
6. Press X(if necessary several times) to leave the Menu.
The rest of this chapter describes each of the main options in the
Menu.

Administration
Page 16
Omit Zones
You may wish to prevent a zone causing an alarm. For example, if
your garage door is protected by a detector, but you wish to
leave it unlocked for the delivery of a parcel, you may wish to
omit that detector when you set the rest of the alarm system. To
do this the control unit allows you to "Omit" a zone.
1. Enter the Menu and select Omit Zones.
The bottom line of the display shows the first of a list of
zones.
2. Press uor nto display the zone you wish to omit.
3. Press >to mark the zone for omission.
The character at the end of the line changes to an "O" to
show that the zone will be Omitted.
If you change your mind then press >again so that the end
of the line shows an "I" (for Included).
4. Repeat steps 2 and 3 for any other zone you wish to omit (or
include).
5. Press Yto store the changes you have made.
The control unit allows you to omit a zone for one
setting/unsetting cycle. You will have to omit the zone again for
the next setting/unsetting cycle.
Users
The control unit can recognise up to 16 individual users. Select
Users in the Menu to add new users, change their details, or to
delete them from the system.
Editing Existing Users
If you wish to change the details for an existing user then:
1. Enter the Menu and select Users - Edit User.
The bottom line of the display shows the first in a list of the
users already programmed into the control unit.

Administration
Page 17
2. Press uor nto display the user you wish to edit, and then
press >.
The bottom line shows one of a list of the options that you
can edit:
Name
Type (this option is not available for User 01)
Code
Prox Tag
Remotes
Panic Alarm
Use the uor nkeys to scroll through the list.
(The options available are the same as those shown when
adding a user.)
3. Press >to select the option you wish to edit.
4. Press Ywhen you have finished.
Name
If you wish to edit the name displayed on the keypad for a user:
1. Select Users - Edit User - User(nn) - Name.
The display shows the current name given to the user, and
places a cursor at the end of the name.
2. Key in the name from the keypad. Press each key one or
more times to obtain the letter you want (the letters of the
alphabet appear on the keys in the same arrangement as on
many mobile phones, see Figure 3.)
Press # to change between capitals and small letters.
The cursor becomes an underline when you type in small
letters and a block when you type in capitals.
Press uto move the cursor left, or nto move the cursor to
the right.
Press <to remove letters to the left of the cursor. Press >
to insert a space.

Administration
Page 18
1
4 ghi
7 pqrs
*0#
2 abc
5 jkl
3 def
6 mno
8 tuv 9 wxyz
ABCÆÅÄ DEF
GHI JKL MNOØÖ
PQRS TUV WXYZ
Space 0
Figure 3. Letters Assigned to Keys
3. Press Ywhen finished.
User Types
To change a user’s type select Users - Edit User - User(nn) - Type.
1. Press uor nto change between Admin User and Normal
User.
2. Press >to select the user type you wish to assign to the user.
See page 15 for a brief explanation of Administrator and Normal
User.
Note: You cannot change User 01’s type.
Access Code
To change a user’s access code, select Users - Edit User - User(nn) -
Code.
1. Key in an access code for the user.
When you press the last digit of the access code the display
asks you to key in the same access code again.
2. Key in the same digits again, in the same order.
Access codes are four digits long.
