Indico 100 Series Service Manual Ch # 740895-00 Rev. A Page 0-1
PRE-INSTALLATION
1¾
SERVICE
AND
INSTALLATION AND CALIBRATION
2¾
INSTALLATION
MANUAL
CONFIGURATION PROGRAMMING
3¾
P.N. #740855
ACCEPTANCE TEST
4¾
TROUBLESHOOTING
5¾
REGULAR MAINTENANCE
6¾
THEORY OF OPERATION
7¾
SPARES
8¾
SCHEMATICS
9¾
The original version of this manual (Aug.21,1997)
has been drafted in the English language by:
Communications & Power Industries
communications & medical products division.

CPI Canada Inc.
Page 0-2 Rev. A Indico 100 Series Service Manual Ch # 740895-00
(This page intentionally left blank)

CPI Canada Inc Pre-installation 1
Indico 100 Series Service Manual Ch # 740895-01 Rev. A Page 1-1
CHAPTER 1
PRE-INSTALLATION
1.0 INTRODUCTION
1.1 Purpose
This manual applies to the Indico 100 family of generators and provides instructions for the installation and
maintenance of all models of that generator.
This Chapter contains the following sections.
SECTION TITLE
1A Introduction
1B Safety
1C Preparing for installation
1D Compatibility listing
1E Generator layout and Major Components

1 Pre-installation CPI Canada Inc
Page 1-2 Rev. A Indico 100 Series Service Manual Ch # 740895-01
(This page intentionally left blank.)

CPI Canada Inc. Introduction 1A
Millenia / Indico 100 Series Service Manual Ch # 740904-00 Rev. E Page 1A-1
CHAPTER 1 SECTION 1A
INTRODUCTION
CONTENTS:
Section Title
1A.1.0 INTRODUCTION.......................................................................................................................................1A-1
1A.1.1 Purpose..................................................................................................................................................1A-1
1A.2.0 GENERATOR DESCRIPTION..................................................................................................................1A-1
1A.3.0 PHYSICAL SPECIFICATIONS..................................................................................................................1A-2
1A.4.0 APPLICATIONS ........................................................................................................................................1A-4
1A.5.0 FEATURES ...............................................................................................................................................1A-4
1A.6.0 ROTOR CONTROL...................................................................................................................................1A-5
1A.7.0 AUXILIARY POWER OUTPUTS...............................................................................................................1A-5
1A.8.0 SYSTEM DOCUMENTATION...................................................................................................................1A-5
1A.9.0 REGULATORIES AND DESIGN STANDARDS........................................................................................1A-6
1A.9.1 Environmental Specifications.................................................................................................................1A-6
1A.9.2 Applicable Standards.............................................................................................................................1A-6
1A.9.3 Electromagnetic Compatibility (EMC)....................................................................................................1A-7
1A.10.0 TECHNIQUE FACTORS DEFINITIONS ................................................................................................1A-7
1A.1.0 INTRODUCTION
1A.1.1 Purpose
This manual describes the Millenia and Indico 100 family of 350, 650, 850, and 1050 X-ray generators. The
manual provides instructions for the installation and service of these generators.
1A.2.0 GENERATOR DESCRIPTION
Depending on configuration and options, the generator provides the power and interfacing to operate X-ray
tubes, buckys, rad tables, GI (gastro-intestinal) tables, remote R&F tables, tomographic devices, and digital
imaging systems. The generator consists of power supply and control systems housed in the upper and
lower cabinets, a control console, and an optional remote fluoro control along with the necessary
interconnecting cable(s).
Major items provided are:
• X-ray generator housed in upper and lower cabinets
• Control console
• Optional remote fluoro control
• Interconnecting cable(s)
• Operator's manual
• Service and installation manual.

1A Introduction CPI Canada Inc.
Page 1A-2 Rev. E Millenia / Indico 100 Series Service Manual Ch # 740904-00
1A.3.0 PHYSICAL SPECIFICATIONS
Figure 1A-1 shows the outline of the Millenia series X-ray generator, control console, and remote fluoro
control. Figure 1A-2 shows the Indico 100 series X-ray generator outline.
Figure 1A-1: Generator outline drawing (Millenia)

