COOPS & FEATHERS 250-71 User manual

123
4
CENTER
BASE SUPPORTS
x2
5
BACK END BASE
6
REAR CENTER
SUPPORT
7
x2
8
x2
9
x4
UPPER
FRAME SIDE
10 x2
11
TOP FRAME
PERCH
12
BACK UPPER
FRAME SUPPORT
13 14
x2
15
CENTER DECK
CONNECTORS
16
RIGHT DECK
SUPPORT
17
DECK PLATFORM
x4
18
SWING SIDE
x2
19
x2
SWING
SEAT
C
1 x
LEFT
END BASE
FRONT
END BASE
CENTER
MIDDLE SUPPORTS
LEFT DECK
SUPPORT
TOP DECK
CONNECTOR
SWING SEAT
IDENTIFY ALL PARTS AND HARDWARE THAT ARE INCLUDED WITH YOUR
CHICKEN PLAY ACTIVITY CENTER. GRAB A SCREWDRIVER (OR HAND
DRILL) AND A RUBBER MALLET. FIND A LEVEL PLACE TO BUILD IT AND
AN EXTRA SET OF HANDS WOULD ALWAYS BE HELPFUL. START
BUILDING!
DD
D
D
D
D
D 6x
D
D
D
D
D
D
D
D
D
D
D
D
D
12 x
A
A
A
A
A
A
A
A
.
.
.
.
.
.
D 8x
D
D
D
D
D
D
D
D
C
D
.
D
9 x
8 pcs
7 pcs
11
4
"
41 pcs 13
4
"
1"
RIGHT
END BASE
FRONT
CENTER SUPPORT
20
HANGING
TREAT BASKET
1
4
3
2
5
A x8
A
B
C
D
E
F
1
2
"
1 pcs
4 pcs
4 pcs
GET PARTS 1-5 AND SET THEM OUT AS THE IMAGE SHOWS. MATCH UP
NOTCHES BEFORE INSERTING ANY OF THE PIECES TOGETHER. BEING
THIS IS THE BASE
OF THE UNIT, THESE PIECES ARE GOING TO FIT VERY
SNUG, SO ENSURING IT IS SET SQUARE AND GENTLY USING A RUBBER
MALLET WILL HELP. INSERT #2 INTO #1 AND #3 FIRST. INSERT #4
(BOTH PIECES) INTO THE NOTCHES OF #2. TAKE YOUR TIME AND
START WITH INSERTING #5 INTO #3 AND THEN WORK TO THE LEFT
WITH ONE OF #4, THEN THE SECOND #3 AND FINALLY INTO #1. YOU
WILL NEED TO SLIGHTLY ADJUST THE FRAME TO ENSURE A TIGHT FIT
AND THAT ALL THE TONGUE AND GROOVES ARE FULLY INSERTED.
SECURE TWO SCREWS (A) ON EACH OUTSIDE EDGE OF THROUGH THE
PRE-DRILLED HOLES INTO EACH PART. SET ASIDE.
ASSEMBLY INSTRUCTIONS
Chicken Play Center Small
Model# 250-71
2
1

A
.
.
.
A
.
.
7
8
6
A x4
13
12
A
A
A
A
A
A
A
A
.
.
.
.
.
A x8
B
11
B x1
DD
D
D
D
D
.
A
A
.
.
.
9
6
7
9
9
9
10
10
B
A
A
A
A
A
A
A
A
.
.
.
.
6
5
10
11
.
.
A
5
11
A x9
GET PARTS 6-8. THIS WILL BE YOUR UPPER FRAME . MATCH UP NOTCHES BEFORE
INSERTING PIECES TOGETHER. ENSURE THE NOTCHES ON #6 AND #7 ARE CLOSEST
TO THE TOP. INSERT TONGUE AND GROOVE ENDS ON PART #8 INTO #6 AND #7.
YOU MIGHT NEED TO TAP LIGHTLY WITH RUBBER MALLET AND SECURE TOGETHER
WITH FOUR SCREWS THROUGH PRE-DRILLED HOLES (A).
GET PARTS 9 (4PC) & 10 (2PC). START WITH LEFT SIDE AND INSERT #9
INTO TONGUE/GROOVE ENDS OF #6 & #7. ENSURE THE TOP OF #9 HAS
THE PRE-DRILLED HOLE ON THE TOP AND IS UPRIGHT. SECURE EACH
WITH ONE SCREW (A) THROUGH PRE-DRILLED HOLES. SET ONE #10 ON
BUILT END AND SECURE WITH TWO SCREWS (A) INTO TOP PORTION.
REPEAT FOR OPPOSITE SIDE WITH TWO #9 USING THE SAME STEPS AND
FINISH WITH THE OTHER #10 ON TOP.
PLACE YOUR COMPLETED BASE UNIT FLAT AND NEST YOUR
COMPLETED UPPER FRAME AS SHOWN IN THE IMAGE. TURN THE
UNIT ON ITS SIDE FOR EASE IN INSERTING 8 SCREWS (A) INTO PRE-
DRILLED HOLES. TURN UPRIGHT AND TAKE PART #11 AND INSERT
TONGUE AND GROOVE INTO BASE WITH THE PRE-DRILLED HOLE
FACING #6. SECURE WITH ONE SCREW (B) INTO PRE-DRILLED HOLE
ON SIDE AND ONE SCREW (A) INTO BASE.
3
4
5

