Costway EP24780US User manual

www.costway.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Visit us: www.costway.com
Follow Costway
Please give us a chance to make it right and do better！
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP!
USER’S MANUAL
High-Pressure Washer
EP24780US

www.costway.com www.costway.com
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: [e-mail]
UK: [e-mail]
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
CAUTION : Do not use this device before reading the instructions.
●The appliance has been designed solely for private use outdoors and not
for commercial use. Keep this appliance away from heat, direct sunlight,
moisture and rain, ice and sharp edges.
●Do not allow anybody that has not been trained to use a pressure washer
to operate the machine without first reading the instruction manual.
●WARNING: High-pressure washers must not be used by children or
untrained persons.
●Before starting your machine, carefully check for defects. If you find
any, do not start your machine and contact your local distributor.
●In particular, ensure that the electric cable insulation is in perfect condi-
tion and free of cracks. If the electric cable is damaged, an approved local
service centre must replace it.
●WARNING: High pressure jets can be dangerous if they are used
incorrectly. The jet must not be directed towards persons, electrical
equipment connected to the mains or the appliance itself.
1.Safety Instructions
02 03

www.costway.com www.costway.com
●WARNING: Do not use the appliance close to other people unless they
are wearing protective clothing.
●CAUTION: Do not direct the jet towards yourself or other persons to
clean clothing or shoes.
●Hold the lance firmly in your hands.
●The operator and persons within close proximity to the cleaning area
must take necessary measures to protect themselves from dislodged debris
when in use.
●Wear protective gloves and clothing during use.
●WARNING: The appliance has been designed for use with a cleaning
agent supplied or recommended by the manufacturer. Using other cleaning
products or chemical products may affect the safety of the appliance.
●WARNING: Disconnect the appliance from the power supply before
carrying out any maintenance.
●CAUTION: To ensure the safety of the appliance, only use spare parts
supplied or approved by the manufacturer.
●Do not use the appliance if the power cable or important parts of the
appliance are damaged, for example, the safety device, high pressure hose
and handgun.
●Do not use the appliance with wet hands. If the appliance is damp or wet,
unplug it immediately. Do not place it in water.
●The tyres and valves on the tyres can be damaged by the high pressure
jet and could burst.
●Never use the machine in an environment where there is a danger of
explosion.
●It is forbidden to clean surfaces containing asbestos at high pressure.
●This high-pressure washer must not be used in temperatures below 0 ° C.
●CAUTION - The hoses, accessories and high pressure couplings are
important for the safety of the machine. Only use hoses, accessories and
couplings recommended by the manufacturer.
●WARNING: Inadequate extension cables may be dangerous. Cables and
spools must always be completely unwound to avoid letting the cable
overheat.
●If an extension cable is used, the plug and socket must be waterproof and
conform to the requirements below regarding the length and dimensions of
the cable.
●1,0 mm ² max. 12,5 m
●1,5mm²max.20 m
If the power cable is damaged, it must be replaced by the manufacturer,
their service agent or a qualified professional in order to avoid any danger.
WARNING: This machine is not designed to be used by persons
(including children) with reduced physical, sensory or mental capacities or
whose lack experience or knowledge.
WARNING: It is advisable that you supervise children to ensure that they
do not play with the appliance.
CAUTION – Risk of explosion – do not spray flammable liquids, do not
direct the jet towards flammable liquids.
WARNING: Water that has circulated in the anti-backflow system is not
considered drinkable.
WARNING: Do not use the appliance if the power cable or important parts
of the appliance are damaged, for example, the safety devices, high
pressure hoses and handgun.
WARNING: If you have an extension cable, it must be waterproof.
WARNING: When you switch on the machine, a recoil movement is
produced due to the force of the water jet. Use two hands to control the
lance. Wear safety gloves when using the appliance. Wear suitable
protective clothing.
●In case of accidental contact with detergent, wash with water. If the
liquid comes into contact with the eyes, also seek medical assistance (the
detergent can cause irritations or burns).
●In the event that the appliance breaks down, do not attempt to repair it
yourself but contact a professional technician to avoid any danger.
Main power connection
The following must be observed when connecting the high pressure washer
to the power supply:
●Connecting the electrical connection should be done by a qualified
electrician conforming to 60364-1 CEI
04 05

