Cozy N Safe ETNA i-Size User manual

40cm-150cm
Without Compromise...
EST- 839
InstructionManual
E T N A i-Size

CHILDINFORMATION
(KEEPWITH CA R SEAT AT ALL TIMES IN CASE OF EMERGENCY)
NAME:
..................................................................................................................................................
DATE OF BIRTH (DD/MM/YYYY) :
..................................................................................................................................................
ADDRESS:
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
ALLERGIES/MEDICAL CONDITIONS:
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
EMERGENCYCONTACT 1:
NAME:
..................................................................................................................................................
PHONE NUMBE R:
..................................................................................................................................................
EMERGENCYCONTACT 2:
NAME:
..................................................................................................................................................
PHONE NUMBE R:
..................................................................................................................................................
www.cozynsafe.com
Without Compromise...
Cozy N Safe
Oxford Street, Wolverhampton, West Midlands, WV14 7DP, UK
Tel: [phone] |Email: [e-mail]
E T N A i-Size

USER'S MANUAL
We are honored that our child safety seat can accompany your child safely
through a new stage of life. To ensure your child's safety, please install and use
this child safety seat correctly as described in this manual. Please feel free to
contact us if you have any questions about use.
2
4
5
7
7
10
13
15
18
19
19
20
22
23
23
23
24
25
Content
1.Warningt
2.Components overview
3.Precautions for vehicle use
4.Child car seat installation
4-1Rearward facing 40-105cm
4-2Forward facing 76-105cm
4-3Forward facing 100-150cm ISOFIX + Adult safety belt
4-4 Forward facing 100-150cm Adult safety belt only
4-5Self 5 point seat belt fixation and removal
4-6Removal of ISOFIX and top tether
5.Adjustment of child car seat
5-1Adjust 5-point harness
5-2Adjust car seat angle
5-3Adjust headrest height
5-4Adjust buckle
5-5Use of cushion
6.Remove/Install car seat cover
7.Car seat Preservation
8.Matters need attention

1
Safety instructions
1. Please read this manual carefully, otherwise improper installation will lead to serious
injury.In this case, the manufacturer will not be held liable
2.This ECRS is suitable for children of 40-150cm height.�
3. For use with Vehicle seat belts, only apply if the applicable model is equipped with
3-point belt with retractor as required by ECE R129
4.(a) Child restraint systems shall not be used without Seat covers. �
(b) System coverings shall not be made of materials other than those recommended by
the manufacturer, which affect the overall integrity of the child restraint system �
5. If the surface covering of the child restraint system is not a fabric, it should be
prompted to keep out of the sun, otherwise the seat surface can burn the child. �
6. Restraint system should be replaced after accident. �
7. Luggage and articles that may cause injury in a collision should be properly placed. �
8. Ensure that the seat belt latch is locked properly and that the child can be quickly
released in case of an emergency. �
9. The rigid and plastic parts of the child restraint system should be properly placed and
installed so that during normal use of the vehicle, the child restraint system does not get
stuck by the movable seats or doors in the car.
10. Secure the child restraint system properly even if no child is sitting on it.��
11. Children's restraint system should be kept away from corrosive objects.
12. Each webbing connected to the vehicle in the child restraint system should be tied
tightly. The webbing used to restrain the child should be adjusted according to the child's
body, and the webbing should not be twisted.
13. The instructions can be clearly seen during the service life cycle (please store the
instructions in the seat for special storage after use). �
14.The manufacturer guarantees the quality of the products, except second-hand
products. �
15. If you have any questions about the use and installation of child seats, please contact
our service hotline. �

2
Warning: �
1.As an important part of the child restraint system to protect the safety of children,
the belt should ensure that it can well restrain the pelvic region when worn (see the
installation instructions on the following page). �
2. For ISOFIX type child restraint systems, the user must read the description of
ISOFIX fixing points in the automobile manufacturer's manual �
3. Uncertified products and modified products are dangerous, and there are no
installation instructions provided by the manufacturer nearb is also dangerous. �
4. Do not use any stress points other than those described in the documentation
and identified on the child restraint system.�
5. Do not leave children unattended in a child restraint system. �
6. Under no circumstances should a child restraint system be used in a car seat
with airbag enabled. �
7. Children sometimes carry objects (such as toys) in their clothes or trouser
pockets, or wear hard objects (such as buckles). Make sure these objects do not
get between the child and the seat belt, as they may cause unnecessary injury in
an accident.��This can happen to adult as well. �
8. Children are naturally active, so you should patiently explain the importance of
using a child restraint system. You must make it clear to your child that the seat
belt should not be touched or the buckle should not be opened.
9. The seat must be as close to/against the back of the vehicle seat as possible. �





















3
01
03
04
05
06
07
08
09
12
11
10
02
14
15
16
17
13
20
21
19
18
01 headrest adjusting
handle
02 shoulder strap
guide hook
03 head restraint
04 shoulder sheath
05 inner liner
06 shoulder strap
07 snap
08 snap pad
09 quick adjustment
button
10 adjusting belt
11 angle adjustment
handle
12 rotary adjustment
handle
13 belt guide groove
14 ISOFIX (m-fix)
secondary lock
15 ISOFIX (m-fix)
release button
16 ISOFIX(m-fix)
17 ISOFIX (m-fix)
plug-in guide sleeve
18 pressure band hook
19upper strap adjuster
20 pull up strap
21 upper strap hook
2. Components of
safety seat: �

