Semi Solution Chanun Ace User manual

사용 설명서
Read carefully through this User Manual for safe use of the product before installation, operation, or use.
User’s Manual

Purpose of the product and warrant and scope of responsibility of video recordings
1. Distributors and users should be noted that this product has completed an electromagnetic compatibility registration for business use
(Class A) and is thus intended for use in places other than homes.
2. This product is an auxiliary device for safe driving that is intended to record the driver’s view with the purposes of raising his/her aware
ness about safe driving, preventing accidents, and providing the circumferential information material when an accident takes place
3. This product does not warrant recording of all the image of an accident. Furthermore, it should be noted that it may not be able to
detect a minor impact that does not trigger the operation of its impact sensor, in which case the moment is not recognized as an event
and consequently does not record it.
4. We are not responsible for all the damages including, but not limited to, loss of recorded image and loss of related driving information,
that may result from the mechanical failure of the product occurring at the time of an accident or under any other circumstances.
5. Precautions when using a constant power cable for parking recording.
All the models on CHANUN Black Box Series are developed to be basically used on a vehicle’s power terminal (DC 12V~24V). If you are
planning to use a constant power cable for recording in the parking mode, you need to consult an expert, for you may have good chances
of experiencing any of the following problems. We are not liable for any and all the damage to the product arising therefrom or in con
nection thereof, especially to the vehicle, for which the user is fully responsible.
Caution
[Possible failures resulting from the use of a constant power cable]
① Lessening of the service life of the black box and development of severe failures
② Deformation of the product in hot summer heat and breakout of car fires
③ Reduced performance of a car battery
④ Damage to a car’s electrical system due to the deterioration in battery performance
⑤ Excessive operation of a generator to make up for a reduction in the battery’s output voltage and resulting shortening of its service life.
⑥ Reduced gas mileage
※ [You are recommended to use an uninterruptible power supply, an auxiliary battery, in order to use a constant power supply to your
black box in the parking mode.]

Warnings for Safe Use
1. Do not look straight at the product or manipulate it behind the wheel.
Staring at or manipulating the product at the wheel may result in an accident. Pull you car over to a
safe place before you manipulate it.
2. Do not disassemble, repair, or remodel the product at your discretion.
which may lead to an electric shock, damage to the product, and/or loss of recorded images and
data. Contact our Customer Service Center for consultation if you find out that the product has
developed any failure.
3. When water gets into the product, do not dry it forcefully with a heating device. (such as a heater,
a hair dryer, or a microwave oven)
which may result in explosion, deformation, or an mechanical failure. Contact our Customer Service
Center for repair service. Furthermore, do not use liquids such as water, benzene, and alcohol
when your clean the product; instead, clean it with a soft dry cloth.
4. Avoid using any components other than those included in the package set.
Use of any parts other than those provided by us may give rise to a failure or an accident.
5. Do not use power that is not specified for this product.
Be sure to connect this product to a vehicles’ rated voltage (12~24V) power supply and observe all
the instructions for installation. Use or installation of the product with any voltage other than speci-
fied ones may result in explosion, fire, or failure.
This “Warnings for Safe Use” is intended to provide you with all the safety precautions and notes for the purposes of
promoting your safe use and protecting you against personal injury and property damage. And, you are advised to
keep this User Manual at a place clearly visible and readily accessible
Caution
This sign refers to a
caution a violation of
which may result in minor
personal injury,
a mild mechanical failure,
or property damage.

Warnings for Safe Use
6. Separate the product from inside the vehicle in hot summer or cold winter and keep it in a different place.
Long storage of the product in the closed vehicle in hot summer or in cold winter may lead to malfunction or
failure. When the vehicle is meant to be parked for a long time, separate the product and store it in other
place.
※ This product is designed to trigger the high-temperature operation shutoff and automatically comes to a
stop when the temperature rises above the product’s operating temperature range due to the ambient
temperature. The product will resume its operation when the temperature decreases below its operating
temperature range.
7. Precautions when using a constant power cable
All the models on CHANUN Black Box Series are developed to be basically used on a vehicle’s power
terminal (DC 12V~24V). If you are planning to use a constant power cable for recording in the parking
mode, you need to consult an expert, for you may have good chances of experiencing any of the following
problems. We are not liable for any and all the damage to the product arising therefrom or in connection
thereof, especially to the vehicle, for which the user is fully responsible.
This “Warnings for Safe Use” is intended to provide you with all the safety precautions and notes for the purposes of
promoting your safe use and protecting you against personal injury and property damage. And, you are advised to
keep this User Manual at a place clearly visible and readily accessible.
Caution
This sign refers to a
caution a violation of
which may result in minor
personal injury,
a mild mechanical failure,
or property damage.

