Cradlepoint ARC SERIES User manual

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 1
User Manual /CBA850 8/25/16
ARC Series
Router
CBA850
User Manual

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 2
User Manual /CBA850 8/25/16
TABLE OF CONTENTS
INTRODUCTION 4
WHAT’S IN THE BOX 4
KEY FEATURES 4
WAN 4
LAN 4
MANAGEMENT 4
ROUTING 4
SECURITY 4
SPECIFICATIONS 5
ACCESSORIES 5
BUSINESS-GRADE MODEM SPECIFICATIONS 6
HARDWARE 8
SUPPORT AND WARRANTY 9
LEDS 10
QUICK START 11
BASIC SETUP 11
ACCESSING THE ADMINISTRATION PAGES 12
FIRST TIME SETUP WIZARD 12
USING ENTERPRISE CLOUD MANAGER 13
ADMINISTRATION PAGES 14
QUICK LINKS 14
DASHBOARD 14
CONNECTION MANAGER 15
WAN INTERFACE PROFILES & PRIORITY 15
STATUS 19
INTERNET 19
CLIENT LIST 24
FIREWALL 24
ROUTING 24
ETHERNET 25
GPS 25

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 3
User Manual /CBA850 8/25/16
LLDP 25
SYSTEM LOGS 25
NETWORKING 26
LOCAL NETWORKS 26
VLAN INTERFACES 30
DNS SERVERS 31
ROUTING 31
WAN AFFINITY 33
SECURITY 36
IDENTITIES 36
ZONE FIREWALL 36
CONTENT FILTERING 41
SYSTEM 43
ADMINISTRATION 43
ENTERPRISE CLOUD MANAGER 48
DEVICE ALERTS 48
SERIAL REDIRECTOR 50
SNMP CONFIGURATION 50
SYSTEM CONTROL 52
DIAGNOSTICS 54
SETUP WIZARDS 55
APPENDIX 57
SAFETY, REGULATORY, AND WARRANTY GUIDE 57
ROUTER COMMUNICATION/DATA USAGE 58

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 4
User Manual /CBA850 8/25/16
INTRODUCTION
WHAT’S IN THE BOX
KEY FEATURES
• CBA850 with integrated MC400 Multi-Carrier Software-Dened Radio modem
• Universal 3G/4G/LTE antennas with dedicated active GPS antenna port
• 12VDC 1A power adapter (1.5 meter cord)
• Ethernet cable
• Quick Start Guide
• Mounting hardware
• Warranty and regulatory information
WAN
• LP6: LTE Advanced LTE/HSPA+ (SIM-based Auto-Carrier Selection for all North American carriers and European
operators)
• LPE: 4G LTE/HSPA+/EVDO (multi-carrier)
• LP3: 4G LTE/HSPA+ (Europe, EMEA, and Australia/New Zealand)
• Advanced Modem Failure Check
• IP Passthrough
• Standby
• Ethernet WAN for inline failover
LAN
• VLAN 802.1Q
• DHCP Server, Client, Relay
• DNS and DNS Proxy
• DynDNS
• UPnP
• DMZ
• MAC Address Filtering
MANAGEMENT
• Cradlepoint Enterprise Cloud Manager1
• Web UI, API, CLI, SSH
• Data Usage Alerts (router and per client)
• Advanced Troubleshooting (support)
• Device Alerts
• SNMP
• SMS control
ROUTING
• Routing Rules
• NAT-less Routing
• Virtual Server/Port Forwarding
• IPv6

