Cosco Fitness SX-3366 User manual

TREADMILL MANUAL
SX-3366

- 2 -
Thanks for buying our Fitness equipment,
Do some warm-up exercise before use, you’ll get twice the result with half the effort. Such as follows:
extend the neck up and down
twist the waist left and right
level push forwards upright straighten one's back

- 3 -
left and right poise exercise up and down extend exercise
thigh extend exercise calf extend exercise
SAFETY GUIDELINES:
Before beginning any exercise program, you should consult with your doctor. It is recommended that you
undergo a complete physical examination. Please follow the instructions:
1. Assemble and operate the treadmill on a solid, level surface
2. Keep the area behind the treadmill clear
3. The treadmill running mat will not stop immediately if any object becomes caught in the mat or rollers-IN
EMERGENCY: Pull the safety key cord to remove safety key
4. Always check the treadmill before using it

- 4 -
5. Make sure all parts are assembled, nuts and bolts are tightened
6. Do not use the treadmill if the unit is disassembled in any way
7. When connecting the power cord, plug the power cord into a grounded circuit. No other appliance
should be on the same circuit. Do not run the power cord underneath your treadmill. Do not operate the
treadmill with a damaged or frayed power cord.
8. Keep hands away from moving parts
9. Please note that there is a weight limitation for this product. If your weight more than 120kgs. It
is not recommended that you use this product. Serious injury may occur if the user weight
exceeds the limit shown here. This product is not intended to support users whose weight
exceeds this limit.
10. This equipment is for home use only. Never allow more than one person on the treadmill at a time.
11. Wear appropriate exercise clothing when using the treadmill. Do not wear loose clothing that could become
caught in the treadmill. Athletic support clothes are recommended for both men and women. Always wear
athletic shoes. Never use the treadmill with bare feet, wearing only stockings, or in sandals. Do not wear
shoes with leather soles or high heels. Tie all long hair back
12. Do not rock the unit from side to side
13. Don’t continuously use this equipment over an hour.
14. Care should be taken when mounting and dismounting the unit
15. Do not place any liquids on any part of the treadmill
16. To prevent shock, keep all electric components, such as the motor cord and switch away from water.
17. Do not use any accessories that are not specifically recommended by the manufacturer, these might cause
injuries or cause the unit to fail
18. Work within your recommended exercise level, do NOT work to exhaustion
19. If you feel any pain or abnormal systems STOP YOUR WORKOUT IMMEDIATELY and consult your
physician immediately
20. Turn off the treadmill while adjusting or working near the rear roller.
21. Keep one side of the magnetic safe key CLIPPING your clothes during exercising to avoid danger
happening.
22. Incorrect or excessive training may lead injures.
23. This equipment is not suitable for therapeutic purposes.
24. Don’t open this equipment cover to avoid damage usually.
25. Ensure the load place is level and free space at least 1m around for safe operation.
26. This equipment is not a toy. Please keep unsupervised children away from the equipment during
use and when equipment is unattended.

- 5 -
EXPLORE DRAWING

- 6 -
PART LIST
PART NO PART NAME Q'TY
1 Front roller 1
2 Running belt 1
3 Rear roller 1
4 Running deck 1
5 Side rail 2
6 Fix cushion of running deck 4
7 Soft cushion 2
8 Motor belt 1
9 Motor 1
10 Motor cover 1
11 Speed sensor frame 1
12 Speed sensor 1
13 Motor frame 1
14 Transformer 1
15 Control board of motor 1
16 Incline motor 1
17 Power cord 1
18 Motor adjustable plug 1
19 Square tube plug 2
20 Cushion of power wire 1
21 Fuse 1
22 Power switch 1
23 Running platform 1
24 Motor belly pan 1
25 Move wheel of running platform 2
26 End cap 2
27 Move wheel cover of running platform 2
28 Incline frame 1
29 Shaft sleeve of incline frame 2
30 Connect sleeve of base frame 2
31 Ф50 move wheel 2
32 Damper 1
33 Base frame 1
34 Rubber washer of base frame 4
35 Move wheel of base frame 2