Warnings for Safe Use
1.Avoid installing the product on an area of the windshield coated with a thick tinting film or a place
where foreign matter (such as a sticker) or an obstacle blocks view.
This may deteriorate the video quality or make the GPS connection (limited to GPS devices) unstable.
2. Be sure to keep the camera lens clean at all times.
When the lens is contaminated by foreign matter, it reduces the quality of recorded videos. Clean
the lens with a soft cloth periodically.
3. When a big accident causes damage to the product or when power is cut off, conduct an inspec-
tion on the product before it is put into operation again.
Use without examination may result in malfunction of the product, causing it to be unable to record
events.
4. When the product is attached at a different location, be sure to re-check the angle of the camera
before it is put to use.
The camera is likely to lose its preset angle when it is unused for a long time or it is exposed to
severe vibration after driving on unpaved roads; so, check it regularly.
This “Warnings for Safe Use” is intended to provide you with all the safety precautions and notes for the purposes of
promoting your safe use and protecting you against personal injury and property damage. And, you are advised to
keep this User Manual at a place clearly visible and readily accessible.
Caution
This sign refers to a
caution a violation of
which may result in minor
personal injury,
a mild mechanical failure,
or property damage.

Warnings for Safe Use
5. The quality of recorded images may vary depending on recording locations and lighting.
This product adopts a camera to record images; therefore, its quality may be reduced in a situation
in which your car experiences sudden changes in brightness such as entering or exiting a tunnel,
driving in full sunlight that produces strong backlight or in the nighttime environment without any
light sources.
6. The automatic event recording may not be enabled in case of a very weak impact,
in which case an arbitrary impact can be exercised to cause the product to record the event
7. Check recorded videos regularly.
You are recommended to inspect recorded videos periodically to check if the product and the SD
memory card function normally.
When you find any abnormality, stop using the product and contact our Customer Service Center for
service.
This “Warnings for Safe Use” is intended to provide you with all the safety precautions and notes for the purposes of
promoting your safe use and protecting you against personal injury and property damage. And, you are advised to
keep this User Manual at a place clearly visible and readily accessible.
Caution
This sign refers to a
caution a violation of
which may result in minor
personal injury,
a mild mechanical failure,
or property damage.

Safety precautions- GPS (limited to model with a GPS receiver)
The Global Positioning System (GPS) is a sophisticated, satellite-based, navigation system that receives data from more than 3 dedicated satellites that
provide accurate time and distance to calculate the current location. This product makes use of the GPS technology to record the vehicle’s location
and driving speed at the time of recoding images, thus enabling it to offer additional circumferential information along with the recorded image. Further-
more, the technology allows the user to combine the location information with a map serviced on the Internet to keep track of his/her travels.
1. GPS signals are influenced by weather, satellite condition, and geographic features.
The antenna mounted in this product receives signals from communications satellites revolving on their orbits above the Earth; therefore, the reception
quality may become unstable when there are such factors as affect the communication between two ends as weather conditions (cloudy days with thick-
ening clouds and rainy days) and surrounding topography (around high-rises, under elevated roads, in tunnels and underground roadways, and under-
ground parking lots).
2. Reception of GPS signals has no effect on the product’s ability to record images.
Even though GPS signals are lost halfway, the product normally records images without writing the location and driving information.
3. When the product is first used or it has been unused for a long time, it can take about 5~30 minute to receive satellite signals properly. That is
because it takes longer time to search for the locations of satellites and receive signals from them.
4. Optimum temperature for a GPS receiver to operate ranges from 0℃ to 50℃.
GPS signals are unstable or take longer time to reach a receiver in hot summer or in cold winter; therefore, it is desirable to keep stable the temperature
inside the vehicle.
5. A GPS receiver can be influenced by such element as metal coating on the vehicle’s window or dark tinting.
It is advised that you should avoid installing the product on such part.
6. A GPS receiver can be affected by items of equipment that generate electromagnetic waves that interfere with GPS signals in the vehicle.
Such GPS devices include some wireless starters and alarms, some MP3 and CD players, and GPS-based security alarms, which produce radio waves
that can interfere with reception by a device of GPS signals.

Safety Precautions- SD Memory Cards
1. SD memory cards are *consumables. Accordingly, perform regular inspections and replace defective cards with new ones.
(*Consumables: The warranty period for SD memory cards is 6 months, as is warranted by makers.)
A SD memory card becomes obsolescent as it continues to record images. Accordingly, you are advised to conduct regular inspections and replace it
with a new product when it has difficulty in being verified.
Formatting a SD memory card regularly can extend its service life (recommended to format it once every two weeks).
Be sure to have a backup of important video files before it is subjected to formatting.
2. Use only genuine SD memory card provided by our company.
You are advised to use or purchase genuine SD memory cards specified by us. Use of unspecified SD memory cards may give rise to
such problems as short service life and compatibility, resulting in inability to perform recording properly.
3. Be sure to disconnect power before you separate the SD memory card from the product.
In the event the memory card is taken out while power is connected, data stored in it may be damaged, lost, or the product can
develop a mechanical failure. Make sure that you should turn off power before you separate the card.
4. Do not disassemble or alter SD memory cards at your discretion.
Arbitrary disassembly or alteration may result in the loss of the data in them or damage to this product.
5. Care should be exercised not to let SD memory cards be exposed to moisture, dust, and heat during separate storage.
Long-term exposure to moisture, dust, and heat may cause memory cards to be deformed or to be unable to perform properly.
6. Be sure to make a backup of important data in other storage media in addition to the SD memory card.
You are recommended to make a backup of important data that need storing safely for a long time using a separate storage medium
(such as a hard disk or CD). Especially, attention should be paid to accident-related images which had better be stored in a sepa-
rate medium, for continued recording after the accident can cause the accident data to be deleted permanently.

