Operator's Manual
ROUTER MOUNTING KIT
FOR MODEL NO. 315.228390 TABLE SAW
Save this manual for
future reference. BSAFETY
• UNPACKING
ACAUTION: Read and follow all
Safety Rules and Operating
Instructions before first use of this
product.
Customer Help Line: 1-800-932-3188
Seams,Roebuck and Co., 3333 Beverly Rd., Hoffman Estates, IL 60179 USA
Visit the Craftsirsan web page: www.seam.com/craflsman
• ASSEMBLY
• PARTS LIST
972000-944
1-02

Thepurposeofsafetysymbolsistoattractyourattentiontopossibledangers.Thesafetysymbols, andthe
explanationswiththem, deserveyourcarefulattentionand understanding,The safetywamingsdo notby
themselveseliminateany danger,The instructionsorwarningsthey giveare notsubstitutesfor properacci-
dent preventionmeasures.
SYMBOL
&
&
A
NOTE:
MEANING
SAFETY ALERT SYMBOL:
Indicateswarningor caution, May be usedin conjunctionwith othersymbols or pictogrsphs.
WARNING: Failureto obeya safetywarningcan result in serious injurytoyourselforto others.
Alwaysfollowthe safety precautionsto reducethe dskoffire,electric shockand personalinjury.
CAUTION: Failureto obey a safetywamingmay resultinpropertydamage or personal injuryto
yourselforto others.Always followthe safety precautionsto reducethe riskoffire, electricshock
and personalinjury.
Advisesyou of informationor instructionsvitalto the operationor maintenance of the equipment.
_. WARNING: Do not to thistool
attempt operate
untilyou have read thoroughlyand understand
completelyall instructions,safetyrules, etc.
containedinthis manual, Failureto comply can
resultin accidentsinvolvingfin), alectdcshock,
or sedouspersonalinjury.Save owner's manual
and review frequentlyfor continuingsafe
operation,and instructingotherswho may use
this tool.
READ ALL INSTRUCTIONS
•READ THESE INSTRUCTIONS AND INSTRUC-
TIONS FOR YOUR TABLE SAW AND ROUTER
THOROUGHLY BEFORE USING ACCESSORY.
•KNOW YOUR POWER TOOL. Read the
operator'smanualfor yourTableSaw carefully.
Learnthe saw'sapplications and limitationsas
well as the specificpotentialhazards relatedto
thistool.
•KEEP THE WORK AREA CLEAN, Cluttered
work areas and work benchesinviteaccidents.
DO NOT leave toolsor piecesofwood onthe
sew while itisin operation,
•ALWAYS WEAR SAFETY GLASSES. Everyday
glasseshave onlyimpect-rasistantlenses;they
are NOT safety glasses.
• ALWAYS DISCONNECTSAW FRO• POWER
SUPPLY BEFORE MAKING ADJUSTMENTS
ORADDING ACCESSORIES, Make sun)the
switchisoffwhen reconnectingto powersupply,
_k WARNING:
• ALWAYS FEED WORKPIECE AGAINST THE
ROTATION OF THE cU'rTER.
•DO NOT USEAWKWARD HAND POSITIONS.
•KEEP FINGERS AWAYfromthe revolvingcutter,
and usefixtureswhen necessary.
•ALWAYSUSETHE DUSTCOVERforoverhead
guardhg.
•DO NOT REMOVE JAMMED CUTOFF PIECES
untilcutterorblade has stoppedand toolhas
beendisconnectedfrom powersoume.
•HOLD THE WORKPIECE FIRMLYAGAINST
THE TABLE,
•ALWAYS USE THE SAW'S MASTER SWITCH
TO TURN THE ROUTER ON AND OFF.
SAVE THESE INSTRUCTIONS. Refer tothem
frequentlyand usato instructother users.If you
loan someonethisaccessory,lean them these
instructionsalso.
_11=WARNING: Usa recommendedacoessodes.
The usa of improperaccessoriesmay createa
riskof injury.Do not usethis routermounting kit
forany purposeother than as an accessory to
the recommendedtable saw.Failuretoheed
thiswarningcanresultin sadous personal
injuryor damage tothe accessory.
_lb WARNING: Beforeattemptingto useyour
routermountingkit,familiadzeyourselfwithall
operatingfeatures and safety requirements.
The operationofanyroutercanresultinforeignobjectsbeing thrownintoyoureyes, which
canresultinsevereeye damage,Beforebeginningpowertooloperation,alwayswearsafety
goggles or safety glasses with side shields and a full face shield when needed. We
recommendWide Vision Safety •ask for useover eyeglassesor standard safety glasses
with side shields,available at Sears Retail Stores. Always wear eye protectionwhich is
marked to complywithANSI Z87.1
2