www.costway.com www.costway.com
It is recommended that the electrical supply to this machine should comprise
a residual current device which interrupts the current if the leakage current
exceeds 30 mA for 30ms.
According to current guidelines, the unit must never be
operated without a system separator on the potable water
system. Use a EN 12729 type BA system separator. Water that
passes through a system separator is classified as non-potable.
According to current guidelines, the unit must never be operated without a
system separator on the potable water system. Use a EN 12729 type BA
system separator. Water that passes through a system separator is classified
as non-potable.
1.Gun
2.High pressure hose
3.Water Inlet connector
4.Main switch
5.Machine body
6.Hose reel
7.Power cable
8.Plug
9.Inlet hose
10.Water tap
Thank you for choosing the High-Pressure Washer
CONNECTING TO THE WATER NETWORK WARNING
WARNING:
Contents
Technical data
The Circuitry
06 07
Temperature

www.costway.com www.costway.com
A thermal sensor protects the motor against overloading. The machine will
restart after a few minutes when the thermal sensor has cooled.
Screw the water inlet coupling (1) tight on to the water inlet Note: The inlet
filter (A) must always be fitted in the water inlet pipe to filter out sand, lime
stone and other impurities as these will damage the pump valves.
Caution: Failure to fit the filter will invalidate the guarantee.
Connect the garden hose with a standard quick coupling.
Attach the high pressure hose to the trigger gun and machine.
Detach the high pressure hose by pressing the pawl (A) or button (B)
This section will explain in details how to make high pressure washer ready
for use.
SAFETY DEVICES
●The unloader valve can reduce pressure if it exceeds pre-set values.
Locking device on trigger gun (see illustration at the beginning of this
manual): The trigger gun features a locking device. When the knob is
activated, the trigger gun cannot be operated.
THERMAL SENSOR
2. First time instructions
3. Operation instructions
3.1 Connection of garden hose
3.2 Connection of garden hose
08 09

www.costway.com www.costway.com
Push the lance into the trigger gun
When inserted turn it. Caution: Make sure the lance is properly fixed to the
gun
Attach the nozzles. Caution: When attaching the nozzle the button (A) on
the nozzle should come out again. Check before activating the trigger that
the nozzle is properly fixed.
Connecting the water supply pipe
Follow your water supplier’s instructions .
For connection information, see the data plate/technical specifications
Use a reinforced hose (not supplied) with a standard connection (ext.
diameter: 16mm/int. 12mm, maximum length: 25m).
IMPORTANT! Only use water without any impurities. If there is a risk of
sand particles in the inlet water (i.e. from your own well), an additional
filter should be mounted.
Let the water run through the water hose before connecting it to the
machine to prevent sand and dirt from penetrating the machine. Note:
Check that the filter is fitted in the water inlet pipe and that it is not
clogged up.
Connect the water hose to the water supply by means of the quick
connector (inlet water, max. pressure: 10 bar, max. temperature: 60°C).
Turn on the water.
The trigger gun (1) and lance is affected by a thrust during operation -
therefore always hold it firmly with both hands.
IMPORTANT: Point the nozzle at the ground.
Check that the machine is in upright position. NOTE: Do not place the
machine in high grass!
Release the trigger lock .
Activate the trigger of the trigger gun (1) and let the water run until all air
has escaped from the water hose.
Press the Start/stop switch (4).
Activate the trigger of the trigger gun (1).
Always adjust the distance and thus the pressure of the nozzle to the
surface, which is to be cleaned.
3.3 Mounting of lance and nozzle
3.4 Water connection
3.5 Start/stop of the machine
Attention: All accessories nozzle can be installed as above
instruction.
10 11

