Core 40155 User manual

1Extend Canopy Frame
CAUTION: Avoid pinch points when opening
or closing the CANOPY FRAME.
• Expand and spread out CANOPY FRAME
halfway.
4Attach Canopy to Frame
7
Secure Canopy
• Position the shelter in its final position before securing with stakes
and guylines.
∙ Locate FOOT at the bottom of each CANOPY LEG (4 total).
• Slide STAKE through holes at bottom of each CANOPY LEG (fig. 6).
• Locate GUYLINES attached to the CANOPY and unroll.
• Slide STAKE through SUYLINE loop on all four corners. Extend GUYLINE
and drive STAKE into ground to provide additional stability (fig. 7).
NOTE: Extend four corner GUYLINES out at a 45º angle from shelter.
• Adjust GUYLINES as needed by adjusting the SLIDER up the cord.
Model #40155
Carry Bag (91799)
Canopy Top (91798)
Stakes (90004)
Apex
Support
Pole
(91972)
E Shape
Joint
(91795) Long Awning
Corner Pole
(91793)
Lower
Roof Pole
(91791)
Roof
Joint
(90755)
Scissor
Pole
A (91788)
B (91789)
Scissor Joint (90749)
Upper Roof Pole (91790)
Center Hub
(90763)
Joint
Endcap
(90748)
Awning
Joint
(91796)
Canopy Leg
(91797)
x 8
Contents & Repair Parts
STITCH LINE
13’ x 13’ Instant Canopy
13ft x 13ft x 114in
2 People Rubber Mallet Level Area
We Recommend...
(continued on back)
Need some help?
1-888-775-5628
coreequipment.com
Lock and Secure Canopy Frame
∙ To finish expanding the frame, grasp the CANOPY LEG above the
GRAY BUTTON and push up on the APEX SUPPORT POLE
until the GRAY BUTTON “clicks” into locked position (fig. 1).
• Repeat for remaining 3 APEX SUPPORT POLES to fully raise
the ROOF PEAK.
3
Fully Extend Frame
∙ Drape CANOPY over FRAME.
∙ Fully extend FRAME by having 2 people
pull from opposite
corners.
2
∙Place LONG AWNING CORNER POLES into corner pockets (fig. 2).
∙ Locate HOOK & LOOP FASTENERS along the seam of the underside
of the CANOPY TOP; then wrap around SCISSOR
POLE to secure (fig. 3).
∙Repeat for remaining 3 sides of the CANOPY.
5
Adjust to Desired Height
∙Place your foot on the CANOPY LEG; then grasp and extend the CANOPY LEG
until the GRAY BUTTON "clicks" into the locked position (fig. 4).
• Repeat for remaining CANOPY LEG POLES.
NOTE: Once locked, push in the GRAY
BUTTON to extend the CANOPY LEG
to desired height (fig. 5).
fig. 1
APEX
SUPPORT
POLE
fig. 2
LONG
AWNING
CORNER POLE
CORNER
POCKET
fig. 3
fig. 5
3-Stage Height
Adjustability
LOW
HIGH
MEDIUM
fig. 4
GRAY
BUTTON
fig. 6
fig. 7
Short
Awning
Corner
Pole
(91794)

Follow the previous steps and illustrations on other side of this tag in
the reverse order:
• Remove all STAKES from GUYLINES and CANOPY LEG and store in
stake bag.
• Release hook-and-loop fasteners underneath CANOPY TOP to
disconnect from frame. This will help prevent the fabric from tearing
during takedown.
• Press the GRAY BUTTONS on each CANOPY LEG and telescope down.
• Press the top GRAY BUTTONS near all four APEX SUPPORT POLES
to release from locked position.
• Remove CANOPY TOP from FRAME. Fold lengthwise and store with
FRAME in CARRY BAG.
• Fold up FRAME and place into CARRY BAG. Be careful to avoid
pinch points!
Storing the Canopy
• Store in a clean, dry area.
• All stakes must be placed in the STAKE BAG before placing in CARRY
BAG to prevent damage to the CANOPY TOP.
• For short-term storage (1-2 weeks), it is acceptable to leave the
CANOPY TOP attached to the FRAME.
• NOTE: For long-term storage, remove the CANOPY TOP & store
separately.
Elevate LLC
Overland Park, KS 66223
Made in China
Take Down Instructions:
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM
THIS SHELTER FABRIC
This shelter is made of flame-resistant fabric which meets CPAI-84
specifications. IT IS NOT FIREPROOF. The fabric will burn if left in
continuous contact with any flame source. The application of any foreign
substance to the product fabric may render the flame-resistant
properties ineffective.
DO NOT use fuel burning devices inside or near shelter materials.
DO NOT permit children to light matches, operate burning appliances or
handle any flame sources in or near the shelter.
• Do not smoke, use matches, candles or open flames of any kind in or
near the shelter.
• Do not refuel lanterns, stoves or heaters inside shelter.
