User’s Guide
Creative WebCam NX
Information in this document is subject to change without notice and does not represent a commitment on the part of Creative Technology
Ltd. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including
photocopying and recording, for any purpose without the written permission of Creative Technology Ltd. The software described in this
document is furnished under a license agreement and may be used or copied only in accordance with the terms of the license agreement.
It is against the law to copy the software on any other medium except as specifically allowed in the license agreement. The licensee may
make one copy of the software for backup purposes.
Copyright © 1998-2003 Creative Technology Ltd. All rights reserved.
Version 1.0
April 2003
PC-CAM is a registered trademark of Creative Technology Ltd. in the United States and/or other countries. Microsoft, MS-DOS, and
Windows are registered trademarks of Microsoft Corporation. All rights reserved. All other products are trademarks or registered
trademarks of their respective owners.

Contents

i
Contents
Before You Begin............................................................................................................................................ v
Package Contents ................................................................................................................................. v
README file........................................................................................................................................... v
Minimum System Requirements ...................................................................................................... v
Document Conventions.................................................................................................................... vi
1 Installing Creative WebCam NX
About Creative WebCam NX ............................................................................................................ 1-2
Installing Creative WebCam NX.......................................................................................................... 1-3
In Windows 98/98SE /Me/2000/ XP.......................................................................................... 1-3
Verifying the installation in Windows 98/98SE and Windows Me......................... 1-6
Verifying the installation in Windows 2000 & XP ....................................................... 1-6
2 Using PC-CAM Center
Starting PC-CAM Center........................................................................................................................ 2-2
Capturing Images and Video .................................................................................................................. 2-3
Taking a Photo.................................................................................................................................. 2-3
Recording a Video ........................................................................................................................... 2-3
Viewing a Photo ......................................................................................................................................... 2-4
Viewing a Video.......................................................................................................................................... 2-4
Reactivating the Camera ......................................................................................................................... 2-4
Starting PC-CAM Center Help ............................................................................................................. 2-5
3 Creative WebCam NX Applications
Creative PC-Cam Center....................................................................................................................... 3-1

ii
Creative WebCam Monitor................................................................................................................... 3-1
Microsoft NetMeeting.............................................................................................................................. 3-1
Microsoft Internet Explorer................................................................................................................... 3-2
Appendixes
A Technical Specifications
Construction .......................................................................................................................... A-1
Power ....................................................................................................................................... A-1
Sensor....................................................................................................................................... A-1
Video Resolution................................................................................................................... A-1
Picture Resolution - Still mode......................................................................................... A-1
Video formats......................................................................................................................... A-1
Exposure control .................................................................................................................. A-1
Color balance......................................................................................................................... A-1
Color matrix........................................................................................................................... A-1
Field-of-view ........................................................................................................................... A-1
Depth-of-field......................................................................................................................... A-1
Port compatibility.................................................................................................................. A-1
Software compatibility......................................................................................................... A-2
B Troubleshooting
Problems Using Creative WebCam NX............................................................................................ B-1
Problems in Windows XP ...................................................................................................................... B-3
C Note on USB Compatibility

Introduction

Introduction v
Introduction
Creative WebCam NX is a digital video camera kit that gives you everything you
need to capture 24-bit still images and video in 16.7 million colors. Not only that, it
also allows you to communicate face-to-face with others on the Internet!
Creative WebCam NX comes with the following software:
❑Creative PC-CAM Center
❑Creative WebCam Monitor
❑Microsoft®NetMeeting
❑Microsoft Internet Explorer
For more information, see "Creative WebCam NX Applications" on page 3-1.
Before You
Begin
Package Contents Your Creative WebCam NX package contains the following items:
❑Creative WebCam NX with USB cable attached
❑Creative WebCam NX installation CD
❑Quick Start.
README file The README file on the CD-ROM contains information not available at the time of
printing. Read the file before you begin installing Creative WebCam NX.
Minimum System
Requirements
For the USB port version of Creative WebCam NX:
❑233 MHz Pentium®II or higher IBM®compatible PC
❑32 MB RAM
❑250 MB free hard disk space
❑Available USB port or a USB hub with external power supply
❑Microsoft Windows®98/98SE, Windows Me, Windows 2000 or Windows XP
(Windows 95 is not supported)
❑16-bit color display at a resolution of 1024 x 768 pixels

Introduction vi
❑CD-ROM drive installed
❑Sound Blaster®or other Windows-compatible sound card. Sound
Blaster 16 or higher required for simultaneous two-way conversation with full-duplex
support.
For Videoconferencing
❑Microphone
❑Modem or LAN access to the Internet at 28.8Kbps or faster
Document
Conventions
Tip. This tells you about short cuts or hints relating to a feature.
Note. This highlights additional or important information about a
feature.
Caution! This highlights proper usage of your product. Use this
information to avoid risky situations.
Warning! This warns you of possible hazards to yourself or your
product, that may result in injury or damage.

