Createbot S3 User manual

㏳㷴䄣ᬽΕ
3D Printer User Manual
Make creation easier
v1.0

1
1
2
2
43
4
〦_,WHP
嗏䰞󰶍_)UDPH
ᓋᓝ_%DVH
0;
0ᕯ෡_06SULQJ:DVKHU
⭫ࣞ㷰ѓ࠶_(OHFWULF6FUHZGULYHU
޻ޣ䀈ᢩᢁ_,QQHU+H[DJRQ6SDQQHU
Make creation easier
ᡌOR
3
用M5内六角扳手将底部4颗M5螺钉依次锁紧
Lock four M5 screws at the bottom in turn with M5 Allen key
操作说明 | Operating Instructions
用电动螺丝刀将底部4颗M5螺钉依次锁紧
Use an electric screwdriver to lock the bottom four M5 screws in turn
Step One
୆ׂڇЊ௺୹߫
Assembly base and frame

1
Make creation easier
1
2
2
3
34
4
〦_,WHP
嗏䰞󰶍_)UDPH
䘷ᯏ󰶍_)HHGLQJ)UDPH
0;
07ශ㷰∃_071XW
用M4内六角扳手依次将2颗T型螺母通过螺钉固定在型材上
Fix two T-nuts on the profile with M4 Allen key in turn
操作说明 | Operating Instructions
޻ޣ䀈ᢩᢁ_,QQHU+H[DJRQ6SDQQHU
Step Two
Ⳟ娚慖㛮㚄㤋
Installation of feeding bracket

Make creation easier
1
1
2
2
3
3
4
4
〦_,WHP
嗏䰞󰶍_)UDPH
ᓋᓝ_%DVH
0;
07ශ㷰∃_071XW
调节好限位开关与Z轴滑板的合理高度用
M5内六角扳手依次将3颗T型螺母通过螺钉固定在型材上
Adjust the limit switch and z-axis slide plate to the reasonable height.
Fix three T-nuts on the profile with M5 Allen key.
操作说明 | Operating Instructions
޻ޣ䀈ᢩᢁ_,QQHU+H[DJRQ6SDQQHU
Step Three
֡ؔ@૸ஒѹڐҼ֡ؔў٘
Fixed Z-axis limit switch retainer (left)

Make creation easier
1
1
2
2
3
3
4
4
〦_,WHP
嗏䰞󰶍_)UDPH
ᓋᓝ_%DVH
0;
07ශ㷰∃_071XW
用M5内六角扳手依次将2颗T型螺母通过螺钉固定在型材上。
装配过程中，T型螺母会自动定位，自动锁紧。
Fix two T-nuts on the profile with M4 Allen key in turn.
During assembly, the T-nut will be positioned and locked automatically.
޻ޣ䀈ᢩᢁ_,QQHU+H[DJRQ6SDQQHU
操作说明 | Operating Instructions
Step Four
֡ؔ:ֺԆڠ䵷՘
Fixed T-shaped reinforcement (right)

1
2
3
〦_,WHP
嗏䰞󰶍_)UDPH
ᓋᓝ_%DVH
؍࢛Ճݎি۸ڐંை
Installation of power supply and wiring (open video)
Step Five
3
1
2
ѱ᧝⭫Ⓠ㇧_0DLQFRQWUROSRZHUER[
此步骤为连接电源及相关部件接线操作，
请打开储存卡或U盘内的视频教程资料进行操作。
您也可以在下方超链接或者扫描二维码直接获取相关的操作视频。
如需其他帮助，您可以在末尾页找到我们的联系方式。
This step is to connect the power supply and related parts wiring operation,
please open the video tutorial information in the memory card or USB flash drive to operate.
You can also get the related operation video directly from the hyperlink below or scan the QR code.
Finally, you can find our contact information at the end of the page in case you need additional help.
操作说明 | Operating Instructions
Youtube URL : https://youtu.be/NmBNpzl8f0M
Bilibili URL : https://www.bilibili.com/video/BV1iB4y1T7fA/
接线视频 | Wiring guide video 组装视频 | Assembly guide video
Make creation easier

Makecreation easier
Congratulations !
You have completed the assembly, then enjoy the fun it brings you!
Wuhu R3D Technology Co., Ltd.
https://www.createbot.net
Whatsapp:[phone]
Email: [email protected]
Add: Factory-Fanchang Economic Development Zone,Wuhu City,Anhui Province