...........................................................................................................
Table of Contents
How to check video on Chanun Ace real time on a smart phone (for Android) ..... 18
How to save and check video files on a smart phone. .......................................... 19
How to set the black box through the Chanun Ace application. ............................. 20
How to check video on Chanun Ace real time on a smart phone (for iPhone)...... 22
How to check video files stored in Chanun Ace ...................................................... 23
How to save and check video files on a smart phone ............................................ 24
How to set the black box through the Chanun Ace application ............................ 25
Constitution of the Product ............................................................................ 10
Points to be checked before asking for repair service .................................. 26
FAQs 27
Certifications ................................................................................................ 28
Product specifications ................................................................................. 29
Functional overview ................................................................................... 11
Installation .............................................................................................. 12
Installing the Player .................................................................................... 13
Using the Player
.................................................................. 14
Menu organization for the Player
................................................................................... 15
Configuration for the Player ......................................................................... 16
List of voice messages .............................................................................. 17
Using the Android application ...................................................................... 18
Using iPhone App ................................................................................. 21

10 Chanun Ace User’s Guide
Constitution of the Product
* The components of this product are subject to change without prior notice for the purpose of improving their performance.
You need to purchase additional parts other than those provided in the basic bundle as well as other accessory items.
Programs and User Manual
Programs and User Manual
Download them from the
archive of our
Homepage at
www.camsolution.co.kr
Check if all of the following components are delivered when you purchase the product. (The parts provided in the package may vary in appearance and color depending on models)
Main body Front / Rear view camera Cigar jack Memory card WiFi dongle
Camera cable Quick reference guide BlackBox Inside sticker GPS cable (Optional)
제품 구성품
* 본 제품의 구성품은 제품 성능의 향상을 위해 사전 예고없이 변경될 수 있으며,
기본품 (본체)외 추가 요청시에는 별도 구매하셔야 합니다.
사용시 주의 사항
메모리 카드를 넣고 뺄 때는 블랙박스 전원을 꺼 주시기 바랍니다.
블랙박스와 함께 제공된 정품 메모리 카드를 사용해 주시기 바랍니다.
(권장 사항)
메모리 카드에는 쓰기/읽기 수명이 있기 때문에 장기간 사용하면 데이터 기록의 오류가 발생할 수 있습니다.
이런 경우에는 새 메모리 카드를 구입하여 사용하시기 바랍니다.
(장기간 쓰기/읽기로 인한 데이터의 오류,
미 기록에 관해서 당사는 일체 그 책임을 지지 않기 때문에 미리 양해 부탁 드립니다.)
정기적으로 포맷하여 사용하시면 SD 메모리 카드의 사용기간을 연장할 수 있습니다. (권장 포맷횟수 2주 1회)
SD 카드를 포맷하기 전 중요 영상파일은 반드시 백업하여 주시기 바랍니다.
메모리 카드에 충격을 가하지 마십시오.
메모리 카드 접촉면에 먼지나 이물이 묻지 않도록 주의 바랍니다.
촬영 상태에서 메모리 카드를 꺼내지 마십시오. 메모리 카드 내의 데이터 파손되는 원인이 됩니다.
제공된 정품 메모리 카드는 타 기종과 혼용하여 사용하지 마십시오.
타 기종에 사용한 메모리를 블랙박스에 적용하시면 녹화 오동작이 발생할 수 있습니다.
※ 비정상적인 전원 연결 사용시 발생하는 문제에 대해서는 본사는 일체 책임지지 않으며 무상 AS 또한 불가합니다.
(퓨즈박스 연결 및 자동차 배터리 연결 등)
엔진 시동을 걸고, 본체의 전원 램프가 켜지면 설치완료입니다. 만일, 전원 램프가 켜지지 않으면 접속부분이
확실히 접속되어있는지 확인하여 주십시오. 또한 시거 소켓의 먼지나 이물을 제거하여 주십시오.
