Cornelius QUEST CAFE Setup guide

QUEST ELITE 4000/QUEST CAFE
Installation And Operator Manual
Release Date: December 10, 2010
Publication Number: 620048956INS
Revision Date: July 16, 2018
Revision: H
Visit the Cornelius web site at www.cornelius.com for all your Literature needs.
QUEST ELITE 4000
QUEST CAFE
QUEST ELITE 4000 (VERTICAL)

The products, technical information, and instructions contained in this manual are subject to change without notice.
These instructions are not intended to cover all details or variations of the equipment, nor to provide for every possi-
ble contingency in the installation, operation or maintenance of this equipment. This manual assumes that the per-
son(s) working on the equipment have been trained and are skilled in working with electrical, plumbing, pneumatic,
and mechanical equipment. It is assumed that appropriate safety precautions are taken and that all local safety and
construction requirements are being met, in addition to the information contained in this manual.
This Product is warranted only as provided in Cornelius’ Commercial Warrant applicable to this Product and is sub-
ject to all of the restrictions and limitations contained in the Commercial Warranty.
Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting
from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal
service conditions with respect to the Product, (2) improper voltage, (3) inadequate wiring, (4) abuse, (5) accident,
(6) alteration, (7) misuse, (8) neglect, (9) unauthorized repair or the failure to utilize suitably qualified and trained per-
sons to perform service and/or repair of the Product, (10) improper cleaning, (11) failure to follow installation, oper-
ating, cleaning or maintenance instructions, (12) use of “non-authorized” parts (i.e., parts that are not 100%
compatible with the Product) which use voids the entire warranty, (13) Product parts in contact with water or the
product dispensed which are adversely impacted by changes in liquid scale or chemical composition.
Contact Information:
To inquire about current revisions of this and other documentation or for assistance with any Cornelius product con-
tact:
www.cornelius.com
800-238-3600
Trademarks and Copyrights:
This document contains proprietary information and it may not be reproduced in any way without permission from
Cornelius.
This document contains the original instructions for the unit described.
CORNELIUS INC
101 Regency Drive
Glendale Heights, IL
Tel: + 1 800-238-3600
Printed in U.S.A.

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 0 - Publication Number: 620048956INS
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Read And Follow All Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Different Types of Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Qualified Service Personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Shipping And Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Mounting In or On A Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unit dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Receiving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Nameplate Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Concentrate Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ice Bank/Pull Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Counter Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Minimum Airflow Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting the Water Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Plumbing and Water Supply Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Filling the Ice Bath . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Priming/Flushing Water System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
BRIXING Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Checking/Adjusting the BRIX Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Programming the Portion Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Clean Splash Zones and Dispense Nozzles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Weekly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sanitize the Juice Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 1 - Publication Number: 620048956INS
SAFETY INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
Safety Overview
• Read and follow ALL SAFETY INSTRUCTIONS in this manual and any warning/caution labels
on the unit (decals, labels or laminated cards).
• Read and understand ALL applicable OSHA (Occupational Safety and Health Administration) safety regula-
tions before operating this unit.
Recognition
Different Types of Alerts
!
DANGER:
Indicates an immediate hazardous situation which if not avoided WILL result in serious injury, death or equipment
damage.
!
WARNING:
Indicates a potentially hazardous situation which, if not avoided, COULD result in serious injury, death, or
equipment damage.
!
CAUTION:
Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury or
equipment damage.
SAFETY TIPS
• Carefully read and follow all safety messages in this manual and safety signs on the unit.
• Keep safety signs in good condition and replace missing or damaged items.
• Learn how to operate the unit and how to use the controls properly.
• Do not let anyone operate the unit without proper training. This appliance is not intended for use by very
young children or infirm persons without supervision. Young children should be supervised to ensure that
they do not play with the appliance.
• Keep your unit in proper working condition and do not allow unauthorized modifications to the unit.
NOTE: The dispenser is not designed for a wash-down environment and MUST NOT be placed in
an area where a water jet could be used.
Recognize Safety Alerts
This is the safety alert symbol. When you see it in this manual or on the unit, be alert
to the potential of personal injury or damage to the unit.
!