www.costway.com www.costway.com
Do not cover the machine during operation or use it in a room without
adequate ventilation!
NOTE: If the machine is left or not used for 5 minutes, it must be switched
off on the start/stop switch (4) "O":
Press the start/stop switch (4) "O".
Disconnect the electrical plug (8) from the socket.
Shut off the water supply and activate the trigger of the trigger gun (1) to
relieve the machine of pressure.
Lock the trigger gun (1)
When releasing the trigger of the trigger gun (1), the machine
automatically stops. The machine will start again when you re- activate the
trigger gun (1)
The pressure for the multi nozzle canbe adjusted by tuning it.
WARNING: Do not do this under operation to avoid that the hand hits the
jet.
Before beginning any cleaning task, determine the best nozzle for the job.
Each of the nozzles has a different spray pattern.
The nozzle patterns are 40˚ (for gentle cleaning), 25˚ (for all-purpose
cleaning), 15˚ (for tough jobs), 0˚ (for spot cleaning or hard-to-reach
areas),84˚(for soap Quick-Connect )
CAUTION! NEVER change nozzles without locking the safety lock on
the trigger handle.
WARNING! High-pressure jets can be dangerous if subject to misuse. The
jet must not be directed at persons, pets, live electrical equipment, or the
appliance itself.
This electric pressure washer is equipped with five (5) Quick-Connect
nozzles that easily connect to the spray lance.
To connect a nozzle to the spray lance:
1. Turn off the pressure washer and shut off the water supply. Pull the
trigger to release water pressure.
2. Engage the safety lock on the trigger handle by pushing right on the
safety lock.
3. Snap the desired nozzle into the spray lance tight .
To disconnect a nozzle from the spray lance once the cleaning job is
complete:
4. Turn off the pressure washer and shut off the water supply.Pull the
trigger to release water pressure.
5. Engage the safety lock on the trigger handle by pushing right on the
safety lock(Fig.11).
6. Remove the nozzle from the spray lance.
WARNING! Do not make changes to the nozzle while the trigger is
engaged. Doing so could result in damage to the pressure washer or injury
to the user.
1.)gun hook assembly ;
3.6 Multi Nozzle
3.7 Install indicator diagram
12 13

www.costway.com www.costway.com
2.)Quick connector structure on the machine body . All the Accessories
can be stored on the machine .
The machine should be stored in a frost-free room!
Pump, hose and accessories should always be emptied of water prior to
storing as follows:
Stop the machine (press the start/stop switch “O” and detach water hose,
high pressure hose and nozzle.
Restart the machine and activate the trigger of the trigger gun.Let the
machine run until no more water runs through the trigger gun.
Stop the machine, unplug and wind up hose and cable.
Place trigger gun, lance, nozzles and other accessories in the holders of
the machine. The hook can be used for storage of the hose and cord. All
accessories can be stored in the washer after using.
WARNING: Never start up a frozen machine. Frost damages are not
covered by the guarantee!
Old appliances contain valuable materials that can be recycled. Please
arrange for the proper recycling of old appliances. Please dispose of your
old appliances using appropriate collection systems.
electrical plug from the socket prior to maintenance or cleaning.
To ensure a long and problem free working life, please take the following
advice:
Wash out water hose, high pressure hose, spray lance and accessories
before mounting.
Clean the connectors of dust and sand.
Rinse the detergent spraying attachment after use.
Clean the nozzles.
Any repair should always be made in an authorized workshop with
original spare parts.
Clean the water inlet filter regularly once a month or more frequently
according to use.
Carefully loosen the filter with a screwdriver and clean it . Check that it is
intact before re-mounting it.
The inlet filter must always be fitted inside the water inlet pipe to filter out
sand, limestone and other impurities, as they will damage the pump valves.
CAUTION: Failure to fit the filter will invalidate the warranty
The machine should be kept clean so as to let cooling air pass freely
through the machine vents.
To ensure an easy connection and that o-rings do not dry up; the couplings
should be greased regularly.
4. After use instructions
5. Environmental protection
6.1 Cleaning of inlet filter
6.2 Cleaning of air vents
6.3Greasing of couplings
6. Maintenance, cleaning and repair
14 15

www.costway.com www.costway.com
7. Breakdown service WEEE - Waste of Electric and Electronic Equipment
The symbol on the product or on its packing indicates that this
product may not be treated as household waste. Instead it shall
be handed over. To the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.
16 17

Welcome to visit our website and purchase our quality products!
Reward Points
Exclusive Customer Service

Permanent Shopping Cart
Order History


this product and giving us valuable feedbacks.
www.costway.com
Your suggestions and comments for COSTWAY are really important to us!
We sincerely solicit you to go back to our shop and leave a good rating in just a
simple click. It would be quite encouraging if you could kindly do so like below:
February 24, 2019
Great products so far. Fast delivery, easy setup, and working without any issues.
Great products so far
With your inspiring rating, COSTWAY will be more consistent to offer you
EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE!
US office: Fontana, California
UK office: Ipswich
www.costway.com
18