제품 사양 제품 보증서
CHANUN 제품을 구입해 주셔서 감사합니다. 본 제품은 세미솔루션 기술진의 정밀검사에 합격하고, 철저한 품질관리를 거친 제품입니다.
만일 제품 보증기간 내에 제조상의 결함이나 정상적인 사용상태에서 고장이 발생했을 경우 당사 A/S 센터에서 수리를 받으실 수 있습니다.
A/S를 받으실 경우 반드시 제품보증서를 지참하셔야 합니다. 제품보증서는 재발급되지 않습니다.
㈜세미솔루션에서는 품목별 소비자분쟁해결기준 (공정거래위원회 고시)에 따라 아래와 같이 제품에 대한 보증을 실시합니다.
제품 모델명, 고장상태, 연락처 등을 정확히 알려주시면 고객 여러분의 궁금한 점을 언제나 친절하게 상담해 드리고 빠른 서비스를 제공합니다.
상시 전원 케이블 사용시 주의사항
당사 블랙박스“CHANUN”시리즈 전 제품은 차량 전용 전원 단자 (DC 12V ~ 24V) 사용을 기본으로 개발된 제품입니다. 주차 시 녹화를 위해 상시 전원
케이블을 사용할 경우 아래와 같은 문제점 발생 소지가 높기 때문에 사용 전 반드시 전문가와 상담하시기 바랍니다. 이 때 발생하는 제품 손상 시에는
무상 A/S를 받을 수 없으며 특히 차량에 문제가 발생 시에는 당사는 일체 책임이 없으며 사용자의 책임임을 알려드립니다.
블랙박스 제품 수명단축 및 심각한 고장
여름철 고온에서의 제품 변형 및 차량 화재 발생
자동차 배터리 성능 저하
배터리 성능 저하로 인한 차량 전기계통 손상
배터리 출력전압 감소 보완을 위한 발전기 과다 작동 및 수명 단축
자동차 연비 감소
<상시 전원 케이블 사용으로 인한 예상 문제>
무상서비스
1. 구입 후 제품 보증기간 이내(2년)에 제품이 고장 날 경우 (단, 상시전원케이블 사용으로 문제 발생 시 유상 A/S 처리됩니다)
2. 보증 기간 이내에 정상적인 사용 상태에서 발생한 성능, 기능상의 하자인 경우 (단, 메모리카드는 소모성 부품이므로 품질 보증기간은 6개월입니다)
* 일반 제품을 영업용도로 전환하여 사용할 경우 보증기간은 1년으로 단축 적용합니다.
소비자 피해유형
보상 내용
품질보증기간 이내
정상적인
사용조건에서
성능, 기능상의
고장 발생시
품질보증기간 이후
구입 후 10일 이내 중요한 수리를 요할 때
동일 하자로 3회까지 고장 발생 시
동일 하자로 4회 고장 발생 시
서로 다른 하자로 5회까지 고장 발생 시
수리용 부품은 있으나 수리 불능 시
부품보유 기간 내 수리용 부품이 없이 수리 불가능 시
제품교환 또는 구입가 환급
제품교환 또는 무상수리
무상수리
제품교환 또는 구입가 환급
제품교환 또는 구입가 환급
제품교환 또는 구입가 환급
해당없음
해당없음
유상수리
유상수리
정액감가상각 후 환급
정액감가상각 후 환급
유상서비스
1. 보증기간 경과 후 제품이 고장 난 경우
2. 무상서비스 기간 내 소비자 과실로 고장 난 경우
사용상의 잘못 또는 취급 부주의(낙하, 침수, 충격, 파손) 임의로 수리, 개조하여 고장 발생 시
부적절한 전원을 연결하여 고장 발생 시
지정 서비스 센터가 아닌 곳에서 부적절한 수리를 받아 고장 발생 시
당사에서 제공하지 않은 액세서리(케이블, 어댑터 등)의 구입, 사용으로 고장 발생 시
3. 그 밖의 경우
천재지변(낙뢰, 화재, 염해, 수해 등)에 의한 고장 발생 시
충격전압으로 보호할 수 없는 불안정한 전원에서 사용한 경우
제품 내부에 이물질(커피, 우유, 음료수, 물 등)이 유입되어 고장이 발생한 경우
수리가 필요한 경우
1. 제품 시리얼 번호를 반드시 기재해 주시기 바랍니다.
2. 본체와 자성을 띄는 제품은 반드시 따로 포장하시기 바랍니다.
3. 택배로 발송할 경우 택배비는 선불 처리 후 발송해 주셔야 하며, 착불로 수리센터로 입고될 경우 반송 처리될 수 있으니 유의하시기 바랍니다.
전압 용량을 틀리게 사용하여 고장 발생 시
소모성 부품의 수명이 다한 경우 (배터리 등)
제품명
모델명
구입일
구입처
제품 일련번호
구입 금액
※ 프리미엄 블랙박스“차눈”은 자동차에서 제공하는 규격전압출구단자 (시거잭등) 사용시에만 무상 AS 적용이 됩니다.
참고
■ 외부 디자인과 제품 규격은 제품의 성능 향상을 위해 사전 통지 없이 변경될 수 있습니다.
■ 외부로부터 강한 노이즈 발생시 이상동작이 발생할 수 있습니다.
■
본 제품을 보호하고 안정적인 녹화를 하기 위해 고온 (75℃ 이상)에서는 제품의 동작을 멈추게 하는 기능이
적용되어 있습니다. 주변 환경 온도에 의해 제품의 동작 온도가 정상적인 동작을 할 수 없는 고온이 되면, 자동으로
고온 동작 차단이 되어 동작이 중지 됩니다. 주변 환경 온도가 내려가서 제품의 동작 온도가 일정 온도 이하로
떨어지면 제품이 다시 정상 동작합니다.
참고
■
당사 홈페이지(www.camsloution.co.kr)에서 차눈 전용 플레이어 다운로드가 가능합니다.
■ SD메모리카드는 정품 사용을 권장하고 있으며, 그 외에 부득이한 경우는 Class10 MLC 계열 이상 제품을
권장하고 있습니다.
Main Features
Components and features of this product are subject to change without notice to the user
in order to improve the performance of the product.
Package
Suite 2005 Heungdeok U-Toewer 120, Heungdeokjungang-ro,
Giheung-gu, Yongin-si, Gyeonggi-do, Korea
www.camsolution.co.kr l Tel [phone] l Fax [phone]
* Components and features of this product are subject to change without notice to the user in order to improve
the performance of the product. You must purchase a separate additional requests except default package.
How to install
Name of each part
Notice
Please turn off the power firstly when you remove or insert micro SD card and use the original micro SD card
privided with blackbox. (Recommendation)
It may be unable to record normally from long period read/write operation because micro SD card, which is
expendable supplies, is damaged after a certain life period.(For errors or recording failure due to long
read/write, we don’t undertake any responsibility)
It can extend the life of SD card by formatting periodically. (recommend format period : 2 weeks)
Please back up the data in SD card before formatting SD card.
Don’t shock to SD card.
Be careful do not contact dust, etc at the SD card contacts.
Don’t remove SD card in the course of recording. It occurs the failure of recording or defect of SD card.