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 5
User Manual /CBA850 8/25/16
SPECIFICATIONS
WAN: Integrated LP6 Category 6 LTE Advanced LTE modem (with DC-HSPA+ failover) or LPE 4G LTE modem (with HSPA+/
EVDO/3G and 2G failover) or LP3 4G LTE modem (with HSPA+ and 2G failover)
LAN:
• Two LAN 10/100/1000 Ethernet ports (default one NAT, one IP Passthrough)
• RJ45 Serial Port for console access or out-of-band management
TEMPERATURE:
• 0°C to 50°C (32°F to 122°F) operating
• −20°C to 70°C (−4°F to 158°F) storage
HUMIDITY (non-condensing):
• 10% to 85% operating
• 5% to 90% storage
POWER:
• 12VDC 1.5A adapter
• 802.3af (15W) or 802.3at (30W) PoE capable
SIZE: 4.8 x 4.8 x 1.7 in (122 x 122 x 42 mm)
HOUSING:
• White plastic, locking compatible
• Wall, desk, or DIN Rail mounting
CERTIFICATIONS:
• FCC, CE, IC
• Safety: UL/CUL/CB Scheme
• Materials: WEEE, RoHS, RoHS-2, California Prop 65
SECURITY
• RADIUS and TACACS+ support*
• 802.1x authentication for Ethernet
• ALGs
• MAC Address Filtering
• Advanced Security Mode (local user management only)
• Per-Client Web Filtering
• IP Filtering
• Content Filtering (basic)
• Website Filtering
*-Native support for authentication. Authorization and accounting support through hotspot/captive portal services.
1 – Enterprise Cloud Manager requires a subscription
ACCESSORIES
• 700 MHz – 2700 MHz Wide Band Directional Antenna (Yagi/Log- Periodic) Part #: 170588-000
• 12” Mag-Mount Antenna with SMA Male Connector Part #: 170605-000
• 4” Mini Mag-Mount Antenna with SMA Male Connector Part #: 170606-000

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 6
User Manual /CBA850 8/25/16
BUSINESS-GRADE MODEM SPECIFICATIONS
ARC CBA850 LP6 models include an integrated LTE Advanced Category 6 4G LTE modem. The LP6 modems support SIM-
Based Auto-Carrier selection so there is only one model for all of North America. Simply insert the SIM and wait for
the router to automatically detect the SIM and establish a connection.
The LTE bands certied for each carrier are listed below.
ARC CBA850LP6-NA, CBA850LP6-EU, CBA850LP6-UK
• Technology: LTE Advanced, HSPA+
• Downlink Rates: LTE 300 Mbps, HSPA+ 42.2 Mbps
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps
• Frequency Bands:
• LTE Bands 1-5, 7, 8, 12, 13, 17, 20, 25, 26, 29, 30, 41
• Verizon: 2, 4, 5, 13 (XLTE support w/carrier aggregation)
• AT&T: 2, 4, 5, 12/17, 29, 30
• Sprint: 25, 26, 41 (LTE Plus Support)
• T-Mobile: 2, 4, 12 (T-Mobile Wideband LTE Support)
• Generic: all
• Carrier Aggregation:
• 1+ 8
• 2+ 2/5/12 (17 w/MFBI)/13/29
• 3+ 7/20
• 4+ 4/5/12 (17 w/MFBI)/13/29
• 5+ 2/4/30
• 7+ 3/7/20
• 8+ 1
• 12 (17 w/MFBI) + 2/4/30
• 13+ 2/4
• 20+ 3/7
• 30+ 5/12 (17 w/MFBI)
• 41+ 41
• Fallback: WCDMA/DC-HSPA+ (42/5.76 Mbps): Bands 1, 2, 3, 4, 5, 8
• Power: LTE 23 dBm +/− 1, HSPA+ 23 dBm +/− 1
• Antennas: two SMA male (plug), nger tighten only (maximum torque spec is 7 kgfcm)
• GPS: active GPS support
• 2.4/5 GHz Dual-band Dual-concurrent WiFi Antenna Part #: 170628-000 (WiFi models only)
• Universal 3G/4G/LTE Modem Antenna Part #: 170649-000
• GPS Screw-Mount Antenna Part #: 170651-000
• GPS Mag-Mount Antenna Part #: 170652-000
• Universal 3G/4G multi-band cellular modem antenna (white) – 2dBi/3dBi (Part # 170659-000)
• Multi-Band Omni-Directional Antenna Part #: 170668-000
• Indoor/Outdoor Panel Patch Part #: 170669-000
• DIN Rail Mounting Bracket (Part # 170656-000)
• Wall/Ceiling Mounting Bracket (Part # 170666-000)
• Rollover Adapter for RJ45 Ethernet cable M/F (Part # 170662-000)
• RJ45 Rollover serial console cable 7ft (Part # 170663-000)
• RJ45 Rollover serial console cable 14ft (Part # 170663-001)
See the Cradlepoint antenna accessories page for more information about antennas. Also see the Antenna Ordering
and Installation Guide, available as a PDF in the Resources section of antenna and router product pages.

