Preface
Safety Instructions
zCORAL MANTA does not replace adult supervision.
zThe connection to the pool unit should be consistent with the local and national wiring rules (electrical code).
zOnly use the pool unit charger supplied with the system.
zCORAL MANTA requires a direct line-of-sight to the entire pool, and has a maximum view angle of 90°.
zCORAL MANTA operation is optimal in pools of up to 10 yards long.
zKeep the pool water as clear as possible according to best practice (consult with a pool service professional).
zVerify that the images retrieved from the camera are clear and that details on the far end of the pool can be viewed clearly.
zCORAL MANTA requires direct sunlight in order to charge its battery using the built-in solar panels.
zCORAL MANTA is another layer of safety and does not replace other pool safety means or devices required by local city/state/country laws.
zCORAL MANTA uses computer vision technology to detect drowning. Depending on various factors, some drowning events might not be
detected.
WARNING:
A Ground Fault Current Interrupter (GFCI-USA) or a Residual
Current Device (RCD-EUROPE) must be installed to protect your
electric outlet and prevent any possible electric shock.
Safety Instructions
3.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


zCORAL MANTA uses cellular (GSM) communication to transfer alerts, warnings, and notifications as well as images from the pool unit to
your paired devices using secured servers in the cloud.
zCommunication to the paired devices depends on the quality of the cellular network and might sometimes be degraded or slowed down
based on signal quality.
zThe drowning detection function is not dependent on cellular communication. It works locally, without cellular communication, by
sounding the alarms in the pool unit and home unit.
zThe home unit must be plugged into a power outlet inside the house, as close as possible to the pool unit. Make sure the home unit can
be clearly seen and heard inside the home at all times (e.g. when there is background noise, music, people talking, or working electrical
appliances).
zADULT SUPERVISION IS REQUIRED AT ALL TIMES.
NOTE:
Do not Install the pool unit in a shady location. The solar panels
must be exposed at all times. Remove any foreign objects covering
the solar panels.
Safety Instructions
4.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


Disclaimers
zUsing CORAL MANTA is subject to the acceptance of the “Terms of Use” and “Privacy Policy”.
zSetting up and installing CORAL MANTA indicates your acceptance of the “Terms of Use” and “Privacy Policy”.
zIf you do NOT accept the “Terms of Use” and “Privacy Policy” please contact us to arrange a refund and return shipment.
zActivating CORAL MANTA requires pairing it with a the Coral Drowning Detection app (using the app is mandatory only for activating the
system).
NOTE:
The shape and position of the pool may eect system
performances. Verify that the pool shape is suitable (see Selecting
Mounting Position on page 21) and that the pool unit is installed
in the proper place (see Mounting the Docking Station on page
23).
Disclaimers
5.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


Introduction
This chapter provides an overview of the system and includes:
zSystem Layout
zPool Unit
zHome Unit
Introduction | Disclaimers
6.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


System Layout
CORAL MANTA is programmed to detect people in the pool, their position and motion. It constantly analyzes the images that are captured by the
underwater camera. Whenever it detects a near-drowning event it generates an alarm. CORAL MANTA also learns based on the image analysis and
attempts to automatically ignore alerts which are false alarms.
CORAL MANTA includes the following:
zPool Unit (2) – mounted on a corner of the
pool, includes a video camera, and generates
alerts according to the scenario identified in
the pool (see Detection Scenarios on page 31).
The pool unit transmits alerts to the home unit
(1) and to the mobile device (3) as needed.
zHome Unit (1) – connected to a power outlet
in the house, communicates with the pool unit
over RF (direct) communication, and provides
audio and visual indication of the alerts
received from the pool unit.
zMobile Application – Coral Drowning Detection
mobile application, installed on a mobile
device (3), provides alerts, system status
notifications and allows for remote monitoring.
13
2
Introduction | System Layout
7.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


Pool Unit
OVERVIEW
The pool unit includes the following:
zUnderwater Tube (1)
zIndicators (2)
zSolar panel (3)
zDocking station (4)
zConnectors (5)
zBattery (6)
3
1
5
6
4
2
Introduction | Pool Unit
8.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


UNDERWATER TUBE
A folding tube holds the camera and the activity sensor under the water.
The underwater tube includes the following:
zUnderwater camera (6) – a built-in underwater video camera that
captures real-time video and has a maximum view angle of 90°
zActivity sensor (4) – provides indication of the water level in the pool
and senses activity in the pool
zCamera illumination (5)
1
4
3
2
6
5
NOTE:
The underwater tube is folded and unfolded using an axle (1).
When folded, a magnet (3) connects to a metal plate (2) to secure
the folded tube.
Introduction | Pool Unit
9.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