CPI Canada Inc. Introduction 1A
Millenia / Indico 100 Series Service Manual Ch # 740904-00 Rev. E Page 1A-3
1A.3.0 PHYSICAL SPECIFICATIONS (CONT)
Figure 1A-2 shows the outline of the Indico 100 series X-ray generator.
22 (559)
18 (457) 16 (406)
ALL DIMENSIONS ARE IN INCHES (MM)
FIGURE 1A-1 SHOWS THE OUTLINE
FOR THE 23 X 56 (CM) CONSOLE.
THIS FIGURE SHOWS THE OUTLINE
FOR THE 31 X 42 (CM) CONSOLE.
FRONT RIGHT SIDE REAR
ANCHORING PLATES
4 PLACES
TOP
18.2 (463)
11.8 (300)
36.8 (935)
21.8 (554)
36 (915)
48.7 (1237)
16.6 (422)
12.3 (313)
3.7 (94)
CONSOLE
Figure 1A-2: Generator outline drawing (Indico 100)

1A Introduction CPI Canada Inc.
Page 1A-4 Rev. E Millenia / Indico 100 Series Service Manual Ch # 740904-00
1A.4.0 APPLICATIONS
RAD SYSTEMS:
• Bucky table, table top and off-table radiography
• Vertical bucky/cassette radiography
• Conventional tomography
R&F SYSTEMS
• Fluoroscopic and spot film applications
• Tomography with conventional and/or remote R&F tables
• Optional digital compatible.
1A.5.0 FEATURES
• High frequency generator.
• One or two tube operation, Rad or Rad / Fluoro.
• Single or dual filament supplies.
• Low speed or dual speed X-ray tube stator supply.
• Optimal matching of X-ray tubes by PROMs.
• Repetitive self checks of generator functions, provides display of system faults and operating errors.
• Optional AEC, up to four inputs.
• Optional ABS with kVp or kVp/mA fluoro stabilizer.
• Optional remote fluoro control box for table top use or SFD mounting.
• X-ray Tube protection. The generator allows setting the following limits:
a) Maximum mA, adjustable for each focal spot.
b) Maximum kVp, adjustable for each X-ray tube.
c) Maximum kW, adjustable for each focal spot.
d) Maximum filament current limit, adjustable for large and small focal spots.
e) Anode heat warning and anode heat alarm levels.
• Calibration features :
a) Microprocessor design allows all calibration and programming to be performed via the Console.
b) mA calibration is automated.
• Messages and diagnostic information: For users and service personnel, the generator console
displays various messages indicating status or equipment problems. The user is prompted in case of
errors.
• Error log stores last 200 errors and associated generator settings.
• Service and diagnostic information available via a lap-top computer (optional).
• KVp range: Radiography 40 to 150 kVp.
Fluoroscopy 40 to 125 kVp.
• mA range: Radiography 10 to 320 mA (30 kW), 10 to 400 mA (37.5 kW), 10 to 630 mA (50
kW), 10 TO 800 mA (65 kW) and 10 to 1000 mA (80 kW).
Fluoroscopy 0.5 to 6.0 mA.
• mAs range: tube dependent, max 1000 mAs.
• Time range: Radiography 2.0 to 6300 ms.
Fluoroscopy 0 to 5 or 0 to 10 minutes.
Refer to product description (end of section 1D) for compatibility and features of this specific generator.

CPI Canada Inc. Introduction 1A
Millenia / Indico 100 Series Service Manual Ch # 740904-00 Rev. E Page 1A-5
1A.6.0 ROTOR CONTROL
The generator will be equipped with a low speed starter, or optional dual speed starter.
DUAL SPEED STARTER
Number of tubes permissible: Maximum of 32 tube types. Tube type is switch selectable
Current monitoring Both stator circuits
Dual speed starter output
frequency 50 or 60 Hz (low speed) 150 or 180 Hz (high speed).
(Independent of line frequency)
Braking Dynamic braking when in high speed rotation
Rotor boost time Determined by tube selection plus incremental boost time changes
from 100 to 700 msec.
Duty cycle Not to exceed 2 high speed starts per minute.
LOW SPEED STARTER
Current monitoring Both stator circuits
Duty cycle Not to exceed 5 consecutive boosts, followed by a minimum 10
second wait period.
1A.7.0 AUXILIARY POWER OUTPUTS
The generator supplies the following power outputs for X-ray room equipment:
• 24 VDC, 4 Amp.
• 120 VAC, 2.5 Amp.
• 240 VAC, 1.5 Amp.
2.5 AMPS IS AVAILABLE AT 120 VAC OR 1.5 AMPS IS AVAILABLE AT 240 VAC, BUT BOTH ARE NOT
AVAILABLE SIMULTANEOUSLY.
The above voltage sources are not compatible with:
• Collimator lamps (24 VDC 150 watts). These lamps exceed the 4 Amp rating of the 24 VDC supply.
• Fluorescent lamps. These have high starting currents and generate transients when the tube strikes.
• Some inductive loads may cause difficulties (some motors and solenoids).
1A.8.0 SYSTEM DOCUMENTATION
The Millenia and Indico 100 series of X-ray generators includes the following documentation:
• Operator’s manual.
• Service and installation manual.
• Insert and application notes as required.