Quest Elite 4000 Installation Manual
Publication Number: 620048956INS - 2 - © 2010-2016, Cornelius Inc.
QUALIFIED SERVICE PERSONNEL
!
WARNING:
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit.
ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY
COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER, ITS SERVICE
AGENT OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
SAFETY PRECAUTIONS
This unit has been specifically designed to provide protection against personal injury. To ensure continued
protection observe the following:
!
WARNING:
Disconnect power to the unit before servicing following all lock out/tag out procedures established by the user. Verify
all of the power is off to the unit before any work is performed.
FAILURE TO DISCONNECT THE POWER COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT
DAMAGE.
!
CAUTION:
Always be sure to keep area around the unit clean and free of clutter. Failure to keep this area clean may result in
injury or equipment damage.
DO NOT STORE EXPLOSIVE SUBSTANCES SUCH AS AEROSOL CANS WITH A FLAMMABLE
PROPELLANT IN THIS APPLIANCE.
CHILDREN SHALL NOT PLAY WITH THE APPLIANCE.
CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY CHILDREN WITHOUT SUPERVISION.
SHIPPING AND STORAGE
!
CAUTION:
Before shipping, storing, or relocating the unit, the unit must be sanitized and all sanitizing solution must be drained
from the system. A freezing ambient environment will cause residual sanitizing solution or water remaining inside the
unit to freeze resulting in damage to internal components.
MOUNTING INOR ONA COUNTER
!
WARNING:
When installing the unit in or on a counter top, the counter must be able to support a weight in excess of 140 lbs. (63.5
kg.) to insure adequate support for the unit.
FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE.
THE APPLIANCE HAS TO BE PLACED IN A HORIZONTAL POSITION

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 3 - Publication Number: 620048956INS
UNIT DIMENSIONS
Figure 1. Quest Elite 4000
Figure 2 Quest Elite 4000 (Vertical)
Figure 3 Quest Cafe

Quest Elite 4000 Installation Manual
Publication Number: 620048956INS - 4 - © 2010-2016, Cornelius Inc.
RECEIVING
Each unit is completely tested and inspected before shipment. At the time of shipment, the carrier accepts the unit
and any claim for damage must be made with the carrier.
Upon receiving the unit(s) from the carrier, inspect the carton for visible damage. If damage exists, have the carrier
make a note on the bill of lading and file a claim with the carrier.
UNPACKING
• Remove staples securing carton to pallet.
• Lift carton up and off of unit.
• Remove inserts and shipping bag.
• Open upper cabinet door and remove installation kit.
• Remove bolts securing unit to pallet.
• Lift unit off of pallet.
NOTE: Do not lay the unit on it’s side or back. This may cause vital oils to drain from the compres-
sor resulting in damage during start-up and consequently voiding the warranty.
Nameplate Data
Concentrate Storage
Four 0.8 gallon (3.0 liter) disposable bottles.
NOTE: Refillable Concentrate reservoirs also available.
Figure 4. Concentrate Storage
Ice Bank/Pull Down
Weight 14-16 lbs. (6.35 - 7.25 kg.). Pull Down: 3.5 - 5.5 hours at 75°F (24°C)
Models VAC Amps Ph Hz Refrigerant Test Pressure psi (Kpa) (bar)
Oz Grams Type High side Low side
QST Elite
4000 115 5 1 60 6.34-6.41 180-182 R-134a 400 (2757.9) / 27.6 88 (606.7) (6.1)
QST Elite
4000 230 2 1 50 6.34-6.41 180-182 R-134a 400 (2757.9) / 27.6 88 (606.7) (6.1)
QST Elite
4000 220 2 1 60 6.34-6.41 180-182 R-134a 400 (2757.9) / 27.6 88 (606.7) (6.1)
QST Cafe
4000 115 5 1 60 6.34-6.41 180-182 R-134a 400 (2757.9) / 27.6 88 (606.7) (6.1)
QST Elite
4000 (Vertical) 115 5 1 60 6.34-6.41 180-182 R-134a 400 (2757.9) / 27.6 88 (606.7) (6.1)

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 5 - Publication Number: 620048956INS
APPLICATIONS
This appliance is intended to be used in household and similar applications such as the following:
• Staff kitchen areas in shops, offices and other working environments.
• Farm houses and by clients in hotels, motels and other residential type environments.
• Bed and breakfast type environments.
• Catering and similar non-retail applications.