Don’t use other model SD card. The use of other model SD card, which is not the provided genuine SD card,
make the failure of recording.
Security LED
Angle of view
121°(Front/Rear)
Easy voice guidance
HD High quality video
3D G-Sensor
Auto turn off at
high temperature
Resolution
STANDARD LIMITED WARRANTY
Problem Types
Warranty
Within Warranty Period
For performance
and functional
problems under normal
use conditions
Malfunction due to
customer fault
Out of Warranty Period
Thank you for purchasing CHANUN Dash Cam.
Semisolution gives you the following limited warranty for this product only if it was originally purchased for use, not resales,
from Semisolution or a Semisolution's Authorized Retail Dealer. Semisolution will repair or replace, free of charge, to the
original purchaser, any part which is found to be defective in material or workmanship within one (1) year of the date of
purchase. (Accessories and Battery / microSD Card : 6 Months)
Semisolution provides the product warranty according to Consumer Dispute Settlement Regulations (drawn up by the Fair
Trade Commission). Semisolution or Authorized Retail Dealer will provide the service upon request.
This limited warranty does not apply to any part subjected to accident, abuse, commercial use, alteration, missuse,
damage caused by fire, the use of voltages other than indicated on the manual, or service of this product by other than
Semisolution or Semisolution's Authorized Service Center. Any commercial use of this product will void this limited
warranty. The warranty and A/S is applied only for the use of vehicle's voltage outlet. (cigarette lighter, etc.)
For serious repair required within 10 days of purchase.
Repeated problem with the same defect 4 times.
Repeated problem with different parts up to 5 times.
When repair is unavailable due to lack of spare parts
within the component holding period.
When repair is unavailable even with spare parts.
Malfunction & damage caused by user negligence
(fall, shock, damage, unreasonable operation, etc.) or careless use.
Malfunction & damage after the customer or
a third party repaired or modified the product.
Malfunction & damage due to used of unauthorized components,
consumables, or separately sold parts.
Exchange / Refund
Exchange / Free Repair
Exchange / Refund
Exchange / Refund
Exchange / Refund
Paid Repair
Paid Repair
Paid Repair
N/A
Paid Repair
Paid Repair
Refund after depreciation
Refund after depreciation
Paid Repair
Paid Repair
Paid Repair
※ Semisolution will not have any responsibility for the problem caused by abnormal power cable connection
(Fuse box connection or Car battery connection etc.) and free A/S will not be provided.
경기도 용인시 기흥구 흥덕중앙로120 (영덕동 흥덕U타워 지식산업센터 2005호)
www.camsolution.co.kr l Tel [phone] l Fax [phone]
Main Features
본 제품의 구성품 및 기능은 제품 성능 향상을 위해 이용자에게 사전 통보없이 변경될 수 있습니다.
WiFi 스마트폰 연동
121
Body Front / Rear camera Cigar jack
Memory card &
WiFi dongle
Rec sticker
GPS cable
(Optional)
Camera cable Program & Manual
Download at our webpage
www.camsolution.co.kr
2CH Camera
Quick Manual
제품 상세 매뉴얼 및 전용뷰어 프로그램은 당사 홈페이지에서 다운로드 받으시기 바랍니다.
www.camsolution.co.kr
Quick Manual
시큐리티 LED
편리한 음성안내
3축 G-Sensor
고온 시 자동차단
HD 고화질 영상 2채널 카메라
121°화각 (전/후방)
WiFi 스마트폰 연동
121
Resolution
본체 전·후방 카메라시가잭
메모리카드 & WiFi동글
퀵매뉴얼촬영 스티커 GPS 케이블 (별매품)
카메라 케이블프로그램 & 매뉴얼
당사 홈페이지
www.camsolution.co.kr
자료실에서
다운로드 받으시기 바랍니다.
QuickManual
제품 상세 매뉴얼 및 전용뷰어 프로그램은 당사 홈페이지에서 다운로드 받으시기 바랍니다.
www.camsolution.co.kr
제품 각부 명칭
카메라 렌즈
거치대
Security LED Event LED
Event button
본체 MIC
GPS LED
Event LED
Format
본체 스피커
MIC/Mute
Speaker/Mute
Event
전원 스위치
USB (Wi-Fi 동글)
SD 카드 삽입구
후방 카메라 단자
전방 카메라 단자
Power 단자
GPS 단자
TV Out 단자
카메라 렌즈
거치대
Security LED Event LED
Event button