1A Introduction CPI Canada Inc.
Page 1A-6 Rev. E Millenia / Indico 100 Series Service Manual Ch # 740904-00
1A.9.0 REGULATORIES AND DESIGN STANDARDS
1A.9.1 Environmental Specifications
OPERATING
Ambient temperature range 10 to 40 °C
Relative humidity 30 to 75%
Atmospheric pressure range 500 to 1060 hPa (375 to 795 mm Hg)
TRANSPORT AND STORAGE
Ambient temperature range -20 to 70 °C
Relative humidity 10 to 95%, including condensation
Atmospheric pressure range 500 to 1060 hPa (375 to 795 mm Hg)
1A.9.2 Applicable Standards
The Millenia / Indico 100 family of generators complies with the following regulatory requirements and design
standards:
• FDA Center for Devices & Radiological Health (CDRH) - 21 CFR title 21 subchapter J (USA).
• Radiation Emitting Devices Act - C34 (Canada).
• Medical Device Regulations (Canada).
• EC Directive 93/42/EEC concerning Medical Devices (European Community).
• IEC 601.1, IEC 601.2.7:1998, CSA 601.1, UL2601.1
-Type of protection against electric shock: Class I equipment.
-Degree of protection against electric shock: Not classified.
-Degree of protection against harmful ingress of water: Ordinary equipment.
-Mode of operation: Continuous operation with intermittent loading (standby - exposure).
-Equipment not suitable for use in presence of a FLAMMABLE ANESTHETIC MIXTURE WITH
AIR OR WITH OXYGEN OR NITROUS OXIDE.
• IEC 601.1.2
Immunity:
IEC1000-4-2 Electrostatic discharge
IEC1000-4-3 Radiated RF field
IEC1000-4-4 Electrical fast transient
IEC1000-4-5 Surge
IEC1000-4-6 Conducted RF immunity
IEC1000-4-8 Magnetic field immunity
IEC1000-4-11 Voltage dips, interrupts and variations
Emission:
EN55011 (CISPR Publications II Emission Standards, Group 1 Class A).

CPI Canada Inc. Introduction 1A
Millenia / Indico 100 Series Service Manual Ch # 740904-00 Rev. E Page 1A-7
1A.9.3 Electromagnetic Compatibility (EMC)
In accordance with the intended use, this X-ray generator complies with the European Council Directive
concerning Medical Devices. The CE marking affixed to this product signifies this. One of the harmonized
standards of this Directive defines the permitted levels of electromagnetic emission from this equipment
and its required immunity from the electromagnetic emissions of other devices.
It is not possible, however, to exclude with absolute certainty the possibility that other high frequency
electronic equipment, which is fully compliant to the EMC regulations, will not adversely affect the
operation of this generator. If the other equipment has a comparatively high level of transmission power
and is in close proximity to the generator, these EMC concerns (the risk of interference) may be more
pronounced. It is therefore recommended that the operation of equipment of this type such as mobile
telephones, cordless microphones and other similar mobile radio equipment be restricted from the vicinity
of this X-ray generator.
1A.10.0 TECHNIQUE FACTORS DEFINITIONS
• KV: KV peak after any initial kV overshoot.
• TIME: Time in milliseconds, (ms) that the high voltage (anode to cathode) is greater or equal
to 75% of the desired kV.
• mA: Average Tube Beam Current (in mA) during the exposure TIME.
• mAs: milliampere-seconds (mA x TIME).
Address any questions regarding X-ray generator operation to:
Mail: Customer Support Department
Communications and Power Industries Canada Inc.
45 River Drive
Georgetown, Ontario, Canada L7G 2J4
Telephone: [phone]
Fax: [phone]
Attention: Customer Support Department
E-mail: [e-mail]
Attention: Customer Support Department