Quest Elite 4000 Installation Manual
Publication Number: 620048956INS - 6 - © 2010-2016, Cornelius Inc.
REQUIREMENTS
COUNTER LOCATION
Select a location in a well ventilated area, close to a grounded electrical outlet. If possible do not place the unit
close to hot and/or steaming machines.
MINIMUM AIRFLOW CLEARANCE
The minimum airflow clearance is: 4” (10.16 cm) in back, 12” (30.48 cm) on top, 4” (10.16) at sides and open to the
front.
!
IMPORTANT:
Condenser air is drawn in from the bottom of the rear panel and discharged out the top of the rear panel &
side panels. Failure to maintain clearance space will reduce capacity of the unit and cause premature
compressor failure.
The Dispenser needs to be placed using 4” legs that are included.
Figure 5. Minimum Clearances
MINIMUM 12’’ AIR
CLEARANCE AT TOP
MINIMUM 4’’ AIR FLOW
CLEARANCE AT BACK
AND 4’’ AT SIDES

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 7 - Publication Number: 620048956INS
CONNECTING THE WATER SUPPLY
The Quest Elite series Juice Dispenser is designed to dispense juice at a high flow rate. It is very important that the
incoming water line be dedicated for use by the dispenser only and does not have other machines connected which
could cause a water surge, (i.e., a dishwasher, coffee maker, etc.).
!
IMPORTANT:
The water supply should be consistent with proper water quality standards (neutral pH of 7.0 to 8.0), and
should not be connected to a water softener. It is the installer’s responsibility to ensure that all water
connections to the dispenser are sized, installed with adequate backflow protection and maintained to
comply with Federal, State, and Local Laws.
PLUMBING AND WATER SUPPLY REQUIREMENTS
This dispenser must be connected to a COLD WATER system with operating pressure between
30 psi (206.8 kPa) (2.1 bar) minimum (dynamic) and 60 psi (413.7 kPa) (4.1 bar) maximum (static). This water
source must be capable of producing a minimum flow rate of 3 fluid ounces (88.7 ml) per second. A shut off valve
should be installed in the line before the dispenser. Install a regulator in the line when pressure is greater than 60
psi (413.7 kPa) to reduce it to 50 psi (345 kPa) (3.5 bar) (dynamic). The regulator is also necessary if the water
source has pressure fluctuations.
!
WARNING:
This equipment must be installed to comply with the International Plumbing Code of the International Code Council
and the Food Code Manual of the Food and Drug Administration (FDA). For models installed outside the U.S.A., you
must comply with the applicable Plumbing/Sanitation Code for your area.
Failure to comply could result in serious injury, death or damage to the equipment.
1. Secure the 3/8” (0.95 cm) swivel nut on the flexible supply tubing to the water inlet located at the rear of the dis-
penser. Make sure that the flared gasket is used (flared gasket P/N 311304000 is included with the installation
kit).
Figure 6 Water Supply Connection on Rear of Unit
2. When securing flare nut, use a backup wrench on the male side of the inlet fitting (unit side) to prevent twisting
of the copper tube inside the unit and/or possible damage to the water strainer/solenoid. Water shut off outside
the unit is recommended.
Water Inlet
with Supply Tubing
Connected
Water Inlet

Quest Elite 4000 Installation Manual
Publication Number: 620048956INS - 8 - © 2010-2016, Cornelius Inc.
FILLING THE ICE BATH
The ice bath holds approximately 3.5 gallons (13.4 liters) of water. The fill tube is located behind the front splash
plate and capped with a 0.5” plug.
1. Remove the 0.5” plug and attach the tube to any one of the dispense nozzles.
2. Open the door and verify that the flush/dispense lever is in the dispense mode. (see Figure 7) Ice
bath must always be filled in the dispense mode.
NOTE: Non flush units does not have a flush/dispense lever hence for filling water bath on non
flush units please remove the concentrate Storage bottles first and then attach the tube to
any one of the dispense nozzles and close the door, press and hold the dispense button
(push) until the tank is filled and water trickles from the overflow
Figure 7. Water Bath and Dispense/Flush Lever
3. Close the door, press and hold the dispense button (push), shown in . Dispense Buttons, until the
tank is filled and water trickles from the overflow.
Figure 8. Dispense Buttons
4. Once the ice bath is full, store the fill tube in the vertically recessed holder. The fill tube can now be
used as a “sight glass” to monitor the water level in the ice bath.
Dispense/Flush
Lever
Water Bath
Fill Tube
Water Bath
Overflow
Water Bath
Fill Tube
Connection