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 7
User Manual /CBA850 8/25/16
• SMS: SMS support
• Industry Standards & Certs: CE, FCC, GCF-CC, IC, PTCRB, AT&T, Sprint, Verizon
• Modem Part Number: MC400LP6
ARC CBA850LPE models include an integrated 4G LTE modem – specic model names include a specic modem (e.g.,
the ARC CBA850LPE-VZ includes a Verizon LTE modem).
Please note that LPE models are exible and support bands for multiple cellular providers; however, only the
frequency bands in bold below are supported by the listed provider.
ARC CBA850LPE-VZ – 4G LTE/EVDO for Verizon
• Technology: LTE, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE: Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700
MHz), Band 25 (1900 MHz)
• GSM/GPRS/EDGE: (850/900/1800/1900 MHz)
• CDMA: EVDO Rev A/1xRTT (800/1900 MHz)
• Power: LTE 23 dBm +/− 1, EVDO 24 dBm +0.5/−1 (typical conducted)
• Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi (Cellular/PCS) gain; nger tighten only (maximum torque spec is
7 kgf-cm)
• GPS: active GPS support
• Industry Standards & Certs: FCC, Verizon
• Modem Part Number: MC400LPE-VZ
• SIM: two 2FF SIM slots
ARC CBA850LPE-AT – 4G LTE/HSPA+/EVDO for AT&T
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE: Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17
(700 MHz), Band 25 (1900 MHz)
• HSPA+/UMTS: (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE: (850/900/1800/1900 MHz)
• CDMA: EVDO Rev A/1xRTT (800/1900 MHz)
• Power: LTE 23 dBm +/− 1, HSPA+ 23 dBm +/− 1, EVDO 24 dBm +0.5/−1 (typical conducted)
• Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi (Cellular/PCS) gain; nger tighten only (maximum torque spec is
7 kgf-cm)
• GPS: active GPS support
• Industry Standards & Certs: FCC, PTCRB, AT&T
• Modem Part Number: MC400LPE-AT
• SIM: two 2FF SIM slots
ARC CBA850LPE-SP – 4G LTE/HSPA+/EVDO for Sprint
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE: Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 8
User Manual /CBA850 8/25/16
MHz), Band 25 (1900 MHz)
• HSPA+/UMTS: (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE: (850/900/1800/1900 MHz)
• CDMA: EVDO Rev A/1xRTT (800/1900 MHz)
• Power: LTE 23 dBm +/− 1, HSPA+ 23 dBm +/− 1, EVDO 24 dBm +0.5/−1 (typical conducted)
• Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi (Cellular/PCS) gain; nger tighten only (maximum torque spec is
7 kgf-cm)
• GPS: active GPS support
• Industry Standards & Certs: FCC, Sprint
• Modem Part Number: MC400LPE-SP
• SIM: two 2FF SIM slots
ARC CBA850LP3-EU – 4G LTE/HSPA+ for Europe
• Technology: LTE, HSPA+
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps (theoretical)
• Frequency Bands:
• LTE: Band 1 (2100 MHz), Band 3 (1800 MHz), Band 7 (2600 MHz), Band 8 (900 MHz), Band 20 (800 MHz)
• HSPA+/UMTS: (800/850/900/1900/2100 MHz)
• GSM/GPRS/EDGE: Quad-Band (850/900/1800/1900 MHz)
• Power: LTE Band 1/3/8/20 – 23 dBm +/− 1; LTE Band 7 – 22 dBm +/− 1, HSPA+ 23 dBm +/− 1 (typical conducted
• Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi (Cellular/PCS) gain; nger tighten only
• GPS: active GPS support
• Industry Standards & Certs: CE, GCF-CC
• Modem Part Number: MC400LP3-EU
• SIM: two 2FF SIM slots
ARC CBA850LPE-GN – 4G LTE/HSPA+/EVDO for Canada and T-Mobile and US Cellular in the U.S.
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE: Band 2 (1900 MHz), Band 4 (AWS), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700 MHz), Band 25
(1900 MHz)
• HSPA+/UMTS: (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE: (850/900/1800/1900 MHz)
• CDMA: EVDO Rev A/1xRTT (800/1900 MHz)
• Power: LTE 23 dBm +/− 1, HSPA+ 23 dBm +/− 1, EVDO 24 dBm +0.5/−1 (typical conducted)
• Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi (Cellular/PCS) gain; nger tighten only (maximum torque spec is
7 kgf-cm)
• GPS: active GPS support
• Industry Standards & Certs: FCC, IC, PTCRB
• Modem Part Number: MC400LPE-GN
• SIM: two 2FF SIM slots
• Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi (Cellular/PCS) gain; nger tighten only (maximum torque spec is
7 kgf-cm)
• GPS: active GPS support
• Industry Standards & Certs: FCC, Verizon
• Modem Part Number: MC400LPE