1Installing Creative WebCam NX

Installing Creative WebCam NX 1-2
Installing Creative WebCam NX
This chapter tells you how to quickly install Creative WebCam NX.
About
Creative
WebCam NX
Figure 1-1 highlights the features of Creative WebCam NX.
Figure 1-1: Creative WebCam NX
Focus ring
Adjusts the view
focus. Point the
lens toward your
subject and then
rotate this ring in
a clockwise or
counterclockwise
motion until the
image is in focus.
USB cable
Snapshot button
Press it to launch
PC-CAM center and
capture images
USB connector
Front View Side View
Hinged lever for
mounting camera on
LCD display panel

Installing Creative WebCam NX 1-3
Installing
Creative
WebCam NX
Follow the installation procedures for your operating system.
In Windows 98/
98SE /Me/2000/ XP
1. Do not connect Creative WebCam NX to your computer before installing the
drivers. If you accidentally begin installation with Creative WebCam NX
connected, the Add New Hardware Wizard or Found New Hardware
Wizard dialog box appears. Click the Cancel button.
2. Insert the Creative WebCam NX Installation CD into your CD-ROM drive. If it
does not run automatically, click Start-> Run and type D:\ctrun\ctrun.exe
(Where D:\ represents your CD-ROM drive).
3. Click the options for installing drivers and applications.
4. Follow the instructions on the screen to complete the installation.
You may be asked, after an application is installed, if you want to restart your
computer. Select No until all the drivers and applications are installed.
• You can install the
WebCam with your
computer turned on.
• The USB port(s) on
your computer may
be found on the
front panel and/or
the back panel.
•Youcandaisy-chain
the WebCam
through another
USB device or
attach the WebCam
to a powered USB
hub.
• If you have a
microphone,
connect it to
computer’s
microphone
connector. Read
your computer’s
documentation.

Installing Creative WebCam NX 1-4
5. Place your Creative WebCam NX on top of your computer monitor or other flat
surface. For LCD flat panel monitors and notebooks, use the integrated hinged
lever to balance the camera. See Figure 1-2.
For Windows 98/98SE and Windows Me only
6. Connect the Creative WebCam NX’s USB cable to an available USB port on your
computer (Figure 1-2). Windows automatically detects the device.
i. If you are prompted to insert the Windows 98 or Windows Me CD, replace
the Creative WebCam NX Installation CD with the appropriate CD.
Note: Windows 98 is available in various editions. Be sure to use the
correct edition for your system.
ii. In the Insert Disk dialog box, click the OK button.
iii. Follow the instructions on the screen.
Figure 1-2: Connecting Creative WebCam NX to your computer
USB port
Hinged
lever

Installing Creative WebCam NX 1-5
7. Check the image in the Video preview pane of the Creative WebCam NX
Camera Configuration dialog box. If it flickers or displays a series of dark
bands, click the Cancel Flicker button.
8. Click the Finish button, and then restart your computer if you are prompted to
do so.
For Windows 2000 only
1. When a Digital Signature Not
Found dialog box appears, telling
you that Creative WebCam NX has
been detected, ignore the message
and click the Yes button.
2. Check the image in the Video
preview pane of the Creative
WebCam NX Camera
Configuration dialog box. If it
flickers or displays a series of dark
bands, click the Cancel Flicker
button.
3. Click the Finish button, and then
restart your computer if you are
prompted to do so.
For Windows XP only
After connecting your camera, Windows automatically detects the device.
1. When the Found New Hardware Wizard dialog box appears, select Install
the software automatically (Recommended), and then click the Next
button.
Figure 1-3: Digital Signature Not Found
dialog box.

Installing Creative WebCam NX 1-6
2. When a Hardware Installation Dialog
box appears (Figure 1-4), ignore the
message and click the Continue
Anyway button. For more details on
this warning message, see "Problems
in Windows XP" on page B-3.
Installation will be complete in a while.
3. Check the image in the Video preview
pane of the Creative WebCam NX
Camera Configuration dialog box. If
it flickers or displays a series of dark
bands, click the Cancel Flicker
button.
4. Click the Finish button, and then
restart your computer if you are
prompted to do so.
Veri fying the
installation in
Windows 98/98SE
and Windows Me
1. Right-click the My Computer icon on your desktop.
2. On the menu that appears, click Properties.
3. In the System Properties dialog box, click the Device Manager tab.
4. Click the plus (+) sign next to the Imaging Device icon.
The entry “Creative WebCam NX” should appear.
Veri fying the
installation in
Windows 2000 &
XP
1. Right-click on My Computer .
2. On the menu that appears, click Properties.
3. In the System Properties dialog box, click the Hardware tab.
4. Click the Device Manager button. A window appears.
5. Click the plus (+) sign next to the Imaging Device icon.
The entry “Creative WebCam NX” should appear.
Figure 1-4: Hardware Installation
dialog box