1A Introduction CPI Canada Inc.
Page 1A-8 Rev. E Millenia / Indico 100 Series Service Manual Ch # 740904-00
(This page intentionally left blank)

CPI Canada Inc. Safety 1B
Millenia / Indico 100 Series Service Manual Ch # 740904-01 Rev. D Page 1B-1
CHAPTER 1 SECTION 1B
SAFETY
CONTENTS:
Section Title
1B.1.0 INTRODUCTION .....................................................................................................................................1B-1
1B.2.0 SAFETY AND WARNING SYMBOLS .....................................................................................................1B-2
1B.3.0 SAFETY NOTICES AND WARNINGS....................................................................................................1B-2
1B.4.0 SAFETY WARNING LABELS - INTRODUCTION...................................................................................1B-4
1B.4.1 Safety Warning Labels - Organization..................................................................................................1B-4
1B.5.0 SAFETY LABELS / NOTICES COMMON TO MILLENIA AND INDICO 100...........................................1B-5
1B.5.1 Caution HV Behind Cover Label ..........................................................................................................1B-5
1B.5.2 Weight Label ........................................................................................................................................1B-6
1B.5.3 DC Bus Label.......................................................................................................................................1B-6
1B.5.4 Console CPU Board / Console Board..................................................................................................1B-7
1B.5.5 Generator Interface Board....................................................................................................................1B-7
1B.5.6 Room Interface Board..........................................................................................................................1B-7
1B.5.7 AEC Board ...........................................................................................................................................1B-7
1B.5.8 Power Input Board................................................................................................................................1B-7
1B.5.9 Dual Speed Starter Board ....................................................................................................................1B-8
1B.6.0 SAFETY LABELS / NOTICES UNIQUE TO MILLENIA...........................................................................1B-8
1B.6.1 HT Tank - Transformer Terminals Label..............................................................................................1B-8
1B.6.2 Live Mains / Fuses / Ground Label.......................................................................................................1B-9
1B.6.3 Live Mains / Fuses Label......................................................................................................................1B-9
1B.6.4 Caution - Hazardous Voltages Label..................................................................................................1B-10
1B.6.5 Warning / Caution / Caution Label .....................................................................................................1B-11
1B.6.6 Tank Vent Label.................................................................................................................................1B-11
1B.6.7 mA Test Jacks Label..........................................................................................................................1B-12
1B.6.8 mA test Jacks.....................................................................................................................................1B-12
1B.6.9 F3 (Auxiliary Power Fuseblock) .........................................................................................................1B-12
1B.7.0 SAFETY LABELS / NOTICES UNIQUE TO INDICO 100......................................................................1B-12
1B.7.1 Caution HV Exposed Label................................................................................................................1B-12
1B.7.2 Caution HV Label...............................................................................................................................1B-13
1B.7.3 Danger HV Label................................................................................................................................1B-13
1B.7.4 High Voltage Warning Label...............................................................................................................1B-13
1B.7.5 HT Tank - Transformer Terminals......................................................................................................1B-14
1B.7.6 Danger High Tension .........................................................................................................................1B-14
1B.1.0 INTRODUCTION
This section contains important safety warnings and safety information required for installing and servicing
the generator.

1B Safety CPI Canada Inc.
Page 1B-2 Rev. D Millenia / Indico 100 Series Service Manual Ch # 740904-01
1B.2.0 SAFETY AND WARNING SYMBOLS
The following advisory symbols are used on the safety warning labels, and/or on circuit boards, and/or on
the operator console and the optional remote fluoro control.
High voltage symbol used to indicate the presence
of high voltage.
Warning symbol used to indicate a potential hazard
to operators, service personnel or to the equipment.
It indicates a requirement to refer to the
accompanying documentation for details.
Radiation exposure symbol used on operator
console. Lights to indicate that an exposure is in
progress. This is accompanied by an audible tone
from the console.
Fluoro radiation exposure symbol used on operator
console and on optional remote fluoro control unit.
Lights to indicate that a fluoro exposure is in
progress. This is accompanied by an audible tone
from the console.
WARNING THIS X-RAY UNIT MAY BE
DANGEROUS TO PATIENT AND
OPERATOR UNLESS SAFE
EXPOSURE FACTORS AND
OPERATING INSTRUCTIONS
ARE OBSERVED.
Radiation warning label on console, used in certain
jurisdictions.
Never allow unqualified personnel to operate the X-
ray generator.
1B.3.0 SAFETY NOTICES AND WARNINGS
WARNING: PROPER USE AND SAFE OPERATING PRACTICES WITH RESPECT TO X-RAY
GENERATORS ARE THE RESPONSIBILITY OF USERS OF SUCH GENERATORS. CPI
CANADA INC. PROVIDES INFORMATION ON ITS PRODUCTS AND ASSOCIATED
HAZARDS, BUT ASSUMES NO RESPONSIBILITIES FOR AFTER-SALE OPERATING AND
SAFETY PRACTICES.
THE MANUFACTURER ACCEPTS NO RESPONSIBILITY FOR ANY GENERATOR NOT
MAINTAINED OR SERVICED ACCORDING TO THIS SERVICE AND INSTALLATION
MANUAL, OR FOR ANY GENERATOR THAT HAS BEEN MODIFIED IN ANY WAY.
THE MANUFACTURER ALSO ASSUMES NO RESPONSIBILITY FOR X-RAY RADIATION
OVEREXPOSURE OF PATIENTS OR PERSONNEL RESULTING FROM POOR OPERATING
TECHNIQUES OR PROCEDURES.