- 7 -
36 Protective cover of upright 2
37 Right upright 1
38 Left upright 1
39 Foam 2
40 Computer frame 1
41 Pressing plate of handlebar 4
42 Computer belly pan 1
43 Fixed plate of computer frame 2
44 Main body of computer 1
45 Down cover of front handlebar 1
46 Up cover of front handlebar 1
47 Down cover of computer 1
48 Computer cover 1
49 Computer control board 1
50 Safety key 1
51 M8*50 Allen head bolt 1
52 φ8 Washer 17
53 M8*85 Allen head bolt 2
54 M8*65 Allen head bolt 4
55 ST4.2*15 Screw 8
56 Cushion of side rail 8
57 ST4.5*16 Screw 14
58 5/32 Bolt 2
59 5/32 Anti-slip washer 2
60 ST2.9*6 Screw 2
61 ST4.2*10 Screw 8
62 M10*50 Allen head bolt 1
63 φ13 Plastic Washer 2
64 M10 Nut 2
65 M10*60 Allen head bolt 1
66 M8*40 Allen head bolt 1
67 M8 Nut 11
68 M8*20 Allen head bolt 4
69 φ8 Elastic washer 6
70 M8*12 Bolt 2
71 M8*40 Allen head bolt 2
72 ST4.2*15 Screw 57
73 ST4.2*20 Screw 2

- 8 -
74 M8*25 Bolt 2
75 φ16 Plastic washer 2
76 M8*60 Allen head bolt 2
77 M8*45 Allen head bolt 1
78 M8*45 Allen head bolt 2
79 M8*50 Allen head bolt 4
80 M8*20 Allen head bolt 4
81 M8*30 Allen head bolt 2
82 M10*20 Allen head bolt 4
83 φ10 Washer 4
84 M8*15 Allen head bolt 6
85 ST4.2*25 Screw 4
86 φ6 Washer 4
87 ST2.0*6 Screw 38
88 M5*15 Bolt 4
89 φ5 Washer 4
HARDWARE COMPARISON CHART
For your convenience, we have identified the hardware used in the assembly of this product. The
chart below is provided to help you to identify items that may be unfamiliar to you.
NO. DESCRIPTION Q'TY
52 φ8 Washer 2
72 ST4.2*15 Screw 6
79 M8*50 Allen head bolt 2
82 M10*20 Allen head bolt 4
83 φ10 Washer 4
84 M8*15 Allen head bolt 6
88 M5*15 Bolt 4
89 φ5 Washer 4
A 5mm SOCKET HEAD WRENCH 1
B 6mm SOCKET HEAD WRENCH 1
C SCREWDRIVER 1
D LUBRICANT 1

- 9 -
ASSEMBLING INSTRUCTIONS
WARNING: Please put on all the screws, washers and bolts then tighten them.
STEP1:
Fix the uprights on the base
frame with M10*20mm Allen
head bolt 82, Ø10 washer83,
M8*50mm Allen head bolt79
and Ø8 washer 52.
$%&'

- 10 -
STEP2:
Fix the main body of computer on the
upright with M8*15 Allen head bolt 84.
STEP3:
Fix the up cover of computer on the
main body of computer with M5*15
bolt 88 and φ5Washer 89.

- 11 -
Folding illustration:
STEP4:
Fix the Protection cover of
upright onto the upright with
ST4.2*15 Screw 72.
To unfold the treadmill:
Folding illustration:
To drop down treadmill:
1. Strike the damper.
2. Hold on to the top end
covers and pull down the
treadmill slowly on the
ground.

- 12 -
COMPUTER OPERATION
Panel layout
To fold up the treadmill:
To fold up treadmill:
Both hands hold on the bottom end
covers and lift up the treadmill.
AUDIO
14 km
16 km
12 km
9
km
6 km
3 km

