COP Security DVR04SHD User manual

DVRSHD Series
DVR04SHD/08SHD/16SHD
www.mdh-system.pl
User Manual
The picture might differ according to the specifications.
This User Manual is based on DVR16SHD.
1997-2005
Contents of this user manual are protected under copyrights and computer program laws.
First Edition: November 1, 2005
Thank You

Thank you for choosing our Digital Video Recorder.
Before operating the system, please read this User’s Manual thoroughly and retain it for future reference.
WARNING
TO
REDUCE FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THE UNIT TO RAIN OR MOISTURE.
This installation should be made by a qualified service person and should
conform to all local codes.

Cautions
Read Before System Operation
Follow these details to prevent material damage or personal injury.
Signs of Caution and Warning
Warning: This sign indicates that the user could die or be seriously wounded if not used or installed
properly.
Caution: This sign indicates that the user could be wounded or could expect property damage if not
used or installed properly.
Warning: Do not expose the product to fog, rain or too much humid to decrease danger from electric shock
or fire.
Important Safeguards
Warning
1. Change the battery after turning the off the power of the product.
2. Check the polarity of the lithium battery while changing.
3. Change the battery with the same one, which is in the product or with the similar type recommended by your vendor.
4. Dispose of the changed battery according to the instructions of the battery manufacturer.
There is danger of explosion when instructions are not followed.
General Warning
Warning
1. Use the power cord, which is supplied or recommended by the supplier.
It may cause fire.
2. Do not dismantle or assemble the product.
It may cause malfunction or fire.
3. Enquire from your vendor for repair.
It may cause electric shock or fire if the repair is not done properly.
4. Do not touch the product with wet hands.
It may cause malfunction or electric shock.
5. Matters must be ensured to a professional for product installation.
It may cause malfunction, electric shock or fire.
6. Consult the place of purchase if the need for installation arises.
Delinquent installation may be the reason for malfunction, electric shock or fire.
7. Ground applies to video products equipped with a 3-wire grounding type plug having a third (grounding) pin.
This plug only fits into a grounding-type power outlet.
If grounding is not done, it may cause malfunction or electric shock.
8. Ground connection must not touch gas pipe, water pipe or telephone line.
If grounding is not done properly, it may cause electric shock.
9. Prevent metallic foreign substance from going inside the product.
It may cause malfunction or electric shock.
10. Do not spray insecticide or flammable spray while driving.
It may cause fire.
11. Prevent water from entering inside electrical parts.
Clean with a dry towel or malfunction or electric shock could result.

Caution
1. Use the power cord, which is supplied or recommended by the supplier.
The internal fan rotates at high speed and may cause an accident.
2. Do not drop, give strong vibration, or shock to the product.
It may cause malfunction.
3. The air inhaler of the front panel and air outlet of the back panel must not be blocked during installation.
The internal temperature of the product would be greater than allowable and could cause malfunction or
fire.
4. Do not touch the product or the power cord when there is thunder.
It may cause electric shock.
5. Do not install the product near or on top of heating source.
The internal temperature of the product would be greater than allowable and could cause malfunction or
fire.
6. Do not install the product on inclined or unstable location or where vibration could be committed.
It may cause malfunction.
Cautions about the Power
Warning
1. Must use the outlet of the grounding to connect the power cord.
It may cause fire.
2. Do not connect on the middle of power cord or use extension cord.
It may generate heat or cause fire.
3. Do not touch the power cord with wet hands.
It may cause electric shock.
4. Keep power cord dry and protect from humidity.
It may generate heat or cause fire. The power cord is not waterproof.
5. Hold the body of the plug while removing the power plug.
Do not pull the power cord. Damage to the power cord may generate heat or cause fire.
6. Check the power plug regularly.
Humidity and moderation in smoking may cause fire.
7. Remove power cord from outlet when product is not used for a long time.
It may cause short-circuit or electric shock.
Caution
1. Do not turn off the power by removal of the power plug.
To turn off the power, click the power button from the front panel.
When the system stops abnormally, the power button might not work. Click power button for 5 full seconds to turn
power off.
2. Do not cut off the power artificially, or give shock or vibration to unit while the hard disk is activating.
It may cause hard disk failure or loss of data.