본체 MIC
GPS LED
Event LED
Format
본체 스피커
MIC/Mute
Speaker/Mute
Event
전원 스위치
USB (Wi-Fi 동글)
SD 카드 삽입구
후방 카메라 단자
전방 카메라 단자
Power 단자
GPS 단자
TV Out 단자
제품 장착
2
전방 카메라
룸 미러
설치시 주의사항
하기와 같이 설치하십시오.
열선 위에 부착하면 추후 해체시에
열선의 손상이 우려되오니 주의하십시오.
양면테이프 접착시 부착할 면의 이물 또는
먼지를 마른헝겊으로 깨끗이 제거한 후에
부착하여 주십시오.
본체 옆면 메모리 카드 슬롯에 그림과 같은
방향으로 메모리 카드를 삽입합니다.
블랙박스의 렌즈가 밖을 향하도록
부착합니다.
본체 후면 시가잭 소켓에 그림과 같은
방향으로 전원단자를 연결하세요.
차량에 시가잭을 연결 후 운전자의 조작에
방해되지 않도록 외곽으로 선을 정리합니다.
전·후방 카메라 소켓에 각 단자를
삽입하세요. 후방 카메라를 자동차 뒷면
유리에 렌즈가 바깥을 향하도록 부착합니다.
차량 시동 후 LED점등을 확인합니다.
LED가 점등되면 제품이 정상 작동합니다.
거치대 양면 테이프의
비닐을 제거합니다.
1 2
45
67
후방 카메라 케이블
전방 카메라 케이블
전방 카메라 케이블후방 카메라 케이블
3
녹색 LED 점등 확인
2
전방 카메라
룸 미러
본체 옆면 메모리 카드 슬롯에 그림과 같은
방향으로 메모리 카드를 삽입합니다.
거치대 양면 테이프의
비닐을 제거합니다.
1 2
CHANUN ACE
전방: HD image sensor / 렌즈 화각: 121°(대각기준)
후방: HD image sensor / 렌즈 화각: 121°(대각기준)
전, 후방: 30fps 녹화 (Max)
전방: HD (1280 x 720)
후방: HD (1280 x 720)
Micro-SD 메모리 (16GB / 32GB / 64GB)
상시녹화
이벤트녹화
수동녹화
주차녹화 (단, 별매품인 차눈파워 사용시 가능)
USB type 와이파이 동글 지원
Mobile App (Android / iOS)
전방(HD), 후방(HD) 2채널 streaming
3축 가속도 센서 (3D)
외장형 GPS 지원
입력전원: DC 10 ~ DC 36V
소비전력: 5W
슈퍼 캡 지원
Micro SD slot / GPS input port / USB port
비디오: AVI
오디오: PCM
모델명
카메라
해상도
저장
녹화
네트워크
실시간 녹화
G Sensor
GPS
전원
인터페이스
비디오 & 오디오
기타
음성안내 지원, Mic내장
Security / Status LED
동작온도: -20℃ ~ 75℃
보관온도: -40℃ ~ 85℃
Please download for product manual and viewer program from our webpage.
www.camsolution.co.kr
Quick manual
QuickManual
제품 상세 매뉴얼 및 전용뷰어 프로그램은 당사 홈페이지에서 다운로드 받으시기 바랍니다.
www.camsolution.co.kr
CHANUN ACE
Front : HD sensor / Lens angle of view: 121˚(Diagonal)
Rear : HD sensor / Lens angle of view: 121˚(Diagonal)
Front / Rear : 30fps recording
Front : HD (1280 x 720)
Rear : HD (1280 x 720)
Micro SD (16GB / 32GB / 64GB)
Normal
Event
Manual
Park record (It can be supported by Chanun power of optional purchase)
WiFi module: USB dongle (optional)
Mobile App (Android / iOS)
Front (HD) / Rear (HD) 2channel streaming
3D G-sensor (3D)
External GPS (Optional)
Input: DC 10 ~ 36V
Model name
Camera
Resolution
Storage
Recording
Network
Streaming
G Sensor
GPS
Cautions when installing the product
Please follow the below steps.
Please note that if the product is
attached on hot-wire, it might damage
the hot-wire, when removing the
product later. When using double-stick
tape, clean the surface with dry cloth
before putting the tape.
스마트폰 앱 사용
1. 스마트폰 앱 설치
APP Store에서“차눈”또는“chanun ACE”로
검색한 후 스마트기기 앱을 다운로드 받습니다.
Keyword:chanunACE
3. 메뉴별 기능설명
1)주행영상 : 블랙박스 촬영 영상을 실시간 재생
2)블랙박스영상 : 블랙박스에 저장된 영상 재생/다운로드
3)휴대기기영상 : 블랙박스에서 핸드폰으로 다운로드 받은
영상을 재생 및 삭제
4)설정 : 블랙박스 설정을 변경
2. 프로그램 실행
다운로드 받은 앱을
실행합니다. 약 5~10초후
블랙박스와 연결됩니다.
4. 실시간 영상
라이브 뷰 화면은 블랙박스에서 카메라를 통해
입력되는 영상을 실시간으로 핸드폰의 화면으로
보여주는 기능입니다. (Front / Rear Camera)
6. 휴대기기 영상
다운로드 받은 영상을 재생 및
삭제하는 기능.
5. 블랙박스 영상
원하는 파일을 클릭하면 영상을
바로 재생 및 저장을 할 수 있습니다.
6. 세팅
- Reset WiFi : 현재 접속된 블랙박스의
WiFi 정보를 삭제
- Factory default : 블랙박스의 설정정보를
공장 초기화 모드로 변경
- SD Format : 블랙박스의 SD카드를 포맷
- Apply : 변경된 설정정보 적용
- Cancel : 설정변경 취소
초기 패스워드: sscw4321
※APP 권장사항
- 안드로이드 APP은 Android 4.0 이상 사용을 권장합니다.
- IOS는 아이폰 5 이상 사용을 권장합니다.
블랙박스의 Firm Ware 버전
영상 저장시 음성 저장여부 설정
영상의 화질을 설정
입력 영상의 상하반전을 설정
영상 녹화 시간을 설정
충격 센서의 민감도를 설정
움직임 감지 기능 사용여부를 설정
SD 카드의 포맷 주기를 설정
블랙박스의 시간 설정
Version
Audio
Quality
Mirror Mode
Record time
Sensitivity
Motion
SD Format
Set Time
스마트폰 앱 사용
1. 스마트폰 앱 설치
APP Store에서“차눈”또는“chanun ACE”로
검색한 후 스마트기기 앱을 다운로드 받습니다.
Keyword:chanunACE
3. 메뉴별 기능설명
1)주행영상 : 블랙박스 촬영 영상을 실시간 재생
2)블랙박스영상 : 블랙박스에 저장된 영상 재생/다운로드
3)휴대기기영상 : 블랙박스에서 핸드폰으로 다운로드 받은
영상을 재생 및 삭제
4)설정 : 블랙박스 설정을 변경
2. 프로그램 실행
다운로드 받은 앱을
실행합니다. 약 5~10초후
블랙박스와 연결됩니다.
4. 실시간 영상
라이브 뷰 화면은 블랙박스에서 카메라를 통해
입력되는 영상을 실시간으로 핸드폰의 화면으로
보여주는 기능입니다. (Front / Rear Camera)
6. 휴대기기 영상
다운로드 받은 영상을 재생 및
삭제하는 기능.
5. 블랙박스 영상
원하는 파일을 클릭하면 영상을
바로 재생 및 저장을 할 수 있습니다.

