Coulisse COCOON User manual

MN180016_20180713
1/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
2 x 2 x 2 x 4 x
B
Max. 1/8 "
QR
rtube.nl/red991
Bracket Chain
Opening width
Inside mount Outside mount
Inside mount
Outside mount
Deduct 1 1/4 inch from opening
width for screw positions

MN180016_20180713
2/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
1
2
Snap on screw covers
First mount pin side
Installation
1
2
3

MN180016_20180713
3/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Than mount clutch side
4
5

MN180016_20180713
4/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
1
2
1
2
Do not go back to store for support and replacement parts,
but call 1-800-575-2756
Mon-Fri 8am to 11pm EST
Sat-Sun 10am to 7pm EST
Insert the screwdriver into the clutch and twist
the screwdriver to take out the roller blind
Removal

MN180017_20180713
1/2
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Semi-Open Chain
Max 2”Max 2”Max 31”
QR
rtube.nl/red992
Distance from ends should be no more than 2 inch.
Distance in between brackets should be no more than 31 inch.
Inside mount Outside mount
Outside mount
Inside mount

MN180017_20180713
2/2
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
1
3
Click!
2
1
2
1
1
3
2
2
Removal
Installation
Installation
Do not go back to store for support and replacement parts,
but call 1-800-575-2756
Mon-Fri 8am to 11pm EST
Sat-Sun 10am to 7pm EST
Twist

MN180019_20180713
1/3
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
2 x 1 x 1 x 1 x 4 x
Opening width
QR
rtube.nl/red994
Fascia Chain
Inside mount Outside mount
Outside mount
Inside mount
Deduct 1 7/16 inch from
opening width for screw
positions

MN180019_20180713
2/3
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Installation
1
2
3
4
First mount pin side
Than mount clutch side

MN180019_20180713
3/3
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
End caps can only be installed when
the blind is outside mount.
5
6
7
Do not go back to store for support and replacement parts,
but call 1-800-575-2756
Mon-Fri 8am to 11pm EST
Sat-Sun 10am to 7pm EST

Installation instruction for safety device
123
231
23
1
A
B
C
MN180059_20180713
1/1
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309

MN180020_20180713
1/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
2 x 2 x 2 x 4 x
B
Max. 1/8 "
QR
rtube.nl/red995
Bracket Motorized
Opening width
Inside mount Outside mount
Outside mount
Inside mount
Deduct 1 1/4 inch from opening
width for screw positions

MN180020_20180713
2/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
1
2
Snap on screw covers
First mount pin side
Installation
1
2
3

MN180020_20180713
3/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Than mount mechanism side
4
5

MN180020_20180713
4/4
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Do not go back to store for support and replacement parts,
but call 1-800-575-2756
Mon-Fri 8am to 11pm EST
Sat-Sun 10am to 7pm EST
1
2
1
2
Insert the screwdriver into the mechanism and
twist the screwdriver to take out the roller blind
Removal

MN180021_20180713
1/2
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Semi-Open Motorized
Max 2”Max 2”Max 31”
QR
rtube.nl/red996
Distance from ends should be no more than 2 inch.
Distance in between brackets should be no more than 31 inch.
Outside mount
Inside mount
Inside mount Outside mount

MN180021_20180713
2/2
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
1
3
Click!
2
1
2
1
1
3
2
2
Removal
Installation
Do not go back to store for support and replacement parts,
but call 1-800-575-2756
Mon-Fri 8am to 11pm EST
Sat-Sun 10am to 7pm EST
Insert the screwdriver and twist
to release the cassette.

MN180023_20180713
1/3
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
2 x 1 x 1 x 4 x
Opening width
QR
rtube.nl/red998
Fascia Motorized
Inside mount Outside mount
Outside mount
Inside mount
Deduct 1 7/16 inch from
opening width for screw
positions

MN180023_20180713
2/3
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Installation
1
2
3
First mount pin side
Than mount mechanism side

MN180023_20180713
3/3
Fabrication Florida Venture
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
End caps can only be installed when
the blind is installed outside mount.
4
5
6
Do not go back to store for support and replacement parts,
but call 1-800-575-2756
Mon-Fri 8am to 11pm EST
Sat-Sun10am to 7pm EST

1/8
MN180020_20180713
Coulisse Fabrication
6600 NW 12th Avenue, Suite 201
Fort Lauderdale, FL 33309
Conforms to
UL Std. 325
Certified to
CSA Std. C22.2#247
Pull Control
Operate with
pull control
Li-ion Battery
Integrated
lithium-ion battery
Motor features
Control options
Support
Remote Control
Operate with a
remote control
USB Rechargeable
Rechargeable with
micro USB
App Control
Operate with the
MOTION app
Wireless
Cable free
installation
Connectivity
Compatible with
home and building
automation
Speed Control
Consistent
rolling speed
Bi-directional
Two-way
communication for
real-time response
Video
How to install,
program and operate
rtube.nl/red1034
CM-03/05
Li-ion battery powered tube motors with
pull and remote operation
WARNING
Read the instructions carefully
before assembling and
using the product. Assembly
can be completed by non-
professionals. For indoor use
only.
Young children can strangle
themselves with the loop
of pull cords, chains and
tapes, and cords that operate
window coverings.
To avoid strangulation and
entanglement, keep cords out
of reach of young children.
Cords may ensnare a child’s
neck.
Move beds, cots and furniture
away from window covering
cords.
Do not tie cords together.
Make sure cords do not twist
together and form a loop.
Cleaning
Follow these general rules when cleaning the
outside of the device and its components:
Use a damp, soft, lint-free cloth. Avoid getting
moisture in openings.
Do not use aerosol sprays, solvents, alcohol,
or abrasives.
Service & Support
Do not perform repairs yourself. Do not attempt
to open the device or disassemble it. You run
the risk of electric shock and voiding the limited
warranty. No user-serviceable parts are inside.
Warranty Service
First follow the advice in this manual. If the
product appears to be damaged or does not
function properly, go to your local dealer for
instructions on how to obtain warranty service.