- 13 -
The Operation
Power The required main power is 220 - 240 VAC.
Connect the power, all the windows will bright for two seconds，then enter the waiting mode.
The speed is zero and the incline is zero.
WAITING MODE
Change the PROGRAM1-PROGRAM28，HRC65 and HRC85 at a fixed time. Press any key to
enter the program choosing mode.
CHOOSING PROGRAM MODE
Change the PROGRAM1-PROGRAM28，HRC65 and HRC85 at a fixed time. Press any key to
enter the program choosing mode
Press MODE key to check the total distance, total calories and the total time in this program.
Press START key to start the treadmill after choosing the program or press ENTER key to enter
the setting time.
Press INCLINE2 and SPEED5 in the time to clean the total distance, total calories and the total
time.
MANUAL MODE
The treadmill will run by pressing START key. The initial speed is 1.0km/h and the incline is 0%.
You can set the target time which is 20 minutes when the time window is flashing. You can change
the target time by press “SPEED+/SPEED-”key. The max value is 99 minutes and the minimum
value is 5 minutes.
Press MODE key to change the target distance. The initial distance is 5.0 km/h. You can change
the target distance by press “SPEED+/SPEED-”key. The max value is 99.0km/h and the minimum
value is 1.0km/h.
Press MODE key again to set the target calories. The initial calorie is 100calories. You can change
the target calories by press “SPEED+/SPEED-”key , the value of calories will increase or decrease
5 when you press one time. The max value is 1000 calories and the minimum value is 5 calories.
PROGRAM
After choosing the program mode, press “ENTER” key to enter. Press “SPEED+/SPEED-”key to
set the time. The max time is 99 minutes and the minimum time is 5 minutes.
There are 23 fixed movement modes. The treadmill will run according the setting value. Press
“SPEED+/SPEED-” key to change the setting value.
USER
The programs 24-28 are user mode.
After choosing the program, press ENTER key to enter, after this, please choose the time. The
default time is 20 munities.
Press MODE key to enter the segment setting. There are 30segments.
Press “SPEED+/SPEED-” key to set the speed and press “INCLINE+/INCLINE-”key to set the
incline value in every segment.
Press START key to run and record the result in the setting state. Press STOP key to adjust the
result and it will display the setting mode.

- 14 -
BODY FAT
Press the BODY FAT key to enter the BODY FAT mode. The HEIGHT display will flash.
Use the “SPEED+/SPEED-” key to select your height value. Press ENTER key to confirm. The
WEIGHT will flash.
Use the “SPEED+/SPEED-”key to select your weight. Press ENTER key to confirm. The age will
flash.
Use the “SPEED+/SPEED-”key to select your age. Press ENTER key to confirm. The gender will
flash.
Use the “SPEED+/SPEED-”key to select your sex. Press ENTER key to confirm.
Your BODY FAT result will be display on the console.
HRC MODE
WAITING MODE
¾Press “SPEED+/SPEED-”key to select the MANUAL, P1-P23, USER1-USER5,HRC 65, HRC85.
¾Press ENTER key to set the time;
¾First press MODE key, then press “SPEED+/SPEED-”key to set the age and the pulse, the window
will flash.
¾The first two minutes is the warm up. The speed and the incline do not change with the changing
of pulse. The window will display WARM UP;
¾If there is not pulse value after two minutes, the window will display NO HRC. The treadmill will
stop after a moment. If there is pulse value, it will display HRC mode.
¾After the warm up, it will change the speed and the incline value every 15 seconds. If you change
the speed 5 times, the incline will change once. The speed change 0.2km/h, the incline will change
1%;
¾Under the HRC mode, press “SPEED+/SPEED-“key to adjust the value.
RUNNING MODE
MANUAL MODE
¾Press “SPEED+/SPEED-”key to change the speed value and press “INCLINE+/INCLINE-” key to
change the incline value.
TARGET
¾The USER can choose the TIME DISTANCE CALORIES target.
SAFETY KEY
Put the safety key to the right place, the treadmill will run. If you put out the safety key in the
running state, the treadmill will stop quickly.
MP3
The treadmill comes supplied with a cable that allows you to connect your MP3 player. Simply
connect one end into the treadmill and the other end into the headphone socket of your MP3
player and press the AUDIO key to turn on. The sound will come from the speakers built into the
treadmill. You will need to adjust the volume using your MP3 player.
USB
Please insert the USB.