11 Chanun Ace User’s Guide
Functional Overview
Camera lens
Cradle
Security LED Event LED
Main body MIC
GPS LED
Event LED
Event button
>>Front view camera >>Rear view camera >>Top side of main body
>>Sides of Main body
Format
Main body loudspeaker
Power
Rear view camera port
Front view camera port
MIC/Mute
Speaker/Mute
Event
USB (WiFi dongle)
SD card slot
Power switch
GPS port
TV Out terminal

12 Chanun Ace User’s Guide
Installation
Safety precautions for installation
Rear view mirror
Front view camera
Insertion of memory card
1
Removal of double-sided tape
Remove the tape liner of the double-sided tape for cradle.
2Attachment on the windshield
3
Insert a memory card into the card slot in the direction as
shown in the figure.
Refer to the following figure when you install this product.
Mounting of the cradle on heating wire may cause damage to the wire
during later disassembly, to which you need to pay attention.
Be sure to wipe foreign matter or dust cleanly off the area where the
product is attached with double-sided tape.
Attach the black box in such a manner that its lens faces
outwards.

12 Chanun Ace User’s Guide
Connection of power cable
45Connection of cigar jack
Connection between front/rear view cameras
6
Rear view camera cable
Front view camera
Front camera cable Rear camera cable
Power Switch Operation Check
7
When the lamp is lighted,
the product operates normally.
Checking
of installation
Connect the power cable to the cigar jack socket on the back of the
main body as shown in the figure.
* Note: Be sure to use the cigar jack provided by us.
Plug the cables in to the front/rear view camera terminals respec-
tively as shown in the figure. Attach the rear view camera on the
back window with its lens facing outwards.
Keep the cable in such a manner that it does not get in the way of
the driver and passengers on the back seat.
Check if the LED lamp comes on after you start the engine.
The installation is completed when you start the engine and see the lamp of the
main body come on; otherwise, check if each connection is securely connected and
clear dust or foreign matter off the cigar socket.
Connect the cord to the vehicle’s cigar jack and keep the cable at the
perimeter so that the line does not get in the way of the driver’s driving
operations.

13
Chanun Ace User’s Guide
Download the latest version of Chanun ACE Program.
※ File location: www.camsolution.co.kr > SUPPORT > DOWNLOAD
The recorded video files are stored in the SD memory card in MP4 format, which can be played in normal video players
(such as Gom Player) that support MP4 files. However, in order to make best use of various optimized additional functions,
file management, and configuration in addition to basic image playback, you are recommended to install the Player provided by us.
Installing the Player
1. Executing installation files
Unzip the downloaded files and double click to start installation.
2. Install (Compatible OS: Window XP, 7, 8, 8.1)
6
6
6
6
6
6
6
6
6
6

13
Chanun Ace User’s Guide
Select the path for saving the Player and click the Next button to continue installation.
Installing the Player
3. Specify the location for installation.
The installation is completed. Click the Finish button to bring the installation to an end.
4. Installation completed
2016-05-12 12:00:00