• Do not cook inside shelter.
• Do not store flammable liquids inside shelter.
WARNING: Keep clear of overhead power lines.
• Do not set up your shelter under trees because of potential
lightning strikes or falling tree limbs in inclement weather.
• Secure with all stakes and guylines provided to prevent property
damage or personal injury.
• Never store shelter, even for a short period of time, without drying it
thoroughly and brushing off caked dirt. Do not pack stakes inside your
shelter. Use a separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE
ITSELF. NEVER PULL ON THE SHELTER TO REMOVE STAKE.
• Do not leave your shelter set up for weeks at a time. Be aware that
exposure to ultraviolet rays from the sun can seriously damage
material and/or cause it to become discolored.
IMPORTANT:
THE ORIGINAL FIRE RETARDANT AND WATER-REPELLENT PROTECTIVE
COATINGS MAY BE COMPROMISED IF SPRAYS OR OTHER CHEMICAL
TREATMENTS ARE USED ON THE SHELTER. THE CANOPY FABRIC HAS BEEN
FACTORY TREATED. IT IS HIGHLY WATER-REPELLENT; HOWEVER, IT IS
NOT WATERPROOF. ALL SHELTERS CAN EXPERIENCE SEAM LEAKAGE
DURING WET WEATHER. IF YOU WANT ADDITIONAL MOISTURE
PROTECTION, TRY A SEAM SEALING COMPOUND ONLY; STRICTLY
FOLLOW THE MANUFACTURER’S DIRECTIONS. IT IS RECOMMENDED
THAT YOU SEAL THE SHELTER DURING THE INITIAL SETUP AS WELL AS
PRIOR TO EACH CAMPING SEASON. SEAM SEALER COMPOUNDS CAN
BE PURCHASED AT YOUR LOCAL CAMPING PRODUCTS OUTLET. FOR
MISSING PARTS CALL 1-888-775-5628.
PLEASE DO NOT RETURN THIS PRODUCT TO THE RETAIL STORE.
DO NOT SPRAY!
Warnings and Cautions:
• Are replacement parts available? Yes, please call Customer Service
at 1-888-775-5628 for replacement parts. All parts can be replaced.
• Why are my CANOPY LEGS not locking into place? Be sure that the
GRAY BUTTONS are secure. Extend pole further if it is not locked.
It will “click” into place.
• How do I clean my CANOPY TOP? Clean the CANOPY TOP with
a soft sponge, a mild soap and tepid water. Be sure to scrub gently
and remove all soap. Let dry in sunlight, which also naturally cleans
the canopy.
• Why is it difficult to extend the roof assembly on my FRAME?
Be sure to stretch the FRAME out fully, and lock the roof assembly into
place before raising the CANOPY LEGS.
• When should I attach the CANOPY TOP? Attach the CANOPY TOP
after the FRAME is expanded, but before extending the CANOPY
LEGS or roof assembly.
Frequently Asked Questions:
CORE®Equipment and Elevate LLC warrants for a period of one year
from the original date of purchase this product against any defects in
materials or workmanship. At its discretion, CORE®Equipment may
provide replacement parts to original purchaser. Original
receipt or proof of purchase as well as proof of defect in the form of a
photograph or video is required. CORE®Equipment will not be
responsible for shipping costs incurred outside the continental USA.
Warranty is valid for the original purchaser one year from the date of
purchase and is not transferable. This warranty does not cover any
product purchased through unauthorized dealers/distributors and/or
unauthorized resellers on online auction websites. CORE®uses
approved and authorized distributors to furnish quality products, and
CORE®provides warranty coverage only on products purchased from
those distributors. If the product was purchased from an unauthorized
reseller, this warranty does not apply. Unauthorized resellers may sell
products that are used, defective, counterfeit, or which may not be
designed for use in that specific country. To determine whether the
seller of a CORE®Equipment product is one that has been approved
and authorized by Elevate LLC owner of the CORE®Equipment brand,
please contact [email protected] or call customer service at
1-888-775-5628.
This 1-Year Limited Warranty does NOT cover normal wear and tear,
abuse or misuse of this product including damage from inclement
conditions, such as wind, rain or hail. In case of inclement weather,
remove all valuables and persons and seek appropriate shelter. Under
no circumstances will CORE®Equipment or Elevate LLC be liable or
responsible for any incidental or consequential damages.
This product is designed and intended for recreational use only.
Prolonged exposure to UV rays will cause any fabric to fade and
deteriorate and is NOT covered by this 1-Year Limited Warranty. All
replacement products or parts will assume the remaining warranty of
the original product. This warranty gives you specific legal rights. You
may also have other rights which vary from state to state. To obtain
Warranty Service: Call Toll Free 1-888-775-5628 for warranty service,
repair parts or product questions. Monday - Friday, 8:00 a.m. - 5:00 p.m.
Central Time.
1-Year Limited Warranty:
Revised 6/9/20
STITCH LINE