- 15 -
Press PLAY key to play or pause the music.
Press TRACK-/VOLUME- or TRACK+/VOLUME+ to choose the music.
Press TRACK-/VOLUME- or TRACK+/VOLUME+ for a long time to adjust the volume.
NOTES: DO NOT play USB and AUDIO at same time.
The shortcut key of PLAY, TRACK-/VOLUME-, TRACK+/VOLUME+ only can control the USB,
it does not control the AUDIO.
The Display Range
Initial value
Count down
Initial value Setting range Display range
TIME(mm:ss) 0:00 20:00 5:00~99:00 0:00~99:59
SPEED (km/h)or (ML/h) 0.0 N/A N/A 1.0~16.0km/hr
DISTANCE (kml) 0.00 N/A N/A 0.0~999.9
CALORIES (calories) 0 N/A N/A 0~999.9
PULSE (bpm) HP N/A N/A 40~240
Incline(%) N/A N/A N/A 0~15
AGE N/A N/A N/A 10~99
PROGRAM
Speed
P1 P2 P3 P4 P5 P6 P7 P8 P9 P10
SEG1 1.0 1.0 1.0 1.0 1.0 3.0 1.0 1.0 3.0 1.0
SEG2 2.0 3.0 3.0 3.0 5.0 7.0 5.0 3.0 5.0 1.0
SEG3 3.0 3.0 3.0 7.0 11.0 11.0 7.0 3.0 11.0 3.0
SEG4 4.0 5.0 3.0 11.0 12.0 12.0 11.0 7.0 12.0 3.0
SEG5 7.0 7.0 5.0 12.0 11.0 12.0 11.0 11.0 11.0 5.0
SEG6 11.0 11.0 5.0 3.0 5.0 12.0 11.0 12.0 5.0 7.0
SEG7 12.0 12.0 5.0 7.0 1.0 12.0 7.0 1.0 3.0 11.0
SEG8 3.0 1.0 7.0 11.0 5.0 7.0 5.0 3.0 5.0 7.0
SEG9 3.0 3.0 7.0 7.0 11.0 7.0 3.0 3.0 11.0 3.0
SEG10 3.0 3.0 7.0 3.0 12.0 3.0 7.0 3.0 12.0 3.0
SEG11 5.0 5.0 9.0 1.0 11.0 3.0 7.0 7.0 11.0 5.0
SEG12 7.0 7.0 9.0 3.0 5.0 7.0 11.0 11.0 5.0 7.0
SEG13 11.0 11.0 9.0 7.0 1.0 7.0 12.0 12.0 3.0 9.0
SEG14 12.0 12.0 10.0 11.0 5.0 12.0 11.0 11.0 5.0 11.0
SEG15 7.0 1.0 10.0 12.0 11.0 12.0 7.0 3.0 11.0 7.0
SEG16 3.0 3.0 10.0 5.0 12.0 12.0 7.0 5.0 12.0 3.0
SEG17 3.0 3.0 10.0 9.0 11.0 12.0 5.0 7.0 11.0 5.0
SEG18 5.0 5.0 10.0 11.0 5.0 12.0 7.0 9.0 5.0 7.0
SEG19 7.0 7.0 10.0 7.0 1.0 7.0 9.0 11.0 3.0 9.0
SEG20 11.0 11.0 12.0 3.0 5.0 7.0 11.0 11.0 5.0 11.0
SEG21 12.0 12.0 12.0 1.0 11.0 3.0 11.0 12.0 11.0 11.0
SEG22 1.0 1.0 12.0 3.0 12.0 3.0 11.0 11.0 12.0 12.0