Category
1. SYSTEM STRUCTURE AND INSTALLATION.................................................................................................................... 1
2. EXPLANATIONS FOR EACH FUNCTION........................................................................................................................... 2
2.1 F RONT P ANEL .......................................................................................................................................................................... 2
2.2 IR R EMOTE C ONTROLLER ....................................................................................................................................................... 5
2.3 R EAR P ANEL ............................................................................................................................................................................ 8
3. INSTALLATION.......................................................................................................................................................................11
3.1 C ONNECTING P ERIPHERAL D EVICE ........................................................................................................................................11
3.2 S YSTEM S TARTUP AND S HUTDOWN ....................................................................................................................................... 12
4. OPERATION........................................................................................................................................................................... 14
4.1 L OG I N ................................................................................................................................................................................... 14
4.2 R EAL TIME L IVE M ODE ......................................................................................................................................................... 15
4.3 R ECORDING I MAGE P LAYBACK M ODE .................................................................................................................................. 16
4.4 S EARCH R ECORDING I MAGE .................................................................................................................................................. 17
5. SETTING................................................................................................................................................................................. 20
5.1 S YSTEM - G ENERAL ............................................................................................................................................................... 22
5.2 S YSTEM - T IME & D ATE ......................................................................................................................................................... 26
5.3 S YSTEM - P ASSWORDS ........................................................................................................................................................... 28
5.4 S YSTEM – I MPORT /E XPORT S ETUP ......................................................................................................................................... 30
5.5 S YSTEM - L OG O FF ................................................................................................................................................................ 32
5.6 C AMERA - R ECORDING .......................................................................................................................................................... 33
5.7 C AMERA - S CHEDULE ............................................................................................................................................................ 36
5.8 C AMERA - T ITLE & S ECURITY ............................................................................................................................................... 38
5.9 C AMERA - C OLOR .................................................................................................................................................................. 41
5.10 C AMERA - PTZ...................................................................................................................................................................... 43
5.11 C AMERA - A UDIO .................................................................................................................................................................. 44
5.12 A LARM - A LARM I N /O UT ....................................................................................................................................................... 45
5.13 A LARM - M OTION A LARM ..................................................................................................................................................... 47
5.14 A LARM - V IDEO L OSS ............................................................................................................................................................ 48
5.15 A LARM – M ISCELLANEOUS A LARM ...................................................................................................................................... 49
5.16 N ETWORK - IP S ETTING ......................................................................................................................................................... 50
5.17 N ETWORK - D YNAMIC IP S ERVER .......................................................................................................................................... 52
5.18 N ETWORK -E VENT NOTIFICATION .......................................................................................................................................... 64
5.19 T OOLS -S YSTEM I NFORMATION .............................................................................................................................................. 65
5.20 T OOLS - S YSTEM L OG ............................................................................................................................................................ 67
5.21 T OOLS - B ACKUP ................................................................................................................................................................... 68
5.22 T OOLS - S YSTEM U PGRADE ................................................................................................................................................... 71
5.23 T OOLS -D ISK F ORMAT ............................................................................................................................................................ 72
5.24 T OOLS - F ACTORY D EFAULT .................................................................................................................................................. 73
6. REMOTE SETTING.............................................................................................................................................................. 74
6.1 R EMOTE S YSTEM S ETTING .................................................................................................................................................... 74
6.2 R EMOTE M ONITORING .......................................................................................................................................................... 75

1
1. System Structure and Installation
The following accessories are supplied with the DVRSHD series digital video recorder. Keep the packing utilities for
moving or storage purposes afterwards.
Note If any of these items is missing or damaged, notify your vendor immediately.
Qty Accessories
1 User Manual + RemoteAgent CD
1 IR Remote Controller
1 Power cable
4 Rubber Mount
2 I/O Terminal Block
DVRSHD Series
(DVRSHD16)

