PORTABLE AUTOMATIC ICEMAKER
ES10200US
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
US office: Fontana UK office: Ipswich AU office: Truganina
DE office: Hamburg
FR office: Saint Vigor d'Ymonville PL office: Gdańsk
US:[e-mail]
UK:[e-mail]
AU:[email protected]

Before You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled
near to the area in which they will be placed in use, to avoid
moving the product unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product
away from babies and children as they potentially pose a serious
choking hazard.
02 03
IMPORTANT SAFETY INSTRUCTIONS
DANGER
WARNING
Your safety and the safety of others are very
important.
We have provided many important safety messages in the manual.
Always read and obey all safety messages.
This is the safety alert symbol:
These words mean:
You can be killed or seriously injured if you don’t immediately
follow instructions.
All safety messages will tell you what the potential hazard is,
tell you how to reduce the chance of injury, and tell you what
can happen if the instructions are not followed.
All safety messages will follow the safety alert
symbol and the word “DANGER” or “WARNING”.

04 05
PREPARING YOUR ICE MAKER FORUSE
When using electrical appliances, basic safety precautions should
be followed to reduce the risk of fire, electric shock, and injury to
persons or property. Read all instructions before using any
appliance.
• Do not operate this, or any other appliance with a damaged cord.
If the supply cord is damaged, it must be replaced by the
manufacturer or a similarly qualified person in order to avoid a
hazard.
This ice-maker must be positioned so that the plug is accessible.
Connect to properly polarized outlets only. No other appliance
should be plugged into the same outlet. Be sure that the plug is
fully inserted into the receptacle.
• Do not run the power cord over carpeting or other heat
insulators. Do not cover the cord. Keep cord away from traffic
areas, and do not submerge in water.
• We do not recommend the use of an extension cord, as it may
overheat and become a risk of fire. If you must use an extension
cord, use No.14AWG minimum size and rated no less than 1875
watts.
• Unplug the ice maker before cleaning or making any repairs or
servicing.
• Use with caution and reasonable supervision when appliance is
used near children.
• Do not use your ice-maker outdoors. Place the ice-maker away
from direct sunlight and make sure that there is at least 4 inches
of space between the back of your unit and wall. Keep a minimum
distance of 4 inches on each side of your unit free.
• Do not use other liquid to make the ice-cube other than water.
• Do not clean your ice maker with flammable fluids. The fumes
can create a fire hazard or explosion.
• Do not tip over.
• If the ice maker is brought in from outside in wintertime, give it a
few hours to warm up to room temperature before plugging it in.
WARNING: This appliance must be earthed.
• DANGER – Risk Of Fire or Explosion. Flammable Refrigerant
Used. Do Not Use Mechanical Devices To Defrost Ice Maker. Do Not
Puncture Refrigerant Tubing.
• CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant
Used. Consult Repair Manual/Owner’s Guide Before Attempting To
Install Or Service This Product. All Safety Precautions Must be
Followed.
• CAUTION – Risk Of Fire Or Explosion. Dispose Of Property In
Accordance With Federal Or Local Regulations. Flammable
Refrigerant Used.
• DANGER – Risk Of Fire Or Explosion. Flammable
Refrigerant Used. To Be Repaired Only By Trained Service
Personnel. Do Not Puncture Refrigerant Tubing.

06 07
• CAUTION-Risk Of Fire Or Explosion Due To Puncture Of
Refrigerant Tubing; Follow Handling Instructions Carefully.
Flammable Refrigerant Used.
• The ice maker should be installed in accordance with the safety
standard for Refrigeration Systems, ASHRAE15. The ice maker
shall not be installed in corridors or hallways of public buildings.
• If the unit is with problem need to be maintained, that replacing
with like components and that servicing shall be done by qualified
technician, so as to minimize the risk of possible ignition due to
incorrect parts or improper service.
IMPORTANT:
The wires in this mains lead are colored in accordance with the
following code: Green or Green with a strip yellow: Grounding
White: Neutral
Black: Live
To avoid a hazard due to instability of the appliance, it must be
placed at an even or flat surface.
GETTING TO KNOW YOUR UNIT
General instruction
1.Evaporator
2.Ice scoop
3.Ice full sensor
4.Ice basket
5.Back top panel
6.Air exhausting
7.Water drain cap: at front bottom side of the unit.
8.Top cover with transparent window
9.MAXIMUM WATER LEVEL: ▲
Remove the ice basket, you can see the water level mark.
9
8
7
6
5
4
3
2
1

08 09
Start the self-cleaning program: Plug on the unit, then press
“ON/OFF”button for more than 5 seconds to enter the self-cleaning
program. Self-cleaning program need 30mins. When the program
is over, please drain out the water and clean inside.
UNPACKING YOUR ICE MAKER
1. Remove the exterior and interior packaging. Check if ice basket
and ice scoop are inside. If any parts are missing, please contact
our customer service.
2. Remove the tapes for fixing ice shovel, ice basket & ice scoop.
Clean the tank & ice basket.
3. Put the ice maker on a level & flat counter top without direct
sunlight and other sources of heat (i.e.: stove, furnace, radiator).
Maker sure that there is at least 4 inches gap between the back &
LH/RH sides with the wall.
OPERATING PROCEDURES & MAINTENANCE
Position of control panel & function
Control Panel: Easy to use, visible functions, touch display setting.
A. Selected ice size displaying: Small and Large.
B. Power indicator
C. Ice-Full indicator
D. Water shortage indicator
E. Button to turn on/off the unit.
F. Button to select ice cube size.