- 16 -
SEG23 3.0 3.0 9.0 7.0 11.0 7.0 9.0 3.0 11.0 7.0
SEG24 3.0 3.0 9.0 11.0 5.0 7.0 7.0 5.0 5.0 3.0
SEG25 5.0 5.0 9.0 12.0 1.0 12.0 3.0 7.0 3.0 5.0
SEG26 7.0 7.0 5.0 7.0 5.0 12.0 7.0 9.0 5.0 7.0
SEG27 9.0 11.0 5.0 11.0 11.0 12.0 7.0 11.0 11.0 9.0
SEG28 7.0 12.0 5.0 11.0 12.0 12.0 5.0 12.0 12.0 11.0
SEG29 5.0 1.5 3.0 7.0 11.0 7.0 3.0 5.0 11.0 3.0
SEG30 3.0 1.0 1.0 3.0 1.0 3.0 1.0 1.0 3.0 1.0
P11 P12 P13 P14 P15 P16 P17 P18 P19 P20
SEG1 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
SEG2 1.0 3.0 3.0 11.0 1.0 1.0 3.0 5.0 3.0 3.0
SEG3 3.0 5.0 5.0 11.0 3.0 1.0 7.0 7.0 5.0 3.0
SEG4 3.0 7.0 5.0 7.0 5.0 11.0 9.0 9.0 7.0 5.0
SEG5 5.0 9.0 7.0 7.0 7.0 1.0 11.0 11.0 5.0 5.0
SEG6 7.0 11.0 7.0 11.0 9.0 11.0 9.0 9.0 7.0 7.0
SEG7 1.0 11.0 9.0 11.0 11.0 1.0 11.0 11.0 9.0 7.0
SEG8 3.0 12.0 9.0 5.0 11.0 11.0 9.0 9.0 7.0 9.0
SEG9 5.0 11.0 11.0 5.0 11.0 1.0 7.0 7.0 9.0 9.0
SEG10 7.0 11.0 11.0 11.0 9.0 11.0 3.0 5.0 11.0 7.0
SEG11 7.0 9.0 11.0 11.0 7.0 1.0 3.0 5.0 9.0 7.0
SEG12 7.0 7.0 11.0 3.0 5.0 11.0 7.0 7.0 11.0 5.0
SEG13 1.0 5.0 12.0 5.0 3.0 1.0 9.0 9.0 11.0 5.0
SEG14 3.0 3.0 12.0 11.0 1.0 11.0 11.0 11.0 3.0 3.0
SEG15 5.0 1.0 12.0 11.0 3.0 1.0 9.0 9.0 5.0 3.0
SEG16 7.0 3.0 12.0 5.0 5.0 11.0 11.0 11.0 7.0 5.0
SEG17 11.0 5.0 12.0 7.0 7.0 1.0 9.0 9.0 7.0 7.0
SEG18 11.0 7.0 12.0 11.0 9.0 11.0 7.0 7.0 5.0 7.0
SEG19 3.0 9.0 11.0 11.0 11.0 1.0 3.0 5.0 7.0 9.0
SEG20 3.0 11.0 11.0 7.0 11.0 11.0 3.0 5.0 9.0 9.0
SEG21 5.0 11.0 11.0 9.0 11.0 1.0 7.0 7.0 7.0 7.0
SEG22 5.0 12.0 11.0 11.0 9.0 11.0 9.0 9.0 9.0 7.0
SEG23 7.0 11.0 9.0 11.0 7.0 1.0 11.0 11.0 11.0 5.0
SEG24 7.0 11.0 9.0 7.0 5.0 11.0 9.0 9.0 9.0 5.0
SEG25 9.0 9.0 7.0 7.0 3.0 1.0 11.0 11.0 11.0 3.0
SEG26 11.0 7.0 7.0 5.0 1.0 11.0 9.0 9.0 11.0 3.0
SEG27 11.0 5.0 5.0 5.0 3.0 1.0 7.0 7.0 3.0 5.0
SEG28 11.0 3.0 5.0 3.0 5.0 11.0 3.0 5.0 5.0 7.0
SEG29 12.0 1.0 3.0 3.0 3.0 1.0 3.0 5.0 7.0 5.0
SEG30 11.0 1.0 1.0 1.0 1.0 1.0 1.0 3.0 3.0 1.0
P21 P22 P23 P24 P25 P26 P27 P28
SEG1 1.0 1.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG2 1.0 1.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG3 7.0 1.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG4 9.0 3.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG5 11.0 5.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG6 9.0 9.0 11.0 1.0 1.0 1.0 1.0 1.0

