Crestron 2 Channel Inductor Module CLX-2IND User manual

Environmental
Temperature: 32° to 104°F (0° to 40°C)
Humidity: 10% to 90% RH (non-condensing)
Enclosure
Surface mount chassis with (2) integral mounting flanges
Occupies 1 module space in any CAEN enclosure
Dimensions
Height: 7.40 in (18.80 cm)
Width: 6.92 in (17.57 cm)
Depth: 3.86 in (9.79 cm)
Weight
6.00 lb (2.72 kg)
AVAILABLE ACCESSORIES
CAEN Automation Enclosures
CLT-2IND Terminal Block
www.crestron.com
|
800.237.2041
> Adds noise suppression for (2) 120 Volt dimmed loads
> Compatible with CLX-DIM and CLX-DELV series modules
> Occupies 1 module space in a CAEN automation enclosure
> Easy termination using CLT-Series terminal block
The CLX-2IND inductor module provides noise suppression for up to 2 dimmed
loads. Each channel inserts a high-inductance filter choke inline between any
channel of a CLX-Series dimmer module and its load. The CLX-2IND occupies a
single module space in a CAEN automation enclosure. Termination of high-voltage
wiring to the module is facilitated by a CLT-2IND terminal block, sold separately to
enable termination of the wiring anytime prior to installing the module.
SPECIFICATIONS
Load Ratings
Inductor Channels: 2
Per Channel: 16 Amps (1920 Watts)
Module Total: 32 Amps (3840 Watts)
Voltage: 120 Volts AC, 50/60Hz
Performance
Rise Time: 350 µSec minimum at full load
Connections via CLT terminal block (sold separately)
IN (1 – 2): (2) DIN rail terminal blocks, black
Inputs from CLX dimmer module(s)
OUT (1 – 2): (2) DIN rail terminal blocks, red
Outputs to loads
Specifications subject to change without notice. Doc.4847 12/07
©2007 Crestron Electronics, Inc. All brand names, product names and trademarks are the property of their respective owners.
Crestron Electronics, Inc. 15 Volvo Drive
l
Rockleigh, NJ 07647
Tel: [phone]
l
Fax: [phone]
Crestron CLX-2IND
2 Channel Inductor Module
Shown with CLT-2IND Terminal Block
