HunterDouglas PowerView M40T User manual

PowerView® Roller Blind 230VAC
Programming with Remote control
The PowerView® M40T tubular motor is suited to be used with EOS® 500 Roller Blinds from Hunter Douglas.
1. Delivery condition
As standard, no remote control or hub is connected to the motor. No limits are set. Motor is default set to ro
ller blind motor type.
IMPORTANT!
Factory fresh motors do not have default limits set. Limits must be set to enable normal operation. If
operated without limits, the shade could be damaged by rolling over the top or wrapping backwards on
the roller.
1.2. Network reset
This procedure will erase all network data stored in the motor, including Network ID and Group assignments.
It will not clear the end limits. Completing a Network reset will prevent a PowerView® remote or App from
operating the window covering until it is reprogrammed.
Page 1 of 18 version: 1.0

2. Pairing a remote to the blind
A PowerView® remote can control up to 6 individual groups of blinds (buttons 1 to 6 at the top of the remote).
The instructions below assign a blind to group 1.
1.2.1 Press and hold the manual control button on
the motor for 12 seconds .
The blind will jog 1x at 6 seconds
and a second time at 12 seconds
1.2.2 Release the manual control button after the
second jog.
The Network ID and Group assignments have
been cleared.
This instruction will make use of these buttons on the
remote:
Page 2 of 18 version: 1.0

Procedure
IMPORTANT
Watch out to perform steps 2.4 and 2.5 within 3 seconds!
2.1 Locate the manual control button on your
blind.
2.2 Press and hold the stop button for 4 seconds.
Keep pressing until the remote
lights start blinking
2.3 Press the group1 button.
Page 3 of 18 version: 1.0

2.4 Press and hold the manual control button .
2.5 Press the open button.
The blind will jog 2x
2.6 Release the manual control button .
2.7 The blind will jog 2x to indicate it has joined the group
2.8 Press and hold the stop button for 4 seconds.
The remote will exit programming mode
automatically after 20 seconds.
Keep pressing until the remote
lights stop blinking
Page 4 of 18 version: 1.0

3. Reversing motor direction
IMPORTANT
Reversing motor direction is only possible with a fresh out of the box motor (no limits set) or when the
end limits are reset. Before any limits are programmed, the motor direction has to be checked and
reversed if needed.
If the top or bottom Limit is already set, and the motor direction has to be reversed, perform a reset
before continuing.
3.1. Deselect all GROUP numbers on the remote
IMPORTANT
Watch out to perform steps 3.1.2 and 3.1.3 within 3 seconds!
3.1.1 Deselect all Group number on the remote
3.1.2 Press and hold the manual control button .
Page 5 of 18 version: 1.0

Note
If end limits were already set, the motor will not jog, indicating the motor direction did not change.
Note
Verify that all GROUP lights are turned off on the remote, clear both limits, and try again.
3.2. Check and confirm
IMPORTANT
Watch out to perform steps 3.2.1 and 3.2.2 immediately after each other to avoid mechanical damage!
Carefully read them first before executing!
3.1.3 Press and release the stop button.
Make sure no group on the remote is
selected.
The blind will jog 2x to indicate it
has reversed motor direction
3.1.4 Release the manual control button .
Page 6 of 18 version: 1.0

4. Setting end limits
It doesn’t matter if you start with setting the open or the close limit first. In this description we start with the
open (top) limit.
Note
It is important to have the fabric of the blind tight around the tube.
3.2.1 Press the arrow down button to check motor
direction.
3.2.2.AIf the blind moves upwards, repeat steps
3.1.1 --> 3.1.3
Motor direction NOT OK!
3.2.2.BIf the blind moves downwards, continue with
step 4.1.4
Motor direction OK!
Page 7 of 18 version: 1.0

4.1. Open limit (top)
4.1.1 Use the manual button on the motor to move the blind
to the desired top position
Each "press and release" of the button will toggle
between Up, Stop and Down.
4.1.2 Use the open , stop and close buttons
to fine tune the blind to the desired position.
4.1.3 Press and hold the stop button for 6 seconds.
DO NOT select a group on the remote!
Keep pressing until the remote
lights start blinking
Page 8 of 18 version: 1.0