B
B
A
A
..
..
FF
FF
AA
AA
AA
AA
.
.
BB
BB
B B
.
B
B
D
D
D
D
.
.
.
.
.
.
.
.
E
.
..
AA
A
.
A
A
A
.
14
15
13
12
A x6
E x1
A x2
B x2
16
B x4
GET PARTS 12-15. THIS WILL BE YOUR DECK LOOKOUT SUPPORT . LAYOUT
OUT PARTS AS SHOWN IN IMAGE WITH NOTCHES/TONGUE/GROOVE
ALIGNED PROPERLY. #12 ON THE LEFT, #13 AT THE TOP WITH THE PRE-
DRILLED HOLE FACING DOWN, TWO #14’S ALIGNED IN THE CENTER AND #15
ON THE RIGHT. SET #15 ON ITS SIDE AND INSERT #13 AND THE TWO #14’S
INTO THE TONGUE GROOVES. SET #12 ON TOP AND GENTLY PUSH INTO
PLACE. THE RUBBER MALLET CAN BE GENTLY USED TO TAP UNIT TOGETHER.
SECURE WITH THREE SCREWS (A) ON EACH SIDE. TWIST HOOK (E) INTO PRE-
DRILLED HOLE ON UNDERSIDE OF #13.
TAKE YOUR COMPLETED DECK LOOKOUT SUPPORT AND INSERT
TONGUE/GROOVE BASE INTO NOTCHED HOLES ON FRONT OF UNIT AND
INSERT. USE YOUR RUBBER MALLET GENTLY IF NEEDED TO TAP IN. SECURE
BACK THROUGH PRE-DRILLED HOLES WITH TWO SCREWS (B). TURN ENTIRE
UNIT ON BACKSIDE AND INSERT TWO SCREWS (A) INTO BASE OF DECK
LOOKOUT SUPPORT. TURN UPRIGHT.
TAKE PART #16 AND SET ON TOP OF DECK LOOKOUT
SUPPORT. SECURE WITH TWO SCREWS (B) ON EACH SIDE
THROUGH PRE-DRILLED HOLES.
6
7
8

C
C
D
D
E
.
.
.
.
FF
FF
AA
A
A
.
.
CC
CC CC
CC
.
.
DD
DD
.
C C
D
D
D
D
.
.
F x4
17
18
18
17
A x4
19
C x8
20
D x4
LOCATE FOUR CHAIN LINKS (F), FOUR-PART #17 AND TWO-PART #18 .
INSERT TWO CHAIN LINKS (F) INTO EACH UNDERSIDE OF PART #17 IN
PRE-DRILLED HOLES. GRAB THE FOUR #17 PARTS AND HAND TURN
INTO EACH OF THE FOUR CHAIN LINKS (F). NEXT AND AS HELPFUL TIP-
PRE-SCREW TWO OF (A) INTO PART #18 UNTIL JUST THE TIP OF THE
SCREW COMES THROUGH. SECURE TWO SCREWS FOR EACH SIDE AND
FULLY SECURE SCREWS (A) INTO EACH PART #17 (TOTAL OF FOUR).
TAKE TWO LADDERS-PART #19 AND SET METAL BRACKETS ON
DECK LOOKOUT WITH BASES RESTING ON PART #1 ON THE LEFT
AND PART #3 ON THE RIGHT. SECURE TOP WITH FOUR SCREWS
(C) ON EACH SIDE THROUGH METAL BRACKETS AND THEN
SECURE THE FEET BASES WITH TWO SCREWS (D) ON THE
BOTTOM OF EACH SIDE.
GRAB PART #20, THE HANGING TREAT BASKET CAN BE FILLED WITH FRUITS,
VEGGIES, CABBAGE OR MORE, AND HANG FROM HOOK (E).
WE RECOMMEND EXTENDING THE LIFE OF YOUR CHICKEN ACTIVITY
CENTER WITH OUTDOOR PAINT OR A CLEAR FINISH. IT HAS BEEN
STAINED BUT USING A NON-TOXIC OUTDOOR PRODUCT OR A CLEAR
POLYURETHANE WILL PROVIDE ADDITIONAL PROTECTION AGAINST
RAIN, MOISTURE, HUMIDITY AND SNOW FOR MANY SEASONS TO COME.
NOW! SET OUTSIDE FOR YOUR FREE-RANGE BIRDS OR WITHIN YOUR
COOP AREA AND LET YOUR BIRDS ENJOY! AND DON’T FORGET THE
YUMMIES IN THE TREAT BASKET FOR YOUR BIRDS!
