Creative Blaster CB5722 User manual

User’s Guide
Creative Modem Blaster with Bluetooth Wireless Technology CB5722
Information in this document is subject to change without notice and does not represent a commitment on the part of Creative
Technology Ltd. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopying and recording, for any purpose without the written permission of Creative Technology Ltd. The software
described in this document is furnished under a license agreement and may be used or copied only in accordance with the terms of
the license agreement. It is against the law to copy the software on any other medium except as specifically allowed in the license
agreement. The licensee may make one copy of the software for backup purposes only.
The Software License Agreement can be found on the Installation CD.
Copyright © 2004 Creative Technology Ltd. All rights reserved.
Version 1.0
July 2004
The Creative logo, Blaster, and Modem Blaster are trademarks or registered trademarks of Creative Technology Ltd. in the United
States and/or other countries. Microsoft, MS-DOS, Windows, Windows NT and the Windows logo are registered trademarks of
Microsoft Corporation. Intel and Pentium are registered trademarks of Intel Corporation. AMD and AMD-K6 are trademarks or
registered trademarks of Advanced Micro Devices, Inc. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
All other products are trademarks or registered trademarks of their respective owners. All specifications are subject to change without
prior notice. Actual contents may differ slightly from those pictured. This product is covered by one or more of the following U.S.
patents:
4,506,579; 4,699,038; 4,987,600; 5,013,105; 5,072,645; 5,111,727; 5,144,676; 5,170,369; 5,248,845; 5,298,671; 5,303,309;
5,317,104; 5,342,990; 5,430,244; 5,524,074; 5,698,803; 5,698,807; 5,748,747; 5,763,800; 5,790,837.

Contents

i
Contents
1 Introduction
Before You Begin....................................................................................................................................... 1-2
Package Contents ............................................................................................................................ 1-2
Minimum System Requirements ................................................................................................. 1-2
Model Number and Serial Number........................................................................................... 1-2
Creative Knowledge Base............................................................................................................. 1-2
Product Registration....................................................................................................................... 1-3
Customer Support Services and Warranty information..................................................... 1-3
Document Conventions................................................................................................................ 1-4
2 About Your Hardware
Your Modem............................................................................................................................................... 2-1
Your USB Adapter.................................................................................................................................... 2-3
3 Setting Up A Bluetooth Connection
Noting Down the Modem BDA and Pin Code ............................................................................... 3-1
Installing Software...................................................................................................................................... 3-1
Installing Hardware.................................................................................................................................... 3-3
Configuring Your Bluetooth Device.................................................................................................... 3-4
Verifying Your Bluetooth Installation .................................................................................................. 3-4
Pairing Your Bluetooth Devices............................................................................................................ 3-5

ii
4 Setting Up A Serial Connection
Installing Software...................................................................................................................................... 4-1
Installing Hardware.................................................................................................................................... 4-2
Notes on connecting the telephone line and telephone..................................................... 4-3
Testing Modem Drivers........................................................................................................................... 4-4
In Windows XP and Windows 2000......................................................................................... 4-4
In Windows Me and Windows 98 SE ....................................................................................... 4-5
5 Uninstalling Drivers and Software
Uninstalling Bluetooth Software............................................................................................................ 5-1
In Windows XP and Windows 2000......................................................................................... 5-1
In Windows Me and Windows 98 SE ....................................................................................... 5-1
Uninstalling Serial Modem Drivers....................................................................................................... 5-2
In Windows XP and Windows 2000......................................................................................... 5-2
In Windows Me and Windows 98 SE ....................................................................................... 5-2
6 Modem Features
Basic Features ............................................................................................................................................. 6-1
System Compatibility...................................................................................................................... 6-1
Bluetooth Connectivity.................................................................................................................. 6-1
Exceptional Performance .............................................................................................................. 6-1
Voice Mail........................................................................................................................................... 6-1
Fax Support........................................................................................................................................ 6-1
Backward Compatibility................................................................................................................. 6-1
V.92 Features .............................................................................................................................................. 6-2
V.44 Compression........................................................................................................................... 6-2
PCM Upstream................................................................................................................................. 6-2