- 17 -
SEG7 11.0 5.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG8 9.0 3.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG9 7.0 3.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG10 3.0 3.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG11 5.0 5.0 7.0 1.0 1.0 1.0 1.0 1.0
SEG12 7.0 7.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG13 9.0 9.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG14 11.0 7.0 9.0 1.0 1.0 1.0 1.0 1.0
SEG15 9.0 5.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG16 11.0 3.0 7.0 1.0 1.0 1.0 1.0 1.0
SEG17 9.0 3.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG18 7.0 5.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG19 5.0 7.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG20 3.0 9.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG21 7.0 7.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG22 9.0 5.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG23 11.0 3.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG24 9.0 3.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG25 11.0 5.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG26 9.0 7.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG27 7.0 9.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG28 5.0 7.0 11.0 1.0 1.0 1.0 1.0 1.0
SEG29 3.0 5.0 5.0 1.0 1.0 1.0 1.0 1.0
SEG30 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
INCLINE
P1 P2 P3 P4 P5 P6 P7 P8 P9 P10
SEG1 0 0 0 0 1 0 0 0 0 1
SEG2 1 1 2 2 4 1 2 1 2 3
SEG3 2 1 2 4 5 2 4 1 3 4
SEG4 2 1 2 6 6 3 6 1 0 2
SEG5 2 2 3 8 1 4 8 2 1 3
SEG6 2 2 3 10 4 5 10 2 2 4
SEG7 2 2 3 8 5 6 8 2 3 2
SEG8 2 3 4 6 6 7 6 3 4 3
SEG9 2 3 4 4 1 6 4 3 2 4
SEG10 2 3 4 2 4 5 2 3 0 2
SEG11 2 4 5 0 5 4 0 4 0 1
SEG12 2 4 5 2 6 3 2 4 1 3
SEG13 2 4 5 4 1 2 4 4 3 4
SEG14 2 5 6 6 4 1 6 5 4 2
SEG15 2 5 6 8 5 2 8 5 2 3
SEG16 2 5 6 10 6 3 10 5 4 4
SEG17 2 6 7 8 1 4 8 6 5 2
SEG18 2 6 7 6 4 5 6 6 3 3
SEG19 2 6 7 4 5 6 4 6 3 4
SEG20 2 7 8 2 6 7 2 7 1 2
SEG21 2 7 8 0 1 6 0 7 1 1
SEG22 2 7 8 2 4 5 2 7 3 3

- 18 -
SEG23 2 4 5 4 5 4 4 4 6 4
SEG24 2 4 5 6 6 3 6 4 7 2
SEG25 2 4 5 8 1 2 8 4 8 3
SEG26 2 2 3 10 4 1 10 2 8 4
SEG27 2 2 3 8 5 2 8 2 7 2
SEG28 2 2 3 6 6 3 6 2 6 3
SEG29 1 1 2 4 1 2 4 1 3 4
SEG30 0 1 1 2 1 1 2 1 1 2
P11 P12 P13 P14 P15 P16 P17 P18 P19 P20
SEG1 1 0 1 1 1 0 1 1 1 0
SEG2 3 2 3 2 3 2 3 3 3 2
SEG3 3 2 3 5 4 3 4 3 3 2
SEG4 1 2 1 5 2 0 2 1 1 2
SEG5 1 3 1 2 3 1 3 1 1 3
SEG6 3 3 3 2 4 2 4 3 3 3
SEG7 3 3 3 2 2 3 2 3 3 3
SEG8 1 4 1 5 3 4 3 1 1 4
SEG9 1 4 1 5 4 2 4 1 1 4
SEG10 3 4 3 5 2 0 2 3 3 4
SEG11 3 5 3 2 1 0 1 3 3 5
SEG12 1 5 1 2 3 1 3 1 1 5
SEG13 1 5 1 2 4 3 4 1 1 5
SEG14 3 6 3 2 2 4 2 3 3 6
SEG15 3 6 3 5 3 2 3 3 3 6
SEG16 1 6 1 5 4 4 4 5 1 6
SEG17 1 7 1 5 2 5 2 5 1 7
SEG18 3 7 3 5 3 3 3 5 3 7
SEG19 3 7 3 2 4 3 4 2 3 7
SEG20 1 8 1 2 2 1 2 2 1 8
SEG21 1 8 1 2 1 1 1 2 1 8
SEG22 3 8 3 5 3 3 3 5 3 8
SEG23 3 5 3 5 4 6 4 5 3 5
SEG24 1 5 1 5 2 7 2 5 1 5
SEG25 1 5 1 2 3 8 3 2 1 5
SEG26 3 3 3 2 4 8 4 2 3 3
SEG27 3 3 3 5 2 7 2 5 3 3
SEG28 1 3 1 5 3 6 3 5 1 3
SEG29 1 2 1 2 4 3 4 2 1 2
SEG30 1 1 1 2 2 1 2 2 1 1
P21 P22 P23 P24 P25 P26 P27 P28
SEG1 1 1 1 0 0 0 0 0
SEG2 3 2 3 0 0 0 0 0
SEG3 3 5 4 0 0 0 0 0