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 9
User Manual /CBA850 8/25/16
HARDWARE
BOTTOM VIEW
RIGHT VIEW

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 10
User Manual /CBA850 8/25/16
REAR VIEW
CradleCare Support available with technical support, software upgrades, and advanced hardware exchange – 1-, 3-, and
5-year options.
One-year limited hardware warranty available in the US and Canada; two-year limited hardware warranty for
integrated EU products when purchased from an authorized EU distributor – extend warranty to 2, 3, or 5 years.
SUPPORT AND WARRANTY
LEDS

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 11
User Manual /CBA850 8/25/16
QUICK START
BASIC SETUP
1. Insert an activated SIM
The Cradlepoint ARC CBA850 requires a SIM with an activated wireless broadband data plan. Contact your carrier
for details about selecting a data plan and about the process for provisioning your SIM.
Once you have an activated SIM, insert it into the integrated modem:
1. Remove the modem cover and pull out the integrated modem.
2. Insert the SIM card into the slot marked SIM 1 (use the other slot, SIM 2, for a secondary/
backup SIM).
Be sure to insert the card with the notch-end rst and the gold contacts facing down – it will click into place.
Notch-end goes in first
Gold contacts face down
2. Insert the removable modem
Slide the integrated modem back into its slot. Put the cover back into place and insert the included security
screw if desired (requires small Phillips screwdriver). NOTE: To remove modem, attach included modem
antennas (nger-tighten only) and pull modem straight out.
3. Attach included modem antennas.
Antennas are nger-tighten only. Attach to connectors marked MAIN and AUX.
4. Connect to a power source.
Attach the included adapter to the device and to a power source OR connect a POE-enabled RJ45 cable to LAN 2.
Then turn the power switch on (I).
5. Connect to a computer or other network equipment.
Connect via Ethernet to LAN 1 for local management. Connect LAN 2 (Default IP Passthrough 0/24) to networking
equipment to Passthrough 3G/4G Internet to Ethernet.

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 12
User Manual /CBA850 8/25/16
ACCESSING THE ADMINISTRATION PAGES
Once you are connected, open the Cradlepoint CBA850’s GUI-based administration pages to make conguration
changes to your router.
1. Open a browser window and type “cp/” or “192.168.0.1” in the address bar. Press ENTER/RETURN.
2. When prompted for your password, type the eight character DEFAULT PASSWORD found on the product
label.
NOTE: The product label below is an example only: your DEFAULT PASSWORD and SSID will be unique.
It’s possible – and more ecient – to do all your conguration changes through Cradlepoint Enterprise Cloud
Manager (ECM) without logging into the local administration pages. Set up a group of routers and set the
conguration for all of them at once. See below for more information about ECM.
FIRST TIME SETUP WIZARD
When you log in for the rst time, you will be automatically directed to the FIRST TIME SETUP WIZARD, which
will walk you through the steps to customize your Cradlepoint CBA850. You have the ability to congure any of
the following:
• Administrator Password
• Time Zone
• Security Mode
• Access Point Name (APN) for SIM-based modems
• Modem Authentication
• Failure Check
NOTE: To return to the First Time Setup Wizard after your initial login, select SYSTEM from the navigation bar,
expand Setup Wizard,and select First Time Setup.

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 13
User Manual /CBA850 8/25/16
USING ENTERPRISE CLOUD MANAGER
Rapidly deploy and dynamically manage networks at geographically distributed stores and branch locations with
Enterprise Cloud Manager, Cradlepoint’s next generation management and application platform. Enterprise Cloud
Manager (ECM) integrates cloud management with your Cradlepoint devices to improve productivity, increase
reliability, reduce costs, and enhance the intelligence of your network and business operations.
Click here to sign up for a free 30-day ECM trial.
Depending on your ordering process, your devices may have already been bulk-loaded into ECM. If so, simply
log in at cradlepointecm.com using your ECM credentials and begin managing your devices seamlessly from the
cloud.
If your device has not yet been loaded into your ECM account, you need to register. Log into the device
administration pages and select Enterprise Cloud Manager from the SYSTEM menu. Enter your ECM username
and password, and click on “Register”.
Once you have registered your device, go to cradlepointecm.com and log in using your ECM credentials.
For more information about how to use Cradlepoint Enterprise Cloud Manager, see the following:
• Getting Started
• ECM on the Knowledge Base

