COXPAL A7 Dual HW User manual

User
Manual
Model No: A7 Dual HW

Page / 01
Fuse Holder
C. Mini ACS Add-A-Circuit Fuse
Holder
D. ATO ACU Add-A-Circuit Fuse
Holder
G. Black Wire to the Ground
B. Mini/LP ACN Add-A-Circuit F. Red Wire to Fuse Box
1. Product Overview
G
F
BE DC
A. Dash Cam Hardwire Kit E. Micro2 Add-A-Circuit
Fuse Holder
A

3. Identify your fuse type
Next you need to identify the type of fuse.
Name Description
Connector
1. Locate your fuse box
Use your vehicle’s owner manual to identify the location of the
internal fuse box.This is normally found by the foot well on the
driver’s side of your vehicle. You may need a tool to gain access.
2. Find the correct fuse slot for your hardwire kit
Next you need to find the fuse map which is a diagram describing
what each fuse does and where it’s located in the box. This
simplifies the process and ensures you don’t pull the airbag fuse.
Or you will need a circuit tester or multimeter to test if a fuse is
ignition switched or always on. If you need to find an ignition
switched fuse, put the key in the vehicle, find the fuse which is not
lit up while the car is off, and test it by turning the car on to see if
it lights up. If your kit requires constant power, turn off the car and
remove the key to see which fuse slots stays lit on.
Output Voltage
Input Voltage
Output Current
USB Type-C
DC 5V
DC 12V-24V
1.5A
Working Temperature
Cable Length
-22℉ ~ 167℉ (-30℃ ~ 75℃)
3.5m (11ft)
Low Voltage Protection 11.7V for 12V vehicle;
23.7V for 24V vehicle.
2. Specications
3. Installation
Page / 02

2
4
a. Once you've determined which fuse slots you need to use for
your hardwiring kit you can crimp the red wire of your hardwire
kit onto the Add-A-Fuse.
b. Make sure the key has been removed from the ignition. Using a
fuse puller or a pair of pliers, gently remove the fuse you
identified.
4. Connect to car fuse box
Page / 03
1
3

Page / 04
c. Install the fuse you just removed into the installation kit add-a-
fuse circuit.
d. Plug the add-a-circuit into the fuse box in the correct
orientation.
a. Next, slip the black wire (which is in the shape of a C) under
a metal bolt or screw in your vehicle (this is the ground wire).
Using a multimeter, check that it is not attached onto plastic
parts. You will typically need a socket wrench to loosen the
nut or bolt that you choose to ground with. To attach the
gounding terminal, loosen the nut or bolt enough to slip it
in and tighten it back up afterwards. A loose ground can
result in power issues for your dash cam.
5. Ground the hardwiring kit

Page / 05
a. Connect the dash cam with the hardwire kit. If everything
was installed correctly, you should see your dashcam turn on
and begin recording! At this point you may go ahead and
reinstall all interior panels that were removed to facilitate
running the power cable.
6. Test your installation

Warranty & Support
Warranty: Full 12-month since the date of purchase.
Your opinion matters!
Coxpal is firmly committed to continually improving our products,
services, and user experience. If you have any thoughts on how we can
do even better, we always welcome your constructive feedback and
suggestions.
Support: [e-mail]
Recommended Mail Subject Format for quickly handling your case:
Model No + Purchase Channel + Order ID
Subject A7 Dual HW + Amazon US + Order ID 123-456789-0123456
For example:
Page / 06