ROUTER MOUNTING KIT
Readtheseinstru_ionscompletelybeforemounting
yourrouter totheaccessorytableofyourCraftsman
table sew.
Amuter mountedon theaccessorytablewillprovide
expandedcapabilitiesfor making rabbets,grooves,
chamfers,dovetails,and mortise and tenonjoints.
Thismuter mounUngkitwillaccommodatemost
CraRsrnanand Ryoblreuters.
Ifused and stored properly,the routermountingkit
willgive you years of dependable, trouble-free
performance, 10
6
=(b
3 °O,r
UNPACKING THE ROUTER MOUNTING KIT
Includedinthe muter mountingkitare twomounting
plates,twoguidefences withguideblocks,a guard/
dustcoverassembly,t]vethroatplates,plusnecessary
bracketsand hardwarerequiredto mount routerto the
accessolytable of yourCraftsmantable sew.
Separateallthepartsand checkthe parts againstthe
parts list.See Figure1.
Duringassemblyand installation,you will needa
phillipsscrswddver,flatheadscrawdriver,and an
adjustablewrench.
13
9
12
Fig. 1
LOOSE PARTS
Check the parts with the list.If any of the parts are missing,delaythe assemblyuntilyou haveobtainedthe
missingpart.
Key Description Quantity
1. Router ExtensionTable ................................ 1
2. GuideFence with Guide Block..................... 2
3, KnobBolt(1/4-20) ........................................ 4
4. Flat Washer (1/4 in. x 16) ............................. 6
5. TappedMountingBar ................................... 2
6. Square Head Bolt(1/4 x 3/4 in.)................... 2
7. Hex Nut (t/4-20) ........................................... 2
Key Description Quantity
8, LockWasher................................................. 2
9. Shims ........................................................... 2
10, Post.............................................................. 1
11. Guard/Dust Coverwith PivetAssembly........ 1
12. Throat Plates................................................ 5
13. Screw (#10-32x 3/4 in.fiat hd.) ................... 3
14. Screw (5/16-18 x 1 in.fiat hd,) ..................... 4
_L Look for this symbol to point out important safety precautions. It means atten-
tiont!! Your safety is involved. 3

INSTALLROUTEREXTENSION
•Unplugthe saw.
AWARNING: Unplugthe powersupplycordofthe
sawbeforemountingthiskit,Failuretounplug
yoursaw couldrasult inaccidentalstarting
causingpossible seriouspersonalinjury.
•ILWARNING: The saw's motorcord muStbe
Hdisconnectedfromthe racaptacle on sawwhen
usingthis kit,The power cord ofthe router muSt
be pluggedintothe receptacleonthe saw,The
saw's maSterswitchmuStbe usedto turn the
muter On and Off, Failureto do socould result
in seriouspersonalinjury,
Note: The muter extensionincludedinthis kitreplaces
the _tableextensionthatcame withyourCrattsman
table saw. Ifyou are assemblingyoursaw forthefirst
timeandwishtomountyourmuter kitatthistime,
follow the assemblyinStructionsthatcame withyour
saw,substitutingthe routerextensionforthe left
extensionwing.Oncethe muter extensionisattached
tothe saw,turntheheadinglabelled=InstallGuard/
DuStCover"on page5 ofthis manualandfollow the
remainderofthe assemblyinStructions.
Ifyouare mountingthis muter kitto aCraftsmantable
sawthat isalreadyassembled,proceedasfollows,
•Remove front and rear railsbylooseningthefour
5/16-t8 hex nuts holdingthe lefttable extension
tothe rails,as well as the two 5116-18 hex nuts
sacudng the left side of the main tableto the rails.
The nutsare locatedon the undersideof the
table. Slide leftsectionsof beth front and rear
railsoff. Sea Figure2.
Fig. 2
•With theassiStanceofanother person, remove
the fourhex nuts,washers and bells holdingthe
table extensiontothe maintable and remove
table extension.
•Withthe assiStanceof another person, position
muter extensionsothatthefour holesalongthe
edge lineupwiththe fourholesinthe maintable.
Feed a 5116-18x 1-114in. belt througheach hole
as shownin Figure3 and attachwashers.Using
an adjuStablewrench,tighen the5/16-18 nuts
sacudng the routerextension tothe main table.
_ll WARNING: The extensionsare very heavy.
Do notattemptto removeor assembleexten-
sionswithoutthe helpof another person, When
liftingtheextensionsor maneuvedngsaw,
alwayskeepyourknees bent and liftwithyour
legs, notyour beck. Ignodngthese precautions
can resultin backInjury.
UNDERTABLEVIEW
HB( NUT LOCKWASHER
,._ _/FLATWASHEH
/Fig.3
•The front and rear rails have slottedtracks
designedto acceptthe belt heads you loosened
Inorderto slidethe railsoff.Stintingat the far left
side,carefully feed the frontrailtowardthe
middle,makingsurethatthe boltheads arefully
engaged inthe track. Repeat with rear rail.
Note: There are two slottedtracksonthe frontrail.
The toptrackisdesignedto acceptthe boltheads.
See Figure4.
•Usingan adjustablewrench,tighteneach of the
sixhex nutssacudng the railsto the router
extension and main table.
4

