CoverCraft Grommet User manual

If your vehicle has an outside radio antenna which will not retract ush with the vehicle body, you will have to provide an opening in the cover.
We have included a non-corrosive plastic grommet set with your cover.
• Place the cover on the vehicle except for the fender or body panel where the antenna is located.
• Center the cover, align both seams with the roof edges and be sure the cover is pulled down evenly over the front and rear bumpers.
• Carefully unfold the portion of the cover that is next to the antenna and position it next to the base of the antenna.
• Recheck the overall positioning of the cover to make sure it has not moved.
• Make sure the cover lies at over the hood and roof areas of the vehicle and mark the cover with the location of the antenna base and make a
hole with a sharp pencil.
• Using sharp scissors, make the hole opening 3/4” in diameter and install grommet. The outside grommet ring t is very tight.
• Place the cover on a clean, hard surface. Position the inside grommet through the opening you made and then secure the outside grommet snap-
ring in place using a rubber mallet.
• Remove the antenna.
• Install cover on the vehicle.
• Check cover is aligned correctly.
• Using a sharp pencil punch a hole through the fabric at the antenna location.
• Using sharp scissors, make the hole opening 3/4” in diameter and install grommet. The outside
grommet ring t is very tight.
• Place the cover on a clean, hard surface. Position the inside grommet through the opening you
made and then secure the outside grommet snap-ring in place using a rubber mallet.
• Lay cover over vehicle with the
front facing you. The front will be
marked with either an ID or logo.
(ID may be located on the inside
front of the cover)
• Make sure if using a grommet that
the antenna is placed through the
cover before proceeding.
• Stretch cover over the front and
rear bumpers.
• Place mirror pockets over mirrors.
• Release both ends of the cover from under the bumpers.
• Fold up both sides onto the top of the vehicle into a long pile approximately 2 feet(60cm) wide.
• Start at the front of the vehicle & fold the cover in 3 foot(1 meter) folds from the front to the back
If you encounter any problems during the installation of your Car Cover, please contact our Customer Service Department, Monday-Friday, 8AM-5PM(CST)
at 800-4-COVERS (800-426-8377) or by e-mail at [email protected]. You may also access help videos on the web at covercraft.com
Scan code on phone or tablet to view full detailed car cover installation video:
Car Cover Installation
Grommet Installation
Car Cover Installation
Car Cover Removal
Non-Removable Antenna
Removable Antenna
TIPS
• To extend the life of your cover place vinyl tape over any areas exposed to severe abrasion.
• If installing cover after driving be careful not to let the cover come in contact with hot exhaust pipe.
• A tie-down rope is included and can be used to tighten the bottom of the cover through the loops sewn
under the driver and passenger side doors.

WARNING TO OWNERS OF REPAINTED VEHICLES: Use of a cover on any recently-painted surface may cause
damage to that surface! If your vehicle has been repainted, check with the painter or body shop on the specics of
how and when you can use this cover.
WARNING FOR USE IN HIGH WIND AREAS: In high wind areas (and for extended storage), use the loops and rope
provided to securely pull the cover tight under the center of the car. This should be done even if the optional lock
and cable is being used.The cover is NOT designed to replace a garage and should be checked for apping in high
winds. If wind gets under the cover, it can cause it to work loose and come o the vehicle, or damage the cover.
WARNING FOR FREEZING WEATHER: In very rare cases when a heavy rainstorm is followed by an extreme tem-
perature drop to below freezing, it is possible for the cover to become frozen to a layer of ice created between the
vehicle body and the cover. DO NOT attempt to remove the cover if this happens. If it is necessary to remove the
cover, we recommend pouring warm water over the vehicle and slowly removing the cover, taking care to inspect
the surfaces of both the cover and the vehicle during the removal process. Stop immediately if you encounter
resistance - the ice has not been melted completely and you must pour more warm water over the vehicle.
WARNING REGARDING TOWING: Vehicle covers are NOT designed for use when towing. Serious damage can
occure to the cover and the paint surface of the vehicle is a cover is used when a vehicle is being towed. Using a
cover while towing is done at your own risk!
WASHING DRYING
FABRIC Machine Type Cleaner Water Temp Machine Dry Air Dry
Gray Polycotton H or C PD Warm Low
Tan Flannel H or C PD Warm Low
Fleeced Satin H or C PD Cold X
Dustop™ C PD Cold X
Form Fit® H or C PD Cold X
Block-IT®380 C PD Cold X
Reec’Tect® H or C PD Warm Low
NOAH® C PD Cold X
WeatherShield®HP H or C PD Cold Medium
Ultra’Tect® H or C PD Cold X
Sunbrella® C PD Cold X
WeatherShield®HD H or C PD Cold X
MACHINE TYPE: H = Large home-sized top or front load, with or without agitator
C = Commercial or Large home front load, no agitator
CLEANER: PD = Mild Powder Detergent [dissolve rst], No Bleach or Fabric Softner
•Polycotton
•Flannel
•Fleeced Satin
•Dustop®
•Form-Fit®
•380 Series
•Reec’tect®
•NOAH®
•WeatherShield®HP
•Ultra’tect®
•Sunbrella®
•WeatherShield®HD
Fabric Warranty
90 Days
90 Days
2 Years
4 Years
4 Years
3 Years
3 Years
4 Years
4 Years
5 Years
6 Years
6 Years
Car Cover Care
Cleaning Instructions
Limited Warranty
• Place the cover in the largest washing machine available. Extra-large covers (for vehicles such as SUV’s and pickup trucks), in any fabric, should
always be washed in large commercial front load machines.
• If available, use the GENTLE cycle.
• Based on your cover fabric, use the cleaning chart below and wash with the appropriate cleaner and washing machine settings.
NEVER USE FABRIC SOFTNER
• Rinse the cover TWICE (2x) with water only to remove all the cleaner.
• Dry according to the fabric chart.
Covers are warranted from date of purchase to the original purchaser. Save your receipt! Warranty coverage protects against defects in ma-
terial and workmanship, as well as the fabric becoming unserviceable during normal use. After factory inspection, we will repair or replace
the cover or specic panels judged to be unusable. Covers are NOT warranted against fading, which occurs naturally on all products used
outdoors. These fabrics are not waterproof - all are breathable to allow moisture, condensation, and heat to escape from under the fabric.
IMPORTANT WARNINGS - PLEASE READ BEFORE USING COVER!
If you encounter any problems during the installation of your Car Cover, please contact our Customer Service Department, Monday-Friday, 8AM-5PM(CST)
at 800-4-COVERS (800-426-8377) or by e-mail at [email protected]. You may also access help videos on the web at covercraft.com
Form #1360011 (10/20)