iii
Quick Connect................................................................................................................................. 6-2
Modem-On-Hold............................................................................................................................. 6-3
Receiving a call ........................................................................................................................ 6-4
Making a call............................................................................................................................. 6-6
Appendixes
A Technical Specifications
Modem.......................................................................................................................................................... A-1
Size (L x W x H) ................................................................................................................... A-1
Weight...................................................................................................................................... A-1
Bluetooth Specifications...................................................................................................... A-1
Data Features......................................................................................................................... A-2
Fax Features............................................................................................................................ A-2
Voice Features ....................................................................................................................... A-2
Video Instant Messaging Support..................................................................................... A-2
LED Indicators ....................................................................................................................... A-2
Interface Switch ..................................................................................................................... A-3
Operating Temperature ..................................................................................................... A-3
Relative Humidity.................................................................................................................. A-3
Storage Temperature .......................................................................................................... A-3
Caller ID .................................................................................................................................. A-3
USB Adapter ............................................................................................................................................... A-3
Size (L x W x H) ................................................................................................................... A-3
Weight...................................................................................................................................... A-3
Profiles...................................................................................................................................... A-3
Operating Temperature ..................................................................................................... A-4
Relative Humidity.................................................................................................................. A-4

iv
Storage Temperature .......................................................................................................... A-4
Compliance............................................................................................................................. A-4
Operating Range ................................................................................................................... A-4
Network Support ................................................................................................................. A-4
Security..................................................................................................................................... A-4
Input Voltage .......................................................................................................................... A-4
Data Rate................................................................................................................................. A-4
RF module sensitivity........................................................................................................... A-4
Transmitting Power.............................................................................................................. A-4
LED Indicators ....................................................................................................................... A-5
B Frequently Asked Questions
Installation and Configuration................................................................................................................ B-1
Operation..................................................................................................................................................... B-3
Difficulties with Modem-On-Hold.............................................................................................. B-7
Maintenance and Safety............................................................................................................................ B-9
Updates......................................................................................................................................................... B-9

Introduction

Introduction 1-1
Introduction
Creative Modem Blaster®with Bluetooth®Wireless Technology CB5722 is an easy-
to-use, external modem that provides mobile access to the Internet for your
Bluetooth enabled Windows®computer. Modem Blaster CB5722 is a Class 1
Bluetooth device that provides wireless connections to computers at ranges of up
to 100 m (330 ft)*. At the flick of a switch, your modem can enable Bluetooth
connectivity immediately.
Modem Blaster CB5722 makes connecting to the Internet much more convenient.
You enjoy shorter dial-up times, and can continue to receive and make phone calls
while surfing**. You can also be assured of outstanding performance from your
computer because of Modem Blaster CB5722's unique modem controller, which
frees up your computer resources.
Security is ensured with the Bluetooth security key, unique to each Bluetooth
device. The key is transmitted in a secure environment to prevent interception.
* Depends on environment and interference.
** Call services are available only with serial connection and requires support from your ISP.

Introduction 1-2
Before You
Begin
Package Contents • Creative Modem Blaster with Bluetooth Wireless Technology modem (CB5722)
• Quick Start leaflet
• Serial cable (RS-232)
• Creative USB Adapter with Bluetooth Wireless Technology (CW2430)
• Telephone cable (RJ-11)
• Power adapter
• Installation CD
Minimum System
Requirements*
• Microsoft®Windows®XP, Windows Millennium Edition (Me), Windows 2000 or
Windows 98 Second Edition (SE)
•Intel
®Pentium®II 300 MHz or equivalent
• 50 MB of free hard disk space (100 MB for full software installation)
• 64 MB RAM (128 MB recommended)
• Available 9-pin or 25-pin serial port (for serial connections)
• Available USB port (for Bluetooth connections)
• CD-ROM/DVD-ROM drive for software installation
Model Number
and Serial Number
Note down the model and serial numbers for your modem. You will need to provide
these numbers if you contact Customer Support Services.
You also need to note down the Bluetooth device address (BDA) and pin code when
setting up your Bluetooth connection.
Creative
Knowledge Base
Resolve and troubleshoot technical queries at Creative's 24-hour self-help
Knowledge Base. Go to www.creative.com and select your region.
* Individual software may have additional system requirements.
