ABB Busch-Watchdog 70 MasterLINE User manual

1473-1-8134 │Rev. 01 │11.2012
Operating Instructions
Busch-Wächter®
Pos: 2 /#Neustruktur#/ Online-Dokumentati on (+KNX)/Titelbl ätter/Waechter /Titelblatt - 6854 -- BJ E @24\ mod_1338444887984_15. docx @ 214436 @ @ 1
6854-500 AGM-…
70 MASTERLINE
=== Ende der Liste für TextmarkeCo ver ===

Operating Instructions
Busch-Wächter®
Operating Instructions | 1473-1-8134 — 2 —
Pos: 4 /#Neustruktur#/ Online-Dokumentati on (+KNX)/Inhalts verzeichnis (- -> Für alle Dokumente <-- )/Inhaltsverzeichni s @ 19\mod_1320649044386_ 15.docx @ 109653 @ @ 1
1Safety....................................................................................................................................................................... 3
2Intended use ............................................................................................................................................................ 3
3Environment............................................................................................................................................................. 3
4Setup and function................................................................................................................................................... 4
4.1 Features of function and equipment........................................................................................................ 4
4.2 Detection ranges..................................................................................................................................... 4
4.2.1 Overview of the detection ranges............................................................................................................ 4
5Technical data.......................................................................................................................................................... 5
6Installation and electrical connection ....................................................................................................................... 6
6.1 Requirements for the electrician ............................................................................................................. 6
6.2 Mounting ................................................................................................................................................. 7
6.2.1 Installation sites ...................................................................................................................................... 7
6.2.2 Preparing the installation......................................................................................................................... 8
6.2.3 Mounting steps........................................................................................................................................ 9
6.3 Electrical connection ............................................................................................................................. 11
6.3.1 Standard connection ............................................................................................................................. 11
6.3.2 Standard connection with extension unit push-button........................................................................... 11
6.3.3 Standard connection with triple-step switch .......................................................................................... 12
6.3.4 Standard connection with RC suppressor 6899 and relay .................................................................... 12
7Commissioning ...................................................................................................................................................... 13
7.1 Setting the coverage ............................................................................................................................. 13
7.2 Activation test........................................................................................................................................ 13
8Operation ............................................................................................................................................................... 14
8.1 Standard operation ............................................................................................................................... 14
8.2 Function status LED.............................................................................................................................. 14
8.3 Auxiliary post operation......................................................................................................................... 15
8.3.1 Operation with extension unit push-button............................................................................................ 15
=== Ende der Liste für Te xtmarke TOC ===

Operating Instructions
Busch-Wächter®Safety
Operating Instructions | 1473-1-8134 — 3 —
Pos:6 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/1.Ebene/S - T/Sicherheit @ 18\mod_130261279179 0_15.docx @ 103357 @ 1 @ 1
1 Safety
Pos:7 /#Neustruktur#/Online-Dokumentation(+KNX)/Sicherheitshinweiseund Hinweise(--> Für alleDokumente<--)/Warnhinweise/Sicherheit - 230 V @ 18\mod_13026068 16750_15.docx @ 103308 @ @ 1
Warnin
g
Electric voltage!
Risk of death and fire due to electrical voltage of 230 V.
– Work on the 230V supply system may only be performed by authorised electricians!
– Disconnect the mains power supply prior to installation and/or disassembly!
Pos:8 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/1.Ebene/A - F/Bestimmungsgemäßer Gebrauch @ 18\mod_1302763321316_15.doc x@ 1034 83 @ 1 @ 1
2 Intended use
Pos: 9 /#Neustruktur#/ Online-Dokumentati on (+KNX)/Besti mmungsgemäßer Gebrauch ( --> Für alle Dokumente <- -)/Busch-Dimmer/Besti mmungsgemäßer Gebrauc h @ 23\mod_13353504498 57_15.docx @ 208763 @ @ 1
The device is to be used exclusively with the components that are supplied and licensed as described in chapter
"Setup and function".
Pos: 10.1 /#Neustrukt ur#/Modul-Strukt ur/Online-Dokumen tation/Überschr iften (--> Für alle Dokument e <--)/1. Ebene/U - Z/Um welt @ 18\mod_1302614158 967_15.docx @ 103383 @ 1 @ 1
3 Environment
Pos:10.2 /#Neustruktur#/Online-Dokumentation (+KNX)/Sicherheitshinweiseund Hinweise(--> Für alleDokumente<--)/Hinweise/Hinweis - Umwelt - Hin weis Elektrogeräte @ 18\mod _1302763973434_15.doc x @ 103500 @ @ 1
Consider the protection of the environment!
Used electric and electronic devices must not be disposed of with domestic waste.
– The device contains valuable raw materials which can be recycled. Therefore, dispose of the
device at the appropriate collecting depot.
Pos:10.3 /#Neustruktur#/Online-Dokumentation (+KNX)/Sicherheitshinweiseund Hinweise(--> Für alleDokumente<--)/Hinweise/Hinweis - Umwelt - Entsorgu ng Elektrogeräte @ 20\ mod_1325760695972_ 15.docx @ 136583 @ @ 1
All packaging materials and devices bear the markings and test seals for proper disposal. Always dispose of the
packaging material and electric devices and their components via the authorized collecting depots and disposal
companies.
The products meet the legal requirements, in particular the laws governing electronic and electrical devices and
the REACH ordinance.
(EU Directive 2002/96/EC WEEE and 2002/95/EC RoHS)
(EU REACH ordinance and law for the implementation of the ordinance (EC) No.1907/2006)
Pos:11 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ @ 1