CPI Canada Inc. Safety 1B
Millenia / Indico 100 Series Service Manual Ch # 740904-01 Rev. D Page 1B-3
SAFETY NOTICES AND WARNINGS (cont)
WARNING: THIS X-RAY UNIT MAY BE DANGEROUS TO PATIENT AND OPERATOR UNLESS SAFE
EXPOSURE FACTORS AND OPERATING INSTRUCTIONS ARE OBSERVED.
X-ray radiation exposure may be damaging to health, with some effects being cumulative and extending
over periods of many months or even years. Operators and service personnel should avoid any
exposure to the primary beam and take protective measures to safeguard against scatter radiation.
Scatter radiation is caused by any object in the path of the primary beam and may be of equal or less
intensity than the primary beam that exposes the film.
Do not connect unapproved equipment to the rear of the console. For the 23 X 56 (cm)
console, J5 is used for the interconnect cable to the generator main cabinet, J4 is not used, J2
is a serial port for use by an external computer, and J1 is for connection of an optional printer.
For the 31 X 42 (cm) console, J5 is used for the interconnect cable to the generator main
cabinet, J2 is a serial port for use by an external computer, and J13 is for connection of an
external hand switch and / or foot switch. INCORRECT CONNECTIONS OR USE OF
UNAPPROVED EQUIPMENT MAY RESULT IN INJURY OR EQUIPMENT DAMAGE.
CAUTION: DO NOT EXCEED THE TUBE MAXIMUM OPERATING LIMITS. INTENDED LIFE AND
RELIABILITY WILL NOT BE OBTAINED UNLESS GENERATORS ARE OPERATED WITHIN
PUBLISHED SPECIFICATIONS.
WARNING: HAZARDOUS VOLTAGES EXIST INSIDE THE GENERATOR WHENEVER THE MAIN POWER
DISCONNECT IS SWITCHED ON. THOSE AREAS INCLUDE THE MAIN FUSEHOLDER AND
ASSOCIATED CIRCUITS IN THE HV POWER SUPPLY, PORTIONS OF THE GENERATOR
INTERFACE BOARD ON THE UPPER DOOR OF THE GENERATOR, AND THE TERMINALS
ON THE LINE ADJUSTING TRANSFORMER IN THE LOWER GENERATOR CABINET IF
FITTED
THE CONSOLE ON/OFF SWITCH DOES NOT DISCONNECT THE MAIN POWER FROM THE
ABOVE AREAS INSIDE THE GENERATOR.
THE BUS CAPACITORS, LOCATED ON THE BASE OF THE POWER SUPPLY PRESENT A
SAFETY HAZARD FOR AT LEAST 5 MINUTES AFTER THE POWER HAS BEEN REMOVED
FROM THE UNIT. CHECK THAT THESE CAPACITORS ARE DISCHARGED BEFORE
SERVICING THE GENERATOR.
No practical design can incorporate complete protection for operators or service personnel who do not
take adequate safety precautions. Only authorized and properly trained service and operating
personnel should be allowed to work with this X-ray generator equipment. The appropriate
personnel must be made aware of the inherent dangers associated with the servicing of high voltage
equipment and the danger of excessive exposure to X-ray radiation during system operation.