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 9 - Publication Number: 620048956INS
ELECTRICAL REQUIREMENTS
!
CAUTION:
Only trained and certified electrical technicians should replace the power cord or the unit should be returned to an
Authorized Service Center for power cord replacement.” The replacement cord must meet all requirements of the
original equipment manufacturer.
FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR DAMAGE TO THE EQUIPMENT.
1. A minimum of 15 amps electrical service is needed for 120VAC power supply. A minimum of 10 amps electrical
service is needed for 230VAC power supply.
2. 6 ft. long (1.83 m) power cord with 3-prong plug attached to dispenser. Export models are shipped with a Euro-
pean plug.

Quest Elite 4000 Installation Manual
Publication Number: 620048956INS - 10 - © 2010-2016, Cornelius Inc.
PRIMING/FLUSHING WATER SYSTEM
To properly prime the unit with water and remove air pockets in the system, open the cabinet door and make sure
that all the valve levers are in the Dispense position.
Close the door and press the dispense button for a few seconds. Repeat until a steady flow of water is observed
from all dispense valves.
NOTE: Some splashing may occur during this purge cycle.
Figure 9. Dispense Nozzle
Static Mixer
Dispenser Nozzle

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 11 - Publication Number: 620048956INS
BRIXING PROCEDURE
NOTE: If concentrate is not properly thawed, it will adversely affect the amount of concentrate dis-
pensed. Thawed product should be between 35°F/1.6°C to 40°F/4.4°C.
SUPPLIES
• 1 - Small 12 oz. cup (354.8 ml)
• 1 - Large 21 oz. cup (621.1 ml)
• 1 - Straw
• Paper Towels
• 1 - Thermometer
• 1 - Refractometer
• 1 - Flat Bladed Screwdriver
NOTE: The refractometer shown is P/N 511004000, and is available through your local Cornelius
Distributor.
CHECKING/ADJUSTING THE BRIX SETTING
The following instructions are for use with a refractometer.
1. Dispense approximately 8 oz. (237 ml) of drink and discard. Now draw a second 8 oz. (237 ml) drink.
2. Check drink temperature with a accurate thermometer (target is 35 to 45°F, or 1.6 to 7.2°C). Discard
this drink after checking temperature.
NOTE: If drink temperature is not within the target range, refer to the basic troubleshooting sec-
tion.
3. Dispense a 12 oz (354.8 ml) drink sample into a clean, 21 oz (621.ml) dry cup. Thoroughly stir the
sample using a straw.
4. Using the straw, transfer a small sample of the finished drink to the refractometer lens (refer to operat-
ing instructions supplied with your refractometer). Check the BRIX reading against the BRIX chart
shown in Table 2.
NOTE: The BRIX chart shown in Table 2 is generic and intended for reference use only. Contact
your frozen concentrate supplier for specific BRX readings.
Table 1.
5. To change the BRIX setting, simply re-adjust the water flow rate. Located on each of the valve assem-
blies inside the refrigerated compartment are the adjusting screws for the water flow rate (one per
valve).
Flavor Ratio BRIX
Orange Juice 4+1 11.8
Grapefruit Juice 5+1 10.6
Cranberry Cocktail 4+1 13.5
Apple Juice 5+1 12.0
Grape 5+1 13.0
Lemonade 5+1 10.5
Tropical Punch 5+1 11.8
Sweetened Ice Tea 7+1 6.0
Pineapple Juice 4+1 12.8
Prune Juice 2+1 16.0