4
3. Precautions for vehicle use
Warning: under no circumstances should the child restraint
system be used on the car seat with airbag enabled.
!
correct installation /Applicable
Wrong installation/Not Applicable
Vehicle seat belt -Shoulder belt
Vehicle seat belt-Lap Belt
1
21
2
?1
?1
Allowed to Install The seat may not be installed in the area
of effect of an airbag
Not allowed to Install
The picture shows the incorrect posi-
tion of the buckle of the adult seat belt
relative to the main stress point of the
child restraint system.��If users have
any questions about this, they are
advised to contact the manufacturer of
the child restraint system. �

5
3. Precautions for vehicle use
Before using ISOFIX and TT straps, check whether the car seat is equipped with
ISOFIX fixed anchor points and whether the size category matches. The car seat is
equipped with ISOFIX fixed anchor points and ISOFIX size category match before
using. �
First read the car instructions and check whether the car seat is equipped with
ISOFIX fixed anchor points and their recommended ISOFIX constraints �
System match or ISOFIX size and type or not
Top tether
Vehcile up
anchor point
ISOFIX
Vehcile below
anchor point

6
4.Baby car seat installation
4-1 Rearward facing 40-105cm
ISOFIX +Top tether + Harness
1. Hold the Angle and rotate the adjusting handle 11, then rotate the seat to the
car's �Rear, the child seat is in reverse mode, facing back. �
2. Pull the seat Angle and rotate the adjusting handle 11 to adjust the seat to
Max.inclined position.
1. If your car is not equipped with ISOFIX plug-in
guide sleeve 19, please use the two ISOFIX
plug-in guide sleeve 19 equipped with this seat to
clip the ISOFIX fixed point J of the car with the
notch facing upwards (as shown in the picture).
Notice
1. When the child seat is installed Rearwards: it
has only one gear that can be adjusted.�
2. The child seat can be rotated directly when it is
in the forward/rearward position. �
!
About
Birth- 3 yeas
ISOFIX install in the vehecile seat

7
5. Shake the child seat to ensure ISOFIX18 is securely fixed
Click
2. Hold down ISOFIX lock button 16 and ISOFIX lock release button 17, and pull
ISOFIX18 to the end position �
3. The left and right ISOFIX18 buckle to the ISOFIX fixed point J of the car, hear the
"click" sound, ISOFIX left and right sides,It shows "green", which means it is closed. �
4. Push the seat inward so that the back of the child seat is against the back of the
car �
1. Untie the top bristle K, and then press
the button to adjust the top Tether 14 to
adjust the top tether 13.
Reminder
!
Top Tether installation
1. Before a child uses a child safety seat, ensure that
the ISOFIX Settings on the left and right are consistent

8
2. Pull Top Tether 13 through car
headrest. �
3. Hook the top tether hook 15 to
the fixed point of the car seat
according to the car manual, and
tighten the top tether 13(when it is
tightened, the button will display
"green"�
4. Place the child in the car seat
and use the five-point fixed(5
point belt refer to 4-4)
Reminder
Never use a luggage hook
instead of a top tether strap ,
Check your car for signs like
this:
!
Notice
1.The 5-point seat belt should not be twisted or wound to ensure
that the child is firmly secured. �
2. When the top tether is tightened, the adjust button of it is
displayed in green. �
3. TheTop tether must pass through the top tether guide.�
4. The seat must be as close to (against) the back of the vehicle
seat as possible. �
!
Reminder
1. The child restraint system
cannot be installed in the effect
of airbag
2.Do not use forward facing
before the child's ageexceeds 15
months
!

9
180°
4-2 Forward facing
76-105cm
ISOFIX+ Top tether+ Harness
1. Hold the Angle and rotate the adjusting handle 11, then rotate the seat to the car's �
Forward, the child seat is in forward mode, facing forward. �
2. Pull the seat Angle and rotate the adjusting handle 11 to adjust the seat to �Most
suitable position, total 5gears .��(Adjustable back and forth to the most suitable
Angle) �
1. If your car does not come standard with ISOFIX
plug-in guide sleeve 19, please useThis seat
equipped two ISOFIX plug-in guide sleeves 19
clipped on the car �On the ISOFIX fixed point J,
the notch faces upward (as shown in the pic).
Notice
1. When the child seat is installed in the forward
direction: the child seat has 5 gears to adjust. �
2. The child seat can be rotated directly when it is in
the forward/rearward position.
!
About 18 months
to 3 years
ISOFIX Installed in the car seat