INDICATORS
The pool unit includes the following indicators:
Pool Activity Indicator
The pool activity indicators (4, 5) provide visual indication of the different scenarios in
the pool (see Detection Scenarios on page 31).
Water visibility indicator
The water visibility indicator (1) provides the following indications of water clarity:
zOff – clear water
zSteady yellow – there is some visibility degradation
zSteady red – there is a significant visibility degradation
Battery Level Indicator
The pool unit battery level indicator (2) provides the following indications:
zSteady green – battery is fully charged
zBlinking green – battery is partially charged
zSteady red – battery charge is below critical level - charge immediately
zBlinking yellow – battery is charging
5
1
2
3
4
Introduction | Pool Unit
10.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


Communication Indicator
The communication indicator (3) provides the following indications of connectivity:
zSteady blue – the pool unit is connected to the Internet
zBlinking blue – no Internet connection in the pool unit
Introduction | Pool Unit
11.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


DISMISS BUTTON
When the alarm is on, the dismiss button (1) is used to silence the alarm.
1
Introduction | Pool Unit
12.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


CONNECTORS
The pool unit includes the following connectors:
zDC IN (3) – for charging the battery
zSystem reset button (1)
zSIM card slot (4) – enables communication with the mobile
application (applicable only for users who purchased CORAL
MANTA without an integrated SIM card)
2
4
1
3
NOTE:
When no DC power is connected, the protection cap (2) must cover
the socket.
Introduction | Pool Unit
13.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


SOLAR PANEL
The pool unit is charged by a set of solar cells (1).
1
NOTE:
Do not Install the pool unit in a shady location. The solar panels
must be exposed at all times. Remove any foreign objects covering
the solar panels.
Introduction | Pool Unit
14.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


BATTERY
The battery (1) is located in the pool unit and is charged using the Solar panel or using the pool unit charger (see Charging the Battery on page 28). The
connector (2) of the battery connects to the battery port in the pool unit. The battery handle (3) is used to pull the battery out of its socket.
The battery level is indicated by the Battery Level Indicator on the pool unit as well as on the home unit.
2
1
3
Introduction | Pool Unit
15.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


DOCKING STATION
The docking station is mounted on a corner of the pool (see Selecting Mounting Position on page 21)and serves as a base for the pool unit. After first
installation of the docking station, the pool unit can be installed or removed quickly. The docking station includes the following:
zDocking station base (3)
zScrews (1) and nuts (5) – two sets of screws and nuts to
secure the docking station to the selected corner of the pool
zDocking posts (2) – two posts that support the pool unit
zMetal plate (4) – attached to the magnet (6) to secure the
pool unit when docked
2
1
3
46
5
Introduction | Pool Unit
16.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


Home Unit
The home unit is plugged into a power outlet inside the user's house and includes the following:
zPool Activity Indicator (2) – provides visual indication of the different scenarios
in the pool (see Detection Scenarios on page 31).
zLED Indicators (3) – provide indication of the system operation (connectivity,
battery level and visibility). The LED indicators on the home unit function the
same as the LEDs located on the pool unit
zBuzzer (4) – produces a sound in the following cases:
»Short high pitch buzz – presence in the pool.
»Short loud alarm – first indication of a possible drowning danger.
»Longer loud alarm – drowning danger is apparent.
»Continuous loud alarm – high drowning danger. You must get to the pool
immediately to pull the person out of the water.
zPlug (1) – connects to a power outlet inside the house
12
3
4
NOTE:
See section Indicators for a more detailed description of the LED
indicators on the pool unit and the home unit.
Introduction | Home Unit
17.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


Mobile Application
Coral Drowning Detection mobile application is available on Google Play Store and on Apple App Store. The mobile application receives alerts from the
CORAL MANTA device and produces notifications on the mobile device.
The mobile application also enables the user to retrieve images of the pool, dismiss alerts, and receive notifications of visibility, connectivity, and battery
statuses.
Introduction | Mobile Application
18.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


First Installation
This chapter provides installation instructions and includes:
zOpening the box
zSelecting Mounting Position
zMounting the Docking Station
zPlacing the Pool Unit
zInserting the SIM Card (Optional)
zInserting the Battery
zCharging the Battery
zConnecting the Home Unit
zDownloading Coral Drowning Detection Application
First Installation | Mobile Application
19.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute


Opening the box
The CORAL MANTA package includes the following:
DESCRIPTION QTY
Pool unit (folded with a tip protective cover) 1
Docking station 1
Battery pack 1
Home unit 1
Pool unit charger 1
Docking station mounting guide sheet 1
Accessories pack 1
Quick Start Guide 1
First Installation | Opening the box
20.
MENU
www.
INTRODUCTION FIRST INSTALLATION ROUTINE OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS
CORAL MANTA | User Guide Rev B | Doc P/N: xxxx
09.07.2018 Do not distribute