Operating Instructions
Busch-Wächter®Setup and function
Operating Instructions | 1473-1-8134 — 4 —
Pos:12 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/1. Ebene/A - F/Aufbau und Funktion @ 11\mod _1279185435352_15.doc x @ 83027 @ 111 @ 1
4 Setup and function
Pos: 13 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Aufbau un d Funktion/Waechter /Funktionen - 6854 70 MasterLI NE @ 28\mod_134737385 5300_15.docx @ 232808 @ 2 @ 1
The Busch-Watchdog 70 MasterLINE is a movement detector with a reduced detection range and is suitable for
use in small terraced houses.
Due to the small distance between the pavement and the house, the reduced detection range prevents the light
from being constantly switched on when persons pass the house or when there is movement on the neighboring
property.
The Busch-Watchdogs are passive infrared movement detectors which switch loads via the KNX bus when
sources of heat move within its detection range.
Busch Watchdog is not an intrusion or attack alarm.
Pos:14 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/2. Ebene/A - F/Funktions- und Aussta ttungsmerkmale @ 23\ mod_1336557630140_15. docx @ 209136 @ 2 @ 1
4.1 Features of function and equipment
Pos: 15 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Aufbau un d Funktion/Waechter /Ausstattungsmerk male - 6854 70 MasterLINE @ 29 \mod_1348036639536_1 5.docx @ 233953 @ 111 @ 1
• 12 meters coverage toward the front and 4 meters toward each side.
• 4 Detection levels
• Status display
• Switch-off delay and brightness switching threshold can be adjusted separately
• Reduced detection range
Pos:16 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/2. Ebene/A - F/Erfassungsbereic he @ 19\mod_1320393658466_ 15.docx @ 109558 @ 22222 @ 1
4.2 Detection ranges
Pos:17 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/3. Ebene/U - Z/Übersicht der Erf assungsbereiche @ 18\mod_1 308563903037_15.doc x@ 106965@ 222 @ 1
4.2.1 Overview of the detection ranges
Pos: 18 /#Neustruktur #/Online-Dokumen tation (+KNX)/Erf assungsbereiche/W aechter/Erfassungsber eiche - 6854 - 70 MasterLI NE@ 29\ mod_1347536549389 _15.docx @ 233361 @ 33 @ 1
Fig. 1: Coverage
Detection range
• The detection range is 70° and the coverage is 12 m to the front and four meters to each side.
Wall mounting
• The movement detector offers optimum surveillance if mounted to the wall at a maximum height of 2.5 m.
Pos:19 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ 111 @ 1
12 m
2,5 m
max. 12 m
ca. 8 m