14
Chanun Ace User’s Guide
File Open, Setting, Image adjustment,
Image capture, Viewer information,
Accident report button
Menu organization of the Player
1. Program Menu
- Switching to Viewer in Korean,
English, Japanese
2. Menu by Language
Displaying front video files
3. Playback of Front View Camera Files
Displaying rear video files
4. Playback of Rear View Camera Files
Displaying the G-Sensor’s variation values
5. Accelerometer Sensor Graph
Displaying the vehicle’s speed
6. Speed window
Button for displaying frames on the screen
7. Frame button
Previous image, Fast backward/ half speed,
Play, Stop, Double/quadruple speed, Next image
8. Video control button
Control the volume of the sound of
a file being played.
9. Volume control
Display the list of files stored in
a memory card.
10. Video file list
11. Map
- Arrange recorded files in the order
of Normal, Event, and Manual recordings.
12. Arrangement of video files
1
3
4
5 6
7 8
2
9
10 11
12
The installation is completed if the power lamp of the main body come on when you start engine. Otherwise,
check if each connection is securely connected and clear dust or foreign matter off the cigar socket.
Reference
■ It may cause abnormal operation when strong noise occurs from external.
■ The function which make product stop upon the high temperature (over 75℃) for safety recording and
protecting product is being adapted. If the product operating temperature reachs so high that can not work
normally, then product will be stop automatically. If the surrounding temperature falls and product operating
temperature falls under certain temperature, product will be operated again normally.
Reference
■ Y
ou can always download it from CAMSOLUTION homepage.
(www.camsolution.co.kr)
■ Using authorized SD card is recommended. If not available, use SDHC product above Class10.
Serious defectiveness on electric system of the car.
Shorten the lifetime of electric generator on the car.
Car fire caused by overheat and short circuit of wires and battery.
Product name
Model name
Purchased date
Purchased place
Serial No.
Purchased Price
전·후방 카메라 소켓에 각 단자를
삽입하세요. 후방 카메라를 자동차 뒷면
유리에 렌즈가 바깥을 향하도록 부착합니다.
차량 시동 후 LED점등을 확인합니다.
LED가 점등되면 제품이 정상 작동합니다.
6
6
6
6
6
6
6
6
6
6

15
Chanun Ace User’s Guide
File: To retrieve video files from the SD memory card
Using the Player
Image adjustment:
To control brightness/contrast. Viewer Language
[Korea]
[English]
[Japaness]
Image capture: To capture images on the Player.
Accident report: To prepare an accident report
(in case of an accident)
Setting: To set configuration for the Player
dedicated for Chanun Ace
2016
2016
2016
2016
2016
2016
2016
2016
2016
2016
2016
2016
2016-05-12 12:00:00
2016-05-20 22:21:48 2016-10-14 10:05:17

15
Chanun Ace User’s Guide
Separate the SD memory card from the black box, insert it into the SD memory card reader, as shown
in the figure, and connect it to a USB port of your computer.
※ Check with the card for its front and rear sides and insert the card in the arrow direction.
※ Use only the genuine card that is provided by us.
There may be a risk of loss of your data in the event the micro SD card being used is not a genuine one.
⇨ You are advised to format your SD card periodically (twice a week).
⇨ The service life of a micro SD card is 6 month.
Our company is not responsible, in any event, for the data saved in your micro SD card (including loss of data).
Using the Player
1. Connecting the memory card to a computer
Double click the Player icon found on your desktop to execute the Player on your computer.
2. Clicking the Player icon on your desktop
The Player screen appears on your computer.
※ This product is designed to reproduce images in HD so they may not achieve smooth playback
on a low specification computer.
When you have difficulty in realizing a desired reproduction, you need to upgrade your computer
or use another computer to view video files.
3. Running the Player
6
6
6
6
6

15
Chanun Ace User’s Guide
Check if the SD memory card is connected to your computer and click the OK button.
※ When you click the Cancel button, you can open recorded video files by clicking the
File menu at the top left side of the Player.
4. Retrieving video files
Select the SD memory card drive, choose the Recording folder, and click the OK button.
5. Selecting the drive for the SD memory card
When the recorded file list is displayed on the File List window on your right, double-click
your desired file to start playing it.
※ You can double click another file to run on the screen while you watch one.
※ You can click the List menu to have the recorded files arranged in order.
They can be arranged in 3 types by their recording statuses (Types of status: Normal,
Event, Manual, and Parking)
They can be arranged in ascending order by date and time.
6. Checking the file list
Using the Player
Information
OK Cancel
6
6
6
6
6

15 Chanun Ace User’s Guide
This graph displays the intensity of front/rear, vertical, and horizontal impacts imposed on the vehicle at
the time of occurrence of an event.
※ This 3-axis G-sensor is for detection of impacts and may not sense minor vibrations; therefore,
it cannot be utilized as circumferential evidence of the accident.
7. 3-Axis G-Sensor Graph
This window displays changes in the vehicle’s travel speed in numbers through the GPS information
received at the time of the recording.
8. Speed
The location of the vehicle can be displayed on the map real time in combination with the Google Map service.
This service is available only when GPS signals are properly received during driving and you computer
must be linked to the Internet.
(GPS connection may be unstable in such areas as signals from the GPS are weak as downtown with
many high-rises and in tunnels.)
9. Map display
Using the Player