2
2. Explanations for each function
2.1 Front Panel
The buttons on both the front panel of the DVRSHD Series and IR Remote Controller have the same functions. Each
button can activate different functions. The buttons on the front panel of DVRSHD Series may be different in shape with
the remote controller buttons, but the IR Remote Controller can also control most of the functions controlled by the front
panel of the DVRSHD Series.
No. Buttons Functions
1 CD-RW Backup the recording image by internal CD-RW. (Option)
2 Network LED LED is lit while the network client(s) (RemoteAgent) is connected to the system.
3 Alarm LED LED is lit when the sensor signal is inputted to the connected system.
4 HDD LED Shows if the camera image is being stored into or retrieved from the HDD (Hard
Disk Drive).
5 Power LED Shows Power On/Off status of the system (GREEN: Working, RED: Stand-by).
6 USB Port USB interface Port to connect to external storage equipment.
7 Power Button Receives input signal of the Remote Controller
8 Remote Control
Receiver
The channel image will change when the corresponding up, down, left and right
button is pressed. This is same as using cursor key (direction key) on the main
screen.
9 Select Channel Use to turn the Power On/Off.
10 ENTER Button Use to enter detail menu, go into the next stage, and select or set value.
11 RETURN Button Use to exit from the setting menu or to cancel setting value.
12 SETUP Menu to set user environment of the system.
13 Screen Mode Selection Select the screen mode from 1, 4, 8 and PIP screen.
14 SEQ Button Automatic time sequencing for monitor images.
15 Playback / Pause Playback recorded images/pause.
16 SEARCH Search recorded images
17 Shuttle Shuttle (outer dial): Speed up the playback speed of the image (2~32X).
18 Jog Jog (inner dial): playback frame by frame.

3
2.1.1. CD-RW (Option)
The DVRSHD series system can select the CD-RW as Option. Use the CD-RW to backup the recorded image. Refer to
“Image Backup” for detail explanation.
2.1.2. Network LED
LED is blue when the system is connected to any network client (RemoteAgent). Light is automatically out when all clients
are disconnected.
2.1.3. Alarm LED
LED is lit if the system’s connectedAlarm activates.
2.1.4. HDD LED
LED is blue when the camera image is being stored into or retrieved from the HDD. So, even though the system is
continuously recording, the HDD LED is only lit when actual data is recorded in the HDD. Usually, the LED will be flickering,
and this is normal.
2.1.5. Power LED
LED to show the power input and status of the system. The LED is red when the system is in stand-by position, but is
green when the system is working and power is being supplied.
2.1.6. USB Port
Use to backup recorded images of the DVRSHD series by using USB storage device. System software upgrade is
possible with USB storage device.
2.1.7. Power Button
Connect the power cable of the product before pressing this button to turn the power on and off.
2.1.8. Remote Controller Receiver
DVRSHD can be operated conveniently, using the remote controller. Receives input signal from the remote controller
2.1.9. Select Channel
These buttons are used to change the channel images. Left/Right button is used to change the channel on 1- screen
mode or PIP mode and Up/Down button is used to change PIP channel from PIP mode. Also, these buttons are used to
move cursor in “Setting” mode as up, down, left, or right, and also used to increase or decrease the setting value.
2.1.10. ENTER Button
The [Enter] button is used to go to the next stage, select value or settings.
2.1.11. RETURN Button
Use to cancel the password just typed at the setting menu or return to previous menu.
2.1.12. SETUP
Set the environment of the DVRSHD system according to the user requirement. Refer to “Setting” for detailed
explanation.
2.1.13. Screen Mode Selection
Screen mode can be selected from the monitor screen. Whenever the buttons is pressed, it will change in sequence in 1, 4, 8, 16 and
PIP screen.