- 19 -
SEG4 1 5 2 0 0 0 0 0
SEG5 1 2 3 0 0 0 0 0
SEG6 3 2 4 0 0 0 0 0
SEG7 3 2 2 0 0 0 0 0
SEG8 1 5 3 0 0 0 0 0
SEG9 1 5 4 0 0 0 0 0
SEG10 3 5 2 0 0 0 0 0
SEG11 3 2 1 0 0 0 0 0
SEG12 1 2 3 0 0 0 0 0
SEG13 1 2 4 0 0 0 0 0
SEG14 3 5 2 0 0 0 0 0
SEG15 3 5 3 0 0 0 0 0
SEG16 1 5 4 0 0 0 0 0
SEG17 1 2 2 0 0 0 0 0
SEG18 3 2 3 0 0 0 0 0
SEG19 3 2 4 0 0 0 0 0
SEG20 1 5 2 0 0 0 0 0
SEG21 1 5 1 0 0 0 0 0
SEG22 3 5 3 0 0 0 0 0
SEG23 3 2 4 0 0 0 0 0
SEG24 1 2 2 0 0 0 0 0
SEG25 1 2 3 0 0 0 0 0
SEG26 3 5 4 0 0 0 0 0
SEG27 3 5 2 0 0 0 0 0
SEG28 1 5 3 0 0 0 0 0
SEG29 1 2 4 0 0 0 0 0
SEG30 1 2 2 0 0 0 0 0
Error Message
Error Specification Treatment
Er1 Connect error between panel and
controller
Check that the lines between panel and controller are
connected or not.
Er2 Error on motor/MOS crash Check that the line to motor is connected or not.
Er3 Error on speed sensor
wire/Un-work of walking belt.
Check that the walking belt is locked by remoras.
Check that the speed sensor line is connected or not.
Check the placement of sensor or the photo disk is
correct or not.
Er4 Binding of RELAY Replace the device
Er5 Over the current Check the current.

- 20 -
MAINTENANCE
Proper maintenance is very important to ensure your treadmill is always in top working condition.
Improper maintenance could cause damage or shorten the life of your treadmill and exceed the
LIMITED WARRANTY coverage.
1. Important: Never use abrasives or solvents to clean the treadmill. To prevent damage to the
computer, keep liquids away and keep it out of direct sunlight.
2. Inspect and tighten all parts of the treadmill regularly. Replace any worn parts immediately
CLEANING:
Routine cleaning of your treadmill will extend the product’s life.
1. Warning: To prevent electrical shock, be sure the power to the treadmill is OFF and the power cord is
unplugged from the wall electrical outlet before attempting any cleaning or maintenance.
2. Important: Never use abrasives or solvents to clean the treadmill. To prevent damage to the computer, keep
liquids away and keep it out of direct sunlight.
3. After each workout: Wipe off the console and other treadmill surfaces with a clean, water dampened
soft cloth to remove excess perspiration
4. Weekly: Use of a treadmill mat is recommended for ease of cleaning. Dirt from your shoes contacts the belt
and eventually makes it to underneath the treadmill. Vacuum the underneath treadmill once a
week.
BELT ADJUSTMENT:
Belt adjustment and tension performs two functions: adjustment for tension and centering. The running
belt has been adjusted properly at the factory. However transportation, uneven flooring or other
unpredicted reasons could cause the belt to shift off center resulting in the belt rubbing with the plastic side
rail or end caps and possibly causing damage. To adjust the belt back to it proper position please follows
the directions below:
1. Walking belt has shifted to the left:
First unplug the power cord from the surge protector. Using the hex key provided, turn the left rear
roller adjustment bolt 1/4 turn in the clockwise direction. Plug the power cord back into the surge
protector and run the treadmill at 2.5 mph. You should see the belt start to correct itself, moving back
towards the center. Repeat the above procedure until the walking belt is centered. It may be necessary
to set walking belt tension once you have completed this procedure if the belt feels like it is slipping
while walking. Refer below to the “Walking belt slipping” instructions.
2. Walking belt has shifted to the right:
First unplug the power cord from the surge protector. Using the hex key provided, turn the right rear
roller adjustment bolt 1/4 turn in the clockwise direction. Plug the power cord back into the surge
protector and run the treadmill at 2.5 mph. You should see the belt start to correct itself, moving back
towards the center. Repeat the above procedure until the walking belt is centered. It may be necessary
to set walking belt tension once you have completed this procedure if the belt feels like it is slipping
while walking. Refer below to the “Walking belt slipping” instructions.
3. Walking belt is slipping:
