USER’S MANUAL
High-Pressure Washer
EP24606US

2
www.costway.com
3
www.costway.com
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: [e-mail]
UK: [e-mail]
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Seperate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near tothe
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
CAUTION : Do not use this device before reading the instructions.
1. Safety Instructions
•The appliance has been designed solely for private use outdoors and not for commercial use.
Keep this appliance away from heat, direct sunlight, moisture and rain, ice and sharp edges.
• Do not allow anybody that has not been trained to use a pressure washer to operate the
machine without first reading the instruction manual.
• WARNING: High-pressure washers must not be used by children or untrained persons.
• Before starting your machine, carefully check for defects. If you find any, do not start your
machine and contact your local distributor.
• In particular, ensure that the electric cable insulation is in perfect condition and free of cracks. If
the electric cable is damaged, an approved local service centre must replace it.
• WARNING: High pressure jets can be dangerous if they are used incorrectly. The jet must not be
directed towards persons, electrical equipment connected to the mains or the appliance itself.
• WARNING: Do not use the appliance close to other
people unless they are wearing protective clothing.
• CAUTION: Do not direct the jet towards yourself or
other persons to clean clothing or shoes.
• Hold the lance firmly in your hands.
•The operator and persons within close proximity to the
cleaning area must take necessary measures to protect
themselves from dislodged debris when in use.
• Wear protective gloves and clothing during use.
• WARNING: The appliance has been designed for use with a cleaning agent supplied or
recommended by the manufacturer. Using other cleaning products or chemical products may
affect the safety of the appliance.
• WARNING: Disconnect the appliance from the power supply before carrying out any
maintenance.
• CAUTION: To ensure the safety of the appliance, only use spare parts supplied or approved by
the manufacturer.
• Do not use the appliance if the power cable or important parts of the appliance are damaged, for
example, the safety device, high pressure hose and handgun.
• Do not use the appliance with wet hands. If the appliance is damp or wet, unplug it immediately.
Do not place it in water.
•The tyres and valves on the tyres can be damaged by the high pressure jet and could burst.
• Never use the machine in an environment where there is a danger of explosion.
• It is forbidden to clean surfaces containing asbestos at high pressure.
•This high-pressure washer must not be used in temperatures below 0 ° C.
• CAUTION - The hoses, accessories and high pressure couplings are important for the safety of
the machine. Only use hoses, accessories and couplings recommended by the manufacturer.

4
www.costway.com
5
www.costway.com
• WARNING: Inadequate extension cables may be dangerous. Cables and spools must always be
completely unwound to avoid letting the cable overheat.
• If an extension cable is used, the plug and socket must be waterproof and conform to the
requirements below regarding the length and dimensions of the cable.
• 1,0 mm ² max. 12,5 m
• 1,5mm²max.20 m
• If the power cable is damaged, it must be replaced by the manufacturer, their service agent or a
qualified professional in order to avoid any danger.
• WARNING: This machine is not designed to be used by persons (including children) with
reduced physical, sensory or mental capacities or whose lack experience or knowledge.
• WARNING: It is advisable that you supervise children to ensure that they do not play with the
appliance.
• CAUTION – Risk of explosion – do not spray flammable liquids, do not direct the jet towards
flammable liquids.
• WARNING: Water that has circulated in the anti-backflow system is not considered drinkable.
• WARNING: Do not use the appliance if the power cable or important parts of the appliance are
damaged, for example, the safety devices, high pressure hoses and handgun.
• WARNING: If you have an extension cable, it must be waterproof.
• WARNING: When you switch on the machine, a recoil movement is produced due to the force of
the water jet. Use two hands to control the lance. Wear safety gloves when using the appliance.
Wear suitable protective clothing.
• In case of accidental contact with detergent, wash with water. If the liquid comes into contact
with the eyes, also seek medical assistance (the detergent can cause irritations or burns).
• In the event that the appliance breaks down, do not attempt to repair it yourself but contact a
professional technician to avoid any danger.
Main power connection
The following must be observed when connecting the high pressure washer to the power supply:
• Connecting the electrical connection should be done by a qualified electrician conforming to
60364-1 CEI
• It is recommended that the electrical supply to this machine should comprise a residual current
device which interrupts the current if the leakage current exceeds 30 mA for 30ms.
CONNECTING TO THE WATER NETWORK
WARNING
According to current guidelines, the unit must never be operated without a
system separator on the potable water system. Use a EN 12729 type BA system
separator. Water that passes through a system separator is classified as
non-potable.
WARNING:
Always connect the system separator to the water supply and never directly to the device!
Contents
Technical data
The Circuitry
Chapter Page
2
7
7
9
9
9
11
12
1. Safety Instructions
2. Getting Started
3. Operating your pressure washer
4. End of operation instructions
5. Environmental protection
6. Maintenance, cleaning and repairing.
7. Breakdown service
8. WEEE - Waste of Electric and Electronic Equipment
Rated Pressure 1885PSI
3500PSI
2.11GPM
1800W
120V,60Hz
5~60℃
Max. pressure
Max.Flow
power
Voltage
Water tamperature