Quest Elite 4000 Installation Manual
Publication Number: 620048956INS - 12 - © 2010-2016, Cornelius Inc.
If the BRIX reading is too high or low, rotate the appropriate water flow control according to Figure 10. Repeat steps
1-5 until the proper BRIX setting is achieved.
Figure 10
IMPORTANT: When making changes to the water flow control, do not rotate more than 1/4 turn per
adjustment. Additionally, prior to taking your next BRIX reading, momentarily press the
corresponding dispense button several times prior to drawing a sample. This clears
any remnants from the dispense nozzle and helps move the flow control to its new
setting.
Water Flow Controls

Quest Elite 4000 Installation Manual
© 2010-2016, Cornelius Inc. - 13 - Publication Number: 620048956INS
PROGRAMMING THE PORTION CONTROL
If the dispenser has optional portion controls, they have been pre-programmed from the factory to pour 7, 12, and
16 ounce drinks. The “extra large” (pitcher icon) size has also been pre-programmed to pour 16 ounces.
To change the pour sizes, please perform the procedure described in .
Figure 11. Control Panel
STOP BUTTON
To pour a drink without using a pre-programmed portion control size, simply push and hold the Stop button.
Release when the glass is full.
Table 2.
Step Action
1
Simultaneously, press and hold Small and Extra Large buttons on
the Portion Control Module until the Refill light starts blinking.
Release the buttons. The blinking Refill light indicates the program-
ming mode is active. See . Control Panel.
2
Place a cup under the dispense nozzle and push the selected size
button (small, medium, large, or extra large). Hold the button in until
the cup fills to the desired portion, then release the button. Repeat
the procedure for the remaining sizes.
3
After programming all the drink sizes, press and release the Stop
button to return the Portion Control to the operational mode. The
blinking REFILL light goes off.
4
In the future, to change the portion size of the drinks, the individual
sizes can be adjusted by performing Step 2. It is not necessary to
reprogram every size. Additionally, the portion control has full mem-
ory retention in case of a power failure.

Quest Elite 4000 Installation Manual
Publication Number: 620048956INS - 14 - © 2010-2016, Cornelius Inc.
CLEAN SPLASH ZONES AND DISPENSE NOZZLES
1. On a daily basis, using a clean, damp cloth, clean the external cabinet and splash areas including the
door gasket. Remove and wash the cup rest and drip tray using mild dish soap.
2. Remove the dispense nozzles and static mixers by rotating each 90° and pulling down. Remove the
mixing chambers by pulling straight forward. Wash using mild dish soap.
IMPORTANT: DO NOT wash nozzles, static mixers, or mixing chambers in a dish washer. This will
distort the plastic and damage the o-rings. Additionally, do not soak them in sanitizing
solution longer than 2 minutes.
Flush once a day for better quality drinks.
!
WARNING:
Do not leave the unit in FLUSH mode. Leaving the unit in flush mode may result in damage.
Weekly
Check concentrate to water brix ratio (refer to the Checking/Adjusting the BRIX Setting section, Page 11).
Sanitize the Juice Dispenser
1. Rinse the unit with hot water.
2. Prepare two 2 oz. (59 ml) packets of Stera-Sheen Green Label sanitizing solution (or similar brand)
by dissolving each packet in 1 gallon (3.8L) of potable water to ensure 200 ppm of available chlorine.
IMPORTANT: Use potable water at 80°F-100°F (26.7°C-37.8°C). Water above this range breaks down
the chlorine count and minimizes sanitation.
3. Remove the juice concentrate containers and place them in separate refrigerated compartment.
4. Flush the system by following the instructions in Flush System on page 12.
5. Fill a clean empty concentrate container with one quart of extremely hot tap water, approximately
140°F (60°C) and place the container into the unit. Dispense all of the hot water into a large con-
tainer. Repeat for all the remaining dispense valves.
6. Remove the mixing chambers, nozzles, and static mixers. Rinse in hot water to remove excess pulp
and concentrate.
7. Place the mixing chambers, nozzles, and static mixers in a separate container of sanitizing solution
and agitate vigorously. Allow the parts to soak for two minutes, then rinse thoroughly with fresh tap
water.
8. Reinstall the static mixer, nozzles and mixing chambers.

Cornelius Inc.
www.cornelius.com