10
5. Shake the child seat to ensure ISOFIX18 is securely fixed.
Click
2 Hold down ISOFIX double lock button 16 and ISOFIX release button 17 at the
same time, and pull ISOFIX18 backward to the final position. �
3. The left and right ISOFIX18 buckle to the ISOFIX fixed point J of the car, hear the
"click" sound, ISOFIX on both sides,If it shows "green", it means it is closed. �
4. Push the seat inward so that the back of the child seat is against the back of the
car. �
1. Untie the top bristle K, and
then press the button 14 to
adjust the top tether 13
Reminder�
!
Top Tether installation
1. Child in front of a car seat.��Ensure that both sides
ISOFIX taps are consistent. �

11
Reminder
Never use a luggage hook
instead of a top tether strap ,
Check your car for signs like
this:
!
Notice
1.The 5-point seat belt should not be twisted or wound to
ensure that the child is firmly secured. �
2. When the top tether is tightened, the adjust button of it is
displayed in green. �
3. TheTop tether must pass under the headrest of the vehicle
seat. �
4. The seat must be as close to (against) the back of the
vehicle seat as possible. �
!
2. Pull belt 13 through car headrest. �
3. Hook the top tether hook 15 to the fixed point of the car seat according to the car
manual, and tighten the top tether 13(when the pull-up belt �adjust button 14 show
"green")
4. Place the child in the car seat and secure the child with a 5-point seat belt (see
4-4 for 5-point seat belt fixation). �

12
4-3 Forward facing
100-150cm
lSOFIX +Adult safety belt
About
3-12 years
1. If your car is not equipped with the standard
lSOFIX plug-in guide sleeve 19, please use the
two lSOFIX plug-in guide sleeve 19 equipped
with this seat to clip the ISOFIX fixed point J of
the car with the cut facing upwards (as shown
in the picture). �
2. Hold lSOFIX double lock button 16
and lSOFIX release lock button 17 at
the same time, and pull lSOFIX 18 to
the end.
lSOFIXinto car seat
Angle adjustment
Pull the Angle of the seat and
rotate the adjusting handle 11 to
adjust the seat to the upright
position.
Hide your own 5-point safety belt when using vehicle safety belt (see 4-4 for details) �

13
1. Place the child in the child car seat
2. Pass the Vehicle seat belt S through
the strap guide hook and around the
child's shoulder. �
3. The car cut the belt belt T through
the lap belt guide12, and around the
child's pelvis. �
4. The shoulder belt S and the belly
side T pass through the plate belt on
the other side at the same time, leading
to the 12 well buckle the safety belt. �
Click
Vehicle seat belt fix the child car seat
Notice
Ensure that the left and right
lSOFIX gears are the same
before your child is in the car
seat.�
!
3. Buckle both sides M-FIT18 to the ISOFIX
fixed point J of the car, hear the sound of
"click", the both sides of ISOFIX above the
display of "green", indicating that the buckle. �
4. Push the seat inward so that the back of
the child seat is against the back of the car. �
5. Shake the child seat to ensure lSOFIX 18
is securely fixed

14
Angle adjustment
Pull the Angle of the seat and
rotate the adjusting handle 11 to
adjust the seat to the upright
position.
Hide your own 5-point safety belt when using vehicle safety belt (see 4-4 for details) �
Notice
1. Check and tighten the vehicle shoulder belt and lap belt to
ensure that the seat and children are firmly fixed. �
2. The shoulder strap and lap belt of the vehicle safety belt should
not be twisted or wound. �
3. The seat must be as close to (against) the back of the vehicle
seat as possible. �
!
4-4 Forward facing 100-150cm
Adult safety belt only

15
Notice
1. Check and tighten the vehicle shoulder belt and lap belt to
ensure that the seat and children are firmly fixed. �
2. The shoulder strap and lap belt of the vehicle safety belt
should not be twisted or wound. �
3. The seat must be as close to (against) the back of the
vehicle seat as possible. �
!
1. Place the child in the child car seat
2. Pass the Vehicle seat belt S through
the strap guide hook and around the
child's shoulder. �
3. The car cut the belt belt T through
the lap belt guide12, and around the
child's pelvis. �
4. The shoulder belt S and the belly
side T pass through the plate belt on
the other side at the same time, leading
to the 12 well buckle the safety belt. �
Vehicle seat belt fix the child car seat

16
Press ISOFIX release button 17 and
ISOFIX double lock button 16 at the
same time and hear the "click" to
remove ISOFIX18 from the car seat. �
4-5 Remove ISOFIX and top tether
Press the adjustable button 14 of
top tether first to loosen the top
tether 13, and then remove the
pull-up belt 15 from the fixed pot
point of the car, and move the top
tether back�
Top Tether dismount
ISOFIX removing car seat

17
Loosen: press the quick regulator button 9 at the front with one hand,
grab the two shoulder straps 6 with one hand (do not pull shoulder
jacket 4), and pull them towards the front of the seat. �
5.Adjustment of child car seat
5-1 5 point belt adjustment
Tighten: hold the adjusting belt 10 and slowly pull it
forward. When two adult fingers can be accommo-
dated between the shoulder strap protector 4 and
the child, release the adjusting belt. At this time, the
tightness of the shoulder belt is the most suitable. �
reminder
When the shoulder strap
passes through the seat
strap hole, it should be
parallel to or slightly higher
than your child's shoulder
height.
!