IMPORTANT
Watch out to perform steps 4.1.6 and 4.1.7 within 3 seconds!
4.1.4 Press and hold the manual control button .
4.1.5 Press the open button.
The blind will jog 2x to
acknowledge the limit is set
4.1.6 Release the manual control button .
Page 9 of 18 version: 1.0

Note
To re-position the top limit of the blind, clear the top limit and repeat step 4.1 Open limit (top)
4.2. Close limit (bottom)
4.1.7 Press and hold the stop button for 6 seconds.
The remote will exit programming mode
automatically after 20 seconds.
Keep pressing until the remote
lights stop blinking
4.1.8 The top limit is set!
4.2.1 Use the manual button on the motor to move the blind
to the desired bottom position
Each "press and release" of the button will toggle
between Up, Stop and Down.
Page 10 of 18 version: 1.0

IMPORTANT
Watch out to perform steps 4.2.6 and 4.2.7 within 3 seconds!
4.2.2 Use the open , stop and close buttons
to fine tune the blind to the desired position.
4.2.3 Press and hold the stop button for 6 seconds.
DO NOT select a group on the remote!
Keep pressing until the remote
lights start blinking
4.2.4 Press and hold the manual control button .
Page 11 of 18 version: 1.0

4.2.5 Press the close button.
The blind will jog 2x to
acknowledge the bottom limit is
set
4.2.6 Release the manual control button .
4.2.7 Press and hold the stop button for 6 seconds.
The remote will exit programming mode
automatically after 20 seconds.
Keep pressing until the remote
lights stop blinking
4.2.8 The bottom limit is set!
Page 12 of 18 version: 1.0

Note
To re-position the bottom limit of the blind, clear the bottom limit and repeat step 4.2. Close limit
(bottom)
5. Clearing end limits
5.1 Clear top limit
IMPORTANT
Watch out to perform steps 6.1.2 and 6.1.3 within 3 seconds!
5.1.1 Deselect all Group number on the remote
5.1.2 Press and hold the manual control button .
Page 13 of 18 version: 1.0

5.2 Clear bottom limit
IMPORTANT
Watch out to perform steps 6.2.2 and 6.2.3 within 3 seconds!
5.1.3 Press the open button.
The blind will jog 2x to indicate
the top limit is cleared
5.1.4 Release the manual control button .
5.2.1 Deselect all Group number on the remote
Page 14 of 18 version: 1.0

6. Set a favourite position (optional)
Note
After the top and bottom limit are set, the motor will hav one FAVOURITE position, which is set at 50%
open by default. Setting a new FAVOURITE position overwrites any previous setting
5.2.2 Press and hold the manual control button .
5.2.3 Press the close button.
The blind will jog 2x to indicate
the bottom limit is cleared
5.2.4 Release the manual control button .
Page 15 of 18 version: 1.0

6.1 Set favourite position
IMPORTANT
Watch out to perform steps 6.1.3 and 6.1.4 within 3 seconds!
6.1.1 Use the open , stop , close , arrow
down and the arrow up buttons to move the
blind to the desired favourite position.
6.1.2 Press and hold the stop button for 6 seconds.
DO NOT select a group on the remote!
Keep pressing until the remote
lights start blinking
6.1.3 Press and hold the manual control button .
Page 16 of 18 version: 1.0

7 Reset to factory default
The factory default reset erases all information stored in a shade motor. The motor is returned to its factory
default settings of no network programming, no limits, and the motor direction is reset. The default FAVORITE
position will be at 50% after limits are set.
6.1.4 Press the heart button.
The blind will jog 2x to indicate
the favourite position is set
6.1.5 Release the manual control button .
7.1 Press and hold the manual control button on
the motor for 18 seconds .
The blind will jog 1x at 6 seconds
1x at 12 seconds and 1x at 18
seconds
Page 17 of 18 version: 1.0

7.2
Release the manual control button after the
third jog.
The Network ID, Group assignments and end
Limits have been cleared.