Operating Instructions
Busch-Wächter®Technical data
Operating Instructions | 1473-1-8134 — 5 —
Pos:20 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/1. Ebene/S - T/Technische Daten @ 11\ mod_1279185386320_15. docx @ 83019 @ 22 @ 1
5 Technical data
Pos: 21 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Techni sche Daten/Waec hter/Technische Daten - 6854 @ 24\mod_1338445237653_15.doc x @ 214466 @ 2 @ 1
Designation Value
Nominal voltage 230 V AC ± 10%, 50/60 Hz
Switching capacity 1380 W/VA
Maximum switching current: 6 AX
Maximum power loss < 1 W
Twilight sensor 3, 15, ∞lux
Switch-off delay 1, 3, 5 minutes
Coverage
(if mounted 2.5 m high)
Maximum of 12 m
Operating temperature -25°C … 55°C
Protection type IP 55
Pos: 22 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Sic herheitshinweise und Hin weise (--> Füralle Dokumente<--)/Hinweise - Allgemein/Hinweis- Anschlussvon EVG's- Herstellerangaben@ 24\ mod_1338458660462_15. docx @ 214629 @ 2 @ 1
Information for the connection of ballasts
Please observe the following points regarding high inrush currents for ballasts:
- The ballast manufacturer’s specification determines the possible number of ballasts.
Pos:23 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ 2222 @ 1

Operating Instructions
Busch-Wächter®Installation and electrical
connection
Operating Instructions | 1473-1-8134 — 6 —
Pos:24 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/1. Ebene/M - O/Montage und elektri scher Anschluss @ 23\mod_1336 477157864_15.doc x@ 209 033 @ 2221111 @ 1
6 Installation and electrical connection
Pos: 25 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Sic herheitshinweise und Hin weise (--> Füralle Dokumente<--)/Warnhinweise/Sicherheit- Fachkenntnisse @ 23\mod_1336 559183027_15.doc x@ 209 179 @ 2222 @ 1
6.1 Requirements for the electrician
Warnin
g
Electric voltage!
Install the device only if you have the necessary electrical engineering knowledge and experience.
• Incorrect installation endangers your life and that of the user of the electrical system.
• Incorrect installation can cause serious damage to property, e.g. due to fire.
The minimum necessary expert knowledge and requirements for the installation are as follows:
• Apply the "five safety rules" (DIN VDE 0105, EN 50110):
1. Disconnect from power;
2. Secure against being re-connected;
3. Ensure there is no voltage;
4. Connect to earth and short-circuit;
5. Cover or barricade adjacent live parts.
• Use suitable personal protective clothing.
• Use only suitable tools and measuring devices.
• Check the supply network type (TN system, IT system, TT system) to secure the following
power supply conditions (classic connection to ground, protective earthing, necessary
additional measures, etc.).
Pos:26 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ 33223331133 3 @ 1

Operating Instructions
Busch-Wächter®Installation and electrical
connection
Operating Instructions | 1473-1-8134 — 7 —
Pos:27 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/2. Ebene/M - O/Montage @ 18\mod_130261596045 8_15.docx @ 103424 @ 3333333 @ 1
6.2 Mounting
Pos: 28 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Sic herheitshinweise und Hin weise (--> Füralle Dokumente<--)/Warnhinweise/Sicherheit- 230 V @ 18\mod_13026 06816750_15.doc x@ 1033 08@ 1322 133 @ 1
Warnin
g
Electric voltage!
Risk of death and fire due to electrical voltage of 230 V.
– Work on the 230V supply system may only be performed by authorised electricians!
– Disconnect the mains power supply prior to installation and/or disassembly!
Pos: 29 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Montage/ Waechter/Montage - 6854@ 25\mod_ 1340271054245_15.doc x @ 219266 @ 2122223 @ 1
Warning
Electric voltage!
Danger from touching current-carrying parts when opening the device.
- Always disconnect the mains voltage before opening the device!
Caution
Risk of damaging the device!
The lens of the device is sensitive and
can easily sustain damage.
- Do not press on the lens when
setting the device!
6.2.1 Installation sites
Fig. 2: Installation sites
• The mounting height of the device should be between 1.7 m and 2.5. m.
• The distance between light and movement detector should be at least 1.5 m.
• For optimum detection of persons the approach into the detection range should always be offset and never
frontal.
>1,7 m