REARRAIL
(SIDEVlBt/) POST
FRONtRAIL
(SIDEVIEW) ,2-? Fig.4
GUIDE FENCE ASSEMBLY
• Lifltheblade guardand placethe dpfenceagainst
the sew bladeand lockthe dpfencein place. This
willinsurethatthe ripfenceremainssquarewhile
installingthe mountingbars.
•Slide mountingbare into fronttrackon dpfence
and move themto the center ofthefence.
•Positionshimssothat the mar edges areflush
withthe rear edge ofthe fence and the slotsline
upwith the twoholes in each mountingbar.
SI Postition the two guideblockassembliessothat
the rearedges are flushwiththe rear edge of the
fence and the two slotsline upwith the slotsin
the shims.
•Assemble 1/4 in, flat wasbars onto each knob
bolt and screw knob bolts into holes on mounting
KNOBBOLT
bars as showninFigure5.
RiPFENCE
SHIM
GUIDEFENCE
ASSEMBLY
Fig,5
INSTALL GUARD/DUST COVER
•Slidethe head ofone ofthe 1/4 x 3/4 in. boltsinto
the mar trackon the guidefenceand the other
intothefronttrack.
SI Feed boltsthroughholes in post,Place a 1/4 in.
fiatwasher and lockwasher on each boltand
securewith 1/4 in.hex nutsusingan adjustable
wrench. See Figure 6.
SUDEHEN)OFHEXBOLTINTO
TRACKSONRIPFENCE Fig.6
• Loosenthe knob onthe guard/dustcoverby
turningthe knobcounterclockwise.Loosenthe
knobenoughso thatthe post slipseasilythrough
the hole in the rear oftheguard/dustcover,
•Positionguard/dustcover sothat itisover the
throatofthe muter table and approximately3-1/4
in.fromthe table surface.See F/gum 7.
• Secure guard/dustcoverbyturningthe tension
knobclockwise,Do not oved:ightan,
Note: The topopeningofthe Guard/DustCover
functionsas an ako(illimydustportandwillfitdust
collectiondeviceswitha 2 in.diameter hose.
5
INSTALL ROUTER
SI Unplug the muter.
Fig. 7
,_k WARNING: Unplugthe routerto avoidpos-
sibleinjury.
SI Place yourmuter upsidedownon a workbech.
SI Removethe subbasescrewsand the subbase
fromyourmuter. Note:The subheseismounted
permanentJyon somemutere and shouldnotbe
removed.
•Selectthe screwsneededfor yourparticularmuter.
Forconsumerreuters,usethe 114o20screws.For
commercial routere,usethe5/16-18 screws.
•Positionmuter upsidedownunderthe muter
extensiontable.The muter label shouldbe facing
the frontofthe table.

•Alignthe holesinthe table withthe holes inyour
muter.Feed the screwsthroughthetable and
intothe muter. See Figure 8.
• "Rghtenall screwswith a flatheadscrewdriver.
Fig. 8
INSTALL BIT AND THROAT PLATE
•Toinstallthe muter bit,followthe instructionsin
theoperator'smanualthatcame withyourmuter.
_1_ CAUTION: Make surethe muter bitwillnot
stdke the accesson/or any metal surface.
•Selectthe correctsize throatplatefor the size of
the muter bit.Alignthe tab on thethroatplate
withthe slotinthe muter extensionand snapIn
place.Make sumthe throatplate isfirmlyseated
belowthetable surface.Recheckthe muter bitto
make sumitwillnot strike the throatplate.
_1= WARN ING: The muter throat platesare
includedtoassure no more than 114in.clear-
ance betweenthe cutterandthe openinginthe
throatplate.Use the con,octthrcet plate. Do not
use a router bitsmallerthen 114in.or larger
then 2in.
RELOCATE ONIOFF SWITCH
When usingthe routerextension,it isrecommended
that you movethe switchboxtothe leftside ofthe
table, Todothis:
•Remove the leftand rightendcapson the front
railusinga phillipsscrewdriver.
•Loosenthe hexnut securingthe switchhoxtothe
frontrailand slideswitchboxoffrail,
•Repositionswitchboxto a convenientlocationon
the leftsideofthefront railby slidingthe square
head ofthe boltintothe lowertrack. "i3ghenhex
nutwithan adjustable wrench.
•Replace railendcapsusing a phillipsscrewdriver.
FINAL PREPARATION FOR OPERATION
•Adjustthe guard/dustcover sothat itwillnot
come in contactwiththeworkpieceor cutter
dudnga cuttingoperation.
•Directionoffeed of theworkplace isfrom fightto
leftor fromthe front ofthe saw towardthe back
withthe bit locatedinthe fence opening.
See Figure 9.
Fig.9
•Directionoffeed mustalways be sothat the
workpisoeisbeingthrustagainstthe sharpedges
ofthe rotatingbit.
•The workplacemustalways be tightagainstthe
guidefence, unless•ball-bearingpilotedbit is
being used.The infeadfence shouldbeadjusted
to supportthe uncutwod,,piecewhgethe ouffeed
fence shouldbe adjustedproperlyto supportthe
workpieceafterthe cut passesthe muter bit,
compensatingfor the removed stock.
AWARNING: The directionofthe feedfor the
workpisceisalwaysagainstthe sharpedges of
the bitand intothe rotationof the cutter.Failure
to heedthiswaming islikelyto resultin sedous
personalinjun/.
AWARNING: Do not usethe guidefence with
ball-.bearingpilotedbits.Failureto heed this
warningmay resultinsedous personalinjury.
_, WARNING: The guard/dustcover must be
used in all muting operations.