3.2 Mounting of high pressure hose
Attach the high pressure hose to the trigger gun and
machine.
Detach the high pressure hose by pressing the pawl (A) or
button (B)
3.3 Mounting of lance and nozzle
Push the lance into the trigger gun
When inserted turn it. Caution: Make sure the lance is properly fixed to the gun
Attach the nozzles. Caution: When attaching the nozzle the button (A) on the nozzle should
come out again. Check before activating the trigger that the nozzle is properly fixed.
Attention: All accessories nozzle can be installed as above instruction.
3.4 Water connection
Connecting the water supply pipe
Follow your water supplier’s instructions .
For connection information, see the data plate/technical specifications
Use a reinforced hose (not supplied) with a standard connection (ext. diameter: 16mm/int. 12mm,
maximum length: 25m).
IMPORTANT! Only use water without any impurities. If there is a risk of sand particles in the inlet
water (i.e. from your own well), an additional filter should be mounted.
Let the water run through the water hose before connecting it to the machine to prevent sand and
dirt from penetrating the machine. Note: Check that the filter is fitted in the water inlet pipe and
that it is not clogged up.
Connect the water hose to the water supply by means of the quick connector (inlet water, max.
pressure: 10 bar, max. temperature: 60°C).
Turn on the water.
7
www.costway.com
6
www.costway.com
Contents
1. Gun nozzle
2. Gun lance
3. Gun handle
4. High pressure hose
5. Outlet connector
6. Machine body
7. Hose reel
8. Power cable
9. Plug
10. Inlet hose
11. Water tap
2. First time instructions
This section will explain in details how to make high pressure washer ready for use.
SAFETY DEVICES
•The unloader valve can reduce pressure if it exceeds pre-set values.
Locking device on trigger gun (see illustration at the beginning of this
manual): The trigger gun features a locking device. When the knob is
activated, the trigger gun cannot be operated.
THERMAL SENSOR
A thermal sensor protects the motor against overloading. The machine will
restart after a few minutes when the thermal sensor has cooled.
3. Operation instructions
3.1 Connection of garden hose
Screw the water inlet coupling (10) tight on to the water inlet
Note: The inlet filter (A) must always be fitted in the water
inlet pipe to filter out sand, lime stone and other impurities as
these will damage the pump valves.
Caution: Failure to fit the filter will invalidate the guarantee
Connect the garden hose with a standard quick coupling

9
www.costway.com
8
www.costway.com
3.8 Install indicator diagram
1.)gun hook assembly ;
2.)Quick connector structure on the machine body . All the Accessories can be storaged on the
machine .
4. After use instructions
The machine should be stored in a frost-free room!
Pump, hose and accessories should always be emptied of water prior to storing as follows:
Stop the machine (press the start/stop switch “O” and detach water hose, high pressure hose
and nozzle
Restart the machine and activate the trigger of the trigger gun.
Let the machine run until no more water runs through the trigger gun.
Stop the machine, unplug and wind up hose and cable.
Place trigger gun, lance, nozzles and other accessories in the holders of the machine.The hook
can be used for storage of the hose and cord.
All accessories can be stored in the washer after using.
WARNING: Never start up a frozen machine. Frost damages are not covered by the guarantee!
5. Environmental protection
Old appliances contain valuable materials that can be recycled. Please arrange for the proper
recycling of old appliances. Please dispose of your old appliances using appropriate collection
systems.
3.5 Start/stop of the machine
The trigger gun and lance is affected by a thrust during operation - therefore always hold it
firmly with both hands.
IMPORTANT: Point the nozzle at the ground.
Check that the machine is in upright position. NOTE: Do not place the machine in high grass!
Release the trigger lock .
Activate the trigger of the trigger gun and let the water run until all air has escaped from the
water hose.
Press the Start/stop switch .
Activate the trigger of the trigger gun .
Always adjust the distance and thus the pressure of the nozzle to the surface, which is to be
cleaned.
Do not cover the machine during operation or use it in a room without adequate ventilation!
NOTE: If the machine is left or not used for 5 minutes, it must be switched off on the start/stop
switch "O":
Press the start/stop switch "O".
Disconnect the electrical plug from the socket.
Shut off the water supply and activate the trigger of the trigger gun to relieve the machine of
pressure.
Lock the trigger gun
When releasing the trigger of the trigger gun , the machine automatically stops. The machine
will start again when you re- activate the trigger gun
3.6 Multi Nozzle
The pressure for the multi nozzle can be adjusted by turning it.
WARNING: Do not do this under operation to avoid that the
hand hits the jet.
3.7 Use of built-in detergent bottle
1. Unscrew the lid built-in detergent bottle.
2. Add detergent to Built-in detergent bottle.
3. Replace the nozzle of the spray gun to the detergent nozzle as below:
4. And then spray detergent.