Operating Instructions
Busch-Wächter®Installation and electrical
connection
Operating Instructions | 1473-1-8134 — 8 —
6.2.2 Preparing the installation
To prepare the installation of the device, perform the following steps:
Fig. 3: Preparing the installation
1. Remove the locking screw (1) (if installed).
2. Press in the clamps (2 ... 5) on the sides of the housing with a suitable tool.
3. Carefully remove the front of the device.
Fig. 4: Opening the water drain
Depending on where the device is installed, the water drain may have to be opened.
• To do this, pierce the plastic membrane on the bottom of the device.
The installation is prepared.
1
23
4
5

Operating Instructions
Busch-Wächter®Installation and electrical
connection
Operating Instructions | 1473-1-8134 — 9 —
6.2.3 Mounting steps
Fig. 5: Fixing to the wall
Connecting terminals
Connection Function
N Neutral conductor
→switched phase?
L Phase (230 V AC, 50 / 60 Hz)
Grounding conductor connection
1. Mount the device on the wall.
- Do not use countersunk head screws for mounting
to the wall.
- Use screws with a head diameter of 6.5 mm - 8.5
mm.
2. Connect the power to the device, see section 6.3.
- Observe the maximum admissible cable cross
sections.
N
L
∅6,5 mm - 8,5 mm
∅3,5 mm - 3,9 mm
mm5,41.xam
²mm
5
,2-5,1

Operating Instructions
Busch-Wächter®Installation and electrical
connection
Operating Instructions | 1473-1-8134 — 10 —
- For cable cross sections larger than 1.5 mm² use
only cable entry (B) or (C).
3. To protect the device against unauthorized opening, the
enclosed screw can be used on the bottom of the
device.
- To protect the device against unauthorized opening,
screw the enclosed screw into the bottom of the
device.
Pos:30 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ 23332 @ 1
BC

Operating Instructions
Busch-Wächter®Installation and electrical
connection
Operating Instructions | 1473-1-8134 — 11 —
Pos:31 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/2. Ebene/A - F/Elektrischer Ansc hluss @ 21\mod_13281770517 24_15.docx @ 138042 @ 1233333 33 @ 1
6.3 Electrical connection
Pos: 32 /#Neustruktur #/Online-Dokumen tation (+KNX)/Anschl uss/Waechter/Ansc hluss - 6854 70 -- MasterLI NE@ 28\ mod_1346844068086_15. docx @ 230375 @ 1333 @ 1
6.3.1 Standard connection
Fig. 6: Universal relay insert
6.3.2 Standard connection with extension unit push-button
Fig. 7: Universal relay insert with extension unit push-button
Note
For more information see chapter "Extension unit operation" 8.3 on page 15.
NL
16A
N
L
N
L
NL
16A

Operating Instructions
Busch-Wächter®Installation and electrical
connection
Operating Instructions | 1473-1-8134 — 12 —
6.3.3 Standard connection with triple-step switch
Fig. 8: Universal relay insert with triple-step switch
The connection is made with a triple-step switch such as 2713 U, 2710 U
Step switch function:
1. Continuous light
2. System off
3. Movement detector
6.3.4 Standard connection with RC suppressor 6899 and relay
Fig. 9: Universal relay insert with RC suppressor 6899 and relay
Pos:33 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ 22222 @ 1
NL
123
N
L
16A
NL
N
L
16A

Operating Instructions
Busch-Wächter®Commissioning
Operating Instructions | 1473-1-8134 — 13 —
Pos:34 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/1. Ebene/G - L/Inbetriebnahme @ 11\mo d_1279185496977_15.doc x @ 83035 @ 22222 @ 1
7 Commissioning
Pos: 35 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Inbetri ebnahme/Waechter /Inbetriebnahme - 6854 @ 25\ mod_1340274623213_1 5.docx @ 219700 @ 222 @ 1
7.1 Setting the coverage
Use the following steps to set the coverage:
Fig. 10: Setting the coverage
1. Set the coverage of the device by turning the controller (1).
- The sensor shifts when the controller is turned. The higher the setting of the sensor the smaller is the
coverage.
- The adjustment range of the sensor ranges from 6 m (sensor position at the top) to a maximum of 12 m
(sensor position at the bottom).
7.2 Activation test
Fig. 11: Control element
To carry out the activation test, perform the following steps:
1. Set selector switch to T/S.
- The device is now in test mode for 10 minutes (daytime operation, switch-off delay 2 sec.). In addition,
each detection is indicated by the status LED flashing quickly.
- After this, the device switches back to standard operating mode.
2. To carry out an additional activation test, set the selector switch back to position T/S or interrupt the operating
voltage supply for more than 15 seconds.
- The device is now in test mode for another 10 minutes. Test mode is exited automatically after 10 minutes
or by adjusting the brightness.
The activation test has been carried out.
Pos:36 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ 333 @ 1
1
+
-
T/S
3 min
1 min
5
min