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 14
User Manual /CBA850 8/25/16
ADMINISTRATION PAGES
Quick Links
Dashboard
Connection Manager
Status
Networking
Security
System
QUICK LINKS
DASHBOARD
The Dashboard is a centralized location for basic
information about the status of your router. The
areas include:
• Device Information
• Ethernet WAN*
• Modems*
• WWAN*
• Ethernet LAN*
*-To quickly edit settings for any of these areas,
click on the pencil icon ( ) in the top-right of the
desired dialog box.
You may return to the Dashboard at any time by
clicking on DASHBOARD from the left menu or by
clicking on the Cradlepoint logo at the top-left of
the screen.
Quick Links allows you to bookmark your most commonly-used settings. Simply click on the bookmark icon ( )
to add an item to your Quick Links menu. To remove an item from your Quick Links menu, select the item and
click on the remove bookmark icon ( ).
Quick Links Menu Add Quick Link Delete Quick Link

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 15
User Manual /CBA850 8/25/16
CONNECTION MANAGER
The Connection Manager is used to manage the various WAN interfaces you have available on your router. WAN
interface types (Ethernet, modems) are prioritized in connection preference and failover order (with the top of the list
being highest priority).
This is a list of the available interfaces used to access the Internet. You can enable, stop, or start devices from this
section. Drag the priority icon ( ) up or down to set the interface the router uses by default and the order that it
allows failover.
WAN INTERFACE PROFILES & PRIORITY
Availability Key
Enable Load Balance
On Demand
WAN Verify Data Usage
FailbackStandby
STANDBY
Standby is used to decrease failover time from one WAN interface to another. When Standby is enabled for a WAN
prole or interface, the relevant interfaces are kept in a connected-but-idle (minimal, non-routed trac) state. When
the current WAN connection is disrupted, the trac will failover to the next priority WAN. If that interface is on
Standby, the connection is already established and failover will take much less time.
Note that the current connected interface(s) is/are indicated by a green connection state. For interfaces on Standby,
the interface is indicated by a yellow connection state. If the interface is indicated in red, the interface is not currently
connected or in Standby.
Standby is used to enable faster failover times only. If you want to manage trac to a specic WAN interface, you
will need to use WAN Anity. If WAN Anity is enabled for a particular prole or interface, do not enable Standby for
that prole or interface as the failover results may vary and be unexpected.

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 16
User Manual /CBA850 8/25/16
ON DEMAND
Typically, modem connections are not always on.
When the On Demand mode is selected a connection
to the Internet is made as needed. When On
Demand is not selected a connection to the Internet
is always maintained.
WAN VERIFY
If this is enabled, the router will check that the highest priority active WAN interface can get to the Internet even if
the WAN connection is not actively being used. If the interface goes down, the router will switch to the next highest
priority interface available. If this is not selected, the router will still failover to the next highest priority interface but
only after the user has attempted to get out to the Internet and failed.
Idle Check Interval: The amount of time between each check. (Default: 30 seconds. Range: 10-3600 seconds.)
Monitor while connected: (Default: O) Select from the following dropdown options:
• Passive DNS (modem only): The router will take no action until data is detected that is destined for the WAN.
LOAD BALANCE
To enable Load Balancing, select the check box for each desired
device. If this is enabled, the router will use multiple WAN
interfaces to increase the data transfer throughput by using any
connected WAN interface consecutively. Selecting Load Balance
will automatically start the WAN interface and add it to the pool
of WAN interfaces to use for data transfer. Turning o Load
Balance for an active WAN interface may require the user to
restart any current browsing session.
From WAN Management, select the Load Balance Algorithm from
the following dropdown options:
• Round-Robin: Evenly distribute each session to the available WAN connections.
• Rate: Distribute load based on the current upload and download rates. A WAN device’s upload and download
bandwidth values can be set in Internet > Connection Manager.
• Spillover: This was the default algorithm in older (version 3) rmware. Load is always given to devices with the
most available bandwidth. The estimated bandwidth rate is based on a combination of the upload and download
conguration values and the observed capabilities of the device.
• Data Usage: This mode works in concert with the Data Usage feature (Internet > Data Usage).
The router will make a best eort to keep data usage between interfaces at a similar percentage of the assigned data
cap in the data usage rule for each interface, rather than distributing sessions based solely on bandwidth. For proper
functioning you need to create data usage rules for each WAN device you will be load balancing. Make certain to select
the “Use with Load Balancing” checkbox in the data usage rule editor.