1B Safety CPI Canada Inc.
Page 1B-4 Rev. D Millenia / Indico 100 Series Service Manual Ch # 740904-01
1B.4.0 SAFETY WARNING LABELS - INTRODUCTION
NOTE: THESE LABELS AND WARNINGS ARE LOCATED TO ALERT SERVICE PERSONNEL THAT
SERIOUS INJURY WILL RESULT IF THE HAZARD IDENTIFIED IS IGNORED.
NOTE: DUE TO THE DIVERSITY OF GENERATOR MODELS, THE EQUIPMENT MAY NOT BE
EXACTLY AS SHOWN.
WARNING: SWITCH OFF THE MAIN POWER DISCONNECT AND ALLOW SUFFICIENT TIME FOR ALL
CAPACITORS TO DISCHARGE BEFORE REMOVING ANY COVERS OR OPENING ANY
SERVICE DOOR.
WARNING: IF ANY BARRIERS OR COVERS MUST BE REMOVED FOR SERVICE, TAKE ALL REQUIRED
PRECAUTIONS WITH RESPECT TO THE HAZARD(S) AND IMMEDIATELY REPLACE THE
BARRIERS/COVERS WHEN THE NEED FOR REMOVAL IS COMPLETED.
REPLACE ALL FUSES IN THIS GENERATOR WITH THE SAME TYPE AND
RATING.
This information is provided to help you establish safe operating conditions for both you and your CPI X-
ray generator. Do not operate this X-ray generator except in accordance with these precautions, and any
additional information provided by the X-ray generator manufacturer and/or competent safety authorities.
1B.4.1 Safety Warning Labels - Organization
The safety warning label information is organized into three subsections:
• Safety labels/notices common to Millenia and Indico 100
• Safety notices unique to Millenia
• Safety notices unique to Indico 100
The safety warning label subsections define the safety labels used inside and outside the generator
cabinets. Depending on configuration, your X-ray generator may contain some or all of the labels shown.

CPI Canada Inc. Safety 1B
Millenia / Indico 100 Series Service Manual Ch # 740904-01 Rev. D Page 1B-5
1B.5.0 SAFETY LABELS / NOTICES COMMON TO MILLENIA AND INDICO 100
1B.5.1 Caution HV Behind Cover Label
MILLENIA: This label is attached to a cover over the main power contactor. This area will have mains
voltage applied as long as the main disconnect is switched on.
MILLENIA: This label is attached to a cover over the resonant circuit and low speed starter
components if a low speed starter is fitted. The resonant components (resonant
capacitors etc) may be energized for 5 minutes after the console is switched off, or the
main disconnect is switched off.
If a low speed starter is fitted, the associated components will have up to 240
VAC applied when the console is switched on.
MILLENIA: This label is attached to each of the access panels on the rear of the generator. The high
voltage hazards behind these panels is similar to that behind the upper and lower
entrance doors, see 1B.7.4.
MILLENIA: This label is attached to a cover over the line adjusting transformer (if fitted). The
terminals on the transformer will have mains voltage applied as long as the main
disconnect is switched on. If access to the transformer connections is needed, SWITCH
OFF THE MAIN DISCONNECT FIRST.
INDICO 100: This label is attached to a cover over the inverter board(s). The inverter assembly is
connected to the main DC bus and will have high voltage applied at all times that the
generator is switched on. This assembly will remain energized for 5 minutes after the
generator is switched off, or the main disconnect is switched off.
INDICO 100: This label is attached to a cover over the main input fuses on the power input board. This
area will have mains voltage applied as long as the main disconnect is switched on.

1B Safety CPI Canada Inc.
Page 1B-6 Rev. D Millenia / Indico 100 Series Service Manual Ch # 740904-01
1B.5.2 Weight Label
MILLENIA: This label is attached to the upper and lower generator cabinets and to the HT oil tank
and states the approximate weight of each of the generator sections and of the HT oil
tank. This label cautions against attempting to lift those assemblies without proper
assistance.
INDICO 100: This label is attached to the lower generator cabinet and to the HT oil tank and states the
approximate weight of the lower generator cabinet and of the HT oil tank. This label
cautions against attempting to lift those assemblies without proper assistance.
1B.5.3 DC Bus Label
MILLENIA: This label is attached to a cover over the DC bus capacitors. These capacitors will hold a
lethal charge for 5 minutes after the console is switched off, or the main disconnect is
switched off. Do not remove the cover for a minimum of 5 minutes after the power has
been switched off.
INDICO 100: This label is attached to the removable panels on the lower (power supply) cabinet. The
internal capacitors will hold a lethal charge for 5 minutes after the console is switched off,
or the main disconnect is switched off. Do not remove the cover for a minimum of 5
minutes after the power has been switched off.
WARNING: WAIT A MINIMUM OF 5 MINUTES AFTER THE INPUT MAINS POWER HAS BEEN REMOVED
BEFORE REMOVING ANY COVERS OR ACCESS PANELS. ONCE THE COVER(S) /
PANEL(S) ARE REMOVED CHECK THAT THE VOLTAGE ACROSS THE DC BUS
CAPACITORS IS LESS THAN 48 VDC BEFORE SERVICING.