CRAFTSMAN ROUTER KIT
IAlways mentionthe accessoryitemnumberin all correspondenceregardingyour muter kitaccessoryor when o_ledng repairparts.
23
23 518
24
15 10
PARTS LIST
Key Part
No. Number Description Quart,
1. 11108015 Dust cover 1
2. 621433-017 *Catriagobot(1/4-20x 1-9/16ir_) 1
3. 11108017 Dustccverpivnt 1
4, 661816-001 Knobnut(1/4ir_) 1
5. 11108019 Post 1
6, 11108022 *Scmw(1/4-20x3/4in.) 2
7, 11108024 Knobbolt(1/4-20) 4
8. 969965-002 Guidefence 2
9. 11108020 Tappedmourtingbar 2
10, 11108008 F_xtensionwing 1
11. 975424-002 Throatplate(1/2in.) 1
12, 975424-003 Throat plate(1 iR) 1
13. 975424-006 Throat plate(1-1/8ir_) 1
Key Part
No. Number I)ucdption Quart,
14. 975424-004 Thmatplate(1-1i2in.) 1
15. 975424-005 Thmatpiate(2in.) 1
16. 969969-001 "Woodscmw(#10x5/8in.) 4
17. $1"D551025 *WVasher(1/4iR) 6
18. STD541025 "Nut(t/4-20) 2
19. 11108023 Woodfence(12 in.x2-1/2x1) 2
20. S'1"D551125 **Lockwasher 2
21. 11108025 *Sc_sw(#10-32x 3N iR) 3
22. S0040307 "Scmw(5/16-18x 1 in.) 4
23. Jl110022 Warninglabel 1
24. 11108027 Shims 2
25. 972000-944 Operator'smanual(notshown) 1
* Standard Hardware Item - May be Purchased Locally
** Available From Div. 98 -Source 980.00

Im
_mE_
_= =_
i+!!+
For repair of major brand appliances in your own home...
no matter who made it, no matter who soldit!
1-800-4-MY-HeM Esm,,_vtin.,.,dayor night
(1-800-469-4663)
www.sears.com
To bring in products such as vacuums, lawn equipment and elec_'onics
_iHi; for repair, call for the location of your nearest Sears Parts & Repair Center.
+!l!+_:
i!._K[
_=ib
ilii-=!
iEJ=_=
i3EH+
ii+
imil
!||iii
1-800-488-1222 ._rti,._,dayor night
www.sears.com
For the replacement parts, accessodes and owner's manuals
that you need to do-it-yourself, call Sears PartsDirect s"!
1-800-366-PART 6a.m.-11p.m.CST,
(1-800-366-7278) 7 days a week
www.sears.corn/partsd irect
:E===
iiLiii
!i!ili
i_ti"
To purchase or inquire about a Sears Service Agreement:
1-800-827-6655
7 a.m. - 5 p.m, CSI, Men. - Sat,
Para pedir serviclo de reparacibn a domlcilio,
y para ordenar piezas con entrega a domicilio:
1-888-SU-HOGAR _"
Au Canada pour eervic_ an francais:
1-877-LE-FOYER _
(1-877-533-6937)
®Re_t e¢edTrademark ITM Trademark of Seats, Roebuck md Co,
O Sears, Roebud_ and CO. ®MeCC_Re_=rada ITM Msrca de FSbdc_ de See_s, ROebud_and Co.