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 17
User Manual /CBA850 8/25/16
When this data is detected, the data will be
sent and the router will check for received
data for two seconds. If no data is received the
router behaves as described below under Active
DNS.
• Active DNS (modem only): A DNS request will be
sent to the DNS servers. If no data is received,
the DNS request will be retried four times at
ve-second intervals. (The rst two requests
will be directed at the Primary DNS server and
the second two requests will be directed at
the Secondary DNS server.) If still no data is
received, the device will be disconnected and
failover will occur.
• Active Ping: A ping request will be sent to the Ping Target. If no data is received, the ping request will be retried
four times at ve-second intervals. If still no data is received, the device will be disconnected and failover will
occur. When “Active Ping” is selected, the next line gives an estimate of data usage in this form: “Active Ping
could use as much as 9.3 MB of data per month.” This amount depends on the Idle Check Interval.
• O: Once the link is established the router takes no action to verify that it is still up.
FAILBACK
This is used to congure failback, which is the ability to go back to a higher priority WAN interface if it regains
connection to its network.
Select the Failback Mode from the following
options:
• Usage
• Time
• Disabled
Usage Threshold: Fail back based on the amount
of data passed over time. This is a good setting
for when you have a dual-mode EVDO/WiMAX
modem and you are going in and out of WiMAX
coverage. If the router has failed over to EVDO it
will wait until you have low data usage before bringing down the EVDO connection to check if a WiMAX connection can
be made.
• High (Rate: 80 KB/s. Time Period: 30 seconds.)
• Normal (Rate: 20 KB/s. Time Period: 90 seconds.)
• Low (Rate: 10 KB/s. Time Period: 240 seconds.)
• Custom (Rate range: 1-100 KB/s. Time Period range: 10-300 seconds.)
Time: Fail back only after a set period of time. (Default: 90 seconds. Range: 10-300 seconds.) This is a good setting if
you have a primary wired WAN connection and only use a modem for failover when your wired connection goes down.
This ensures that the higher priority interface has remained online for a set period of time before it becomes active
(in case the connection is dropping in and out, for example).

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 18
User Manual /CBA850 8/25/16
DATA USAGE
Data Usage displays upload and download trac for each LAN client. Check Monitor Monthly (or Weekly or Daily)
Usage to begin tracking this information. This data is not retained between router reboots.
For Monthly and Weekly you are able to specify the day to start each cycle (e.g. the 1st or Tuesday, respectively).
Usage Cap: Enter a Cap amount in Megabytes. 1024
Megabyte is equal to 1 Gigabyte.
Use with Load Balancing: When checked, the Load
Balancing feature is allowed to use the thresholds and
metrics of this rule when making balance decisions. This
causes Load Balancing to spread the data usage between
interfaces according to the assigned usage rather than
bandwidth. This is a best eort to keep all interfaces with
these rules at a similar percentage utilization of data (e.g.
10%, 50%, 90%) as the cycle progresses, rather than quickly
using 100% of a fast 1GB capped interface while using only
a fraction of a slow 10GB capped interface, thus leaving
the rest of the cycle with only the slow interface. The Data
Usage algorithm on the WAN Anity/Load Balancing page
must be selected or this checkbox has no eect.
Shutdown on Cap: When checked, the WAN device will
shutdown when the assigned usage is reached. A cycle
reset or a rule deletion will re-enable the device.
Alert on Cap: An email alert will be generated and sent when the assigned data cap is reached. NOTE: The SMTP mail
server must be congured in System > Device Alerts.
Custom Alerts: Check to enable custom alerts at specied percentage of
usage cap.
Custom Alert Percentages: Example: “50,80,90,110” (values can exceed
100%) (Triggers alerts when 50, 80, 90, 110% of usage cap is used)
NOTE: To enable data usage, check Data Usage Enabled from WAN
Management.
Disabled: Deactivate failback mode.
Immediate Mode: Fail back immediately whenever a higher priority interface is plugged in or when there is a priority
change. Immediate failback returns you to the use of your preferred Internet source more quickly which may have
advantages such as reducing the cost of a failover data plan, but it may cause more interruptions in your network than
Usage or Time modes.

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 19
User Manual /CBA850 8/25/16
STATUS
Internet
Client List
Firewall
Routing
Ethernet
GPS
LLDP
System Logs
INTERNET
CONNECTIONS
Select your device to reveal
detailed information about the
following device properties:
• Summary
• Modem
• Cellular Network
• General Information
• IPv4 Information
• Statistics

©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 20
User Manual /CBA850 8/25/16