CPI Canada Inc. Safety 1B
Millenia / Indico 100 Series Service Manual Ch # 740904-01 Rev. D Page 1B-7
1B.5.4 Console CPU Board / Console Board
For 23 X 56 (cm) consoles: This symbol is printed on the console CPU board near U32.
HIGH VOLTAGE HAZARD: Approximately 400 VAC is present on this board in the area of U32
and J10. This voltage is used to light the backlight for the LCD display assembly in the
console.
For 31 X 42 (cm) consoles: This symbol is printed on the console board near U40.
HIGH VOLTAGE HAZARD IF U40 IS FITTED: U40 is a high voltage source for the fluorescent
backlight on the LCD display. Approximately 400 VAC is present on this board in the area of
U40 and J10 if U40 is fitted. On LED backlight versions of the LCD display, high voltage
source U40 is not fitted and no high voltage is present in this area.
1B.5.5 Generator Interface Board
This symbol is printed on the generator interface board in the high volage (mains) area.
HIGH VOLTAGE HAZARD: Components within the dashed line on the board have high
voltage applied at all times that the main disconnect is switched ON. These components are
live EVEN WITH THE CONSOLE SWITCHED OFF.
This symbol is printed on the generator interface board near fuses F1 to F6.
FUSE RATINGS:
F1: 1.6A 250V slow blow
F2, F5: 2.5A 250V slow blow
F3, F4: 5A 250V slow blow
F6: 2A 250 V slow blow
1B.5.6 Room Interface Board
This symbol is printed on the room interface board near the 110/220 VAC terminal blocks.
HIGH VOLTAGE HAZARD: 110/220 VAC may be present on this board at all times that the AC
mains to the generator is switched on.
1B.5.7 AEC Board
This symbol is printed on some versions of AEC board with a high voltage power supply for a
PMT or ion chamber.
HIGH VOLTAGE HAZARD: Depending on the AEC board type, up to approximately 1000 VDC
may be present on the AEC board at all times that the generator is switched on.
1B.5.8 Power Input Board
Power input boards for single phase 240 VAC generators are fitted with several high power
resistors that operate at temperatures sufficient to cause skin burn. Ensure that these resistors
have cooled sufficiently after the power has been switched off before servicing.

1B Safety CPI Canada Inc.
Page 1B-8 Rev. D Millenia / Indico 100 Series Service Manual Ch # 740904-01
1B.5.9 Dual Speed Starter Board
This symbol is printed on the dual speed starter board if fitted.
HIGH VOLTAGE HAZARD: Approximately 600 VDC is present on this board. This voltage is
supplied from the DC bus capacitors in the HF power supply. USE EXTREME CAUTION
WHEN SERVICING, this voltage and current combination is lethal. Ensure that the DC bus
capacitors are fully discharged before servicing as these capacitors will hold a lethal charge for
5 minutes AFTER THE EQUIPMENT IS SWITCHED OFF.
WARNING: COMPONENTS BEHIND VARIOUS COVERS, AS NOTED IN THIS SECTION, REMAIN LIVE
EVEN WITH THE OPERATOR CONSOLE SWITCHED OFF. THE ONLY WAY TO REMOVE
POWER FROM THESE AREAS IS TO SWITCH OFF THE MAIN DISCONNECT.
1B.6.0 SAFETY LABELS / NOTICES UNIQUE TO MILLENIA
1B.6.1 HT Tank - Transformer Terminals Label
This label indicates that if the power supply inverter leads that attach to the high tension transformer
primary terminals are not connected the generator must not be energized.
This label also cautions against over tightening the nuts on the transformer feedthrough terminals
mentioned in the above paragraph.
