Cozy N Safe FUJI EST-508 User manual

E C E R 1 6 N o 4 4 . 0 4
I N S T R U C T I O N M A N U A L
E S T - 5 0 8
G r o u p 1 / 2 / 3
9 k g t o 3 6 k g
( A p p r o x i m a t e l y 1 y e a r - 1 1 y e a r s )
C S
COZY N SAFE R
F U J I

2
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
Thank you for choosing our Child Car Seat
model EST-508 to protect your child
NOTICE!
1. This is a “Universal” child restraint, it is approved
to Regulaon NO.44.04 series of amendments, for
general use in vehilcles and it will fit most, but not all,
car seats.
2. A correct fit is likely if the vehicle manufacturer has
declared in the vehicle handbook that the vehicle is
capable of accepng a “Universal” child restraint for
this age group.
3. This child restraint has been classified as “Universal”

3
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
Under more stringent condions than those which
applied to earlier designs which do not carry this noce.
4. If in doubt, consult either the child restraint
manufacturer or the retailer.
Only suitable if the vehicle is fied with 3-point safety
belts, Approved to UN/ECE Regulaon No.16 or other
equivalent standards.
EXTREME HAZARD
Do not use in passenger seats equipped with airbags(SRS)

4
C S
COZY N SAFE R
S A F E T Y
W A R N I N G S

5
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
Do not install or use this child restraint unl you
carefully read the installaon instrucons provided by the
child restraint manufacturer.
This child restraint is for forward facing use only.
Do not secure your child restraint in the front passenger
vehicle seang posion equipped with an airbag.
Please pay aenon to all the red markings / sckers or
red plasc parts on the seat, which are the belt routes
for installaon.

6
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
Any straps holding the restraint to vehicle should be
adjusted to the child’s body. Straps should not be
twisted.
Ensure that any lap strap is worn low down so that the
pelvis is firmly engaged.

7
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
The child restraint system should be changed when it
has been involved in any accident, there could be hidden
damages.
Do not make any alteraons or addions to the device
without the approval of the competent authority.
Any luggage or other subjects should be properly secured
or stored as they may cause injuries in the event of a
collision or sudden braking.
The child restraint must not be used without the cover.

8
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
The seat cover should not be replaced with any other
than the one recommended by the manufacturer as
restraint system performance.
for its life period.
Do not use any load bearing contact points other than
child restraint.
s

9
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
The rigid items and plasc parts of a child restraint must
be located aer reading this instrucon manual and
installed so that they are not liable during everyday use
of the vehicle by becoming trapped by a movable seat or in
a door of the vehicle.

10
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
P A R T S
Slot
Buckle
Harness adjuster lever
Harness adjuster strap
Headrest
Backrest
Harness
Chest pad
Comfort pad
Seat cushion

11
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
P A R T S
Diagonal belt hook
Seats belt route slots
Red buon
(adjust the headrest height)
Belt lock
(only used 15-36kg)
Diagonal belt hook
Seats belt route slots
Harness straps
Harness connector

12
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
Safety Instrucon
Only suitable if the
approved vehicles are
fied with 3 point
safety-belts, approved
to UN/ECE Regulaon
No.16 or other
equivalent standards.

13
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
CORRECT SHOULDER STRAPS HEIGHT
Always check that the
shoulder straps are at
the correct height for
your child. The child's
shoulders should always
be below the slot for the
harness.

14
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
CHANGING THE SHOULDER STRAP HEIGHT

15
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
CHANGING THE SHOULDER STRAP HEIGHT
Firstly release the strap holding the backrest cover on to
gain access to the harness. Slide one of the harness
straps off the harness connector.
Then from the front of the seat, pull the harness
through the slot in the backrest and fabric cover. Thread
the harness strap back through the next hole up or down
on the seat backrest.

16
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
CHANGING THE SHOULDER STRAP HEIGHT
Re-thread the harness strap back onto the harness
connector at the back of the seat.
Repeat the same process for the other harness strap.
Make sure both of he straps go through slots at the
same height.

17
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
REMOVING THE SAFETY HARNESS SHOULDER STRAPS

18
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
REMOVING THE SAFETY HARNESS SHOULDER STRAPS
Release the strap at the boom of the backrest cover
to gain access to the harness.
Slide both of the harness straps off the harness
connector at the back of the backrest and pull the
webbing through the slots in the seat backrest and
fabric cover.

19
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
REMOVING THE SAFETY HARNESS LAP STRAPS
Turn the webbing retainers on their narrowest end and
feed them though the slots in the base of the seat and
then through the slots in the fabric cover.

20
E S T - 5 0 8 C a r S e a t
C S
COZY N SAFE R
FASTENING THE SAFETY SEAT BUCKLE
Step 1. Slot the two metal secons
of the buckle connectors together.
Step 2. Slot the two buckle
connectors into the slot in the top
of the buckle unl they click into
place.