10 11
4. Allow one hour for the refrigerant fluid to settle before plugging
the ice maker in.
5. The appliance must be positioned so that the plug is accessible.
WARNING: Fill with potable water only. Only use drinking water.
CONNECTING YOUR ICE MAKER
* Improper use of the grounded plug can result in the risk of
electrical shock. If the power cord is damaged, please call our
customer service.
1. This unit should be properly grounded for your safety. The
power cord of this appliance is equipped with a three-prong plug
which mates with standard three prong wall outlets to minimize
the possibility of electric shock.
2. Plug your appliance into an exclusive, properly installed,
grounded wall outlet. Under any circumstances, do not cut or
remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed
toward a certified electrician.
3. This appliance requires a standard 110-120 volt, 60Hz electrical
outlet with three-prong ground.
DANGER
CLEANING AND MAINTAINING YOUR ICE MAKER
Before using your ice maker, it is strongly recommended to clean it
thoroughly.
1. Take out the ice basket.
2. Clean the interior with diluted detergent, warm water and a soft
cloth.
3. Then use the water to rinse the inside parts, and drain out the
water by unplugging the drain cap on front bottom side.
4. The outside of the ice maker should be cleaned regularly with a
mild detergent solution and warm water.
5. Dry the interior and exterior with a clean soft cloth.
6. When the machine is not to be used for a long time, drain water
completely & dry the interior.

12 13
USING YOUR ICE MAKER TROUBLE SHOOTING
1. Open the cover, remove the ice basket and pour water into tank.
Keep water level below the water level mark.
2. Press “ON/OFF” button on the control panel to begin the ice
making cycle.
3. Select the ice cube size by pressing the “SELECT” button. If the
room temperature is lower than 60OF, it is recommended to select
small ice cube in order to avoid ice sticking together.
4. The ice making cycle lasts approx. 6 to 13 minutes, depending
on selection of ice cube size and the room temperature. The
recommended room temperature is 50OF to 105OF.
5. If water pump can’t inject water, the ice maker will stop
automatically, and the “ADD WATER” indicator will be on. Press
“ON/OFF” button, fill water up to the max. water level mark and
press “ON/OFF” button again to turn on the unit again. Allow the
refrigerant liquid inside the compressor at least 3 minutes to settle
before restarting.
6. The ice maker stops when the ice basket is full and the “ICE
FULL” indicator will be on. Warning: Direct sunlight or sunlight
reflection may cause infrared sensor malfunction. If the unit
doesn’t stop even ice cubes obstruct sensor, move the unit to the
place where there is no sunlight.
7. Change water in the water reservoir every 24 hours to ensure a
reasonable hygiene level.
If unit isn’t to be used, drain all the water and dry the tank.
PROBLEM POSSIBLE CAUSE SOLUTION
Stop the ice maker,
fill water, and press
“ON/OFF” button
again to restart the
unit.
Remove ice from ice
basket. Keep
pressing “Select”
button for 5 seconds,
the unit could make
ice 10 cycles even
“Ice” indicator is on.
Stop the ice maker,
and restart it when
the ice blocks melt.
Select the small size
ice cube selection.
Replace the water.
Temperature of water
recommended at
40OF-90OF
The room
temperature should
be 50OF -105OF, water
temperature should
be 40OF-90OF.
Verify by a qualified
technician.
Verify by a qualified
technician.
Lack of Water.
Ice is full in basket.
The ice making cycle
is too long.
Water temperature in
inner tank is too low.
Room temperature or
water temperature in
inner tank is too high.
Refrigerant in cooling
system leaks.
Pipe in the cooling
system is blocked.
“ ADD WATER ”
indicator is on.
“ICE FULL”
indicator is on.
Ice cubes
stick together.
Ice making cycle
is normal but
no ice formed.

14 15
TECHNINCAL PARAMETERS & CIRCUIT DIAGRAM
Model
Protection Type
Power
Ice Making Current
Ice Harvest Current
Refrigerant
High Side
Low Side
Vesicant
Net Weight
Dimension ( W * D *H )
Enclosure
ES10200US
I
115V/60Hz
1.7A
2.0A
R600a 0.74Oz
290Psig
88Psig
C5H10
16.7lbs
9.5” x 14” x 13”
Plastic
1
M
3
S
2
N
L
G
AC- L
AC- N
ELECTRICAL DIAGRAM
MAIN CONTROL PCB
WATER
MCU
CN5
CN7
-FAN+
+PUMP-
VALVE
ICE
ON/OFF
Solenoid
Valve
DC WATER PUMP
DC FAN
MOTOR
COND TEMP
SENSOR
COMP MOTOR
CN3
6C
T1
T1
WATER LEVEL
DETECTING
RELAY
OPERATION PCB
POWER
LED2S
SELECT
LED3S
POWER
SUPPLY SM
Protector shovel
verload Motor For Ice
COMP
Start
Lelay
INFRARED
SENSOR
DETECTOR
MICRO SWITCH
MICRO SWITCH