2Using PC-CAM Center

Using PC-CAM Center 2-2
Using PC-CAM Center
This chapter tells you how to quickly set up Creative WebCam NX as a Web Camera
using PC-CAM Center software.
For detailed information about the application’s features and settings, refer to its
Help file. (See “Starting PC-CAM Center Help” on page 2-5.)
Starting
PC-CAM
Center
PC-CAM Center is an easy to use application that enables you to take pictures and
record videos with the Creative WebCam NX. You can also view pictures and videos,
and create and manage albums.
You can start PC-CAM Center in
any of the following ways:
❑Click Start -> Programs ->
Creative -> Creative
WebCam -> Creative PC-
CAM Center
.
❑Double-click the Creative Cam
Detector icon in your
taskbar.
This icon appears if, during
installation, you clicked the
option for Creative Cam
Detector to launch
automatically at Windows
startup.
❑Plug your camera into the USB
port and let Windows
auto-detect it. You can choose to start PC-CAM Center in Live Video mode from
a popup window that appears.
• If PC-CAM Center
does not recognize
the camera
correctly, see
Appendix A,
“Troubleshooting.”
• PC-CAM Center
automatically
detects your
installed model of
Creative WebCam,
and disables any
unsupported
features in the user
interface.
Figure 2-1: PC-CAM Center screen.

Using PC-CAM Center 2-3
Capturing
Images and
Video
With PC-CAM Center, you can take photos and record videos.
For more instructions on how to take a photo or record a video, refer to the PC-CAM
Center Help file. To launch PC-CAM Center Help,Figure 2-1See “Starting PC-CAM
Center Help” on page 2-5.
Taking a Photo To take a photo:
1. In the PC-CAM Center window, click the Live Video button. The current
camera view is displayed in the Viewing window.
2. In the Save Photo in box, select the destination album for your photo.
3. To save the photo automatically, click the Save automatically check box to
select it.
4. To preview the photo before saving it, click the Save automatically check box
to clear it.
5. To capture the image shown in the viewing window, click the Snap an image
button at the bottom of the window.
The image is captured but not saved. A preview of the photo is shown at the
bottom-left corner of the Live Video window.
6. Click the Save button.
The photo is added to the destination album.
Recording a Video 1. In the PC-CAM Center window, click the Live Video button. The current
camera view is displayed in the Viewing window.
2. In the Video Size box, select a suitable resolution.
3. In the Save video in box, select an album to put your videos in.
If you want captured video to be saved automatically, click the Save
automatically check box. Otherwise, click the check box again to clear it.
4. Click the Capture video button to start recording.
The button starts blinking to indicate that recording is in progress.
The Save
automatically check
box is selected, by
default.

Using PC-CAM Center 2-4
5. To stop the recording, click the button again.
The button stops blinking. The video is added to your selected album.
If the Save automatically check box is not selected, click the Save button to
save the video. Otherwise the video is not saved or added to your selected
album.
6. To preview the video, click the Play button on the bottom-left corner of the
Preview window.
Viewing a
1. Click the My Album button. PC-CAM Center is now in My Album mode.
2. In the My Album box, click the My Photo folder and then click the album that
contains the photos that you want to view.
Thumbnails of photos in the album are displayed in the Thumbnails window.
3. Double-click the thumbnail of the photo displayed in the Thumbnails window.
The photo, in its actual size, is displayed in the PC-CAM Center Viewing
window.
If you are not satisfied with the result, you can select a higher resolution, and
then capture the image again.
Viewing a
Video
1. Click the My Album button. PC-CAM Center is now in My Album mode.
2. In the My Album box, click the My Video folder and then click the album that
contains the video that you want to view.
Thumbnails of videos in the album are displayed in the Thumbnails window.
3. Double-click the thumbnail of the video you want to view.
The video plays in the Viewing window.
If you are not satisfied with the result, you can select a higher resolution, and
then capture the video again.
Reactivating
the Camera
If your computer goes into standby mode, your camera will go into suspend mode.
You can reactivate the camera and computer by moving the mouse or pressing a
key on the keyboard.

Using PC-CAM Center 2-5
Starting PC-
CAM Center
Help
This Help file contains instructions on how to use PC-CAM Center to take photos and
record videos. It also teaches you how to optimize settings to take high quality
photos and videos.
To start the Help file:
1. Click the PC-Cam Center logo at the top left corner of PC-CAM Center’s main
window.
2. On the PC-CAM Center menu, click Help.

3Creative WebCam NX Applications
