Perfmaster Dash

2
TABLE OF CONTENTS
SPECIFICATIONS…………………………………………………………………………………………….3
SAFETY PROCEDURES/CARE & MAINTENANCE.………………………………………………….3
COMPONENT IDENTIFICATION…………………………………………………………………………4
PAPER STOP ASSEMBLIES………………………………………………………………………….…....5
ROTARY PERF &SCORE ASSEMBLY………………………………………………………………....6
TROUBLESHOOTING……………………………………………………………………………………….7

3
SPECIFICATIONS
Net Weight: PERFMASTER DASH.........................................................60 lbs
Overall Dimensions: …………………………………………………………………..41”Lx30”Wx19”H
Boxed Dimensions: …………………………………………………………………32”Lx35”Wx25”H
Min. Sheet Size: ………………………………………………………………..3”x5”
Max. Sheet Size: …………………………………………………………………18”x20”
NOTE: The Perfmaster Dash is capable of handling many types of applications above
and beyond the standard specifications. It is possible to feed quite avariety of jobs,
from 30” sheets to die cut stocks. However, the performance of the Perfmaster Dash
on these special applications is directly related to the experience of the operator.
SAFETY PROCEDURES
BEFORE USE:
•Read through the owner’s manual. Follow instructions CAREFULLY.
DURING USE:
•Keep fingers and hands away from score blades, perf blades, and rubber
rollers.
BE ALERT! BE CAREFUL!
CARE AND MAINTENANCE
The PERFMASTER DASH is aprecision machine. It is very important to keep it free of
excessive dust, dirt and foreign matter. We recommend that you keep the machine
covered when not in use.
BEARINGS/BUSHINGS: The bearings are sealed roller bearings and are designed to
be self lubricating, however dirt and dust can get into them causing clogging and dirt
build up. It is recommended to oil them daily under heavy use or monthly under light
use. The Bushings are Bronze and do require lubrication more frequently. Oil these
once aweek under heavy use.
RUBBER ROLLERS: These tend to harden when exposed, and in use, use “water to
clean them before and after each use. This will increase the life and require less
replacement. “Do not use Blanket Wash or Other Cleaners.”
REMOVEABLE SCREWS: When these show signsof wear or stripping, replace as soon
as possible. If these strip or hollow out they can be costly to remove. If you do keep
your Perfmaster DASH clean and in top condition, it will give you years of service.

4
COMPONENT IDENTIFICATION
REFERENCES
Perf and Score Assemblies
Pg. 6
Paper Stops
Perf and Score Assemblies Pg. 7
Paper Stops

5
PAPER STOP ASSEMBLIES
INSTALLING THEPAPER STOPS
There are 3different paper stops. 2will have bends and 1will be straight. The
straight paper stop is the rear or back paper stop. The other 2are theright and left
paper stopsand should be positioned as shown below. Theyhold there position using a
magnet which makes it easy for adjustment. The positions for the paper stops will
change for each individual job. If the paper stops are set to close,the paper will hit
them as it exits the machine and will cause apaper jam. If they are set too loose the
paper will stack in an unorganized manner. Getting the position correct is imperative to
smooth operation of the machine.

6
PERFORATING AND SCORING ASSEMBLIES
Replacing Worn Blades
1. Loosen the socket head cap screw to remove pressure from the pressure adjust
mounting bracket.
2. Loosen the set screw and remove the pressure adjust mounting bracket.
3. Remove the button head cap screw that is retaining the score or perf blade.
4. Remove worn blade and replace with new blade. Attach new blade with existing
button head cap screw and washer.
5. Reinstall pressure adjust mounting bracket on machine.
6. Position upper and lower score/perf assemblies as desired, making sure to align the
upper and lower assembly.
7. Once the assemblies are aligned, tighten the set screw.
8. Reapply pressure to blade by tightening the socket head cap screw.
Complete: #S-APP-0129 Complete: #S-APP-0139
1 4
876
3
5
2
11
1 4
2
11
9106
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 H-0250 10-32 1-1/2 SOCKET SCREW 1
2 F-2652 LOCKNUT PRESSURE BRACKET 1
3 F-2040 CNC PERF GUARD 1
4 H-0278 SCREW, 1/4-20X1/2" SOCKET SET HALF DOG 1
5 H-0410 HEXNUT 10-32 LOCK-KEPNUT 1
6 H-0456 WASHER, FLAT .200 X .438 X .031 1
7
S-APP-0143
PERF BLADE ASSY 1
8 H-0239 10-32 X 3/4 BHCS 1
9 H-0215 SCREW 10-32X1/2 BHSC 1
10 S-APP-0131 SCORE BLADE ASSY 1
11 PRESSURE ADJUST MOUNTING BRACKET 1

7
TROUBLE SHOOTING
•FEED TABLE NOT FEEDING CORRECTLY
1. Check Caliper Adjustment.
2. Feed wheelsdo not haveequal pressureon them, check adjustment.
•SHEETS NOT FEEDING STRAIGHT
1. Unequal feed wheel pressure.
2. Align feed rails“check for squareness”. Thiscan bechecked by the lead edge
ofthe paper feeding into the machine should line up withthe front edge of the
feed plate.
3. Not enough pressureon forwarding rollers.
4. Clean ALL rubber rollers.
•PERFISNOT STRAIGHT
1. Checkfor equal pressure onall grip wheels and that none are hanging up.
2. Recheck all steps under (SHEET NOT FEEDING STRAIGHT)
•PERFORATION ISNOT CLEAN OR CUTS SHEETS
1. Not enough pressureon perf wheel.
2. Perf bladeisworn.