Operating Instructions
Busch-Wächter®Operation
Operating Instructions | 1473-1-8134 — 14 —
Pos:37 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/1. Ebene/A - F/Bedienung @ 11\mod_1279185 541649_15.doc x@ 83043 @ 3233 333 @ 1
8 Operation
Pos: 38 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Bedienu ng/Waechter/Bedi enung - 6854 @ 24\mod_13384487 58706_15.docx @ 214557 @ 3333 @ 1
8.1 Standard operation
Fig. 12: Control element
Set the ON period and the switch-on brightness on the rotary switch.
ON period and switch-on brightness
Icon Function
ON period during daytime operation
ON period at the start of twilight
ON period during advancing twilight
ON period at the start of twilight
ON period during advancing twilight
T/S Selector switch
8.2 Function status LED
Fig. 13: Status LED
Status LED (1)
LED Status
-Flashes fast Detection in test mode
-Flashes 3 times Detection in standard mode
Pos:39 /#Neustruktur#/Online-Dokumentation(+KNX)/Steuermodule- Online-Dokumentation(--> Füralle Dokumente<--)/++++++++++++ Seitenumbruch +++++ +++++++ @ 9\mod_1268898668093 _0.docx @ 52149 @ 2223333 @ 1
T/S
3 min
1 min
5
min
3
min
1 min
1 min
5
min
5
min
1

Operating Instructions
Busch-Wächter®Operation
Operating Instructions | 1473-1-8134 — 15 —
Pos:40 /#Neustruktur#/Online-Dokumentation(+KNX)/Überschriften(--> Füralle Dokumente<--)/2. Ebene/M - O/Nebenstellenbetri eb @ 18\mod_1308568178899_ 15.docx @ 107029 @ 2222222 @ 1
8.3 Auxiliary post operation
Pos: 41 /#Neustruktur #/Online-Dokumen tation (+KNX)/Nebenst ellenbetreib/W aechter/Nebenstel lenbetrieb - 6854 -- 70MasterLI NE@ 29\ mod_1347536933190_ 15.docx @ 233375 @ 2222 @ 1
8.3.1 Operation with extension unit push-button
Aside from the movement detector being triggered by the infrared radiation in the detection range, manual
operation is possible via an extension unit push-button.
For example, when an exit is not within the detection range of the movement detector, the extension unit push-
button can be used. The lighting can there be switched on or off manually with the push-button.
Fig. 14: Operation with extension unit push-button
• When operating with an extension unit push-button, the lighting for the set operating mode is switched on.
=== Ende der Liste für TextmarkeCon tent ===

Operating Instructions
Busch-Wächter®
1473-1-8134 | Rev. 01 | 11.2012
Pos:43 /#Neustruktur#/Online-Dokumentation(+KNX)/Rückseiten(--> Für alleDokumente<--)/Rückseite- Busch-Jaeger- A llgemein @ 28\mod_1347009779 995_15.docx @ 232282 @ @ 1
A
member of the ABB Group
Busch-Jaeger Elektro GmbH
PO box
58505 Lüdenscheid
Freisenbergstraße 2
58513 Lüdenscheid
Germany
www.BUSCH-JAEGER.com
[email protected]om
Central sales service:
Phone: [phone]
Fax: [phone]
Notice
We reserve the right to at all times make
technical changes as well as changes to the
contents of this document without prior notice.
The detailed specifications agreed to at the time
of ordering apply to all orders. ABB accepts no
responsibility for possible errors or
incompleteness in this document.
We reserve all rights to this document and the
topics and illustrations contained therein. The
document and its contents, or extracts thereof,
must not be reproduced, transmitted or reused by
third parties without prior written consent by ABB.
Copyright© 2012 Busch-Jaeger Elektro GmbH
A
ll rights reserved
=== Ende der Liste für TextmarkeBac kcover ===
